Bischoff & Bischoff RL-smart User manual

Enjoy mobility.
Bedienungsanleitung
Enjoy mobility.
Instruction manual
RL-SMART

Bischoff & Bischoff GmbH | 16.10.2017
EN
32
RL-SMART | Lightweight rollator Lightweight rollator | RL-SMART
Index
1. Introduction 03
1.1. Signd and symbols 03
2. Important safety Instructions 04
2.1. General safety Instructions 04
2.2. Indications / Contra-indications 04
2.3. Purpose 05
2.4. Declaration of Conformity 05
2.5. Resposibility 05
2.6. Product life 05
3. Description of product and contents 06
3.1. Inspection on delivery 06
3.2. Type plate and Serial number 07
3.3. Contents 08
3.4. Summary 08
4. Assembly/adjustments 09
4.1. Unfolding 09
4.2. Folding up 09
4.3. Installing the functional bag 09
4.4. Adjusting the handles 09
4.5. Brake application and adjustment 10
4.7. Wheels and tyres 11
5. Use 11
6. Technical data 12
7. Maintenance tips for users 13
7.1. Cleaning and disinfection 13
7.2. Rollator check by the user 13
7.2.1. Brake Inspection 13
7.2.2. Checking the tyres 14
8. Maintenance tips for retailers 14
9. Storage/shipping 15
10. Re-use 15
11. Repairs 15
12. Disposal 16
13. Warranty certificate 17
1. Introduction
Dear Customer,
Congratulations on your decision to purchase this rollator. It is a
German product that will improve your everyday life and bring you
much enjoyment.
Before you take your first steps with the rollator, we ask that you read
this instruction manual carefully and follow our recommendations. This
will help you get to know your walking aid and ensure maximum safety
when using it day-to-day.
As you will find out, the rollator is very simple to use. We are sure that
you will get used to it very quickly and soon won’t be able to imagine
life without it.
Take full advantage of your new-found mobility!
With kind regards
You B+B team
1.1. Signs and symbols
Important! This is especially useful information on
a given subject..
Warning! These are especially safety-relevant
instructions. Follow the directions in the manual!

Bischoff & Bischoff GmbH | 16.10.2017
EN
54
RL-SMART | Lightweight rollator Lightweight rollator | RL-SMART
2. Important safety Instructions
2.1. General Safety instructions
• Max. capacity Rollator RL-smart 136 kg
• Please note there is a danger of trapping fingers and/or clothing
when folding and unfolding. Do not catch any clothing or body
parts between the moving parts.
• Please note the minimum insertion depth of the handles bars!
• Each brake only affects one running wheel!
• The bag can be loaded with max. 5 kg.
• When cleaning, do not use any aggressive or corrosive cleaning
agents!
• Check the rollator for correct assembly before every use. The brake
operation should be checked.
• Brakes should be checked every 6 months by a specialist!
• The surfaces of the rollator can heat up when in direct expo-sure
with the sun. This may result in injury.
2.2. Indications / Contra-indications
•The rollator supports users with limited mobility to move, e.g. for
domestic use, when shopping or walking outdoors
•The seat area allows a place to rest during longer distances.
•The rollator must be used on level and solid ground only.
•The product must not be used as a climbing aid or means of
transport for heavy loads.
2.3. Purpose
The rollator is intended to support mobility of persons with an impaired
ability to walk, in accordance with the above-mentioned indications.
2.4. Declaration of Conformity
B+B, as manufacturer of the product, declares that the rollator fully
meets the requirements of the guideline 93/42/EEC.
2.5. Resposibility
We are only able to provide a warranty if the product is used in
accordance with the specified conditions and for the intended purposes.
If modifications, repairs or maintenance works are made, please make
sure only authorised persons perform these works in accordance to the
instructions of B+B.
2.6. Product life
The expected product life of the rollator amounts up to 5 years if used
as intended and in compliance with the safety, care and maintenance
instructions. Over this period and beyond, the rollator can be used if the
product is in a safe condition.
We are only able to issue a guarantee if the product
is used in accordance with the specified conditions
and for the specified purpose.

Bischoff & Bischoff GmbH | 16.10.2017
EN
76
RL-SMART | Lightweight rollator Lightweight rollator | RL-SMART
3. Description of product and
contents
3.1. Inspection on delivery
All B+B rollators are subject to a proper final inspection in our house
and receive the CE mark.
The rollator is supplied in a special box. After unpacking, please save
the box if possible. You may need it later for storage or to return the
product.
Assembly, adjustment to your body size and first instructions are taken
care of by your qualified mobility dealer.
If delivered by rail or a forwarding agent, the product is to be checked
with regard to transportation damage at once in the presence of the
shipper.
Check the contents for completeness and make sure nothing is
damaged. Should you find any irregularities or damage, please contact
our customer service (Tel.: [phone]).
We are only able to issue a guarantee if the product
is used in accordance with the specified conditions
and for the specified purpose.
3.2. Type plate and Serial number
The type plate (Fig. 1) and serial number are located on the bottom of
the frame.
Manufacturer‘s logo
Manufacturer‘s information
Caution! - Follow instructions for use
CE mark
Important! - Follow instructions for use
Model designation
Application class
Model number
Date of manufacture
Carrying capacity of the bag
Maximum load capacity
Required dimensions
EAN 13 item number
Serial number
A
B
C
D
E
F
G
H
I
J
Bischoff & Bischoff GmbH
Becker-Göring-Straße 13
D - 76307 Karlsbad
Telefon 0700 - 60007070
GB
CE Sticker & EAN Codes (Size 80 mm x 23 mm)
Rollator
EAN 13 SN
Payload of the bag: 5kg
Max. user weight: 136kg
Angle of push handles max.: 0°
Max. height of push handles: 945mm
Max. width: 630mm
Model: RL- Smart - platin Indoor and Outdoor
2017-03
Model no.: 4026
A B C
F
I
J
G H
1
E
K
K
L
MN
L
M
N
D

Bischoff & Bischoff GmbH | 16.10.2017
EN
98
RL-SMART | Lightweight rollator Lightweight rollator | RL-SMART
3.3. Contents
After receiving the goods, please check the contents for completeness
right away. The content consists of:
• Outer package
• Rollator pre-assembled
• Instruction manual
3.4. Summary
Product overview RL-Smart (Fig. 2):
2
Handle
Brake with locking device
Backrest
Handle bar
Seat
Bag
Locking mechanism
Walking stick holder
(optional)
Steering wheel
Running wheel
4. Assembly/adjustments
4.1. Unfolding
• Position the B+B Rollator in front of you in the direction of travel.
• Apply the parking brakes.
• To unfold the rollator, push the frame of the sit downwards (Fig. 3).
Make sure that the frame is laid out correctly and that it clicks into
place.
4.2. Folding up
• Apply the parking brakes.
• Hold the rollator firmly with one hand on the handle. With the
other hand, pull the strap on the seat upwards (Fig. 4).
• You need to push past the resistance of the locking mechanism.
4.3. Installing the functional bag
• The B+B Rollator is unfolded. Apply the parking brakes.
• Position yourself with your back towards the direction of travel in
front of the B+B Rollator.
• Pull the straps of the bag over the handle and slide these under the
pins (Fig. 5).
4.4. Adjusting the handles
• The B+B Rollator is unfolded. Apply the parking brakes.
• Loosen the nut (Fig. 6) and remove the fixation screw.
• Stand behind the B+B Rollator and allow your arms to hang loosely
down.
• Now insert the handles so they are at the height of your wrists.
• Secure the screw and tighten the nut.
3
4
5
6

Bischoff & Bischoff GmbH | 16.10.2017
EN
1110
RL-SMART | Lightweight rollator Lightweight rollator | RL-SMART
• Repeat the process for the other side. Make sure that both handles
are at the same height.
4.5. Brake application and
adjustment
Service brake
The service brake is operated by both hand brake levers on the
handles by pulling upwards (Fig. 7). Service and parking brakes
affect the running wheels.
Parking brake
• To lock, push both brake levers downwards (Fig. 8).
• To release, pull both brake levers back to the central position.
Brake adjustment
The brake is set properly, if the brake pins do not touch the wheel and
the locking brake can be activated easily.
• To adjust the brake to make it harder, unscrew the knurled-screw
(Fig.8) on the braking mechanism and lock it with the other nut.
• With the adjusting of the Bowden cable (M6), loosen the locknut
first.
• Next the threaded sleeve is adjusted until the correct adjustment is
found. To prevent the setting from changing, the threaded sleeve
(M6) must be locked with the nut (M6).
• To adjust the brake to make it softer, follow the above procedure in
reverse.
4.6. Wheels and tyres
Your rollator is fitted with puncture resistant PU wheels with
sizes 190 x 43 mm at the front and 170 x 43 mm at the back.
7
8
9
5. Use
Walking
Make your first attempts to walk with the rollator on a flat, firm surface.
Familiarise yourself with the function of the brakes. Let someone
accompany you during this initial period.
For an anatomically correct gait, the push handles must be set at
proper height (see sec. 4.4).
• Place yourself in the rollator so that your ankles are at the height of
the rear wheels.
• Stand with good posture.
• Grasp the push handles with both hands and your arms bent at a
slight angle.
When walking with the rollator try to stay as close as possible with
the body to the push handles. This increases the stability and safety
against tipping over; in addition, avoid a crooked back. Try to generally
walk in the rollator and not behind it. Take small steps and do not push
the rollator too far ahead.
You can determine the change of direction and speed by pushing
the rollator. Always use the brakes to slow down your movement. The
rollator could otherwise turn with the unbraked wheel and the braked
wheel, and could fall over.
Go around obstacles whenever possible. Try to use ramps or take lifts. If
this is not possible, the rollator must be carried over the obstacle. Find
a second person to help you do this, if possible
.

Bischoff & Bischoff GmbH | 16.10.2017
EN
1312
RL-SMART | Lightweight rollator Lightweight rollator | RL-SMART
6. Technical data
Type: Lightweight rollator
Colour: 4026 platin / 4027 metallic blue
Height: 790 - 920 mm
Length: 740 mm
Width: 630 mm
Width between the handles: 490 mm
Width of the handles: 30 mm
Seat height: 540 mm
Seat width: 450 mm
Folded: 240 mm
Turning circle: 865 mm
Weight: 6,72 kg
Max. capacity: 136 kg
Max. load of bag: 5 kg
• Complete with walking stick holder and bag.
• Anatomically shaped handles.
• Integrated service and parking brakes.
• Stable aluminium construction, corrosion-proof coating.
• Safe turning handles, adjustable to 830 - 960 mm.
7. Maintenance tips for users
7.1.Cleaning and disinfection
• The frame and the paneling of the wheelchair can be cleaned with
a moist cloth. You can use a mild detergent for more stubborn dirt.
• The wheels can be cleaned with a wet synthetic fiber brush (do not
use a wire brush!)
• Push handles, arm pads and seat pads can be washed off. Use a
mild detergent.
• Use a disinfectant listed by VAH for disinfection..
7.2. Rollator check by the user
7.2.1. Brake Inspection
Make sure your brakes are operating properly before each use.
It should not be possible to push the rollator away while the brakes
are activated.
The rollator should be easy to drive without grinding noises and with
good direction stability when the brakes are released.
If you notice unusual behaviour when braking, inform your qualified
mobility dealer immediately and do not use the rollator.

Bischoff & Bischoff GmbH | 16.10.2017
EN
1514
RL-SMART | Lightweight rollator Lightweight rollator | RL-SMART
7.2.2. Checking the tyres
Check whether the tyres are intact every time before driving.
If the tyre is damaged, it must be repaired by an authorised dealer.
8. Maintenance tips for retailers
We recommend that the brakes of the rollator be inspected by the
mobility dealer every six months.
If faults or defects at the rollator are found, it must be returned to the
dealer for repair immediately.
The dealer can receive the required information and documentation for
repair and service on request. A training program is also available for
dealers.
B+B customer service is available at +49 (0)700/60007070.
The rollator must be inspected in accordance to the
service plan and must be in good condition.
9. Storage/shipping
In the event that the rollator will be stored or shipped, it is advised to
keep the original packaging to store in it for this purpose, so that it is
on hand if necessary. Then your rollator can be optimally protected
against environmental influences during storage or transport.
10. Re-use
The rollator is suitable for re-use. For re-use, the rollator should
firstly be thoroughly cleaned and disinfected in accordance with the
enclosed care and cleaning instructions. Finally, the product should
be professionally checked for general condition, wear and tear and
damage and if necessary, repaired by an authorised specialist..
11. Repairs
Repairs and maintenance measures are only permitted to be carried
out by authorised partners (medical houses or specialist suppliers).
For a partner near you, please call our customer service team:
Tel.: +49(0)700 / 6000 7070.

Bischoff & Bischoff GmbH | 16.10.2017
EN
1716
RL-SMART | Lightweight rollator Lightweight rollator | RL-SMART
12. Disposal
A worn out rollator has a valuable source of material, which can be
recycled into the industrial cycle. Therefore, do not throw your rollator
away with household waste, but allow it to be professionally disposed of
by a state approved disposal department. Your local rubbish collection
will have information regarding this. The environment will thank you.
If you wish to dispose the rollator yourself, please
contact a local recycling company for the disposal
regulations of your local jurisdiction.
13. Warranty certificate
Guarantees refer to all faults of the product that are attributed
to material of manufacturing faults. In the event of complaints, the
complete, filled in warranty certificate shall be submitted.
Warning! Non-observance of the instruction
manual, improper maintenance and in particular
any technical changes and supplements (added
fittings) without the approval of B+B will generally
lead to forfeiture of warranty and product liability
claims.
Our products come with a statutory guarantee of 2 years. For
replacement devices and repairs, a warranty period of 1 year applies.
Please also observe the B+B care, warranty, hygiene and maintenance
instructions. Your qualified mobility dealer will be happy to provide
these to you.

Bischoff & Bischoff GmbH | 16.10.2017
EN
1918
RL-SMART | Lightweight rollator Lightweight rollator | RL-SMART
Notes
Warranty-Certificate
Product: RL-Smart
Model number:
Serial number:*
* (to be filled in by authorized retailer)
Specialist retailer:
Date and stamp
(Please note our general business terms and conditions)
*The serial number is located on the side frame.
Tip!
In spite of careful research and editing, incorrect information
may have crept into our operating manuals.
The current version of each of the operating manuals can be found
in the download area of our website: www.bischoff-bischoff.com

Bischoff & Bischoff GmbH
Becker-Göring-Straße 13
D-76307 Karlsbad
www.bischoff-bischoff.com
