BGS 1010
Oil Dipsticks Set for Mercedes-Benz, 4 pcs.
ATTENTION
Read and understand all instructions and information in this manual.
Failure to follow the instructions and information below may cause serious injury and damage.
Keep the manual for future reference in a safe and dry place.
INTENDED USE
Four colour codes dipsticks are used to measure transmission and engine oil levels on Mercedes
vehicles where no dipstick is provided. The dipstick set also fits on Jaguar models where a Mercedes
gear box is fitted. Kit consists of 2 transmission oil dipsticks and 2 engine oil dipsticks.
SAFETY INFORMATIONS
•Always read the instructions carefully before using the tool.
•The dipsticks in this kit may only be used in accordance with their purpose and under the
conditions provided.
•Follow the manufacturer’s specifications. This manual is supposed to inform you about the tool
itself and does not replace specific servicing handbooks.
•Before use, make sure that the tool is in perfect condition.
•Regularly check the condition of the dipsticks and replace a damaged dipstick directly.
•Inform yourself before use about the correct use of the oil dip sticks taking into account the
necessary safety measures.
•Keep children and unauthorized persons away from the working area.
•Do not let children play with this tool or its packaging.
•Ensure the working area has adequate lighting.
•Keep working area clean and tidy, dry and free from unrelated materials.
•Do not allow untrained persons to use this tool kit.
•Only use oil which is approved by the vehicle manufacturer. Oil specifications can be found in
the vehicle owner's manual or in the vehicle-specific service literature.
•Close the dipstick tube properly after the measuring process. Oil dipstick tubes that are not
properly closed can lead to engine or gearbox damage.
•Only use a lint-free cloth to clean the dipstick, between and after the measuring procedures.
Cleaning with a different cloth may cause a malfunction and damage of the automatic
transmission.

BGS technic KG
Bandwirkerstr. 3
D-42929 Wermelskirchen
Tel.: [phone]
Fax.: [phone]
[e-mail]
www.bgstechnic.com
© BGS technic KG, Copying and further use not allowed
TRANSMISSIONS OIL LEVEL CHECK
Transmission 722.6 L / G / P / V, found in C-Class, CLK, S-Class, SL, Vito, Sprinter
Also fits Mercedes gearbox used in Jaguar models.
Red Dipstick, to be used as OEM 140 589 15 21 00
1. Remove dipstick tube cover
2. Fill transmission with required volume of ATF (consult manufacturers data)
3. Run engine, check ATF level and top up if required
4. Check ATF Temperature (via diagnostic equipment)
5. Check level of ATF as follows:
Cold range = 25°C = area marked A on dipstick
Hot range = 80°C = area marked B on dipstick
Note: Accurate measurement only possible at 80°C
Close the dipstick tube properly after the measuring process. Oil dipstick tubes
that are not properly closed can lead to gearbox damage.
Only use a lint-free cloth to clean the dipstick, between and after the measuring
procedures.
Transmission 722.7xx, found in A-Class (W168) and Vaneo (W414)
Green Dipstick, to be used as OEM 168 589 01 21 00
1. Remove dipstick tube cover
2. Fill transmission with required volume of ATF (consult manufacturers data)
3. Run engine, check ATF level and top up if required
4. Check ATF Temperature
5. Check level of ATF as follows:
Cold range = 30°C = area marked 2 to 4 on dipstick
Hot range = 70 to 80 C = area marked 8 to 12 on dipstick
Note: Accurate measurement only possible at 80°C
Close the dipstick tube properly after the measuring process. Oil dipstick tubes
that are not properly closed can lead to gearbox damage.
Only use a lint-free cloth to clean the dipstick, between and after the measuring
procedures.
Transmission 722.8xx (CVT), found in A-Class (W169) and B-Class (W245)
Green Dipstick, to be used as OEM 168 589 01 21 00
1. Remove dipstick tube cover
2. Fill transmission with required volume of ATF (consult manufacturers data)
3. Run engine, check ATF level and top up if required
4. Check ATF Temperature
5. Check level of ATF as follows:
Cold range = 30°C = area marked 2 to 4 on dipstick
Hot range = 70 to 80°C = area marked 5 to 7 on dipstick
Note: Accurate measurement only possible at 80°C
Close the dipstick tube properly after the measuring process. Oil dipstick tubes
that are not properly closed can lead to gearbox damage.
Only use a lint-free cloth to clean the dipstick, between and after the measuring
procedures.

BGS technic KG
Bandwirkerstr. 3
D-42929 Wermelskirchen
Tel.: [phone]
Fax.: [phone]
[e-mail]
www.bgstechnic.com
© BGS technic KG, Copying and further use not allowed
ENGINE OIL LEVEL CHECK
Blue Dipstick, to be used as OEM 120 589 07 21 00
Yellow Dipstick, to be used as OEM 120 589 06 21 00
GUIDE VALUES FOR ENGINE OIL VOLUME
Important note: The information provided by the vehicle manufacturer must always be observed.
Amount of oil volume in liters
Engine
Filling quantity
incl. filter
M103.943/ 984/ 985
6.5
M104
7.0
M111.92/ 94/ 952/ 956/ 957/ 958/ 96/ 97/ 982/ 983
5.5
M111.951/ 955/ 981
7.0
M112.916/ 953
7.5
M112.975 / M113.948/ 966
8.0
M113.940/ 941/ 942/ 943/ 960/ 961/ 962/ 967/ 969/ 982/ 989
8.0
M113.944/ 980/ 981/ 984/ 986/ 991
7.5
M113.963/ 965/ 968
7.5
M113.987/ 988/ 990/ 992/ 993/ 964/ 971
8.5
M119
8.0
M120
10
M137.970
9.0
M271
5.5
M603.913/ 96/ 970
7.5
M603.971
8.0
M604
6.5
M605
6.5
M606.91/96
7.5
M611.960/ 961
6.0
M611.962
6.5
M612.961
7.0
M612.962/ 967
6.5
M612.963/ 966
7.5
M612.965
7.0
M612.990
6.5
M613.960
8.5
M613.961
7.5
M628.960/ 963
10
M628.961
8.5
M628.962
9.5
M646.951
6.5
M646.961
6.5
M646.962/ 963
6.5
M646.982/ 983
8.5
M647.961
6.5
M648.960
8.5
M648.961
6.5

BGS technic KG
Bandwirkerstr. 3
D-42929 Wermelskirchen
Tel.: [phone]
Fax.: [phone]
[e-mail]
www.bgstechnic.com
© BGS technic KG, Copying and further use not allowed
GUIDE VALUES FOR USE OF ENGINE OIL DIPSTICK MARKINGS
Important note: The information provided by the vehicle manufacturer must always be observed.
Engine
Model
Min.
Max.
Dipstick
M112.910 / 919 / 914 / 915
98
124
Blue
M112.920 / 922 / 923 / 940
98
124
Blue
M112.942 / 943 / 944 / 947
98
124
Blue
M112.970 / 972 / 975
98
124
Blue
M112.912 / 913 / 946 / 948
151
171
Blue
M112.949 / 955 / 961 / 973
151
171
Blue
M112.916 / 953
203 with 4-Matic
104
124
Blue
M112.917 / 954
211
96
125
Blue
M112.975
220 with 4-Matic
96
125
Blue
M112.921 / 941
220 with 4-Matic
89
115
Blue
M112.960
170
99
125
Blue
M112.961
203
152
172
Blue
M113.940
210 with 4-Matic
87
109
Blue
M113.940
without 4-Matic
91
112
Blue
M113.943 / 944 / 961
91
112
Blue
M113.941 / 960
95
116
Blue
M113.963 / 967 / 968
132
149
Blue
M113.964 / 971
101
127
Blue
M113.965
95
112
Blue
M113.969
211
98
120
Blue
M113.948 / 966
with 4-Matic
98
120
Blue
M113.981
163
97
108
Blue
M113.986
215 / 220
93
112
Blue
M113.987
209
133
164
Blue
M113.988
203
133
164
Blue
M113.989
171
128
148
Blue
M113.990 / 992
137
168
Blue
M113. 991
215 / 220
95
110
Blue
M137.970
105
116
Yellow
M271
171 / 203 / 209 / 211
98
119
Yellow
M611.962 up to #448 572
203.004 / 006 / 204 / 206 / 706
110
138
Yellow
M611.952 from #448 573
203.004 / 006 / 204 / 206 / 706
100
128
Yellow
M612.961
110
133
Yellow
M612.962
203.016 / 216
100
125
Yellow
M612.962
203.016 / 216
110
135
Yellow
M612.990
203
110
137
Yellow
M628
220
107
128
Yellow
M628
220
107
128
Yellow
M628
211
104
124
Yellow
M646
203 / 211
139
163
Blue
M646
211 without Lancaster
118
143
Blue
M647
211
116
139
Blue
M648
211
114
134
Blue
M648
220
123
145
Blue
