bioBidet BB-1700 User manual

Thank you for purchasing Bio Bidet Advanced Toilet Seats.
Intended for household use only.
Lifestyle Upgrade
2
171102_BB-1700,2000 USER's MANUAL.indd 2 2017-11-03 오전 11:27:58

MAINTENANCE
WATER DRAINING
TROUBLE SHOOTING
SPECIFICATIONS
WARRANTY
INFORMATION TO THE USER
OPERATION (BASIC)
OPERATION (DETAILS)
INSTALLATION
SEPARATION OF THE UNIT FROM
THE TOILET BOWL
IMPORTANT SAFEGUARDS /
GENERAL CAUTIONS
CAUTIONS BEFORE INSTALLATION
CARTON CONTENTS / IDENTIFICATION
4
6
8
12
14
18
21
22
23
24
25
26
27
Contents
PREPARATION OPERATION INSTALLATION MAINTENANCE
Installation Manual and Operating Instructions
3
171102_BB-1700,2000 USER's MANUAL.indd 3 2017-11-03 오전 11:27:58

4
The following terms are used in this manual to indicate hazards of varying degrees of severity.
I ndicates potentially hazardous situation which, if not avoided, may result in minor or
moderate injury or in damage to the product or other property.
Indicates potentially hazardous situation which, if not avoided,
could result in death or serious injury.
WARNING
Indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury.
DANGER
CAUTION
READ ALL INSTRUCTIONS BEFORE INSTALLATION AND USE
DANGER - To reduce the risk of electrocution
WARNING - To reduce the risk of burns, electrocution, fire, or injury to persons
PLEASE OBSERVE THE FOLLOWING PRECAUTION BEFORE USING THIS PRODUCT
Do not open the product to repair or remodel.
Only qualified service personnel should service this product.
Do not use attachments not recommended by the manufacturer.
Do not dismantle
Connect this product to cold water supply pipe carrying potable water.
Do not connect to an industrial water supply line that
does not carry water of drinking quality.
This will negatively effect hygiene and performance.
Prohibited
About Low Temperature Burns-
A burn occurs when the skin has been exposed to high temperatures.
However, a low temperature burn may occur when the skin has been in contact with an
object at relatively low temperature (about 104 ℉). Close supervision is necessary when
this product is used by children or adults with sensitive skin.
Prohibited
If using any chemical toilet bowl cleaner, be sure to wipe up
any spills that splash onto Electric Bidet.
Do not use benzene or any acid chemical detergent.
Only neutral detergent permitted.
Prohibited
1
IMPORTANT SAFEGUARDS / GENERAL CAUTIONS
171102_BB-1700,2000 USER's MANUAL.indd 4 2017-11-03 오전 11:27:59

PREPARATION
Installation Manual and Operating Instructions
5
Do not plug in the power cord before connecting the water supply hose.
Prohibited
This product must be grounded.
An approved Ground Fault Circuit Interrupt must be used.
Grounding
Do not splash water on this product.
Please provide adequate ventilation to avoid high levels of humidity
which can damage the electronic components.
It is necessary to provide adequate ventilation with a fan,
open door or open window when bathing.
Do not spray water
Do not touch the power cord with wet hands.
Do not reach for a product that has fallen into water.
Unplug immediately!
Wet hands prohibited
This product must be connected to a standard voltage power source.
Do not connect power cord if the cord is damaged or broken.
Do not plug the unit into a loose electric outlet.
Observe at all times
Please disconnect the power cord when you clean this product or
detach it from toilet bowl.
Do not supply electrical power to the unit until the plumbing work
has been completed.
Observe at all times
Keep the electrical cord away from heated surfaces to prevent a fire
hazard.
Also, keep any flammable materials away from this product at all times.
Use of fire prohibited
IMPORTANT SAFEGUARDS / GENERAL CAUTIONS
171102_BB-1700,2000 USER's MANUAL.indd 5 2017-11-03 오전 11:27:59

6
CAUTION
Never operate this product if it is not
working properly, if it has been
dropped or damaged, or dropped into
water. Return the product to a service
center for examination and repair.
Prohibited
Do not obstruct or put
anything into the dry air
outlet. Do not apply
excessive force to the
shower nozzle.
Prohibited
Do not strain or push the connected hose and tube connecter;
it may cause water leakage.
Never drop or insert any object into any opening or hose.
Use proper plumbing supplies if any modification is to be made.
Prohibited
Drain the water from unit and unplug the power if this product is
not going to be used for an extended period of time.
Refer to page 19.
Observe at all times
Do not stand or sit on
the seat cover lid.
It is not designed to
support a user痴
body weight.
Prohibited
Allow the seat
and lid to close
automatically.
Do not force the
lid closed.
Prohibited
Use this product only as described
in the operating instructions.
Never use while sleeping or drowsy.
Do not use while bathing.
Observe at all times
Be careful so that
this product does not
become stained with
excrement and urine.
Observe at all times
- SAVE THESE INSTRUCTIONS -
THIS PRODUCT MUST BE PLUGGED into a regular voltage grounded GFCI outlet (North America 120V ac).
The rated power consumption is 1400W. In locations where only a standard two-prong outlet is available,
it is the responsibility of the user to install a grounded three-prong outlet.
Using a higher voltage is dangerous and may result in a fire or other accident.
This product is not responsible for damage resulting from the use of it on other than specified voltage,
or operating it without proper grounding.
WIRING REQUIREMENT
1
IMPORTANT SAFEGUARDS / GENERAL CAUTIONS
2
CAUTIONS BEFORE INSTALLATION
171102_BB-1700,2000 USER's MANUAL.indd 6 2017-11-03 오전 11:28:00

PREPARATION
Installation Manual and Operating Instructions
7
(1) This product has a three-prong grounding plug, which must be plugged into an outlet that is properly installed and
grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an
escape wire for the electric current. If repair or replacement of the cord or plug is necessary, do not connect the
grounding wire to either flat blade terminal. The wire with insulation having an outer surface that is green with or
without yellow stripes is the grounding wire. Check with a qualified electrician or service person if the grounding
instructions are not completely understood, or if in doubt as to whether the product is properly grounded.
(2) This product is for use on a nominal 120V circuit, and has a grounding plug that looks like the plug illustrated in
sketch A in Figure 1. A temporary adapter, which looks like the adapter illustrated in sketches B and C, may be
used to connect this plug to a 2-pole receptacle as shown in sketch B if a properly grounded outlet is not available.
The temporary adapter should be used only until a properly grounded outlet (sketch A) can be installed by a qualified
electrician. The green colored rigid ear, lug, or the like extending from the adapter must be connected to a permanent
ground such as a properly grounded outlet box cover. Whenever the adapter is used, it must be held in place by the screw.
This appliance has to be earthed.
GROUND INSTRUCTIONS
GROUNDING PIN
ADAPTER ADAPTER
METAL SCREW TAB for
Grounding Screw
GROUNDED
OUTLET
- Figure 1-
The use of an extension cord is not recommended or advised. If it is necessary to use an extension cord, use
only a three-prong extension cord (one to one), and a three slot built-in GFCI receptacle that will accept the
plug on this product. The marked rating of the extension cord should be equal to or greater than the electrical
rating of the unit (10amp). Consult a qualified electrician or service person if you are not sure whether the unit is
properly grounded.
IMPROPER GROUNDING CAN RESULT IN A RISK OF ELECTRIC SHOCK.
Electric wiring has to be done in accordance with all local codes,
or in the absence of local codes, with the National Electrical Codes.
DANGER
OPTIONAL GROUND INSTRUCTIONS
This Product must be on a separate circuit. No other appliance
should share the circuit with this product.
Sharing a circuit could cause the branch circuit fuse to blow
or the circuit breaker to trip. Continuous usage under these
conditions could result in fire or property damage.
WARNING
GROUNDED
OUTLET BOX
IMPORTANT SAFEGUARDS / GENERAL CAUTIONS
CAUTIONS BEFORE INSTALLATION
171102_BB-1700,2000 USER's MANUAL.indd 7 2017-11-03 오전 11:28:01

8
MAIN UNIT
1
ACCESSORIES
2
Posterior Wash Nozzle
Turbo Wash Nozzle
Digital Occupied Sensor
Drain / Quick Release
Operation LED Window
Heated Seat
Lid
Caution Label
Deodorizer
Dryer Vent
Control Panel for BB-1700
Feminine Wash Nozzle
BB-1700
3 Identification
Cone packing
(2 pcs)
Mounting bolts (2 pcs) Catch Plate (1 pcs)
Nuts
(2 pcs)
Bolt Case
(2 pcs)
User manual
For plumbing For product fixation Installation
instructions
Water supply hose
(for electronic bidet)
Water supply hose
(for toilet flush water tank)
T-Valve
Drain button
L-Valve
1/2" O.D.Compression
Conversion Nut
171102_BB-1700,2000 USER's MANUAL.indd 8 2017-11-03 오전 11:28:02

PREPARATION
Installation Manual and Operating Instructions
9
BB-1700 Control Panel
3
Installation
instructions
- When you sit down on this product, sit in the center in order to activate the sensor.
(If the unit's input water temperature is lower than 54 ℉ , the water temperature could be
lower than the above noted temperatures)
Stop all operation.
Posterior wash. Feminine wash.
Turbo wash. Dry washed area.
Adjust the water pressure and
warm air dryer temperature.
Adjust the oscillation function and
nozzle position (5 levels).
Adjust the water temperature (4 levels). Adjust the seat temperature (4 levels).
When selected during the wash function, the
nozzle oscillates automatically for a wider wash.
When selected during the wash function,
it starts the massage wash.
If move button is selected when user is not
sitting on the seat, it operates nozzle shower
function.
If massage function selected when user is not
using wash functions, it automatically operates
wash and dry function sequentially.
If Economy mode is selected, seat temperature
and water temperature will stay at 89.6℉.
When user sits on the seat, it automatically
operates to deodorize. (Can select on/off)
171102_BB-1700,2000 USER's MANUAL.indd 9 2017-11-03 오전 11:28:03

10
MAIN UNIT
1
Digital Occupied Sensor
Drain / Quick Release
Operation LED Window
Heated Seat
Lid
Caution Label
Deodorizer
Dryer Vent
3 Identification
BB-2000
ACCESSORIES
2
Cone packing
(2 pcs)
Mounting bolts (2 pcs) Catch Plate (1 pcs)
Nuts
(2 pcs)
Bolt Case
(2 pcs)
Remote control User manual
Remote control
holder
1.5V AAA type
Battery (2pcs)
For plumbing For product fixation For remote control Installation
instructions
Simple Operation Panel
For BB-2000
Drain button
Posterior Wash Nozzle
Turbo Wash Nozzle
Feminine Wash Nozzle
T-Valve L-Valve
1/2" O.D.Compression
Conversion Nut
Water supply hose
(for electronic bidet)
Water supply hose
(for toilet flush water tank)
171102_BB-1700,2000 USER's MANUAL.indd 10 2017-11-03 오전 11:28:04

PREPARATION
Installation Manual and Operating Instructions
11
Posterior Wash
Feminine Wash
Dry
Turbo
Deodrant
Remote signal intensity
battery life
Set Water Temperature
Heated Water
❿






Heated Seat
Set Seat Temperature
Water Pressure
Dry On / Off
Set Nozzle position
Watter pressure
Nozzle position
❶ ❷ ❸
❹ ❺
❻
❼
❽
❾
❿






Display
Installation
instructions
BB-2000 Remote Control
3
Simple Operation Panel
Feminine
Wash
Posterior
Wash
Stop
- When you sit down on this product, sit in the center in order to activate the sensor.
(If the unit's input water temperature is lower than 54
℉ , the water temperature could be
lower than the above noted temperatures)
❶
❷
❸
❹
❺
❻
❼
❽
❾
Stop all operation.
Posterior wash.
Feminine wash.
Dry washed area.
VORTEX wash.
When selected during wash function nozzle
oscillates automatically for a wider wash.
If move button is selected when user is not sitting
on the seat, it operates nozzle shower function.
When selected during wash function,
it start massage wash.
If massage function selected when user is not
using wash functions, it automatically operates
wash and dry function sequentially.
When user sits on the seat, it automatically
operates to deodorize. (Can select on/off)
The water temperature can be adjusted up to 4 levels
(off, low, middle, high).
Can set time in the remote control with
hour( ) and minutes( ) buttons.
If Economy mode is selected, seat temperature
and water temperature will stay at 89.6℉.
If this( ) symbol flashes, please change
the battery in remote control.
The seat temperature can be adjusted up to 4 levels
(off, low, middle, high).
171102_BB-1700,2000 USER's MANUAL.indd 11 2017-11-03 오전 11:28:05

12
PREPARATION
2
ᆞPlease plug the power cord into AC120V power outlet.
ᆞPlug the unit into the proper power source and the LED power light will start flashing.
ᆞWait until the LED power light stops flashing and becomes solid red.
ᆞThe water tank will be filled after pushing a "wash" or , or ) button.
ᆞWhen the water tank is filling the buzzer "Beeps"continuously.
After the water tank is full the buzzer will end with "One Solid Beep".
Check for any water leaks.
1
ᆞPlease turn on the water supply valve and check connected spots(1~5) for the leakage.
4 Operation (Basic)
CAUTION
Please press the "off"or "low"button to reduce the seat temperature after using.
Special precautions should be taken for children, those who cannot adjust the temperature,
and those who have sensitive skin.
CAUTION
CAUTION
DO NOT ALLOW CHILDREN TO USE THE TURBO WASH or VORTEX WASH FUNCTION!
SUPERVISION IS STRONGLY RECOMMENDED FOR THE ELDERLY OR OTHER PERSONS
THAT MAY HAVE LIMITATIONS IN BODY MOVEMENT, ILLNESS OR DISABILITIES!
Observe at all times
water supply
vavle










171102_BB-1700,2000 USER's MANUAL.indd 12 2017-11-03 오전 11:28:06

OPERATION
Installation Manual and Operating Instructions
13
SIT DOWN ON THE SEAT
ᆞWhen you sit down on the seat, the ORANGE LED lamp on the control panel will light up.
ᆞWhen the digital sensor on the seat is activated, the operation LED window on the main unit
will light "Occupied sensor"and simultaneously, the deodorizer fan will start to work.
(BB-1700 / BB-2000 Models)
ᆞSee page 14 for details about changing the seat or water temperature.
OPERATION
3
CLEANSING
ᆞCLEANSING 1. (Posterior Wash)
1- Press "Posterior Wash"( , ). Automatically, the nozzle comes out and
sprays warm water to posterior.
2- Additional functions during your Posterior Wash experience are available. See Oscillation,
page 15 and Massage, page 16 for details.
STOP
ᆞPress this button to stop all operation.
ᆞCLEANSING 2. (Feminine Wash)
1- Press "Feminine Wash"( , ). Automatically, the nozzle comes out and
sprays warm water to feminine area.
2- Additional functions during your Feminine Wash experience are available. See Oscillation,
page 15 and Massage, page 16 for details.
ᆞCLEANSING 3. (Turbo Wash / Vortex Wash)
1- Press "Turbo Wash"( ) or "Vortex Wash"( ), the nozzle spray is more or
focused to produce the effect of strong wash, to help stimulate bowel movement.
2- Press "Water pressure - High & Low button"to adjust the water pressure.
CLEANSING cont.
ᆞCLEANSING 3. (Turbo Wash or Vortex Wash)
1- Press "Turbo Wash"or "Vortex Wash"continuously for 3 to 5 seconds. Automatically, the water
nozzle comes out and sprays a warm stream of water to the posterior center of the rectum.
2- If necessary, adjust "Position"of water stream with the ( / )buttons.
3- Press "Water pressure High & Low button" ( / )to adjust the water pressure
to your desired comfort.
4- Press the "STOP"( )button when you feel your abdomen is full or wait until
the "Turbo Wash"or "Vortex Wash"function stops, approximately 1 minute.
5- You will shortly feel the urge to push the water out of your colon, push the water and feces
out as thoroughly as you can.
6- Relax for a few minutes and be sure you feel your colon is empty and then use
the "Posterior Wash"and "Air Dry" function to finish.
171102_BB-1700,2000 USER's MANUAL.indd 13 2017-11-03 오전 11:28:07

14
5 Operation (Details)
WARM WATER TEMPERATURE
AND SEAT TEMPERATURE ADJUSTMENT
WARM AIR DRYER
1- Press "Dry"( , ), warm, dry air is gently directed to washed area for about 3 minutes.
2- You may adjust the warm air temperature by pressing High( ) and Low( ) buttons.
※This product memorizes the air temperature of prior use.
WATER PRESSURE ADJUSTMENT
ᆞAfter sitting down on the this product, the LED lamp( ) for water
pressure on the Power Control will light at third or middle level( ).
ᆞPress high( ) , or low( ) to adjust the pressure of the water spray to
your desired comfort level.
ᆞThe temperature of water and seat are adjustable to the desired level by pressing
the "WATER" ( )and "SEAT" ( ) button.
OFF /
Room temperature
GREEN
Normal
ORANGE
Low
RED
High
WATER TEMPERATURE
OFF /
Room temperature
GREEN
Normal
ORANGE
Low
RED
High
SEAT TEMPERATURE
BB-1700
WARM WATER TEMPERATURE
AND SEAT TEMPERATURE ADJUSTMENT
ᆞThe temperature of water and seat are adjustable to the desired level by pressing
the "WATER" ( )and "SEAT" ( ) button.
OFF /
Room temperature
GREEN
Normal
ORANGE
Low
RED
High
WATER TEMPERATURE
BB-2000
SEAT TEMPERATURE
BB-1700 BB-2000
171102_BB-1700,2000 USER's MANUAL.indd 14 2017-11-03 오전 11:28:08

OPERATION
Installation Manual and Operating Instructions
15
ᆞNozzle position is adjustable to the desired position by pressing "Front"() or
"Rear"() button from 1 to 5 positions.
After using this product, the nozzle will return to position 3.
NOZZLE POSITION ADJUSTMENT
DEODORIZER
ᆞWhen using Posterior or Feminine Washing functions, pressing the "MOVE"( , )
button will provide a short-motion, front to back oscillating spray for a much wider cleansing
experience.
ᆞYou may change the position of the Oscillating spray by pressing the "MOVE"( , )
button again and "Front" ( ) or "Rear" ) buttons simultaneously.
ᆞPush the "MOVE"( , ) button again and the oscillation motion will stop automatically.
Auto-Setting of Oscillation Feature
ᆞYou can set this function to automatically oscillate whenever the seat is occupied and the Posterior or
Feminine washes are in operation.
Step 1: Sit on this product.
Step 2: Press the "MOVE"( , ) button for 3 seconds or until you hear a single Chime.
Step 3: Sit on the this product and proceed with Posterior or Feminine Wash.
Note: In the automatic setting, you may still adjust the position of the Oscillating spray by pressing the
"Front"( ) or "Rear"( ) buttons.
Canceling the Automatic Oscillation function
Step 1: Sit on this product.
Step 2: Press the "MOVE"( , ) button for 3 seconds or until you hear a double Chime.
OSCILLATION ( Nozzle Movement Function)
- Select: Single Chime
- Cancel: Double Chime
Deodorizer ON/Off (initial setting is Off)
- Press button for( , ) 3 seconds (press the button again for 3 seconds, the function is canceled.)
- After setting Deodorizer function, it is automatically activated when sensing the human body.
- Once used, the Deodorizer function automatically stops after 1 minute of operation.
"Deodorizer"button
Press 3 seconds
Single Chime
"Deodorizer"button
Press 3 seconds
Double Chime
Reference
- Deodorizer function stops while dryer is selected. After dryer function completes, deodorizer automatically is activated.
171102_BB-1700,2000 USER's MANUAL.indd 15 2017-11-03 오전 11:28:09

16
5 Operation (Details)
Auto Wash
- If the "MASSAGE"( , ) function selected when user is not using wash functions,
it automatically operates wash and dry function sequentially.
- Wash (30 Seconds) + Dryer (1minute) then automatically stops
ᆞWhen using the Posterior Wash or Feminine Wash functions, pressing the "MASSAGE"( , )
button will provide a pulsation spray.
ᆞYou may change the pressure of the spray by pressing the "High"( ) button or "Low"( ) buttons.
ᆞPush the "MASSAGE"( , ) button again and the pulsating action will stop automatically.
Auto-Setting of Massage Feature
ᆞYou can set this function to automatically pulsate whenever the seat is occupied and the Posterior
or Feminine washes are in operation.
Step 1: Sit on this product.
Step 2: Press the "MASSAGE"( , ) button for 3 seconds or until you hear a single Chime.
Step 3: Sit on this product and proceed with Posterior or Feminine Wash.
Note: In the automatic setting, you may still adjust the pressure of the pulsating spray by
pressing the "High"( ) or "Low"( ) functions.
Canceling the Automatic Oscillation function
Step 1: Sit on this product.
Step 2: Press the "MASSAGE"( , ) button for 3 seconds or until you hear a double Chime.
MASSAGE (Rhythm Wash)
Night Light on/off setting
- Press "Stop"and "Temperature"remote buttons simultaneously until
night light is turned on or off.
+
Nozzle Shower
- Press "Move"( , ) button while seat is not occupied.
- Nozzle shower will initiate to clean nozzle and tip for about 20 seconds.
- Nozzle will automatically retract once finished.
171102_BB-1700,2000 USER's MANUAL.indd 16 2017-11-03 오전 11:28:11

OPERATION
Installation Manual and Operating Instructions
17
Nozzle Cleaning (Automatic)
- This product has an automatic nozzle self-cleaning function that
cleans the nozzle before and after each use.
- If the "MASSAGE"( , ) function selected when user is not using wash functions,
it automatically operates wash and dry function sequentially.
- Wash (30 Seconds) + Dryer (1minute) then automatically stops
Nozzle Cleaning (Manual)
- Press the "Posterior"( , ) button on the Auxiliary Control panel on the side of the seat without
occupying seat. The nozzle will fully extend. Gently clean the nozzle with a soft cloth or toothbrush.
- Press "Stop"( , ) button to retract nozzle to stand-by mode.
Selecting/Cancelling Silent Mode
- Beeping mode can be enabled or disabled.
- To select or cancel silent mode, press and hold down the "Stop"( , ) and "Massage"( , )
remote buttons simultaneously for approximately 3 seconds or until short beeps
Single short beep - Silent mode has been cancelled
Double short beeps - Silent mode has been set
- The new setting will automatically be saved if no other buttons are pressed.
ECONOMY (Energy Save Mode)
- Keep seat cover closed when not in use to prevent heat from being lost.
- Keep temperature set to low.
- Unplug the power cord if you do not plan to use the unit for a long period of time.
Saver On/ Off
- When pressing( , ) the energy saver LED on the main unit will turn on.
(press button again, the saver LED will turn off)
- Energy saver mode automatically maintains a water and
seat temperature of 89.6℉(32℃).
- When using bidet in saver mode, it is turned to automatic saver.
- When you rise from the seat, it goes into saver mode.
- Seat temperature is maintained 32℃.
Other energy saver tips
In order to save energy, please abide by the following instructions:
In energy saver mode, the seat heating
temperature could appear to be lower
than the actual temperature setting.
OFF
State
ON
State
Flashing
State
OCCUPIED
SENSOR
ENERGY
SAVER
POWER
BB-2000
DEODORANT ENERGY
SAVER
POWER
BB-1700
171102_BB-1700,2000 USER's MANUAL.indd 17 2017-11-03 오전 11:28:11

18
CAUTION BEFORE INSTALLATION
ᆞDo not plug in before installation.
ᆞIf you need an electric power system or extension, please consult a qualified electrician.
ᆞPlease contact our service center(847-458-2334) when you want to reinstall the bidet
product(move or replacement).
STEPS
ᆞShut off the water supply shut off valve.
ᆞDrain the toilet tank completely.
ᆞThen remove the existing fill valve water supply hose.
Flexible Tube
Water supply hose
(for toilet flush water tank)
1
Connect T-Valve.
ᆞRemove existing supply hose connected to the toilet tank.
Make sure not to damage the water supply hose
ᆞInstall T-Valve at the thread from tank.
ᆞRemove existing supply tube from fresh tank
ᆞIf your shut off valve is
1/2" O.D compression size,
use supplied
1/2" conversion nut as shown below.
2Removing the existing seat and lid.
ᆞRemove mounting bolts to release existing
toilet seat from toilet.
※Check for any water leaks.
3Connect the water supply hose to the
assembled T-valve.
4
1/2" O.D.Comp. conversion
nut with packing
Turn Off Water.
6 Installation
171102_BB-1700,2000 USER's MANUAL.indd 18 2017-11-03 오전 11:28:12

INSTALLATION
Installation Manual and Operating Instructions
19
Removing the existing seat and lid.
※Check for any water leaks.
Connect the water supply hose to the
assembled T-valve.
Catch plate
Place the plate and guides over each mounting hole.
Insert the mounting bolts through the plate and
mounting holes.
5
1. Slide this product onto the catch plate
centering the unit with the guide arrows on the Base.
2. You will hear a click once this product is securely
mounted to the catch plate.
3. This product will feel a little loose on the toilet bowl.
Adjust the fit from front to back and side to side for balance.
4. Tighten the nuts on both bolts securely.
7
Check for any water leaks.
※Customers should use the new hose set provided
with the product. Do not use used set again.
8
Slide cone packing and washers onto the bolts
then fasten to securely mount bidet seat to toilet.
6
Installation Catch Plate. Bolt and Nut Assembly.
Assembly. Connect the flexible tube from side of
T-Valve to this product,
Open the Angle Stop valve to fill water.
Cone Packing
Nut
Bolt Case
Bolt
Central mounting
groove
Bolt
BACK
L-Valve
171102_BB-1700,2000 USER's MANUAL.indd 19 2017-11-03 오전 11:28:12

20
Wireless remote mounting guide. (BB-2000)
9
Nozzle Change
10
6 Installation
Install wireless remote with adhesive tape
Inserting batteries
ᆞInsert supplied batteries (1.5V AAA) and close battery cover.
Nozzle Combiation
Nozzle Seperation
ᆞRemove adhesive from back of bracket and
place bracket where desired.
(Please check the polarity,
before insert the batteries.)
Adhesive
tape Wall
171102_BB-1700,2000 USER's MANUAL.indd 20 2017-11-03 오전 11:28:13

INSTALLATION
Installation Manual and Operating Instructions
21
Disconnect the power plug.
Close water supply shut-off valve.
Drain water from bidet seat using drainage
as illustrated.
Remove bidet seat from toilet as illustrated.
Do not turn unit upside down.
1
2
3
4
7
Separation Of Unit From The Toilet Bowl
171102_BB-1700,2000 USER's MANUAL.indd 21 2017-11-03 오전 11:28:13
