Bestway P3122 User manual

DUAL FUNCTION:
NOTICE:
CAUTION:
OWNER’S MANUAL
P3122
INFLATION & DEFLATION EXCLUSIVELY DESIGNED
FOR AIRBEDS
READ CAREFULLY BEFORE OPERATING AND SAVE
THESE INSTRUCTIONS.
TO AVOID THE RISK OF ELECTRIC SHOCK, DO NOT
EXPOSE TO WATER OR RAIN.
HOUSEHOLD USE ONLY.
WARNING:
1. This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of
electric shock, this plug is intended to fit in a polarized outlet only one way, if the plug does
not fit fully in the outlet, reverse the plug, if it still does not fit, contact a qualified electrician.
Do not attempt to defeat this safety feature.
2. To reduce the risk of electric shock or injury, use indoors only.
3. Motor run time should not exceed 5 minutes. Operator should allow motor to cool for 10
minutes between uses.
4. The air vent on the cover should be kept free of debris during use.
5. Product must be stored in a dry location.
6. Infants have suffocated on inflatable mattresses. Never place infant aged birth to 15 months
to sleep on this inflatable air mattress/air bed. Infants can suffocate on an underinflated or
deflated mattress, on bedding, by co-sleeping with another person, and by entrapment
between the mattress and bed frame or between the mattress and a vertical surface.
7. Children can be entrapped between the inflatable mattress and an adjacent vertical surface.
Provide at least a shoulder width space between the inflatable mattress/airbed and adjacent
vertical surfaces such as walls, dressers, or other objects.
8. Always keep the inflatable mattress fully inflated when in use.
9. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
10. This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety. Children should be supervised to ensure that they do not play with the appliance.
Cleaning and user maintenance shall not be made by children.
11. This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
12. Any changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
SERVICING OF A DOUBLE-INSULATED PRODUCT
In a double-insulated product, two systems of insulation are provided instead of grounding.
No grounding means is provided on a double-insulated product, nor should a means for
grounding be added to the product. Servicing of a double-insulated product requires extreme
care and knowledge of the system, and should be done only by qualified service personnel.
Replacement parts for a double-insulated product must be identical to those parts in the
product.
13.
FCC ID:2AS3R-P3122
SAR Value:<0.01W/kg,1g

NOTE:This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
--Consult the dealer or an experienced radio/TV technician for help.
NOTE: Drawings for illustration purpose only. May not reflect actual product. Not to
scale.
CLEANING, MAINTENANCE & STORAGE:
1. If product gets dirty, use a clean damp cloth and wipe gently on the air bed surface.
Do not use harsh detergents to clean. Fold and store after product is dried.
2. Before storing the product, release all the air. Store in a cool and dry place.
3. Do not place sharp or heavy objects near or on top of the mattress. Doing so will
cause damage and tears.
14.Please note that changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
15.This equipment complies with radio frequency exposure limits set forth by the FCC for an
uncontrolled environment.
This device must not be co-located or operating in conjunction with any other antenna or
transmitter.

Pump operation instructions
Note：Inflation and deflation will stop automatically within 5min.
Note：Hold deflation button for 2sec. to start the deflation.
Note：The output voltage and current of the USB charging port is DC 5V 1A. When the
power is turned on, the USB port can charge devices such as a mobile phone;
Note：When the pump inflates or deflates the mattress, press the " "or " " button
and the pumpwill stop working.
Important: The pump should not be operated for more than 5 minutes at a time. After each
use of the main pump, the pump should be cool down completely.

APP connection instruction：
The “Bestway APP” can operate with Android system or IOS system.Follow the below
instruction to connect your phone to the pump.
1. Make sure your phone is connected to WIFI；
2. Download the “Bestway APP” from the store of your smartphone or scan the following
QR code:
3. Open the APP and do the follows:
After the BestwayAPP is installed on your phone，in case you don’t have an account ,you
need register first.Follow the below instruction:
1) Open the app,and click the “sign up”
2) Select your country that you staying in.
3) Input your E-mail address and select “Read and agree to the user's terms of use
and privacy” click "next step"
4) Input your password 6 character at least and confirm
if you have your account,follow below instruction to log in:
1) Open the app and select your country that you staying in
2) Input your E-mail address and password and confirm
Note:Before connect the APP to the pump please keep your mobile phone, device and
WIFI close to one another;
Note: The device only supports distributing 2.4G network, but does not support 5G
network;
Note: It is not recommended to use public Wi-Fi. And connect to public Wi-Fi you can
have problem when input verification codes durning log-in.
The device can only be connected to one mobile phone at a time. If you need to connect
to another mobile phone, please press and hold the "inflation" and "deflation" buttons for 3
seconds. When the indicator light flashes slowly, the device will clear the connection
information of the previous mobile phone. Please follow the instruction to connect the new
phone to the pump.
You can share device control authority with other mobile phones that have installed APP
software through‘device sharing’command of the mobile APP.
Instructions for mobile phones with the Android Operating System
1. After the app download is complete, you will need to turn on location services in
phone set up.
pending

2. Open the APP，and press "Add device"
3. Select " SLEEP CONTROL "
4. Select “DEVICE IS POWER ON” and confirm
5. Select the WIFI name and input the WIFI password and click "next step"
6. Wait until the connection is 100% complete
7. Select " Default "
8. Name your device and confirm(optional)
9. Push on the icon with the device name you will go inside the “BESTWAY
AIRBED SLEEP CONTROL” panel.
Instructions for mobile phone with the IOS Operating System
1. Open the APP，and press "add device"
2. Select " SLEEP CONTROL "
3. Select “DEVICE IS POWER ON” and confirm
4. Select the WIFI name and input the WIFI password and click "next step"
5. Click "Change WIFI"
6. Choose the device hotspot : BW-Airbed-XXXX(Last 4 digits are different for
different product)
7. Input the password: 123456789
8. Return to the app
9. Click "Join"on the pop up window
10. Wait until the connection is 100% complete
11. Select " Default "
12. Name your device and confirm
13. Push on the icon with the device name you will go inside the “BESTWAY
AIRBED SLEEP CONTROL” panel.
APP PANEL INSTRUCTION:
1. Click the “FULL INFLATE”,the pump will inflate the air bed.
2. Click the “FULL DEFLATE”,the pump will deflate the air bed.
3. Click the”STOP”,The pump will stop whether inflating or deflating.
4. Click the “MICRO INFLATE”,the pump will inflate the air bed and it will automatically
stop after 5sec.
5. Click the “MICRO DEFLATE”,the pump will deflate the air bed and it will automatically
stop after 2sec.
TROUBLE SHOOTING
Indicator light show The state of the pump
Indicator light flash slowly Waiting connect the Wi-Fi
Indicator light on Connected the Wi-Fi
Indicator light flash quickly Lost Wi-Fi simple signal
Indicator light off Light damaged & Wi-Fi module is damaged
