Black Box AC650A-2 User manual

1000 Park Drive • Lawrence, PA 15055-1018 • 724-746-5500 • Fax [phone]
© Copyright 2008. Black Box Corporation. All rights reserved.

CUSTOMER
SUPPORT
INFORMATION
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax [phone]
Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: [email protected]
AUGUST 2008
AC650A-2
AC650A-4
AC650A-2-EU
AC650A-4-EU
AC650A-2-UK
AC650A-4-UK
2-Port and 4-Port Audio/Video Splitters

1
FCC AND IC RFI STATEMENTS
FEDERAL COMMUNICATIONS COMMISSION
AND
INDUSTRY CANADA
RADIO FREQUENCY INTERFERENCE STATEMENTS
This equipment generates, uses, and can radiate radio-frequency energy, and if not
installed and used properly, that is, in strict accordance with the manufacturer’s
instructions, may cause interference to radio communication. It has been tested
and found to comply with the limits for a Class A computing device in accordance
with the specifications in Subpart B of Part 15 of FCC rules, which are designed to
provide reasonable protection against such interference when the equipment is
operated in a commercial environment. Operation of this equipment in a
residential area is likely to cause interference, in which case the user at his own
expense will be required to take whatever measures may be necessary to correct
the interference.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
This digital apparatus does not exceed the Class A limits for radio noise emission from
digital apparatus set out in the Radio Interference Regulation of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites
applicables aux appareils numériques de la classe A prescrites dans le Règlement sur le
brouillage radioélectrique publié par Industrie Canada.

2
2-PORT AND 4-PORT AUDIO/VIDEO SPLITTERS
NORMAS OFICIALES MEXICANAS (NOM)
ELECTRICAL SAFETY STATEMENT
INSTRUCCIONES DE SEGURIDAD
1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de
que el aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas para
referencia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de
operación deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca
de la tina de baño, lavabo, sótano mojado o cerca de una alberca, etc..
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales que
sean recomendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea
recomendado por el fabricante.
8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá
a lo descrito en las instrucciones de operación. Todo otro servicio deberá ser
referido a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no
interfiera su uso. La colocación del aparato eléctrico sobre una cama, sofá,
alfombra o superficie similar puede bloquea la ventilación, no se debe
colocar en libreros o gabinetes que impidan el flujo de aire por los orificios
de ventilación.
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor
como radiadores, registros de calor, estufas u otros aparatos (incluyendo
amplificadores) que producen calor.
11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del
tipo descrito en el instructivo de operación, o como se indique en el aparato.

3
NOM STATEMENT
12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización
del equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que no
sean pisados ni pellizcados por objetos colocados sobre o contra ellos,
poniendo particular atención a los contactos y receptáculos donde salen del
aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las
recomendaciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las lineas
de energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no sea
usado por un largo periodo de tiempo.
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean
derramados sobre la cubierta u orificios de ventilación.
18. Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en su
desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.

4
2-PORT AND 4-PORT AUDIO/VIDEO SPLITTERS
TRADEMARKS USED IN THIS MANUAL
BLACK BOX and the Double Diamond logo are registered trademarks of
BB Technologies, Inc.
Any other trademarks mentioned in this manual are acknowledged to be the property of the
trademark owners.

5
Contents
Chapter Page
1. Specifications ....................................................................................................6
2. Overview ............................................................................................................7
2.1 Introduction.......................................................................................... 7
2.2 Front Panel............................................................................................ 7
2.3 Back Panel..............................................................................................8
3. Installation.......................................................................................................10
3.1 Basic Installation................................................................................. 10
3.2 Cascaded Installation ..........................................................................11
3.3 Supported Resolutions/Distances..................................................... 12
4. Troubleshooting............................................................................................. 13
4.1 Calling Black Box.................................................................................13
4.2 Shipping and Packaging .....................................................................13
CONTENTS

6
2-PORT AND 4-PORT AUDIO/VIDEO SPLITTERS
1. Specifications
Distance (Maximum): 213.2 ft. (65 m)
Input/Output Signals:
Pin Number Signal
1 Red video
2 Green video
3 Blue video
4 ID2
5, 10 Ground
6, 7, 8 Analog Ground
9 Not connected
11 ID0
12 ID1
13 Horizontal sync
14 Vertical sync
15 ID3
Pixel Frequency: 400 MHz
Resolution (Maximum): 2048 x 1536 at 60 Hz
CE Approval: Yes
Connectors: Video input: Both: (1) HD15 F;
Video output: AC650A-2: (2) HD15 F;
AC650A-4: (4) HD15 F;
Audio input: Both: (1) 3.5-mm stereo F;
Audio output: AC650A-2: (2) 3.5-mm stereo F;
AC650A-4: (4) HD15 F; (4) 3.5-mm stereo F
Power: AC650A-2, AC650A-4: Input: 120-VAC, 60 Hz;
Output: 7.5 VAC, 800 mA;
AC650A-2-EU, AC650A-4-EU, AC650A-2-UK, AC650A-4-UK:
Input: 240 VAC, 60 Hz;
Output: 7.5 VAC, 800 mA
Size: AC650A-2: 1.7"H x 5.1"W x 3"D (4.3 x 13 x 7.6 cm);
AC650A-4: 1.7"H x 13.5"W x 4.1"D (4.3 x 34.3 x 10.4 cm)
Weight: AC650A-2: 0.9 lb. (0.4 kg); AC650A-4: 1.5 lb. (0.7 kg)

7
2. Overview
2.1 Introduction
With the 2-Port and 4-Port Audio/Video Splitters, you can transmit audio and video
signals from one PC to two or four monitors and headphones located up to 213.2
feet (65 m) away at a maximum resolution of 640 x 480, or up to 32 feet (10 m)
away with a maximum resolution of 2048 x 1536. Use the splitters in test bench
facilities, data centers, help desks, and video broadcasting applications
(presentations, stock quotes, timetables, schools).
You can cascade the splitters up to two levels. Link up to three monitors and
headphones to the source PC using the AC650A-2 or connect up to seven monitors
and headphones to the source PC using the AC650A-4.
The splitters have easy-to-use front-panel select switches and support the VESA
DDC, DDC2, DDC2B standards (for video out Port 1).
Plus, the splitters are compatible with a broad range of video interfaces, including
VGA, SVGA, XGA, UXGA, QXGA, and multisync.
2.2 Front Panel
The front panels of the 2- and 4-port splitters are shown in Figures 2-1 and 2-2.
Table 2-1 describes the components.
Figure 2-1. Front panel: 2-port splitter.
CHAPTER 2: Overview
1

8
2-PORT AND 4-PORT AUDIO/VIDEO SPLITTERS
Figure 2-2. Front panel: 4-port splitter.
Table 2-1. Front panel components.
Number Component Description
1 Power LED Lights when power is on
2.3 Back Panel
The back panels of the 2- and 4-port splitters are shown in Figures 2-3 and 2-4.
Table 2-2 describes the components.
Figure 2-3. Back panel: 2-port splitter.
23
5
4
6
1

9
Figure 2-4. Back panel: 4-port splitter.
Table 2-2. Back panel components.
Number Component Description
2 Power input receptacle Plug in the included 7.5 VAC,
800 mA power adapter
3 HD15 F connector Video in port
4 HD15F connector Video out ports
5 3.5-mm stereo F Audio in port
connector
6 3.5-mm stereo F Audio out ports
connectors
NOTE: The AC650A-2 has two audio and video output ports and the AC650A-4 has four audio
and video output ports.
CHAPTER 2: Overview
23
5
4
6

10
2-PORT AND 4-PORT AUDIO/VIDEO SPLITTERS
3. Installation
3.1 Basic Installation
Follow these steps and refer to Figure 3-1 to install the audio/video splitter.
1. Turn off the PC and monitor.
2. Connect the HD15 cable to the PC’s video output port and the splitter’s video
input port.
3. Connect the 3.5-mm audio cable to the PC’s audio output port and the
splitter’s audio input port.
4. Attach the HD15 video cables to the monitors’ video input ports and the
splitter’s video output ports.
5. Link the 3.5-mm audio cables to the monitors’ audio input ports and the
splitter’s audio output ports.
6. Plug the 3.5-mm headphone cables into the monitors’ audio output ports and
the splitter’s audio input ports.
NOTE: If you connect a DDC monitor to the splitter, all of the monitors must be the same
resolution as the DDC monitor.
PC
Audio
Video
Monitor 1
Monitor 2
Speakers
Speakers
4-Port Audio/
Video Splitter
(AC650A-4)
Figure 3-1. Typical installation.

11
3.2 Cascaded Installation
You can cascade the splitters up to two levels. Mix or match 2-port and 4-port
splitters. Instructions follow for cascading a 2-port splitter and a 4-port splitter. See
Figure 3-2.
1. Connect a HD15 male/male video cable between the first-level splitter’s video
output port and the second-level splitter’s video input port.
2. Link a 3.5-mm audio cable to the first-level splitter’s audio output port and
the second-level splitter’s audio input port.
Monitors
2-Port Audio/
Video Splitter
(AC650A-2)
4-Port Audio/
Video Splitter
(AC650A-4)
Figure 3-2. Cascaded installation.
CHAPTER 3: Installation
Monitor
PC
Speaker
Speakers

12
2-PORT AND 4-PORT AUDIO/VIDEO SPLITTERS
3.3 Supported Resolutions/Distances
Table 3-1. Supported resolutions/distances.
Resolution Frequency Distance
640 x 480 60 Hz 213 ft. (65 m)
800 x 60 60 Hz 164 ft. (50 m)
1024 x 768 60 Hz 131 ft. (40 m)
1280 x 1024 60 Hz 98 ft. (30 m)
1600 x 1200 60 Hz 49 ft. (15 m)
2048 x 1536 60 Hz 32 ft. (10 m)
NOTE: The maximum resolution is 2048 x 1536 at 32 feet (10 m) and the maximum
distance is 213 feet (65 m) at 640 x 480 resolution.

13
4. Troubleshooting
4.1 Calling Black Box
If you determine that your 2-Port or 4-Port Audio/Video Splitter is malfunctioning,
do not attempt to alter or repair the unit. It contains no user-serviceable parts.
Contact Black Box Technical Support at 724-746-5500.
Before you do, make a record of the history of the problem. We will be able to
provide more efficient and accurate assistance if you have a complete description,
including:
• thenatureanddurationoftheproblem.
• whentheproblemoccurs.
• thecomponentsinvolvedintheproblem.
• anyparticularapplicationthat,whenused,appearstocreatetheproblemor
make it worse.
4.2 Shipping and Packaging
If you need to transport or ship your 2-Port or 4-Port Audio/Video Splitter:
• Packageitcarefully.Werecommendthatyouusetheoriginalcontainer.
• Ifyouarereturningtheunit,makesureyouincludeeverythingyoureceived
with it. Before you ship for return or repair, contact Black Box to get a Return
Authorization (RA) number.
CHAPTER 4: Troubleshooting
