PRD1000 Analog Input Process Meter
Instruction Manual
For use with Bindicator Model TDR-2000
0-20 mA, 4-20 mA, 0-5 V, 1-5 V, and ±10 V Inputs
NEMA 4X, IP65 Front
Universal 85-265 VAC, or 12/24 VDC Input Power Models
Large Dual-Line 6-Digit Display, 0.60" & 0.46"
Dual-Scale for some Level Applications – Single Input
Sunlight Readable Display Models
Isolated 24 VDC Transmitter Power Supply
Signal Input Conditioning for Flow & Round Horizontal Tanks
Programmable Display & Function Keys
32-Point, Square Root, or Exponential Linearization
Multi-Pump Alternation Control
2 Relays Option
RS-485 Serial Communication Options
Tare Function
Modbus
®
RTU Communication Protocol Standard
Custom configuration available from Bindicator
