Binary B-660-EXT-444-100AS User manual

Source | Mute | 2ch
(HDMI Out Audio)
INSTALLATION
MANUAL
4K HDR HDBaseT Extender with IR & RS-232,
Ethernet, Audio Return, & Loop Out
B-660-EXT-444-100AS

2
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of re or electric shock, read and follow all instructions and warnings in this
manual. Keep this manual for future reference.
1. Do not expose this apparatus to rain or moisture. Do not expose this equipment to dripping
or splashing, and ensure that no objects lled with liquids, such as vases, are placed on the
equipment. Do not use this apparatus near water.
2. Do not remove cover. No user serviceable parts inside.
3. Clean only with a dry cloth.
4. Do not block any ventilation openings. Install according to manufacturer’s instructions.
5. Do not install near any heat sources such as radiators, heat registers, stoves or other
apparatus (including ampliers) that produce heat.
6. Do not override the safety purpose of the polarized or grounding plug. A polarized plug has
two blades, one of which is wider than the other. A grounding plug has two matching blades
and a third grounding prong. The wide blade or the third prong is provided for your safety. If
the provided plug does not t into your outlet, consult an electrician for replacement of the
obsolete outlet.
7. Protect the power cord from being walked on or pinched, particularly at the plug end and
where the power cord is attached to the apparatus.
8. Only use attachments and accessories specied by the manufacturer.
9. Refer all servicing to qualied service personnel. Servicing is required when the apparatus
has been damaged in any way, such as when the power supply cord or plug is damaged,
liquid has been spilled on or objects have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, the apparatus does not operate normally, or it has been
dropped.
10. To completely disconnect this equipment from power, disconnect the power supply cord
from the power outlet.
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated dangerous voltage
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
CAUTION
CAUTION: TO REDUCE THE RISK OF
ELECTRICAL SHOCK.
DONOT REMOVE COVER. NOUS ER
SERVICEABLE PARTS INS IDE.
REFER S ERVICI NG TO QUALIFIED
SERVICE PERSONNEL.

3
FCC WARNINGS
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
TRADEMARKS
Dolby Digital™, Dolby TrueHD™, and Dolby Atmos™ are registered trademarks of Dolby
Laboratories DTS 5.1™, DTS-HD Master Audio™ and DTS:X™ are registered trademarks of DTS,
Inc. All other trademarks and registered trademarks are owned by their respective holders.

4
CONTENTS
1. Product Overview ........................................................................................................................................................ 5
2. Features ............................................................................................................................................................................. 5
3. Package Contents .......................................................................................................................................................... 5
4. Device Layout .................................................................................................................................................................. 6
4.1. B-660-EXT-444-100AS Transmitter ........................................................................................................... 6
4.2. B-660-EXT-444-100AS Receiver ................................................................................................................. 8
5. Installation & Wiring ..................................................................................................................................................10
5.1. Installation ...........................................................................................................................................................10
5.2. Wiring ....................................................................................................................................................................10
6. EDID Management .....................................................................................................................................................12
7. Function Setting ...........................................................................................................................................................12
7.1. Audio Setting (Group 1) ..................................................................................................................................13
7.2. IR & RS-232 Setting (Group 2) .....................................................................................................................15
8. Connections ...................................................................................................................................................................15
8.1. HDBaseT Link (RJ45) Connection ..............................................................................................................15
8.2. RS-232 Control Connections .......................................................................................................................16
8.2.1. RS-232 Control (DB-9) Connection .............................................................................................17
9. Specications ................................................................................................................................................................18
9.1. Transmission Distance ....................................................................................................................................19
10. Warranty .........................................................................................................................................................................19
11. Support ............................................................................................................................................................................19

5
1. PRODUCT OVERVIEW
The B-660-EXT-444-100AS is a 4K HDR HDBaseT extender with HDMI loop out and support
for 4K@60Hz 4:4:4 8bit including DCI 4K (4096 x 2160), and HDCP 2.2 compatibility. It can
transmit 1080P signals up to 100m/330ft and 4K@60Hz signals up to 70m/230ft via Cat 5e/6
cable, and transmit 1080P and 4K@60Hz 4:4:4 8bit signals up to 100m/330ft via Cat 6a/7
cable.
The B-660-EXT-444-100AS supports bi-directional IR pass through, RS-232 pass through,
CEC pass through, S/PDIF pass through and ethernet pass-through. It also supports ARC
function, which can be congured by the Function DIP switch. With bi-directional PoC support,
only one power adapter is needed. The built-in scaler, is capable of scaling down the incoming
4k (including 3840x2160 and 4096x2160) video signal automatically to 1080P when the
connected display is not able to reproduce the 4k signal.
Two independent 4-pin Video and Audio EDID DIP Switches provide a variety of EDID
combinations to t the needs of the installation and operation environment. The 6-pin Function
DIP Switches provide a variety of congurations and upgrading requirements to t multiple
application scenarios.
2. FEATURES
• Supports resolutions up to 4K@60Hz 4:4:4 8bit and HDCP 2.2.
• Supports HDR (High Dynamic Range), including HDR 10, HLG up to 4K@60 and HDR 10+
and Dolby Vision up to 4K@30Hz.
• The transmitter supports local output/loop out.
• Supports digital and analog audio de-embedding and S/PDIF pass through.
• Over a Cat 5e/6 cable, HDBT transmits 4K@60Hz 4:4:4 8bit up to 70m/230ft, and 1080P up
to 100m/330ft; Over a Cat 6a/7 cable, HDBT transmits 4K@60Hz 4:4:4 8bit and 1080P up
to 100m/330ft.
• DIP Switches congure EDID, IR, RS-232, ARC functions and FW update.
• Ability to down-scale automatically.
• CEC pass through capable.
• Supports bi-directional IR pass through, RS-232 pass through and ethernet pass through.
• Bi-directional PoC, one power adapter at either transmitter or receiver side can power both
units.
3. PACKAGE CONTENTS
• 1 x B-660-EXT-444-100AS Extender
• 1 x DC 12V Power Adapter with US Pins
• 4 x Mounting Ears (with Screws)
• 4 x Drywall Screws
• 8 x Rubber Feet
• 1 x Installation Manual

6
4. DEVICE LAYOUT
4.1. B-660-EXT-444-100AS Transmitter
1 2 3 4 5 6 7 8
Front
1. POWER LED
On/Off: The transmitter is powered on/off.
2. STATUS LED
Blinking: The transmitter is working properly.
Off: The transmitter is not working properly.
3. LINK LED
On: HDBT link is normal.
Off: No HDBT link.
4. HDCP LED
On: HDCP encrypted signal is being transmitted.
Blinking: Non-HDCP encrypted signal is being transmitted.
Off: No signal is being transmitted.
5. SCALER LED
On: The Scaler function is enabled.
Off: The Scaler function is disabled.
6. Video
Video EDID DIP Switch. For more information, see EDID Management Section.
7. Audio
Audio EDID DIP Switch. For more information, see EDID Management Section.
8. Function
Function DIP Switch. For more information, see Function Setting Section.

7
Rear
1 2 3 4 5 6 7 8 910
1. +12V DC
Connect the 12V power cord provided.
2. HDBT OUT
Connect to the receiver via a Cat 5e/6/6a/7 cable.
3. IR Receiver
Connect to an IR receiver cable.
4. IR Flasher
Connect to an IR emitter cable.
5. RS-232
RJ45 port. Connect to a RS-232 control device such as a control system for RS-232 pass-
through or a PC for rmware update.
6. HDMI IN
Connect to an HDMI source device.
7. HDMI OUT
Connect to an HDMI display device.
8. AUDIO OUT
3.5mm analog audio out, HDMI IN de-embedding, connect to an audio system.
9. SPDIF OUT
TOSLINK connector, connect to an audio system such as an AV receiver.
10.Network 1&2
Connect to internet devices or to the internet. These two ports share the same built-in
switch, so when one of the network ports is connected to an Ethernet switch, the other port
is prohibited to connect to the same switch to avoid network loops.

8
4.2. B-660-EXT-444-100AS Receiver
1 2 3 4 5 6
Front
1. POWER LED
On/Off: The receiver is powered on/off.
2. STATUS LED
Blinking: The receiver is working properly.
Off: The receiver is not working properly.
3. LINK LED
On: HDBT link is normal.
Off: No HDBT link.
4. HDCP LED
On: HDCP encrypted signal is being transmitted.
Blinking: Non-HDCP encrypted signal is being transmitted.
Off: No signal is being transmitted.
5. ARC LED
On: ARC function is enabled.
Off: ARC function is disabled.
6. Function
Function DIP Switch. For more information, see Function Setting Section.
Rear
1 2 3 4 5 6 7 89

9
1. +12V DC
Connect the 12V power cord provided.
2. HDBT IN
Connect to the transmitter via a Cat 5e/6/6a/7 cable.
3. IR Receiver
Connect to an IR receiver cable.
4. IR Flasher
Connect to an IR emitter cable.
5. RS-232
RJ45 port. Connect to a RS-232 control device such as a control system for RS-232 pass-
through or a PC for rmware update.
6. HDMI OUT
Connect to an HDMI display.
7. AUDIO OUT
3.5mm analog jack, HDMI OUT audio de-embedding, connect to an audio system such as an
amplier.
8. SPDIF IN
TOSLINK connector, connect to an audio source device.
9. Network 1&2
Connect to internet devices or to the internet. These two ports share the same built-in
switch, so when one of the network ports is connected to an Ethernet switch, the other port
is prohibited to connect to the same switch to avoid network loops.
5. INSTALLATION & WIRING
5.1. Installation
Before installation, please ensure the device is disconnected from the power.
Steps to install the device on a suitable position:
1. Attach the mounting ear to the enclosure using the screws provided in the package
separately.
2. The mounting ear is attached to the enclosure as shown.
3. Repeat steps 1-2 for the other side of the transmitter.
4. Repeat above steps to install the receiver.

10
5.2. Wiring
Warnings:
• Before wiring, disconnect the power from all devices.
• During wiring, connect and disconnect the cables gently.
Steps for device wiring:
1. Connect HDMI IN
Connect the HDMI sources (such as PC, Blu-ray player, Apple TV, 4K media player, etc.) to
the HDMI IN of the transmitter.
2. Connect HDBT OUT
Connect HDBT OUT of the transmitter to HDBT IN of the receiver with Cat 5e/6/7 cables.
3. Connect HDMI OUT
Connect HDMI display device (such as TV, projector) to the HDMI OUT of the transmitter
and receiver.
4. Connect Audio Outputs
Set the front panel Function1 DIP switch to down or “audio de-embedding” mode, and
connect to the SPDIF OUT or AUDIO OUT port.
5. Connect for additional control options:
• IR Pass Through: Connect the IR emitter cable to the IR Flasher port or the IR receiver
cable to the IR Receiver port of the transmitter, and connect the IR receiver cable to
the IR Receiver port or the IR emitter cable to the IR Flasher port of the receiver. The
source remote can control the source at the receiver side or the display remote can
control the display at the transmitter side.
• To set RS-232 mode see “Function Setting” Section, below. Connect the RS-232 ports
of a control system to the RS-232 ports of the transmitter and receiver to facilitate RS-
232 pass through. For details, see, RS-232 Control Connections Section.
• ETHERNET Pass Through: A built in Ethernet switch is provided on the Transmitter and
Receiver in order to pass through internet connectivity via the HDBaseT connection to
local devices at the end point.
6. Connect the DC 12V power cord provided.
7. Power on all attached devices.

11
Display
Display
DisplayRemote
IR Emitter 1
IR Emitter 2 HDMIOUT
HDMIOUT
AUDIOOUT
Audio
HDMI IN
ETHERNET
ETHERNE T
HDBT
IR Receive r 1
IR Receiver 2
Transmitter
Receiver
SourceRemote
Blu-rayPlayer
AnalogAudio System
PC
de-embedding
Application Diagram 1
To connect HDMI de-embedding audio for amplication, when using 3.5mm AUDIO OUT, the
transmitter front panel AUDIO dip switch should be set to 2CH PCM.
TV
Display
DisplayRemote
IR Emitter 1
IR Emitter 2 HDMIOUT
HDMIOUT
HDMI IN ETHERNET
ETHERNE T
HDBT
IR Receive r 1
IR Receiver 2
Transmitter
Receiver
SourceRemote
Blu-rayPlayer
AV Receiver
PC
SPDIFOUT
SPDIF IN
Application Diagram 2
To connect HDMI de-embedding audio for amplication, and when using SPDIF OUT port, the
transmitter front panel AUDIO dip switch should be set to COMPRESSED 5.1. At same time,
the 3.5mm AUDIO OUT port will be muted.
When using SPDIF OUT for audio return from the receiver SPDIF IN, the transmitter Function
1 dip switch should be set to UP.

12
6. EDID MANAGEMENT
EDID is congured by separate Video and Audio DIP Switches. The default setting is Auto.,
please Please refer to the following table to congure
O
N1234
Video DIP Switch Position
EDID Resolution 1 2 3 4
0Auto (Default) Up Up Up Up
1 1080P SDR Up Up Up Down
2 1080P HDR Up Up Down Up
3 4K@30 SDR Up Up Down Down
4 4K@30 HDR Up Down Up Up
54K@60 4:2:0 SDR Up Down Up Down
6 4K@60 HDR Up Down Down Down
7EDID Copy (HDBaseT OUT) Down Down Down Down
Audio DIP Switch Position
EDID Resolution 1 2 3 4
0Auto (Default) Up Up Up Up
12CH (PCM) Up Up Up Down
26CH (PCM) Up Up Down Up
3Compressed 5.1 Up Up Down Down
48CH (PCM) Up Down Up Up
5Compressed 7.1 Up Down Up Down
6EDID Copy (HDBaseT OUT) Down Down Down Down

13
7. FUNCTION SETTING
IR, RS-232 and ARC functions can be congured by Function DIP Switch. The default setting is
“Up, Up, Up, Up, Up, Up”. Please refer to the following table to congure.
O
N
O
N1 2
1 2 3 4
12
TX Function Settings
Function Group 1
Audio Settings 2-Pin DIP Positions
1 2
SPDIF OUT (SPDIF IN RX) Up -
SPDIF OUT (HDMI De-embed) Down -
Reserved - Up
Reserved - Down
TX Function Settings
Function Group 2
IR/RS-232/ FW Update 4-Pin DIP Positions
1234
IR RCVR PWR OFF (12v) Up - - -
IR RCVR PWR ON (12v) Down - - -
DTE (RS-232) - Up - -
DCE (RS-232) - Down - -
RS-232 pass-thru - - Up Up
System f/w update - - Down Up
HDBT f/w update - - Up Down
Reserved - - Down Down
RX Function Settings
Function Group 1
Audio Settings 2-Pin DIP Positions
1 2
ARC (HDMI OUT) Up -
Audio Return (SPDIF IN) Down -
Reserved - Up
Reserved - Down
RX Function Settings
Function Group 2
IR/RS-232/ FW Update 4-Pin DIP Positions
1234
IR RCVR PWR OFF (12v) Up - - -
IR RCVR PWR ON (12v) Down - - -
DTE (RS-232) - Up - -
DCE (RS-232) - Down - -
RS-232 pass-thru - - Up Up
System f/w update - - Down Up
HDBT f/w update - - Up Down
Reserved - - Down Down

14
7.1. Audio Setting (Group 1)
2-Pin (Group 1) DIP Switch of FUNCTION DIP Switch is used to set audio function.
To return HDMI ARC from TV to AVR:
• Set Pin1 of receiver (RX) to “up”, ARC mode. RX HDMI ARC will be returned through
HDBaseT link to TX connected AVR. In this case, AVR HDMI out is connected to TX HDMI
IN. See Figure 1.
To return SPDIF inserted audio:
• Set Pin1 of transmitter (TX) to “up”, audio return mode. And,
• Set Pin1 of receiver (RX) to “down”, SPDIF IN mode.
• After above settings, audio inserted via RX SPDIF IN port can be returned back to TX and
output from TX SPDIF OUT. See Figure 2.
To extract TX HDMI IN audio:
• Set Pin1 of transmitter (TX) to “down”, HDMI de-embed mode. HDMI IN embedded audio
will be extracted and outputs via SPDIF OUT. See Figure 3. HDMI extraction audio supports
up to 5.1CH Dolby&DTS, or 2CH PCM.
HDMIOUT
AudioReturn
AudioReturn
HDMI IN
HDBT
Transmitter
Receiver
AV Receiver
Display
with or without streaming
DVD Player
Roku or Apple TV
AudioDeviceBuilt-inTuner
Or Or
Speaker
NOTE: For CEC to work end-to-end,
ensure CEC functionality is enabled
on extender, sources and displays.
Figure 1: To return HDMI ARC from TV to AVR

15
Display
HDMIOUT
HDMI IN
HDBT
Transmitter
Receiver
Blu-rayPlayer
AV Receiver
OuputAudiofrom
SPDIF IN of RX
SPDIFOUT
SPDIF IN
Figure 2: To return SPDIF inserted audio
Display
HDMIOUT
HDMI IN
HDBT
Transmitter
Receiver
Blu-rayPlayer
AV Receiver
AudioDe-embedding
fromHDMI IN of TX
SPDIFOUT
Figure 3: To extract TX HDMI IN audio
7.2. IR & RS-232 Setting (Group 2)
4-Pin (Group 2) DIP Switch of FUNCTION DIP Switch is used to set IR and RS-232 function.
• Pin1 is set to “Up”, IR Receiver port does not supply 12V power, when set to “Down”, IR
Receiver port does supply 12V power . Transmitter and receiver are congured separately.
• Pin2 is set to “Up”, RS-232 Serial DTE mode. Pin2 is set to “Down”, RS-232 Serial DCE mode.
Transmitter and receiver are congured separately.
• Pin3 and Pin4 are set to “Up” simultaneously, RS-232 port is set to pass through.
• Pin3 and Pin4 are set to “down, up”, connect to a PC to upgrade unit rmware.
• Pin3 and Pin4 are set to “Up, Down”, use Valens tool to upgrade Valens chip.

16
8. CONNECTIONS
8.1. HDBaseT Link (RJ45) Connection
This device is designed to operate with category cables for communication between the
transmitter and receiver. The transmission path may include a maximum of two keystones and
two patch cables, as long as the total length does not exceed 100 m depending on the category
cable and resolution desired.
TIA/EIA-568-B
3 876543321
TIA/EIA Standard 568-B
(Gold Pins Facing Up)
Pin 5 - White/Blue
Pin 6 - Green
Pin 7 - White/Brown
Pin 8 - Brown
Pin 1 - White/Orange
Pin 2 - Orange
Pin 3 - White/Green
Pin 4 - Blue
Figure 4: HDBaseT RJ45 Connections
Note: The HDBaseT Link RJ45 connection includes a 48V signal. Do not connect anything to
this port other than a B-660-EXT-444-100AS transmitter or receiver.
8.2. RS-232 Control Connections
• Bidirectional RS-232 signals are transmitted between the device transmitter and receiver
over the category cable. The transmitter may be connected to a control system, and the
receiver may be connected to an RS-232 controllable device.
B
A
HDBaseT Link Category - See Section 8.1
RS-232 Control (DB-9) - See Section 8.2.1
HDBT
T
ransmitter
Control System
RS-232ControllableDevic e
Receiver
B
A
A
DTE Mode
DCE Mode
TX Function Group
4
ON 32
DTE
1
RX Function Group
4
ON 32
DCE
1
Example 1
HDBT
T
ransmitter
RS-232ControllableDevic e
Receive
r
B
A
Control System
A
DTE Mode
4
ON
32
DTE
1
RX Function Group
DCE Mode
TX Function Group
4
ON 32
DCE
1
Example 2

17
HDBT
T
ransmitter
Control System
RS-232Control Terminal
Receive
r
B
A
A
TX Function Group
DTE Mode
4
ON
32
DTE
1
DTE Mode
4
ON 32
DTE
1
RX Function Group
Example 3
Figure 5: RS-232 Connections
8.2.1. RS-232 Control (DB-9) Connection
To eliminate the need to make crossover or null modem cables, the RS-232 pinouts can be
congured for DCE or DTE. Set switch 2 to DCE if the connected device is DCE, and to DTE if
the connected device is DTE.
Typically, the control system will be DTE and the controlled device will be DCE, however,
devices may vary. Refer to the manual for the connected devices for proper pinout
conguration.
T
ransmitter
Receiver
4
ON 32
DTE
1
DTE Mode
4
ON 32
DTE
1
DCE Mode
4
ON 32
DCE
1
4
ON 32
DCE
1
1 (NC)
3 (NC)
2 (NC)
4 (GND)
6 (TxD)
5 (RxD)
7 (NC)
8 (NC)
1
2
3
4
5
6
7
8
Figure 6: RS-232 Modes and Connections

18
9. SPECIFICATIONS
Technical
Input/Output Port
Transmitter:
1 x HDMI IN, 1 x HDBT OUT, 1 x HDMI OUT,
1 x IR Receiver,1 x IR Flasher,
1 x RS-232 (RJ45),
1 x AUDIO OUT (3.5mm analog audio out),
1 x SPDIF OUT, 2 x ETHERNET, 1 x DC 12V IN
Receiver:
1 x HDMI OUT, 1 x HDBT IN, 1 x IR Receiver,
1 x IR Flasher, 1 x RS-232 (RJ45),
1 x AUDIO OUT, 1 x SPDIF IN,
2 x ETHERNET, 1 x DC 12V IN
Input/Output Signal Type HDMI with 4K@60Hz YUV 4:4:4, HDCP 2.2,
including DCI 4K (4090x2160)
Input/Output Resolution Supported
VESA:
800x6008, 1024x7688, 1280x7688, 1280x8008,
1280x9608, 1280x10248, 1360x7688,
1366x7688, 1440x9008, 1600x9008,
1600x12008, 1680x10508, 1920x12008,
2560x14408, 2560x16008
SMPTE:
1280x720P6,7,8, 1080I6,7,8,
1920x1080P1,2,3,4,5,6,7,8,
3840x2160P2,3,5,6,8, 4096x2160P2,3,5,6,8
NOTE: 1 = at 23.98 Hz, 2 = at 24 Hz, 3 = at 25 Hz,
4 = at 29.97 Hz, 5 = at 30 Hz, 6 = at 50 Hz, 7= at
59.94 Hz, 8 = 60 Hz, 9 = 75 Hz
Audio Format
HDMI IN/OUT: Fully supports audio formats
in HDMI 2.0 specication, including PCM
2.0/5.1/7.1, Dolby TrueHD™, Dolby Atmos™,
DTS-HD Master Audio™ and DTS:X™
3.5mm Analog AUDIO OUT: PCM 2.0
SPDIF: PCM 2.0, Dolby Digital™, DTS 5.1™
Maximum Data Rate HDMI IN & HDMI OUT: 18Gbps
Control Method IR, RS-232, CEC, DIP Switches
General
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Humidity 10% to 90%, non-condensing
ESD Protection Human-body Model:
±15kV (Air-gap discharge)
Power Supply DC 12V 3A
Power Consumption (Max)
Receiver is powered by transmitter: 28.44W
Transmitter is powered by receiver: 28.92W
Transmitter and receiver are powered
separately: Transmitter: 10.44W,
Receiver: 12.12W
Device Dimension
(W x H x D)
212.5mm x 15.4mm x 110mm/8.37” x 0.61”
x 4.33” (Transmitter/Receiver, without
mounting ears)
Product Weight 0.48kg/1.05lb

19
9.1. Transmission Distance
Note: Straight-through category cable wired to T568B standard is recommended.
Cable Type Range Supported Video
Cat 5e/6
100m/330ft Up to 1080P@60Hz 36bpp
70m/230ft 1080P@60Hz 48bpp
4K@30Hz 24bpp
4K@60 4:2:0 24bpp
4K@60 4:4:4 24bpp
Cat 6a/7 100m/330ft
HDMI recommended max
length of 3m/10ft all supported resolutions
10. WARRANTY
2-Year Limited Warranty
This Binary product has a 2-Year limited warranty. This warranty includes parts and labor
repairs on all components found to be defective in material or workmanship under normal
conditions of use. This warranty shall not apply to products that have been abused, modied
or disassembled. Products to be repaired under this warranty must be returned to SnapAV
or a designated service center with prior notication and an assigned return authorization
number (RA).
11. SUPPORT
Need Help? Contact Tech Support!
If you need further clarication, please call tech support at 800.838.5052, or email support@
snapav.com. For other information, instructional videos, support documentation, or ideas, visit
our website and view your item’s product page at www.snapav.com.

Rev: 200401-170015
© 2020 Binary
