Bischoff & Bischoff Rollator RL-smart User manual

Enjoy mobility.
Bischoff & Bischoff
Instruction manual
Rollator RL-s art

2
Contents
1| Declaration of Conformity 3
2| Indications / Contra-indications 3
3| Safety instructions 4
4| Unfolding 5
5| Folding up 5
6| Installing the functional bag 5
7| Adjusting the handles 5
8| Brake application and adjustment 6
9| Wheels and tyres 7
10| Technical data 7
11| Storage/shipping 8
12| Re-use 8
13| Repairs 8
14| Disposal 9
15| Attachments: 9
Care, cleaning and maintenance instructions
Cleaning + risk assessment
Maintenance plan
16| Warranty certificate 15

Bischoff & Bischoff GmbH As of 27.09.2011 3
English
Rollator
RL-smart
Rollator RL-s art
(walking aid)
2. Indic tions / Contr -indic tions
Dear customer,
by purchasing this B+B wheeled walker you have a first-class
German product that has been proven and tested thousands of
times in professional use.
This instruction manual shall make you more familiar with the
operation and handling, and thus enable safer use of your B+B
wheeled walker.
We hope you enjoy our product and the mobility it gives you!
1. Decl r tion of Conformity
B+B, as manufacturer of the product, declares that the rollator
fully meets the requirements of the guideline 93/42/EEC.
The rollator supports users with limited mobility to move, e.g.
for domestic use, when shopping or walking outdoors.
The seat area allows a place to rest during longer distances.
The rollator must be used on level and solid ground only.
The product must not be used as a climbing aid or means of
transport for heavy loads.

3. S fety instructions
• Max. capacity Rollator R -smart 136 kg
• Please note there is a danger of trapping fingers and/or
clothing when folding and unfolding. Do not catch any
clothing or body parts between the moving parts.
• Please note the minimum insertion depth of the handles
bars!
• Each brake only affects one running wheel!
• The bag can be loaded with max. 5 kg.
• When cleaning, do not use any aggressive or corrosive
cleaning agents!
• Check the rollator for correct assembly before every use. The
brake operation should be checked.
• Brakes should be checked every 6 months by a specialist!
• The surfaces of the rollator can heat up when in direct expo
sure with the sun. This may result in injury.
4
Handle
Brake with locking de-
vice
Backrest
Handle bar
Seat
ocking lever
Functional bag
Walking stick holder
Steering wheel
Running wheel
Fig. 1

Bischoff & Bischoff GmbH As of 27.09.2011 5
English
Rollator
RL-smart
Fig. 2
Fig. 3
Fig. 4
Fig. 5
4. Unfolding
Position the B+B Rollator in front of you in the direction of travel.
• Apply the parking brakes.
• To unfold the rollator, push the frame of the sit downwards
(Fig. 2). Make sure that the frame is laid out correctly and that it
clicks into place.
5. Folding up
• Apply the parking brakes.
• Hold the rollator firmly with one hand on the handle. With
the other hand, pull the strap on the seat upwards (Fig. 3).
• You need to push past the resistance of the locking mecha-
nism.
6. Inst lling the function l
b g
• The B+B Rollator is unfolded. Apply the parking brakes.
• Position yourself with your back towards the direction of
travel in front of the B+B Rollator.
• The functional bag can be attached with straps onto the
frame of the seat (Fig. 4).
• Finally, the bag needs to be attached underneath by the two
Velcro fasteners onto the frame (Fig. 4).
7. Adjusting the h ndles
• The B+B Rollator is unfolded.
• Apply the parking brakes.
• oosen the nut (Fig. 5) and remove the fixation screw.
• Stand behind the B+B Rollator and allow your arms to hang
loosely down

• Now insert the handles so they are at the height of your
wrists.
• Secure the screw and tighten the nut.
• Repeat the process for the other side. Make sure that both
handles are at the same height.
8. Br ke pplic tion nd d-
justment
Service brake
The service brake is operated by both hand brake levers on the
handles by pulling upwards (Fig. 6). Service and parking brakes
affect the running wheels.
Parking brake
• To lock, push both brake levers downwards (Fig. 7).
• To release, pull both brake levers back to the central
position.
Brake adjust ent
The brakes can be adjusted directly at the brake lever. The bra-
kes are correctly adjusted when the brake pins do not touch
the running wheel when the brakes are not pressed and the
parking brake is still comfortable to operate.
• To adjust the brake to make it harder, unscrew the knurled--
screw (Fig. 8) on the braking mechanism and lock it with the
other nut.
• With the adjusting of the Bowden cable (M6), loosen the
locknut first.
• Next the threaded sleeve is adjusted until the correct adjust-
ment is found. To prevent the setting from changing, the
threaded sleeve (M6) must be locked with the nut (M6).
• To adjust the brake to make it softer, follow the above proce-
dure in reverse.
6
Fig. 6
Fig. 7
Fig. 8

Bischoff & Bischoff GmbH As of 27.09.2011 7
English
Rollator
RL-smart
9. Wheels nd tyres
Your rollator is fitted with puncture resistant PU wheels with
sizes 190 x 43 mm at the front and 170 x 43 mm at the back.
10. Technic l d t
Type: Rollator R -smart
Colour: 4026 platin
4027 metallic blue
Height: 79 - 92 cm
ength: 74 cm
Width: 63 cm
Width: 49 cm
(between the handles)
Width of the handles: 3 cm
Seat height 54 cm
Seat width 45 cm
Folded 24 cm
Turning circle 86,5 cm
Weight 6.72 kg
Max. capacity 136 kg
• Complete with walking stick holder and bag.
• Anatomically shaped handles.
• Integrated service and parking brakes.
• Stable aluminium construction, corrosion-proof coating.
•Safe turning handles, adjustable to 83 - 96 cm.

8
11. Stor ge/shipping
In the event that the rollator will be stored or shipped, it is
advised to keep the original packaging to store in it for
this purpose, so that it is on hand if necessary. Then your
rollator can be optimally protected against environmental
influences during storage or transport.
12. Re-use
The rollator is suitable for re-use. For re-use, the rollator
should firstly be thoroughly cleaned and disinfected in ac-
cordance with the enclosed care and cleaning instructions.
Finally, the product should be professionally checked for
general condition, wear and tear and damage and if neces-
sary, repaired by an authorised specialist.
13. Rep irs
Repairs and maintenance measures are only permitted to
be carried out by authorised partners (medical houses or
specialist suppliers). For a partner near you, please call our
customer service team:
Tel.: +49(0)700 / 6000 7070.

Bischoff & Bischoff GmbH As of 27.09.2011 9
English
Rollator
RL-smart
14. Dispos l
A worn out Rollator has a valuable source of material,
which can be recycled into the industrial cycle. Therefore,
do not throw your Rollator away with household waste,
but allow it to be professionally disposed of by a state ap-
proved disposal department. Your local rubbish collection
will have information regarding this. The environment will
thank you.
15. Att chments
Product life
The expected product life of the rollator amounts up to 5
years if used as intended and in compliance with the
safety, care and maintenance instructions. Over this period
and beyond, the rollator can be used if the product is in a
safe condition.
C re, cle ning nd m inten nce in-
structions for the Bischoff & Bi-
schoff instruction m nu l
As of 13.01.2011
Just as with all technical products, the Rollator R -smart
should also undergo regular checking or maintenance by
authorised specialists. First and foremost, these tests
should guarantee the safety of the users. In addition,
through regular care of the product, faultless operation
should also be guaranteed after extended use. We have
devised the following care tips and cleaning plan, as well
as maintenance table for you. We hope to have provided
you with a good overview of the most important care,
cleaning and maintenance work for your Bischoff & Bi-
schoff product

10
) C re instructions
Cleaning can be carried out with warm water and with the
aid of a sponge. With more stubborn dirt, a commercially
available cleaning agent can be added to the water. Note:
Under no circumstances should aggressive cleaning pro-
ducts, such as solvents / abrasives or hard brushes be used.
Plastic parts are best cleaned with a commercially available
plastic cleaning agent. Please note the product information
of the cleaning agent.

Bischoff & Bischoff GmbH As of 27.09.2011 11
English
Rollator
RL-smart
Cle ning pl n nd risk ssess-
ment of B+B medic l products
before tre tment.
1. Product
walking aid
2. Risk cl ssific tion
Uncritical medical device
Medical device, which only comes into contact with intact skin
3. Frequency of cle ning
At the latest, after every change of user
4. N ture of the process
Scrubbing and wiping disinfection method
With one of the products from the Association for Applied Hy-
giene (VAH). Bischoff & Bischoff GmbH recommends Kohrsolin FF
from the company Bode Chemie
5. Pre-tre tment of the product
Visible dirt should be removed with a cloth soaked in a disinfec-
ting agent
6. Disinfection
1. Put on protective gloves before treating the product
2. Disinfect the areas to be treated sufficiently and whilst wet,
wipe off by applying slight pressure (do not rub dry)
3. Allow the treated areas to air dry
4. Dispose of protective gloves and paper towels
7. Specific l belling
Not required
8. Sterilis tion
Not required
9. Critic l process steps, speci l requi-
rements
Not required

12
M inten nce t ble
Before each use
When Wh t
Performance test of the braking system
Press the brakes to a stop. In normal use, when the brakes
are applied, the wheels must no longer rotate.
Wear test of the pressure brake
Move the brake lever sideways. Secure locking of all
screws.
Testing of the tyre tread
Every 4 weeks (depending on
the frequency of use)
Oil the moving parts
• All centres of rotation of the cross bracing
• Braking lever bearings
Checking the screws are tight
AEvery 6 months (depending
on the frequency of use)
Tests
• Cleanliness
• General condition
• Brakes

Bischoff & Bischoff GmbH As of 27.09.2011 13
English
Rollator
RL-smart
Ple se note
Carrying out of the test by the user or an assistant.
In the event of faulty brakes, repairs should be carried out
by an authorised specialist workshop.
Carrying out of the test by the user or an assistant. In the
event of large slackness of the braking lever, the brake re-
pair should be carried out by an authorised specialist
workshop.
Visual inspection by the user. In the event of worn tyre
tread or tyre damage, repairs should be carried out by an
authorised specialist workshop.
Carrying out by the user or helper. Before oiling the parts,
clear these of used oil. Remove excess oil.
Carrying out of the test by the user or an assistant.
Please follow the care and cleaning instructions. In the
event of any possible faults, please only employ authori-
sed specialist workshops to carry out the necessary repair
work because only these are briefed on the carrying out
of necessary work and as a rule, have sufficiently trained
staff.
The brakes should be tested every 6 months by a specia-
list supplier.

14
16. W rr nty certific te
Guarantees refer to all faults of the product that are attri-
buted to material of manufacturing faults.
In the event of complaints, the
complete, filled in warranty certificate shall be submitted.
For the rollator, we assume a warranty of 5 years. For all
attachment parts, we assume a warranty of 1 year.
If you have any questions, please do not hesitate to con-
tact the B+B customer service team on +49(0)700/6000
7070.

Bischoff & Bischoff GmbH As of 27.09.2011 15
English
Rollator
RL-smart
Type: B+B Rollator R -smart
Serial number:
(To be filled out by the specialist supplier)
Specialist supplier:
Date and stamp
Warranty section
(General terms and conditions apply)

Bischoff & Bischoff GmbH
Becker-Göring-Straße 13 • D-76307 Kar sbad
Te .: +49 700/60000 7070 • Fax: [phone]
www.bischoff-bischoff.com
[email protected]
