Bischoff & Bischoff Rollator B User manual

Enjoy mobility.
Bedienungsanleitung
Enjoy mobility.
Instruction Manual
Rollator B
Rollator B XXL

Bischoff & Bischoff GmbH | 08.08.2017
EN
32
Rollator B / B XXL | Rollator Rollator | Rollator B / B XXL|
5. Use 13
6. Technical data 14
7. Maintenance tips for users 16
7.1. Cleaning and disinfection 16
7.2. Rollator check by the user 16
7.2.1. Brake Inspection 16
7.2.2. Checking the tyres 17
8. Maintenance tips for retailers 17
9. Storage/shipping 17
10. Transfering the rollator 18
11. Disposal 18
12. Warranty 19
Index
1. Introduction 4
1.1. Signs and symbols 4
2. Important safety Instructions 5
2.1. General safety instructions 5
2.2. Indications / Contraindications 5
2.3. Purpose 6
2.4. Declaration of conformity 6
2.5. Resposibility 6
2.6. Service life 6
3. Description of product and contents 7
3.1. Inspection on delivery 7
3.2. Contents 7
3.3. Type plate and serial number 8
3.4. Summary 9
4. Assembly/adjustments 10
4.1. Fitting push handles 10
4.2. Unfolding 10
4.3. Folding 10
4.4. Attach basket and tray 11
4.5. Adjusting the push handles 11
4.6. Adjusting / activating the brakes 12
4.7. Wheels and tyres 12

Bischoff & Bischoff GmbH | 08.08.2017
EN
54
Rollator B / B XXL | Rollator Rollator | Rollator B / B XXL|
Important! This is especially useful information on
a given subject.
Warning! These are especially safety-relevant
instructions. Follow the directions in the manual!
1. Introduction
Dear user,
By purchasing a B+B rollator, Rollators B / B XXL you are now the
owner of a top-quality German product that is setting new standards
in terms of its variability. This instruction manual is intended to help
you become more familiar with the operation and use of the rollator.
Please read and follow the instruction manual carefully before using
your new rollator for the first time. The instruction manual is an integral
and necessary component of the product. Keep the instruction manual
where you can refer to it, and if you transfer the rollator to another user,
please provide the manual to the new owner.
For visually impaired users, this document is available as a PDF file at
our website www.bischoff-bischoff.com.
Any repairs and adjustments require special technical training and may
therefore only be carried out by authorized B+B dealers.
1.1. Signs and symbols
2. Important safety Instructions
2.1. General safety instructions
• Max. load of B: 120 kg
• Max load of B XXL: 200 kg
• Pinch risk! Be careful when folding up and unfolding the rollator.
Make sure that clothing and body parts are not pinched between
the folding parts of the rollator.
• Observe the minimum insertion depth of the handholds.
• Each brake affects only one wheel.
• The basket can carry a weight of max. 5 kg.
• Do not use aggressive or caustic detergents to clean the rollator!
• Check that the rollator is fully intact each time before using it.
Check that the brake is working.
• Have your mobility dealer check the brakes every six months!
• The surfaces of the rollator can heat up when exposed to direct
sunlight. There is a risk of injury.
2.2. Indications / Contraindications
• The rollator supports mobility-impaired users to walk, e.g. at home,
for shopping or walking outdoors.
• The seat allows the user to rest during longer periods of use.
• Only use the rollator on a level and firm surface.
• The rollator may not be used as an aid for climbing or for
transportation of heavy loads.

Bischoff & Bischoff GmbH | 08.08.2017
EN
76
Rollator B / B XXL | Rollator Rollator | Rollator B / B XXL|
2.3. Purpose
The rollator is intended to support mobility of persons with an impaired
ability to walk, in accordance with the above-mentioned indications.
Please note:
We are only able to issue a guarantee if the product is used in
accordance with the specified conditions and for the specified purpose.
2.4. Declaration of conformity
B+B, as manufacturer and solely responsible party, hereby declares
that the rollator B / B XXL complies with the requirements of the EC
Directive 93/42.
2.5. Resposibility
We are only able to provide a warranty if the product is used in
accordance with the specified conditions and for the intended purposes.
If modifications, repairs or maintenance works are made, please make
sure only authorised persons perform these works in accordance to the
instructions of B+B.
2.6. Service life
If used as intended, and the safety, care and maintenance instructions
are observed, the expected service life is up to 5 years. Beyond this time
the rollator can be used continuously, provided it is in a safe condition.
3. Description of product and
contents
3.1. Inspection on delivery
All B+B rollators are subject to a proper final inspection in our house
and receive the CE mark.
The rollator is supplied in a special box. After unpacking please save
the box if possible. You may need it later for storage or to return the
product.
Assembly, adjustment to your body size and first instructions are taken
care of by your qualified mobility dealer.
If delivered by rail or a forwarding agent, the product is to be checked
with regard to transportation damage at once in the presence of the
shipper.
Check the contents for completeness and make sure nothing is
damaged. Should you find any irregularities or damage, please contact
our customer service (Tel.: [phone]).
3.2.Contents
After receiving the goods, please check the contents for completeness
right away. The content consists of:
• Outer package
• Rollator pre-assembled
• Instruction manual
• Basket
• Tray

Bischoff & Bischoff GmbH | 08.08.2017
EN
98
Rollator B / B XXL | Rollator Rollator | Rollator B / B XXL|
3.3.Type plate and serial number
The type plate (Fig. 1) and serial number are located on the bottom of
Manufacturer‘s logo
Manufacturer‘s information
Caution! - Follow instructions for use
CE mark
Important! - Follow instructions for use
Model designation
Application class
Model number
Date of manufacture
Carrying capacity of the basket
Maximum load capacity
Required dimensions
EAN 13 item number
Serial number
A
B
C
D
E
F
G
H
I
J
Bischoff & Bischoff GmbH
Becker-Göring-Straße 13
D - 76307 Karlsbad
Telefon 0700 - 60007070
GB
CE Sticker & EAN Codes (Size 80 mm x 23 mm)
Rollator
EAN 13 SN
Payload of the basket: 5kg
Max. user weight: 200kg
Angle of push handles max.: 0°
Max. height of push handles: 940mm
Max. width: 705mm
Model: Rollator B XXL Indoor and Outdoor Rollator
2017-04
Model no.: 4002
AB C
F
I
J
G
1
E
K
the frame.
3.4.Summary
Product overview Rollator B (Fig 2) and Rollator B XXL (Fig. 3):
K
L
MN
L
M
N
D
H
3
2
Rollator B XXL
Rollator B
Handles
Tray
Seat
Basket
Steered wheel
Fixed wheel
Brakes with locking device
Tray
Cane holder

Bischoff & Bischoff GmbH | 08.08.2017
EN
1110
Rollator B / B XXL | Rollator Rollator | Rollator B / B XXL|
4. Assembly/adjustments
4.1. Fitting push handles
• Remove the marked protective sleeves from the tube (Fig 4).
• Insert the push handles into the handlholds and fix them using the
wing screw.
• Please observe the minimum insertion depth (knurled area)
(section 4.5).
4.2.Unfolding
• Position the rollator in the travel direction.
• Release the locking brakes (see sec. 4.5).
• Tip the B+B rollator towards yourself until the load is taken off the
steered wheels and press the handles downwards at the same time
with a gentle jolt.
• To lock the folding mechanism, now fold the seat plate tight to
your seat (Fig. 4). This locks the rollator.
4.3.Folding
• Position the rollator in the travel direction.
• Activate the locking brakes.
Note that the rollator may suddenly fold up when
the lever is activated.
• Hold the rollator firmly with both hands and tilt it by pulling it
towards you.
• For unlocking, take one hand off the handle and use it to activate
the lever of the auto-lock system (Fig. 7). Ensure that neither body
parts nor pieces of clothing become pinched during the folding
process.
• To fold the rollator up completely, pull the handles towards you.
4.4.Attach basket and tray
• The rollator is unfolded. Activate the locking brakes.
• Position yourself against the travel direction in front of the rollator.
• Simply hang the basket onto the hooks attached to the front frame
tubes (Fig. 8)
• To remove the basket, simply grasp the carrying handle and pull it
up and off.
• Place the tray onto the seat from above in such a way that the four
plastic pins of the tray fit into the holes of the seat (Fig. 9).
4.5.Adjusting the push handles
• The rollator is unfolded. Activate the locking brakes.
• Turn the plastic lever on the handholds until the handles move
freely (Fig. 10).
• Position yourself behind the B+B rollator and allow your arms to
hang loosely downwards.
• Now adjust the push handles so that they are located at the height
of your wrists. Select the nearest hole in the push tube.
• Retighten the plastic lever after the adjustment procedure. Observe
the minimum insertion depth. (knurled area)
• Repeat this procedure on the other side.
• Check to make sure that both the push handles are at the same
height.
4
5
7
6
8
9
10
11

Bischoff & Bischoff GmbH | 08.08.2017
EN
1312
Rollator B / B XXL | Rollator Rollator | Rollator B / B XXL|
• The push handles may be turned a maximum of 45° outwards.
4.6.Adjusting / activating the brakes
Service brake
To activate the service brake, pull both handbrake levers upward on
the push handles upward (Fig. 12). Service and locking brake act on
the fixed wheels.
Locking brake
• Press down on both brake levers to activate the locking device
(Fig. 13).
• To release the locking brake pull both brake levers back into middle
position (Fig 14).
Adjusting the brakes
We recommend adjusting the brakes together with your mobility
dealer. If you have the necessary technical knowledge, you can do this
yourself as well.
The brake is set properly, if the brake pins do not touch the wheel and
the locking brake can be activated easily.
• Loosen the locknut (Fig. 15, arrow) so the adjustment nut can turn.
• Now turn the wide adjustment nut further inwards or outwards to
increase or decrease the braking effect.
• Retighten the locknut.
• Repeat the procedure on the other brake if necessary.
4.7.Wheels and tyres
Your rollator is equipped with flat-proof PU wheels 192 x 48 mm.
5. Use
Walking
Make your first attempts to walk with the rollator on a flat, firm surface.
Familiarise yourself with the function of the brakes. Let someone
accompany you during this initial period.
For an anatomically correct gait, the push handles must be set at
proper height (see sec. 4.4.).
• Place yourself in the rollator so that your ankles are at the height of
the rear wheels.
• Stand with good posture.
• Grasp the push handles with both hands and your arms bent at a
slight angle.
When walking with the rollator try to stay as close as possible with
the body to the push handles. This increases the stability and safety
against tipping over; in addition, avoid a crooked back. Try to generally
walk in the rollator and not behind it. Take small steps and do not push
the rollator too far ahead.
You can determine the change of direction and speed by pushing
the rollator. Always use the brakes to slow down your movement. The
rollator could otherwise turn with the unbraked wheel and the braked
wheel, and could fall over.
Go around obstacles whenever possible. Try to use ramps or take lifts. If
this is not possible, the rollator must be carried over the obstacle. Find
a second person to help you do this, if possible.
The seat
The rollator is also designed to be used as a seat by the user for short
breaks. It is therefore equipped with a seating area. You must absolutely
activate the locking brakes before sitting down. The rollator could roll
12
13
14
15

Bischoff & Bischoff GmbH | 08.08.2017
EN
1514
Rollator B / B XXL | Rollator Rollator | Rollator B / B XXL|
away and you could fall.
Lifting points
You can lift the rollator on the grips or frame sections, in order to carry
it over obstacles or steps.
6. Technical data
Dimensions and weights
Type: Rollator
Colour: Silver
Model: 4003*, 4002**
Height (push handle height): max. 940 mm
Length: 710 mm*, 720 mm**
Folded: 250 mm*, 240 mm**
Width: 600 mm*, 705 mm**
Width between handles: 445 mm
Width of handles: 60 mm
Angle of push handles max.: 0°
Seat height: 610 mm*, 630 mm**
Seat width: 380 mm*, 490 mm**
Effective seat width: 420 mm*, 550 mm**
Turning radius: 1360 mm*, 1290 mm**
Weight: 10,1 kg* , 12,1 kg**
including basket and tray
Max. load: 120 kg*, 200 kg**
Max. load of bag: 5 kg
Tyres
Rear wheels: 192 x 48 mm
Steered wheels: 192 x 48 mm
Material
Frame: steel, corrosion-resistant coating
Handles: PP
Seat: PU
Flammability: flame-retardant
Operating conditions
Temperature: 0 to 50°C
Air humidity: 45 to 60%
Storage conditions
Temperature: -20 to + 60°C
Air humidity: 45 to 80%
• Including basket, tray and cane holder
• Anatomically shaped handles
• Combined operating and locking brake
• Stable steel design, corrosion-resistant coating
• Non-rotating handholds
Standard equipment for: *Rollator B/ **Rollator B / XXL

Bischoff & Bischoff GmbH | 08.08.2017
EN
1716
Rollator B / B XXL | Rollator Rollator | Rollator B / B XXL|
7. Maintenance tips for users
7.1. Cleaning and disinfection
• The frame and the paneling of the wheelchair can be cleaned with
a moist cloth. You can use a mild detergent for more stubborn dirt.
• The wheels can be cleaned with a wet synthetic fiber brush (do not
use a wire brush!)
• Push handles, arm pads and seat pads can be washed off. Use a
mild detergent.
• Use a disinfectant listed by VAH for disinfection.
7.2.Rollator check by the user
7.2.1.Brake Inspection
Make sure your brakes are operating properly before each use.
It should not be possible to push the rollator away while the brakes
are activated.
The rollator should be easy to drive without grinding noises and with
good direction stability when the brakes are released.
If you notice unusual behaviour when braking, inform your qualified
mobility dealer immediately and do not use the rollator.
7.2.2.Checking the tyres
Check whether the tyres are intact every time before driving.
If the tyre is damaged, it must be repaired by an authorised dealer.
8. Maintenance tips for retailers
We recommend that the brakes of the rollator be inspected by the
mobility dealer every six months.
If faults or defects at the rollator are found, it must be returned to the
dealer for repair immediately.
The dealer can receive the required information and documentation for
repair and service on request. A training program is also available for
dealers.
B+B customer service is available at +49 (0)700/60007070.
9. Storage/shipping
If the rollator is to be stored or shipped,it is advisable to retain the
original packaging.
Your rollator will have an optimum protection against environmental
influences during storage and transport.

Bischoff & Bischoff GmbH | 08.08.2017
EN
1918
Rollator B / B XXL | Rollator Rollator | Rollator B / B XXL|
12. Warranty
The warranty covers all defects of the rollator that are demonstrably
due to material or manufacturing defects.
Any claim must be accompanied by the completely filled-out warranty
certificate.
Our products come with a statutory guarantee of 2 years. For
replacement devices and repairs, a warranty period of 1 year applies.
Please also observe the B+B care, warranty, hygiene and maintenance
instructions. Your qualified mobility dealer will be happy to provide
these to you.
Warning! Non-observance of the instruction
manual, improper maintenance and in particular
any technical changes and supplements (added
fittings) without the approval of B+B will generally
lead to forfeiture of warranty and product liability
claims.
10. Transfering the rollator
The rollator B / B XXL is suitable for re-use. For further use, the rollator
must first be thoroughly cleaned and disinfected in accordance with
the attached care and maintenance instructions. Subsequently the
product has to be inspected to establish its general condition and any
wear or damage by an authorised dealer and repaired if necessary.
Please also observe the B+B care, warranty, hygiene and maintenance
instructions. Your qualified mobility dealer will be happy to provide
these to you.
The rollator must be inspected in accordance to the
service plan and must be in good condition.
11. Disposal
If the rollator is no longer used and you wish to dispose it, please
contact your dealer.
If you wish to dispose the rollator yourself, please
contact a local recycling company for the disposal
regulations of your local jurisdiction.

Bischoff & Bischoff GmbH | 08.08.2017
EN
2120
Rollator B / B XXL | Rollator Rollator | Rollator B / B XXL|
Warranty-Certificate
Product: Rollator B / B XXL
Serial number:*
*(to be filled in by authorized dealer)
Dealer:
Date and stamp
(Please note our general business terms and conditions)
*The serial number is located on the side frame.
Notes

Bischoff & Bischoff GmbH | 08.08.2017
EN
2322
Rollator B / B XXL | Rollator Rollator | Rollator B / B XXL|
Notes
Note:
No liability is accepted for printing errors, product and colour
modifications, or changes to technical specifications. The colours of
the product shown may vary slightly in reality.

Bischoff & Bischoff GmbH
Becker-Göring-Straße 13
D-76307 Karlsbad
www.bischoff-bischoff.com
