Better Homes and Gardens SAVANNAH BH17-084-099-50 User manual

PB 1
model# BH17-084-099-50
model# BH17-084-099-51
model# BH17-084-099-49
Lot#_________Date________
Customer Service:
1.877.436.7290
[email protected]
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
gray
teal
ivory
Manufactured By:
BDDMI
1321 Tyler St NE, Minneapolis, MN 55413
Assembly Instructions
SAVANNAH
2 DOOR CABINET

2
TOP PANEL
LEFT SIDE ASSEMBLY
RIGHT SIDE ASSEMBLY
BOTTOM PANEL
BACK PANEL
UPPER REAR RAIL
BOTTOM FRONT PANEL
ADJUSTABLE SHELF
LEFT DOOR
RIGHT DOOR
A
B
C
D
E
F
G
H
I
J
Before you begin:
1. Check for damaged or missing parts.
2. Use the carton as a working surface to prevent product damage during assembly.
TOOLS NEEDED
Hammer Flat Head Screwdriver Phillips Head Screwdriver
PARTS LIST

2 3
HARDWARE LIST
CAUTION:
1. Make sure the screws go through the pre-drilled holes properly.
2. Do not over tighten bolts.
5. Knob
x2
3. Cam
x16
4. 15mm Pan Head
Screw
x19
1. Wood Dowel
x18
2. Cam Bolt
x16
6. Knob Bolt
x2

4
HARDWARE LIST
CAUTION:
1. Make sure the screws go through the pre-drilled holes properly.
2. Do not over tighten bolts.
10. Washer
x2
9. Shelf Pin
x4
7. 15mm Flat Head
Screw
x8
12. Wall Strap
x1
8. Magnet Catch
x1
11. Wall Screw
x1

4 5
HARDWARE LIST
CAUTION:
1. Make sure the screws go through the pre-drilled holes properly.
2. Do not over tighten bolts.
14. Wall Anchor
x1
13. 19mm Pan Head
Screw
x1

6
3 4 5
180º
HOW TO USE THE CAM LOCK SYSTEM

6 7
x3 x3 x3
STEP 1
1. Carefully tap small wooden dowels into place. Leave 1/2”of the dowels sticking out.
2. Screw-In cam bolts must be screwed down ush.
3. Refer to page 6 for instructions on how to use the cam lock system.
1. Wood
Dowel
2. Cam Bolt 3. Cam
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.

8
x3 x3 x3
STEP 2
1. Carefully tap small wooden dowels into place. Leave 1/2”of the dowels sticking out.
2. Screw-In cam bolts must be screwed down ush.
3. Refer to page 6 for instructions on how to use the cam lock system.
1. Wood
D o w e l
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
2. Cam Bolt 3. Cam

8 9
x6 x1x6 x6
x2
STEP 3
1. Carefully tap small wooden dowels into place. Leave 1/2”of the dowels sticking out.
2. Screw-In cam bolts must be screwed down ush.
3. Refer to page 6 for instructions on how to use the cam lock system.
1. Wood
D o w e l
4. 15mm Pan
Head Screw
8. Magnet
C a t c h
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
2. Cam Bolt 3. Cam

10
x17
STEP 4
1. Make sure the screws go through pre-drilled holes properly.
2. Do not over tighten screws.
4. 15mm Pan
Head Screw
hole for anti-tip strap
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
Begin by installing all of the screws along one
edge of the back panel. Next, using a square
or tape measure, make sure that the case is
square. (if using a tape measure, the distance
from one corner, diagonally to the other corner
should be the same in both directions.) Install
the remaining screws, starting with the corners.
pre-drilled holes

10 11
x6 x4 x4
STEP 5
1. Carefully tap small wooden dowels into place. Leave 1/2”of the dowels sticking out.
2. Screw-In cam bolts must be screwed down ush.
3. Refer to page 6 for instructions on how to use the cam lock system.
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
1. Wood
Dowel
2. Cam Bolt 3. Cam

12
x2x2
STEP 6
1. Make sure the bolts go through the pre-drilled holes properly.
2. Do not over tighten bolts.
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
5. Knob 6. Knob Bolt

12 13
x8
STEP 7
1. Make sure the screws go through pre-drilled holes properly.
2. Do not over tighten screws.
7. 15mm Flat
Head Screw
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.

14
x4
STEP 8
1. Insert shelf supports into desired holes. Dierent holes accommodate dierent shelf heights.
2. Angle shelves to t between the rails and set on top of shelf supports.
9. Shelf
Pin
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.

14 15
x1x1x1x1
x2
12
10
13
14
11 10
STEP 9
12. Wall
Strap
10. Washer
13. 19mm
Pan Head
Screw
11. Wall
Screw
14. Wall
Anchor
position against wall
mark position of strap hole on wall
drill 1/4”hole
tap in wall anchor
fasten anti-tip strap with wall
screw provided
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.

16
50 lbs. / 22.7 kg.
40 lbs. / 18.1 kg.
!WARNING
Serious or fatal crushing injuries can occur
from furniture tip-over. To help prevent
tip-over:
• Install tip-over restraint provided.
• Place heaviest items in the lowest drawers.
• Do not set TV’s or other heavy objects on top
of this product, unless the product is
specifically designed to accommodate them.
• Never allow children to climb or hang on drawers,
doors, or shelves.
• Never open more than one drawer at a time.
(OR)
• Do not defeat or remove the drawer interlock
system.
Use of tip-over restraints may only reduce,
but not eliminate, the risk of tip-over.
This is a permanent label. Do not remove.
WARNING: Do not exceed the maximum load capacity. Exceeding the maximum load capacity may result in
collapse and possible injury.
Furniture Care Instructions:
Dust with clean, lint-free cloth.
Use furniture spray polish as needed.
Customer Service:
877.436.7290
[email protected]
Your complete satisfaction is our number 1 priority. Our product is designed and manufactured to meet the
highest quality of standards. In the event that you have assembly questions, or parts are missing or damaged,
our customer service department would appreciate the opportunity to assist you.
This product carries a one (1) year warranty against defects in workmanship and materials. Defective product
will be replaced free of charge within the stated warranty period, when returned by the original purchaser with
proof of purchase. This product is not guaranteed against wear or breakage due to misuse and/or abuse. Please
contact our Customer Service at 1-877-436-7290 to obtain information on warranty performance. This warranty
gives you specic legal rights and you may also have other rights which vary from State to State.

PB 1
model# BH17-084-099-50
model# BH17-084-099-51
model# BH17-084-099-49
Lot#_________Fecha_______
Servicio al Cliente:
1.877.436.7290
[email protected]
ESTE MANUAL DE INSTRUCCIONES CONTIENE INFORMACIÓN IMPORTANTE DE SEGURIDAD.
POR FAVOR LEA Y GUARDE PARA REFERENCIA FUTURA.
gris
azul verde
marl
Fabricado Por :
BDDMI
1321 Tyler St NE, Minneapolis, MN 55413
GABINETE DE 2 PUERTA
SAVANNAH
Instrucciones de Ensamble

2
Antes de comenzar:
1. Compruebe si hay piezas dañadas o faltantes.
2. Utilice la caja de cartón como supercie de trabajo para evitar daños al producto durante el montaje.
PANEL SUPERIOR
ENSAMBLE DEL LADO IZQUIERDO
ENSAMBLE DEL LADO DERECHO
PANEL INFERIOR
PANEL POSTERIOR
RIEL POSTERIOR SUPERIOR
PANEL FRONTAL INFERIOR
REPISA AJUSTABLE
PUERTA IZQUIERDO
PUERTA DERECHO
A
B
C
D
E
F
G
H
I
J
Martillo Destornillador de Cabeza Plana Destornillador Phillips
HERRAMIENTAS NECESARIAS
LISTA DE PARTES

2 3
LISTA DE ARTÍCULOS DE FERRETERÍA
PRECAUCIÓN:
1. Cerciórese que los tornillos pasen por los agujeros pretaladrados de manera apropiada.
2. No sobreapriete los tornillos.
5. Perilla
x2
3. Leva
x16
4. 15mm Tornillo de
Cabeza de Noria
x19
1. Cavija de Madera
x17
2. Tornillo de Leva
x16
6. Perno de Perilla
x2

4
LISTA DE ARTÍCULOS DE FERRETERÍA
PRECAUCIÓN:
1. Cerciórese que los tornillos pasen por los agujeros pretaladrados de manera apropiada.
2. No sobreapriete los tornillos.
10. Arandela
x2
9. Pasador Para Repisa
x4
7. 15mm Tornillo de
Cabeza de Plana
x8
12. Cincha de Pared
x1
8. Imán
x1
11. Tornillo de Pared
x1
