BestScope BS-2093B Series User manual

BS-2093B Series
Inverted Biological Microscope
Instruction Manual
BS-2093B BS-2093BF
To ensure the safety and obtain satisfactory performance, please study this operation instruction thoroughly before
your operation.

BestScope International Limited
1
ATTENTIONS
1. Please clean sample-touching part after using.
•Following the Fig.1 step to move the instrument, make sure the sample is taken away. Use one
hand holding ①position,the other hand holding②position.
•Once the sample is damaged, must take steps to avoid pollution.
•If rising microscope’s height with other parts, must keep it in horizontal
position, avoid incline and sample slip.
Fig.1 Carrying Diagram
Fig.2 Replace Bulb
2. Before replacing the lamp, first turn off
power switch at off position O, and
unplug it in case of electric shock and
burn.If microscope is in use or after use,
the bulb and lamp house must be cooled
off completely before proceeding, please
see Fig.2 ,Loosening screw and replace
bad bulb with required bulb. The power
supply must be cut off before bulb
replacement.
3. Microscope must be placed on stable and horizontal table.
4. Only use our power line, wrong power line can’t guarantee instrument safety and performance.
5. The microscope ground terminal must be tightly connected with plug ground terminal.
6. If unexpected situation happens, please pull the plug out.
7. Disassembly only by the professionals. The microscope has been adjusted before shipping,
Unprofessional-person should not disassemble and remove any other parts.
If you have any questions, please contact with manufacturer or local distributor.
8. Wide voltage input 100～240V, 47～63Hz, if not in this range, it may cause damage for equipment.
9. Don’t open microscope lower plate when in use or else exposed electrical element will lead to electric
shock. Before replacing the lamp or fuse, please turn off power switch and pull out the plug from the
socket.
10. Do not use alcohol, gasoline, paper and other combustibles near the instrument, to prevent fire ! !

BestScope International Limited
2
MARK
MEANING
Surface will be hot, don’t touch it.
Please read manual instruction carefully at first. Misuse will lead to body damage
or instrument damage.
It is near the fuse socket , means be care of electric leakage.
Main switch “ ON ”
Main switch “ OFF ”
1）PREPARATION
a. Microscope is precise instrument, carefully operation, avoid collisions and shaky.
Using environment should not be in direct sunlight , high temperature or high humidity and dusty,
avoid violent shaky.
b. Tension for coarse focusing knob can adjustable.
c. Please leave enough space (10cm) for ventilation.
d. Please follow Fig.1 to carry microscope.
★Firstly, take away sample, filters and round stage parts avoid damage .
★If the microscope is leaning slightly, not in good position, rubber gasket may be fall off.
2）MAINTENANCE AND STORE
a. Please use gauze with 70% ether and 30% alcohol mixed liquor to gently wipe the lens, Alcohol
and ether are inflammable material, please take them away from fire. Be careful for turn on and
off power . Please keep indoor air ventilation.
b. Please use soft fabric to clean other parts with neutral detergent besides glass parts.
c. If not in use ,please put dust cover on microscope.
d. Please collect packing material for storage and carry after unpack carton.
Safety Mark

BestScope International Limited
3
CONTENTS
Attentions.......................................................................................................................................1
1. Parts Name..........................................................................................................................................4
2. Observation Steps...............................................................................................................................6
3. Operation............................................................................................................................................7
3.1 Main Body.........................................................................................................................................7
3.1.1 Turn On Light Source..................................................................................................................7
3.1.2 Aperture Diaphragm ..................................................................................................................7
3.1.3 Adjustment of Field Diaphragm and Lamp Filament .................................................................7
3.1.4 Usage of Filter............................................................................................................................8
3.2 Focusing Unit ........................................................................................................................................8
Adjustment of Coaxial Coarse Focusing Knob Tension........................................................................8
3.3 Observation Tube..................................................................................................................................8
3.3.1 Adjustment Of Interpupilary Distance.......................................................................................8
3.3.2 Adjustment Of Diopter ..............................................................................................................9
3.3.3 Locking Eyepiece........................................................................................................................9
3.4 Stage .....................................................................................................................................................9
3.4.1 Fixed Stage.................................................................................................................................9
3.4.2 Mechanical Stage.....................................................................................................................10
3.5 Condenser...........................................................................................................................................10
3.6 Fluorescence Attachment ...................................................................................................................11
3.6.1 Mechanism of Fluorescence Production .................................................................................11
3.6.2 Parts Name...............................................................................................................................13
3.6.3 Fluorescence Observation Processes.......................................................................................13
3.6.4 Mercury Lamp Power House....................................................................................................14
3.6.5 Replacement of Mercury Bulb.................................................................................................15
3.6.6 Replacement of Mercury Lamp Fuse.......................................................................................16
4. Trouble Shooting...................................................................................................................................17
5. Installation ............................................................................................................................................18
5.1 Installation Diagram............................................................................................................................18
5.2 Installation Steps.................................................................................................................................19
5.2.1 Installation And Replacement of Bulb .............................................................................................19
5.2.2 Replacement of Fuse .......................................................................................................................19
5.2.3 Connecting Power Line ....................................................................................................................19
5.2.4 Installation Of Turnable Phase Contrast Condenser ........................................................................20
5.2.5 Installation Of Photography System.................................................................................................20
5.2.5.1 Video System (Optional) .............................................................................................................20
5.2.5.2 DSLR Camera System(Optional) ..................................................................................................21

BestScope International Limited
4
Fig.3 Main Parts Name
1）Eyepiece
2）Seidentopf Trinocular Head
3）Main Body
4）Adaptor for DSLR Camera
5）Coaxial Coarse and Fine Focusing Knob
6）Nosepiece
7）Attached Mechanical Stage
8）Fixed Stage
9）Turnable Phase Contrast Condenser
10）Lamphouse
1. Parts Name

BestScope International Limited
5
Fig.4 Control Parts
1）Lamp House
2）Turnable Phase Contrast Condenser
3）Liftable Knob for Turnable Phase
Contrast Condenser
4）Fixed Stage
5）Objective
6）Nosepiece
7）Surplus Water Plate
8）Main Body
9）Convertible handle for DSLR Camera
10）Infrared Sensors Indicator
11）Adaptor for DSLR Camera
12）Coarse & Fine Focusing Knobs
13）Fastening Screw for DSLR Camera
Adaptor
14）Culture Dish Holder
15）Trinocular Switch Lever
16) Seidentopf Trinocular Head
17) Aperture Diaphragm Lever
18) Eyepiece
19) Fastening Screw for Lamphouse
20) Field Diaphragm Lever
21) Adjustable Knob for lamp bulb
22) Attachable Mechanical Stage
23) Handle
24) Lamphouse Plug
25) Power Socket (with fuse holder)
26) Power Switch
27) Infrared Sensors Switch
28) Potentiometer Knob

Please read chapter 6 about assembly steps.
Turn on main power source
Place sample
Put 10X objective in optical path
Focusing sample
Adjusting brightness
Adjusting
interpupillary
distance and diopter
2. Observation Steps
Adjusting lamp filament position
Adjusting field diaphragm
Putting objective in optical path and focusing
Adjusting aperture diaphragm
Turn filter into optical
path
Adjusting brightness
Observation

BestScope International Limited
7
3.1.1 Turn On Light Source (Fig.5)
a. Turn potentiometer knob②to the minimum, turn on power switch to①position I(ON).
b. Rotating potentiometer knob②to increase and decrease brightness for good illumination .
c. Push button○ 4to open infrared sensors switch,if you leaving the Infrared sensors window for 10
minutes , it will be off automatically. If someone closing to it ,the bulb will turn to bright again.
Fig.5 Power Switch
3.1.2 Aperture Diaphragm (Fig.6)
Gently moving diaphragm lever ①to adjust aperture diaphragm for best image contrast .
Fig.6 Adjustment of Aperture Diaphragm and Placement Fig.7 Adjustment of Field Diaphragm and filament
Of filter
3.1.3 Adjustment of Field Diaphragm and Lamp Filament
a．Adjust field diaphragm lever○ 1to make diaphragm smaller until see the field. (Fig.7)
3. Operation
3.1 Main Body

BestScope International Limited
8
b．Adjust phase contrast condenser liftable knob○ 3 (Fig.4) for for clear field image.
c．Adjust centring screw○ 3 (Fig.6) to make field diaphragm coincide with field , fasten the thumb screw○ 4
(Fig.6),adjust field diaphragm to make image edge
d．Adjust lamphouse knobs○ 2○ 3○ 4 (Fig.7) to make lamp filament image in the centre of aperture diaphragm,
keep left right image in symmetry.
3.1.4 Usage of Filter (Fig.6)
a．Take out the filter○ 5 .
b．Place the filer○ 5into the hole which above turnable phase contrast condenser.
Adjustment of Coaxial Coarse Focusing Knob Tension (Fig.8)
a. Coarse focusing knob tension can be adjustable ,hold adjustable ring ①and rotate it. Anti-clockwise
direction is decrease, clockwise direction is increase.
b. If stage is decreasing automatically, the sample is deviating from the focusing point, means tension
too low ,clockwise rotating adjustable ring ①to increase tension.
Fig.8 Tension Adjustment For Coarse Focusing Knob
Don’t rotate coarse and fine focusing knobs with reverse direction at the same time.
3.3.1 Adjustment of Interpupillary Distance
Please adjusting binocular tube to make left and right field coincide completely. Indication point ●is
interpupilary distance.
3.2 Focusing Unit
3.3 Observation Tube

BestScope International Limited
9
Fig.9 Adjustment of Interpupilary Distance Fig.10 Adjustment Of Diopter
3.3.2 Adjustment of Diopter (Fig.10)
Please turn adjusting ring scale 0to scale line at the first use.
a．With right eye to observation by right eyepiece, focusing the sample by coarse and fine focusing
knob .
b．With left eye to observation by left eyepiece, focusing the sample by coarse and fine focusing knob .
3.3.3 Locking Eyepiece
Eyepiece can be tighten by using thumb screw ①
(Fig. 11). If want to change eyepiece, must unscrew it at
first.
Fig.11 Locking Eyepiece
3.4.1 Fixed Stage
a. Insert standard round plate ①in stage.
b. Install the clamps○ 2on the stage by screw joint.
Fig.12 Fixed Stage
3.4 Stage

BestScope International Limited
10
3.4.2 Mechanical Stage
a. Mechanical stage can be moved freely at X and Y direction.
b. Insert standard stage round plate○ 1in stage. (also don’t insert round plate as needed).
c. Install attached mechanical stage○ 2in stage with knurled screw○ 3or hexagon socket cap screws.
d. Put stage plate ○ 4in stage as needed and fixed with clamps.
Fig. 13 Mechanical Stage
◎According to culture dish height to decide whether to disassemble the condenser.
a. Rotate liftable knob○ 2 to lower phase contrast
condenser.
b. Unscrew thumb screw①to disassemble phase contrast
condenser○ 5 .
c. Whe removing the condenser，please hold the
condenser with hand in case of falling and damage.
d. Knurled screw○ 3 is condenser centring screw，
condenser positioning screw○ 4 should be installed in relevant
hole.
Fig. 14 Condenser Installation
3.5 Condenser

BestScope International Limited
11
◎BS-2093B inverted biological microscope can configured with fluorescence attachment (lamp house,
power supply etc.)
3.6.1 Mechanism of Fluorescence Production
Ultraviolet(U), Violet(V), Blue(B), Green(G) transmittance characteristic curve.
UV ( Ultraviolet )Excitation V (Violet) Excitation
B( Blue Light )Excitation G (Green Light )Excitation
Fluorescence is a kind of photoluminescence in natural world. This kind of material will emit more longer
wavelength light than irradiation light wavelength ,if stop light, emitted light will disappeared. The longer
wavelength is fluorescent light. The substance which can launch the fluorescent is called fluorescence material.
Stimulate the principle:
Now use blue-ray as example (B light, the wavelength of 490nm), when the light is emitted from the DC mercury
lamp, after condenser and stimulated color filter, get the exciting light wavelength of 490 nm or so, then through
color spectroscope reflection into the objective, color spectroscope has the nature of selective reflection in a
certain spectrum area. It will completely reflect all light which is shorter than a certain wavelengths and all light
which is longer than a certain wavelengths of light will totally through it. According to this feature , color
spectroscope can be designed corresponds to the excitation light beam splitter, it reflects the light of wavelength
under 490 nm, and the wavelength is more than 490 nm light can through. So such a wavelength of 490 nm or so
exciting light after color spectroscope, greater than 490 nm light through color spectroscope to be removed, and
3.6 Fluorescence Attachment

BestScope International Limited
12
the excitation under 490 nm light irradiation by fluorescence objective can converge on the fluorescent
specimens, specimen inspire greater than 490 nm wavelength of fluorescence(effective fluorescence wavelength
of 525nm) and fluorescence imaging by objective gathering, and through the color spectroscope (with a small
amount of under 490 nm exciting light is reflected back to the light source and not through) and cut-off filter
(cutoff wavelength less than 525 nm light), pure fluorescent light beam for observation and photography.
Fluorescent Attachment Diagram
1) Mercury Lamp
2) Condenser
3) Excitation Filter
4) Specimen
5) Objective
6) Color Spectroscope
7) Filter for Resistance
8) Prisms Group For Inverting Light Path Direction
9) Eyepiece

BestScope International Limited
13
3.6.2 Parts Name
Fig. 15 Fluorescence Parts Name
1) Eyepiece 2) Trinocular Switch knob 3) Main Body 4) Adaptor for DSLR Camera
5) Fastening Screw for DSLR Camera Adaptor 6) Infrared Sensors Indicator
7) Coarse & Fine Focusing Knobs 8) Potentiometer Knob 9) Fluorescent Transforming Handle
10) Diaphragm Slider 11) Mechanical Stage Hand Knob 12) Power Switch
13) Infrared Sensors Switch 14) Nosepiece 15) Attached Mechanical Stage For 96-hole Plate
16) 100W Mercury Lamphouse 17) Stage Plate 18) Field Diaphragm Lever
19) 12V50W Halogen Lamphouse 20) Turnable Phase Contrast Condenser
21) Aperture Diaphragm Lever 22) UV Protecting Plate 23) Digital Camera 24) C-mount
3.6.3 Fluorescence Observation Processes
According to bright field observation methods to adjust microscope, take following steps to make
observation:
●Put mercury lamp power supply power plug into the power socket, please firstly check the power
supply voltage whether conform to the requirements of the instrument and supply voltage.
●Open the mercury lamp power switch, mercury lamp power voltage fluctuation may not be out of
100～240V, otherwise affect the start of mercury lamp. It takes about 10 minutes to reach stable state,
the maximum luminous efficiency.
●Put 10X objective in optical path. Put fluorescent specimen on the slide, with fixed clamp, regulating

BestScope International Limited
14
stage vertical moving handle to make the objective in the optical path.
●Through push and pull the fluorescent transform handle, fluorescence excitation cube will be moved
into light path .
●Adjusting coarse and fine focusing knob to get clear image.
●Adjusting the center of the low and high pressure mercury lamp.
After getting clear image by focusing , using condenser axial adjustment knob, mercury lamp arc
light can be seen in the eyepiece . If arc light regiment not in the center of the field, by adjusting the
vertical and horizontal adjustment knob of mercury lamp light box to make the center of the arc light
group in the field of view, adjusting the mirror, make the brightness to the brightest. When arc light
group in the center, adjusting condenser axial adjustment knob to make arc light group into the whole
field, fluorescence observation can be made.
Try to avoid frequent open mercury lamp power supply, it will reduce mercury lamp working life.
Once closed, mercury should be restart after five minutes later.
3.6.4 Mercury Lamp Power House
a) Main Parameter
Input Voltage: AC 100 ～240 V 47～63 Hz
Output Voltage: DC18V~ 40V Maximum
Stable Output Current: 3.6A ～ 4.9A
Start Stable time: 2 minutes
Fig.17 Adjustment For Mercury Lamp House
1) Condenser Adjusting Knob
2) Vertical Adjusting Knob for Mercury lamp
3) Horizontal Adjusting Knob for Mercury lamp
b) Use Of Power Supply
●Determine the input voltage is conform to the requirements of the instrument, can open the
main power switch, open the indicator lights on the rear panel is light, indicating the power switch
on.
●Gently press the trigger switch, power box above positive press switch in place can let go, don't
have to hold for a long time. If you don't can trigger mercury lamp, please check the mercury lamp
light boxes closed is complete.
●Mercury lamp light will be stable after 2 minutes commonly, lamp power consumption between
90 W and 135 W.
●Mercury lamp service life is 100 hours or so, so use for a period of time after the brightness will
decrease.
●After replacing mercury lamp, power box timers need to reset, pressing the reset which on the
front side of power box.
●Don't often press the power box timer reset button, also can't often time, according to otherwise

BestScope International Limited
15
it will affect the service life.
●Don't no-load test output voltage, also don't open source box to adjust or modified, in order to
avoid damage to mercury lamp or power box.
Fig.18 Front Side Fig.19 Back Side
1) Timer 2) Reset 3) Trigger Switch 4) Power Switch 5) Output Socket 6) Cooling Fan
7) Voltage Transfer Switch 8) Input Power Plug 9) Fuse Holder
3.6.5 Replacement of Mercury Bulb
Cut off the power supply, with inner
hexagon screwdriver to adjust the socket head
screw which in the rear of the mercury lamp light
box , then slowly remove the mercury lamp light
box upper portion, upside down on top of the
desktop. Unscrew two mercury lamp set screw,
remove the old mercury lamp, change new
mercury lamp, then tighten the two fixed screw
will recover lamp holder, open screw tightening
the mercury lamp holder. Then according to the
mentioned methods for mercury lamp in front of
the center.
Fig.20 Replacement Of Mercury Lamp
●Don’t remove mercury lamp under the condition of electricity from inside the box! Danger!
●Mercury lamp must be replaced after cooling.
●Note mercury lamp installation in negative direction, and the lamp glass shell on uneven parts from
the direction of the condenser.
●With gauze dipped in a little alcohol ether 4:6 mixture to wipe the lamp glass shell surface, there is no
dust, fingerprints, etc contamination tubes.

BestScope International Limited
16
3.6.6 Replacement of Mercury Lamp Fuse
Turn off the power, pull out the plug and open fuse box. Mercury power supply fuse:
Φ5×20mm, 5.0A, 250V (The detail steps are as follows).
1.
2.
3.
Fig.21 Replacement Of Fuse Tube

BestScope International Limited
17
Trouble
Causation
Remedy
1. Optical System
a. Field incomplete or
illumination irregular.
Nosepiece not in right location.
Readjust nosepiece in right position.
Filter slider not in right place.
Readjust filter slider
Phase Contrast Slider aren’t moved out of optical path.
Moving out the slider.
b. Dirt or dust in objective
field.
Lens of collector is dirty.
Thoroughly clean.
Sample is dirty.
Eyepiece is dirty.
c. Dazzling image
Aperture diaphragm isn’t wide enough.
Readjust it.
d. Bad Image quality, for
example, not sharp, low
picture contrast, image
detail not clear.
Objective isn’t in right position.
Rotate nosepiece to locating position.
Objective front lens is dirty.
Thoroughly clean .
Culture dish bottom is thick.
Use normal size culture dish.
Culture dish optical performance isn’t good.
Use standard culture dish.
Sample is dirty.
Thoroughly clean
e. Partial image isn’t clear or
unsteady .
Objective isn’t in right position.
Rotate nosepiece to locating position.
Sample isn’t placed at right stage place.
Correctly placing sample and fixer it
with holder.
f. The effect of phase
contrast observation image
is poor.
Annular spot don’t focus with dish holder.
Readjust it.
Culture dish bottom isn’t flat.
Use standard culture dish.
2. Mechanical Focusing Unit
a) Coarse focusing knob is
too tight.
Tension too big.
Loosing tension adjusting ring，reset
again.
b) Nosepiece glide down
automatically.
Tension too small.
Tightening tension adjusting ring, reset
again.
3. Binocular Observation Tube
Field of Binocular observation
tube isn’t inconsistent.
Wrong interpupillary distance.
Correctly set again.
Binocular diopter is incorrect.
Left eye and right eye with different eyepiece.
Change one eyepiece, to make it same
as another eyepiece.
4. Nosepiece
When using high power
objective, it will touch the
sample.
Improper sample.
Use right sample.
Culture dish bottom is too thick.
Use standard dish.
5. Power System
a) Bulb don’t work.
No bulb.
Install bulb.
Bulb or fuse is broken.
Change new bulb or fuse.
Don’t plug in power.
Plug in power safely.
b) Bulb is easy broken.
Don’t use specified specification bulb.
Use specified specification bulb.
No bulb.
Install bulb.
加装机械载物台
4. Trouble Shooting

BestScope International Limited
18
Fig. 21
○
a Centring Telescope ○ bEyepiece ○ c C-mount ○ dFilters
○
e Turnable Phase Contrast Condenser ○ f Halogen Lamphouse ○ g Clamps
○
hStage Round plate ○ i○ j○ k Culture Dish Holder ○ l Blood Cell Counter Holder ○ mAttached Mechanical
Stage For 96-hole Plate ○ nSurplus Water Plate
○
0 LWD Infinity Plan Phase Contrast Objectives ○ pLWD Infinity Plan Objectives
○ qMainbody ○ r Adaptor for DSLR Camera ○ s DSLR Camera
5. Installation
5.1 Installation Diagram

BestScope International Limited
19
5.2.1 Installation And Replacement of Bulb (Fig.2 ,Fig.4)
WARNING: Cut off the power line plug before replace bulb.
a. Completely loosening screw on the top of the lamp house, pulling out lamp shade.
b. Loosening bulb pins locking screw, using glove or gauze to hold the bulb and insert fully
into the socket.
c. Install the lamp again.
◎Bulb: 6V 30W Halogen
5.2.2 Replacement of Fuse
WARNING：Turn off the power plug before replacement.
Fuse box is installed below the power socket, fuse rating: Φ5×20mm, 5A/250V.
Fig. 22 Replacement Of Fuse
5.2.3 Connecting Power Line
a. Don’t curve or twine power line .
b. Make sure the main switch at off mark O when
connecting power lines.
c. Must use three-phase plug which can connect
ground electrode, Otherwise can’t use the
microscope. Fig. 23 Power Line Connection
If power line is close to lamp house or relevant device, it will melt and cause electric leakage. So don’t close to
lamp house.
5.2 Installation Steps
