Black & Decker Speedy Roller User manual

BDPR400

2
A B
C D
E F

3
G H
I J
K L

4
M N
O P
Q R

5
S T
U V
W X

6
ENGLISH (Original instructions)
Intended use
Your Black & Decker Speedy RollerTM has been designed for
applying paint to walls and ceilings. This appliance is intended
for indoor household use only.
Safety instructions
@Warning! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions listed below may result in injury.
uRead all of this manual carefully before using the appli-
ance.
uThe intended use is described in this manual. The use of
any accessory or attachment or the performance of any
operation with this appliance other than those recom-
mended in this instruction manual may present a risk of
personal injury.
uRetain this manual for future reference.
Using your appliance
uNever put descaling, aromatic, alcoholic or detergent
products into the speedy roller, as this may damage it or
make it unsafe for use.
After use
uWhen not in use, the appliance should be stored in a dry
place.
uChildren should not have access to stored appliances.
Inspection and repairs
uBefore use, check the appliance for damaged or defective
parts. Check for breakage of parts, damage to switches
and any other conditions that may affect its operation.
uDo not use the appliance if any part is damaged or defec-
tive.
uHave any damaged or defective parts repaired or
replaced by an authorized repair agent.
uNever attempt to remove or replace any parts other than
those specied in this manual.
Safety of others
uThis appliance is not intended for use by persons (includ-
ing children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concern-
ing the use of the appliance by a person responsible for
their safety.
uChildren should be supervised to ensure that they do not
play with the appliance.
Residual risks.
Additional residual risks may arise when using the tool which
may not be included in the enclosed safety warnings. These
risks can arise from misuse, prolonged use etc.
Even with the application of the relevant safety regulations
and the implementation of safety devices, certain residual
risks can not be avoided. These include:
uInjuries caused by touching any moving parts.
uInjuries caused when changing any parts or accessories.
uInjuries caused by prolonged use of the appliance. When
using any appliance for prolonged periods ensure you
take regular breaks.
Labels on the appliance
The following pictograms are shown on the tool:
:Warning! To reduce the risk of injury, the user
must read the instruction manual.
&Warning! Only use non-amable liquids.
Warning! Keep bystanders away.
6Warning! Wear a dust mask.
OWarning! Wear safety glasses.
Features
This appliance includes some or all of the following features.
1. Plunger
2. Trigger
3. Paint resevior
4. Kick stand
5. Fill valve
6. Head rotation button
7. Roller head
8. Roller
9. Drip tray
Assembly
Attaching the handle (g. A)
uSlide the handle (10) into the paint reservoir (3) ensuring
that the orange collar (11) meets the handle (3).
uThread the orange collar (11) onto the threads of the
handle (3) and tighten.

7
ENGLISH
(Original instructions)
Attaching the roller head (g. B)
uSlide the handle assembly (12) into the roller head (7) en-
suring that the O-ring (13) is seated inside the roller head
(7) and the black collar (14) meets the roller head (7).
uThread the black collar (14) onto the threads of the roller
head (7) and tighten.
Attaching a roller to the roller head (g. C)
uLubricate the tips (15) at either end of the roller frame (16)
using petroleum jelly.
uSlide the assembled roller (8) onto the roller frame (16).
Note: Make sure the roller assembly snaps into the locking
clip on the outer end cap of the roller.
Attaching the drip tray (g. D)
The drip tray helps reduce spatter and drips when painting,
especially on ceilings.
uClip the drip tray (9) onto the roller frame (16) so that it ts
around the roller (8).
uRotate the drip tray to the required position.
Note: The drip tray is also helpful to prevent dripping when the
Speedy RollerTM is resting on the kickstand and is not in use.
Position the drip tray under the roller.
Use
Filling with paint (g. E & F)
Note: When using the Speedy RollerTM for the rst application,
it will take most of the paint in the paint reservoir to saturate
the roller cover. A second ll may be needed.
uInsert the small end of the ll tube (17) through the hole in
the bottom side of the paint can clip (18). Push gently until
it click into place.
uPlace the paint can clip (18) over the edge of your paint
can.
Note: For deeper containers, t a section of 19mm inner
diameter clear tubing over the ribs of the ll tube to extend it
and clip to side of pail with ll tube can clip. Cut the bottom
end of the tubing at a slight angle. Tubing is available at most
DIY stores.
uLubricate the top of the ll tube (17) with a small amount
of petroleum jelly.
uHold the Speedy RollerTM at a 45O angle and place the ll
valve (5) over the ll tube (17). Gently push the Speedy
RollerTM down so it completely covers the ll tube.
Note: Make sure the orange ll cap cover (19) is com-
pletely covered by the shroud of the can clip.
uVery rmly pull the plunger (1) all the way back to draw
paint into Speedy RollerTM ensuring you apply sufcient
pressure to maintain an adequate union between the ll
valve and ll tube.
uLift the Speedy RollerTM slowly off the ll tube.
Note: If you do not receive a complete ll the rst time, push
the plunger slowly to return paint to can and then pull the back
plunger making sure the angle is correct and the orange ll
cap cover is fully seated.
Adjusting the angle of the roller head (g. G & H)
The roller head can be adjusted to three different angles.
uPress and hold the orange head ratation button (6) on the
roller head (7).
uRotate the rollerhead (7) to the required angle.
Note: Use straight on for general painting and 40Oor 80O
angles for hard to reach places or when painting close to
ceiling or edging.
Note: The handle (10) can be rotated to make it more comfort-
able when painting with an angled roller frame. To rotate
handle to desired position, loosen collar (11), adjust handle
and retighten collar (g H).
Painting with the Speedy RollerTM (g. I & J)
uBegin rolling on wall and push plunger handle (1) or
squeeze trigger (2) to feed paint into the roller cover.
Note: Initial saturation of the roller may require the full amount
of paint from the rst ll. Fill Speedy RollerTM as needed.
Helpful hints
uThe trigger only needs to be squeezed when paint is
needed.
uIf you are getting a dot pattern when painting, apply more
paint.
uIf the roller is sliding on the surface, apply less paint.
uYou may notice petroleum jelly within the handle. This is
necessary and will help in its operation and will not affect
the paint.
uWhen not in use, rest the Speedy RollerTM on the kick-
stand (4) with the drip tray (9) attached and positioned
under the roller..
Returning excess paint to paint tin (g. K - M)
uPlace thumb over orange ll cap cover (19).
uPull plunger (1) back to draw excess paint from roller
frame into tube.
uHold the Speedy RollerTM at a 45O angle and place the ll
valve (5) over the ll tube (17). Gently push the Speedy
RollerTM down so it completely covers the ll tube.
Note: Make sure the orange ll cap cover (19) is com-
pletely covered by the shroud of the can clip.
uPush the plunger all of the way into the tube.
uRemove the roller (8) by grasping the outer end cap (20)
and the roller frame (16) and using your thumb on the
opposite hand to push the roller off
Note: Wear disposable gloves or use a plastic bag over roller
to keep your hands clean.

8
ENGLISH (Original instructions)
uScrape any excess paint into the tin from the roller.
uRemove the inner end cap by inserting the metal tube of
the roller frame into the cap about 2-3 centimetres and at
an angle.
uPull the roller frame gently towards you.
uRemove the roller core.
uEmpty any remaining paint.
uRemove the outer cap (20) by inserting the roller frame
into the roller and gently pushing the cap off.
Hints for optimum use
uOnly use a perforated Black & DeckerSpeedy RollerTM
roller cover (Accessory number : BDPRA09-XJ &
BDPRA18-XJ). Standard roller covers will not work.
uInspect the roller cover for lint before painting, if needed
wash and dry before using.
uWhen using the Speedy RollerTM for the rst application, it
will take most of the paint in the Speedy RollerTM tube to
saturate the roller cover. A second ll may be needed.
uKeep the roller moving while pushing the plunger in or
squeezing the trigger to prevent dripping.
uStop pushing the plunger in or squeezing trigger if the
roller starts to skid, slide or drip.
uWhen painting in tight areas partially ll the Speedy
RollerTM or pivot the frame. This reduces its overall length.
uWhen leaving the Speedy RollerTM unattended for a longer
period of time, wrap the roller in a plastic bag to prevent
drying, removing as much air as possible from bag.
uMake sure the type of paint you use can be cleaned with
either mineral spirits (for oil-based paints) or a warm water
and soap solution (for water soluble paints)
uUse suitable coverings to protect your oors and anything
else in the room that you do not want accidentally splat-
tered with paint.
uWhen using the kickstand, always pivot the head to the
straight position and release pressure by pulling the
plunger out slightly.
Maintenance and cleaning
Cleaning the Speedy RollerTM (g. O - T)
uRemove the roller sleve.
uPush the ll tube directly into the ll valve. When cleaning
water soluble paints, submerge the ll tube into warm,
soapy water and pull the plunger in and out 5 or more
times. When using oil based paints, instead of water, use
proper cleaning solvent listed on manufacturers container
and dispose of properly.
Note: Use a sink, a wash tub, or any container that will hold
water to perform above ushing process. Replace water when
dirty or when moving to the next step.
uRemove the ll tube. Then submerge the roller frame, and
ensuring the ll valve is also under water, pull the plunger
in and out 5 or more times (g. P).
Note: When using a small container, pivot the roller frame to
the 80 degree position to t inside container (g. Q).
uRemove roller frame and continue cleaning as needed.
Submerge the handle in the warm, soapy water and pull
the plunger in and out 5 or more times.
Note: Wipe off remaining paint from the end of plunger (1).
uUnthread valve cap (19) and remove wiper seal (22) and
duck bill valve (21) to clean. Rinse all remaining parts and
drain all uid from the Speedy RollerTM (g. S).
uRemove tubing from frame (if needed) by pinching hose
clamps. Flush frame and tubing. Replace tubing and
secure with hose clamps (24) (g. T).
Note:Always purchase a perforated Black & DeckerSpeedy
RollerTM roller cover (Accessory number : BDPRA09-XJ &
BDPRA18-XJ).Astandard roller will not work.
Lubricating the Speedy RollerTM (g. U - X)
Lubrication helps with normal operation and should be done
after cleaning and before each use.
uTurn the threaded assembly collar (11) near the trigger
counterclockwise until the main tube assembly slides off.
Note: When reassembling, the orange threaded collar (11)
should be towards trigger handle.
uApply petroleum jelly around and in between the rubber
seals (25). Reassemble making sure the rubber seals are
not twisted or damaged. Tighten the locking collar.
uApply petroleum jelly to the duck bill valve (21) and wiper
seal (22) and replace within unit threading the valve cap
(19) back into place.
uApply petroleum jelly to the inner seals on the end caps
(26) then assemble the roller by placing the core (27)
inside of roller cover (28) and attaching end caps and as
shown.
Protecting the environment
ZSeparate collection. This product must not be disposed of with normal household waste.
Should you nd one day that your Black & Decker product
needs replacement, or if it is of no further use to you, do not
dispose of it with household waste. Make this product avail-
able for separate collection.
zSeparate collection of used products and packaging allows materials to be recycled and used again.
Re-use of recycled materials helps prevent environ-
mental pollution and reduces the demand for raw
materials.

9
ENGLISH
(Original instructions)
Local regulations may provide for separate collection of elec-
trical products from the household, at municipal waste sites or
by the retailer when you purchase a new product.
Black & Decker provides a facility for the collection and
recycling of Black & Decker products once they have reached
the end of their working life. To take advantage of this service
please return your product to any authorised repair agent who
will collect them on our behalf.
You can check the location of your nearest authorised repair
agent by contacting your local Black & Decker ofce at
the address indicated in this manual.Alternatively, a list of
authorised Black & Decker repair agents and full details of our
after-sales service and contacts are available on the Internet
at: www.2helpU.com
Technical data
BDPR400
Capacity ml
650
Weight kg 1.4
Guarantee
Black & Decker is condent of the quality of its products and
offers an outstanding guarantee. This guarantee statement is
in addition to and in no way prejudices your statutory rights.
The guarantee is valid within the territories of the Member
States of the European Union and the European Free Trade
Area.
If a Black & Decker product becomes defective due to faulty
materials, workmanship or lack of conformity, within 24
months from the date of purchase, Black & Decker guarantees
to replace defective parts, repair products subjected to fair
wear and tear or replace such products to ensure minimum
inconvenience to the customer unless:
uThe product has been used for trade, professional or hire
purposes;
uThe product has been subjected to misuse or neglect;
uThe product has sustained damage through foreign
objects, substances or accidents;
uRepairs have been attempted by persons other than
authorised repair agents or Black & Decker service staff.
To claim on the guarantee, you will need to submit proof of
purchase to the seller or an authorised repair agent. You can
check the location of your nearest authorised repair agent
by contacting your local Black & Decker ofce at the address
indicated in this manual.Alternatively, a list of authorised
Black & Decker repair agents and full details of our after-
sales service and contacts are available on the Internet at:
www.2helpU.com
Please visit our website www.blackanddecker.co.uk to register
your new Black & Decker product and to be kept up to date
on new products and special offers. Further information on the
Black & Decker brand and our range of products is available
at www.blackanddecker.co.uk

10
(Übersetzung der ursprünglichenAnweisungen)
DEUTSCH
Bestimmungsgemäße Verwendung
Ihr Black & Decker Speedy RollerTM wurde zum Streichen von
Wänden und Decken konstruiert. Dieses Gerät darf nur im
Innenbereich verwendet werden und ist nicht für den
gewerblichen Einsatz vorgesehen.
Sicherheitshinweise
@Achtung! Lesen Sie sämtliche Sicher-
heitswarnungen und Anweisungen. Die
Nichteinhaltung der nachstehend aufgeführten
Warnungen undAnweisungen kann Verletzun-
gen verursachen.
uLesen Sie dieseAnleitung vollständig und aufmerksam
durch, bevor Sie das Gerät zum ersten Mal verwenden.
uDer vorgesehene Verwendungszweck ist in dieser Anlei-
tung beschrieben. Bei Verwendung von Zubehör oder An-
bauteilen, die nicht in dieserAnleitung empfohlen werden,
sowie bei der Verwendung des Geräts in Abweichung von
den in dieserAnleitung beschriebenen Verfahren besteht
Verletzungsgefahr.
uBewahren Sie dieseAnleitung auf.
Verwendung des Geräts
uBefüllen Sie den Speedy Roller nicht mit Entkalker, alko-
holhaltigen Stoffen sowie Duft- oder Reinigungsmitteln, da
das Gerät hierdurch beschädigt oder die Gerätesicherheit
beeinträchtigt werden kann.
Nach dem Gebrauch
uBewahren Sie das Gerät bei Nichtgebrauch an einem
trockenen Ort auf.
uKinder sollten keinen Zugang zu aufbewahrten Geräten
haben.
Inspektion und Reparaturen
uPrüfen Sie das Gerät vor der Verwendung auf beschädigte
oder defekte Teile. Prüfen Sie, ob Teile gebrochen sind,
Schalter beschädigt sind oder andere Bedingungen
vorliegen, die die Funktion beeinträchtigen könnten.
uBetreiben Sie das Gerät nicht, wenn ein Teil beschädigt
oder defekt ist.
uLassen Sie beschädigte oder defekte Teile in einer Vert-
ragswerkstatt reparieren oder austauschen.
uErsetzen oder entfernen Sie keine Teile, für die in dieser
Anleitung keine entsprechende Beschreibung enthalten
ist.
Sicherheit anderer Personen
uDieses Gerät darf nicht von Personen (einschließlich
Kindern) mit eingeschränkten körperlichen, sensorischen
oder geistigen Fähigkeiten sowie mangelnder Erfahrung
und Kenntnissen bedient werden, es sei denn, sie werden
bei der Verwendung des Geräts von einer erfahrenen
Person beaufsichtigt oder angeleitet.
uKinder müssen beaufsichtigt werden, um sicherzustellen,
dass sie nicht mit dem Gerät spielen.
Restrisiken.
Für den Gebrauch dieses Geräts verbleiben zusätzliche Re-
strisiken, die möglicherweise nicht in den Sicherheitswarnun-
gen genannt werden. Diese Risiken bestehen beispielsweise
bei Missbrauch oder längerem Gebrauch.
Auch bei der Einhaltung der entsprechenden Sicherheits-
vorschriften und der Verwendung aller Sicherheitsgeräte
bestehen weiterhin bestimmte Restrisiken. Diese werden im
Folgenden aufgeführt:
uVerletzungen, die durch das Berühren von sich bewegen-
den Teilen verursacht werden.
uVerletzungen, die durch das Austauschen von Teilen oder
Zubehör verursacht werden.
uVerletzungen, die durch längeren Gebrauch des Geräts
verursacht werden. Legen Sie bei längerem Gebrauch
regelmäßige Pausen ein.
Warnsymbole am Gerät
Am Gerät sind folgende Warnsymbole angebracht:
:Achtung! Lesen Sie vor Gebrauch die Anleitung.
Andernfalls besteht Verletzungsgefahr.
&Achtung! Verwenden Sie ausschließlich nicht
entammbare Flüssigkeiten.
KAchtung! Halten Sie andere Personen vom
Gefahrenbereich fern.
6Achtung! Tragen Sie eine Staubmaske.
OAchtung! Tragen Sie eine Schutzbrille.
Merkmale
Dieses Gerät verfügt über einige oder alle der folgenden
Merkmale:
1. Stange
2. Griffhebel
