Better Homes and Gardens LAUREL BH17-084-097-39 User manual

1PB
model# BH17-084-097-39
model# BH17-084-097-40
model# BH17-084-097-38
Lot#_________Date________
Customer Service:
1.877.436.7290
[email protected]
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
gray
black
ivory
Manufactured By:
BDDMI
1321 Tyler St NE, Minneapolis, MN 55413
Assembly Instructions
LAUREL ACCENT TABLE

2
TOP PANEL
LEFT SIDE FRAME
RIGHT SIDE FRAME
BOTTOM PANEL
BACK PANEL
FRONT RAIL
DRAWER FACE
DRAWER SIDE [X2]
DRAWER BACK
DRAWER BOTTOM
A
B
C
D
E
F
G
H
I
J
Before you begin:
1. Check for damaged or missing parts.
2. Use the carton as a working surface to prevent product damage during assembly.
TOOLS NEEDED
PARTS LIST
Flat Head Screwdriver Phillips Head Screwdriver

2 3
HARDWARE LIST
CAUTION:
1. Make sure the screws go through the pre-drilled holes properly.
2. Do not over tighten bolts.
5. Knob
x1
3. Cam
x15
4. 25mm Flat Head
Screw
x8
1. Wood Dowel
x8
2. Cam Bolt
x15
6. Knob Bolt
x1

4
1 2
3 4 5
180º
HOW TO USE THE CAM LOCK SYSTEM

4 5
x2 x3 x3
STEP 1
1. Carefully tap small wooden dowels into place. Leave 1/2”of the dowels sticking out.
2. Screw-In cam bolts must be screwed down ush.
3. Refer to page 4 for instructions on how to use the cam lock system.
1. Wood
D o w e l
finished edge
2. Cam Bolt 3. Cam
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.

6
x2 x2
STEP 2
1. Screw-In cam bolts must be screwed down ush.
2. Refer to page 4 for instructions on how to use the cam lock system.
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
2. Cam Bolt 3. Cam

6 7
x2 x5 x5
STEP 3
1. Carefully tap small wooden dowels into place. Leave 1/2”of the dowels sticking out.
2. Screw-In cam bolts must be screwed down ush.
3. Refer to page 4 for instructions on how to use the cam lock system.
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
1. Wood
D o w e l
2. Cam Bolt 3. Cam

8
x4 x5 x5
STEP 4
1. Carefully tap small wooden dowels into place. Leave 1/2”of the dowels sticking out.
2. Screw-In cam bolts must be screwed down ush.
3. Refer to page 4 for instructions on how to use the cam lock system.
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
1. Wood
D o w e l
2. Cam Bolt 3. Cam

8 9
x8
1. Make sure the screws go through the pre-drilled holes properly.
2. Do not over tighten screws.
STEP 5
4. 25mm
Flat Head
Screw
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.

10
x1x1
STEP 6
1. Make sure the bolt goes through the pre-drilled hole properly.
2. Do not over tighten bolt.
5. Knob 6. Knob Bolt
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.

10 11
25 lbs. / 11.3 kg.
10 lbs. / 4.5 kg.
20 lbs. / 9.1 kg.
WARNING: Do not exceed the maximum load capacity. Exceeding the maximum load capacity may result in
collapse and possible injury.
Furniture Care Instructions:
Dust with clean, lint-free cloth.
Use furniture spray polish as needed.
Customer Service:
877.436.7290
[email protected]
Your complete satisfaction is our number 1 priority. Our product is designed and manufactured to meet the
highest quality of standards. In the event that you have assembly questions, or parts are missing or damaged,
our customer service department would appreciate the opportunity to assist you.
This product carries a one (1) year warranty against defects in workmanship and materials. Defective product
will be replaced free of charge within the stated warranty period, when returned by the original purchaser with
proof of purchase. This product is not guaranteed against wear or breakage due to misuse and/or abuse. Please
contact our Customer Service at 1-877-436-7290 to obtain information on warranty performance. This warranty
gives you specic legal rights and you may also have other rights which vary from State to State.

1PB
model# BH17-084-097-39
model# BH17-084-097-40
model# BH17-084-097-38
Lot#_________Fecha_______
Servicio al Cliente:
1.877.436.7290
[email protected]
ESTE MANUAL DE INSTRUCCIONES CONTIENE INFORMACIÓN IMPORTANTE DE SEGURIDAD.
POR FAVOR LEA Y GUARDE PARA REFERENCIA FUTURA.
gris
negro
marl
Fabricado Por :
BDDMI
1321 Tyler St NE, Minneapolis, MN 55413
MESA DE ACENTO LAUREL
Instrucciones de Ensamble

2
Antes de comenzar:
1. Compruebe si hay piezas dañadas o faltantes.
2. Utilice la caja de cartón como supercie de trabajo para evitar daños al producto durante el montaje.
HERRAMIENTAS NECESARIAS
LISTA DE PARTES
PANEL SUPERIOR
ENSAMBLE DEL LADO IZQUIERDO
ENSAMBLE DEL LADO DERECHO
PANEL INFERIOR
PANEL POSTERIOR
RIEL FRONTAL
CAJÓN FRONTAL
CAJÓN LATERAL [X2]
CAJÓN POSTERIOR
CAJÓN INFERIOR
A
B
C
D
E
F
G
H
I
J
Destornillador de Cabeza Plana Destornillador Phillips

2 3
LISTA DE ARTÍCULOS DE FERRETERÍA
PRECAUCIÓN:
1. Cerciórese que los tornillos pasen por los agujeros pretaladrados de manera apropiada.
2. No sobreapriete los tornillos.
5. Perilla
x1
3. Leva
x15
4. 25mm Tornillo de
Cabeza de Noria
x8
1. Clavija de Madera
x8
2. Tornillo de Leva
x15
6. Perno de Perilla
x1

4
1 2
3 4 5
180º
COMO USAR EL SISTEMA FIJADOR DE LEVA

4 5
x2 x3 x3
PASO 1
1. Con cuidado golpee las clavijas de madera en su lugar. Deje un saliente de 1.27 cm (½”) en las clavijas.
2. Los tornillos de leva deben de estar atornillados al ras.
3. Reérase a la página 4 para instrucciones para como usar el sistema de levas.
1. Clavija de
Madera
2. Tornillo
de Leva
3. Leva
NO ESTÁ A ESCALA. CONSULTE LA PÁGINA 3 FOR HARDWARE DE TAMAÑO REAL.
borde acabado

6
x2 x2
PASO 2
1. Los tornillos de leva deben de estar atornillados al ras.
2. Reérase a la página 4 para instrucciones para como usar el sistema de levas.
NO ESTÁ A ESCALA. CONSULTE LA PÁGINA 3 FOR HARDWARE DE TAMAÑO REAL.
2. Tornillo
de Leva
3. Leva

6 7
x2 x5 x5
PASO 3
1. Con cuidado golpee las clavijas de madera en su lugar. Deje un saliente de 1.27 cm (½”) en las clavijas.
2. Los tornillos de leva deben de estar atornillados al ras.
3. Reérase a la página 4 para instrucciones para como usar el sistema de levas.
NO ESTÁ A ESCALA. CONSULTE LA PÁGINA 3 FOR HARDWARE DE TAMAÑO REAL.
1. Clavija de
Madera
2. Tornillo
de Leva
3. Leva

8
x4 x5 x5
PASO 4
1. Con cuidado golpee las clavijas de madera en su lugar. Deje un saliente de 1.27 cm (½”) en las clavijas.
2. Los tornillos de leva deben de estar atornillados al ras.
3. Reérase a la página 4 para instrucciones para como usar el sistema de levas.
NO ESTÁ A ESCALA. CONSULTE LA PÁGINA 3 FOR HARDWARE DE TAMAÑO REAL.
1. Clavija de
Madera
2. Tornillo
de Leva
3. Leva

8 9
x8
PASO 5
4. 25mm
Tornillo de
Cabeza Plana
1. Cerciórese que los tornillos pasen por los agujeros pretaladrados de manera apropiada.
2. No sobreapriete los tornillos.
NO ESTÁ A ESCALA. CONSULTE LA PÁGINA 3 FOR HARDWARE DE TAMAÑO REAL.
