Black Box LR0005A-KIT User manual

CUSTOMER
SUPPORT
INFORMATION
Order toll-free in the U.S. 24 hours, 7 A.M. Monday to midnight Friday: 877-877-BBOX
FREE technical support, 24 hours a day, 7 days a week: Call 724-746-5500 or fax [phone]
Mail order: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: [email protected]
MARCH 2000
LR0005A-KIT LR0010A-KIT
LR0006A-AC LR0011A-AC
LR0006A-DC LR0011A-DC
LR0007A LR0012A
IDSL and SDSL Network Extenders
IDSL Network Extender - Provider Unit - 12 Port - AC
1 2 3 4 5 6
CONFIGURATION
7 8 9 10 11 12
WAN
RX
TX
LNK
1
ETHERNET
IDSL
2345678910 11 12
PWR

1
FCC STATEMENT
FEDERAL COMMUNICATIONS COMMISSION
and INDUSTRY CANADA
RADIO FREQUENCY INTERFERENCE STATEMENTS
Class B Digital Device. This equipment has been tested and found to comply with
the limits for a Class B computing device pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. However, there is no guarantee that
interference will not occur in a particular installation. This equipment generates,
uses, and can radiate radio frequency energy, and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. If this equipment does cause harmful interference to radio or
telephone reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult an experienced radio/TV technician for help.
Caution:
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
To meet FCC requirements, shielded cables and power cords are required to
connect this device to a personal computer or other Class B certified device.
This digital apparatus does not exceed the Class B limits for radio noise emission from digital
apparatus set out in the Radio Interference Regulation of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites
applicables aux appareils numériques de classe B prescrites dans le Règlement sur le brouillage
radioélectrique publié par Industrie Canada.

2
IDSL AND SDSL NETWORK EXTENDERS
NORMAS OFICIALES MEXICANAS (NOM)
ELECTRICAL SAFETY STATEMENT
INSTRUCCIONES DE SEGURIDAD
1. Todas las instrucciones de seguridad y operación deberán ser leídas
antes de que el aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas
para referencia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de
operación deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo,
cerca de la tina de baño, lavabo, sótano mojado o cerca de una alberca,
etc..
6. El aparato eléctrico debe ser usado únicamente con carritos o
pedestales que sean recomendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como
sea recomendado por el fabricante.
8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico
más allá a lo descrito en las instrucciones de operación. Todo otro
servicio deberá ser referido a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no
interfiera su uso. La colocación del aparato eléctrico sobre una cama,
sofá, alfombra o superficie similar puede bloquea la ventilación, no se
debe colocar en libreros o gabinetes que impidan el flujo de aire por los
orificios de ventilación.
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de
calor como radiadores, registros de calor, estufas u otros aparatos
(incluyendo amplificadores) que producen calor.
11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo
del tipo descrito en el instructivo de operación, o como se indique en el
aparato.

3
NOM STATEMENT
12. Precaución debe ser tomada de tal manera que la tierra fisica y la
polarización del equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que
no sean pisados ni pellizcados por objetos colocados sobre o contra
ellos, poniendo particular atención a los contactos y receptáculos donde
salen del aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las
recomendaciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las
lineas de energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no
sea usado por un largo periodo de tiempo.
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean
derramados sobre la cubierta u orificios de ventilación.
18. Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del
aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en
su desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.

4
IDSL AND SDSL NETWORK EXTENDERS
TRADEMARKS USED IN THIS MANUAL
Any trademarks mentioned in this manual are acknowledged to be the property of
the trademark owners.

5
CONTENTS
Contents
Chapter Page
1. Specifications ..........................................................................................................6
2. Introduction............................................................................................................7
2.1 Overview ..........................................................................................................7
2.2 Features............................................................................................................8
2.3 Selecting IDSL Bandwidth ............................................................................8
2.4 Selecting SDSL Bandwidth ............................................................................9
2.5 LEDs ................................................................................................................9
3. Installation ............................................................................................................13
3.1 Installation for LR0005A-KIT, LR0007A, LR0010A-KIT, and LR0012A ..13
3.2 Installation for LR0006A-AC/DC and LR0011A-AC/DC ..........................14
Appendix. Port Pinouts ............................................................................................17
A.1 LR0005A-KIT, LR0007A, LR0010A-KIT, and LR0012A ............................17
A.2 LR0006A-AC/DC and LR0011A-AC/DC ....................................................17

6
IDSL AND SDSL NETWORK EXTENDERS
1. Specifications
Bandwidth — SDSL models: Selectable to 272 kbps, 528 kbps, 784 kbps,
1.168 Mbps (all bandwidths are symmetrical); IDSL models:
144/128 kbps (symmetrical)
Distance — Over 24 AWG wire: SDSL: 1.168 Mbps up to 11,000 feet
(3352 m), 784 kbps up to 13,000 feet (3962 m), 528 kbps
up to 15,000 feet (4572 m), and 272 kbps up to 17,000 feet
(5182 m); IDSL: 128 or 144 kbps up to 18,000 feet
(5486 m)
IDSL Interface — All: 2B1Q Encoding; LR0010A-KIT, LR0012A: RJ-45;
LR0011A: RJ-21 50-pin telco
Network Interface — All: IEEE 802.3 Ethernet 10BASE-T; LR0005A-KIT,
LR0007A, LR0010A-KIT, LR0012A: RJ-45; LR0006A,
LR0011A: (12) RJ-21
SDSL Interface — All: 2B1Q Encoding; LR0005A-KIT, LR0007A: RJ-45;
LR0006A: RJ-21 50-pin telco
Indicators — Connection, Power, Collision, TX, RX, Link
Power — LR0005A-KIT, LR0006A-AC, LR0007A, LR0010A-KIT,
LR0012A, LR0011A-AC: 100–120 VAC, 60 Hz; LR0006A-DC,
LR0011A-DC: 40–56 VDC Positive Ground
Size — LR0005A-KIT, LR0007A, LR0010A-KIT, LR0012A: 1.3"H x
5.5"W x 4.6"D (3.3 x 14 x 11.4 cm); LR0006A-AC: 1.8"H x
17"W x 17"D (4.6 x 43.2 x 43.2 cm); LR0006A-DC: 1.8"H x
17"W x 14"D (4.6 x 43.2 x 35.6 cm); LR0011A-AC,
LR0011A-DC: 1.8"H x 17"W x 18"D (4.6 x 43.2 x 45.7 cm)
Weight — LR0005A-KIT, LR0007A, LR0010A-KIT, LR0012A: 0.6 lb.
(0.3 kg); LR0006A, LR0011A: 7.7 lb. (3.5 kg)

7
CHAPTER 2: Introduction
2. Introduction
2.1 Overview
The Network Extenders convert either SDSL (Symmetrical Digital Subscriber
Line) or IDSL (ISDN Digital Subscriber Line) to Ethernet. This is a Layer 1
conversion, and Ethernet frames are then passed across the SDSL or IDSL link.
Each model’s function is described below.
• The LR0005A-KIT includes one Provider unit and one Subscriber unit, to
make one individual SDSL-to-Ethernet line.
• The LR0006A-AC/DC is a 12-port Provider unit with 12 individual SDSL-to-
Ethernet ports to which you can attach 12 Subscriber units. No bridging or
routing is done internally.
• The LR0007A is a single SDSL-to-Ethernet Subscriber unit.
• The LR0010A-KIT includes one Provider unit and one Subscriber unit, to
make one individual IDSL-to-Ethernet line.
• The LR0011A-AC/DC is a 12-port Provider unit with 12 individual IDSL-to-
Ethernet ports to which you can attach 12 Subscriber units. No bridging or
routing is done internally.
• The LR0012A is a single IDSL-to-Ethernet Subscriber unit.
The connection across the SDSL line may be at 272, 528, or 728 kbps or 1.168
Mbps in both directions. Connection across the IDSL line may either 144 or 128
kbps. Speed is selectable and determined by the Provider unit; the remote
Subscriber unit will determine its line speed through communication with the
Provider unit.
SDSL/IDSL technology is intended for use from the telephone company central
office across the local loop to the home or business, or may also be used in
multiple-dwelling-unit environments to provide high-speed, long-reach data service
over phone-grade copper cable up to 18,000 feet (5486 m). Distance is determined
by speed selection and cable grade.
The typical application for IDSL or SDSL technology is high-speed Internet access
or remote LAN access.

8
IDSL AND SDSL NETWORK EXTENDERS
2.2 Features
•Traffic Indicators — All units feature an LED that will steadily pulse (once per
second) when the SDSL or IDSL connection is operational and the unit is
receiving valid data packets or status packets from the SDSL or IDSL Network
Extender on the remote side of the link.
•Link Down Notification — Allows for alarm notification for the SDSL or IDSL
link to the Ethernet device to which the Provider unit is connected.
•Broadcast Limiting (IDSL and SDSL Subscriber Units Only) —Ensures that pure
broadcast traffic will only be allowed to consume up to 20% of the total SDSL
or IDSL bandwidth. Unicast and multicast traffic are guaranteed at least 80%
of the total SDSL or IDSL bandwidth.
•Local Traffic Filtering (IDSL and SDSL Provider and Subscriber Units) —The
units will build a database up to 255 MAC addresses and will provide traffic
filtering based on the learned MAC addresses. MAC addresses are learned
based on the Source Address of the Ethernet packets, and are filtered based
on the Destination Address of the Ethernet packets. Addresses are removed
from the filtering database if the unit does not receive traffic from that Source
for a 5-minute period, but are relearned once the unit receives packets from
that Source Address.
2.3 Selecting IDSL Bandwidth
For LR0010A-KIT, LR0011A-AC/DC, and LR0012A, Switch #2 on the Provider
Unit’s front panel controls the IDSL bandwidth. (Switch #1 is not used.)
If Switch 2 is in the up position, the IDSL connection will provide 128-kbps
symmetrical bandwidth. If Switch 2 is in the down position, the IDSL connection
will provide 144-kbps symmetrical bandwidth. There is no switch on the Subscriber
Unit; it will determine its speed through communication with the Provider Unit.

9
CHAPTER 2: Introduction
2.4 Selecting SDSL Bandwidth
For LR0005A-KIT, LR0006A-AC/DC, and LR0007A, two switches are used to select
the SDSL bandwidth for each SDSL/Ethernet port pairing. The table below shows
switch configurations and associated bandwidth and distance support (in feet).
Left Switch Right Switch Bandwidth 26 AWG 24 AWG
Down Down 1.168 Mbps 9,000 12,000
Down Up 784 kbps 11,000 13,000
Up Down 528 kbps 13,000 15,000
Up Up 272 kbps 15,000 17,000
2.5 LEDs
Indicators for each model are listed below by product code.
LR0005A-KIT (P ROVIDER U NIT ; S UBSCRIBER U NIT F UNCTIONS AS LR0007A)
SDSL LED: Pulsing green (once per second) indicates that the SDSL
connection is operational and the unit is receiving either valid data packets or
status packets from the remote unit on the other side of the SDSL connection.
Power: Steady green indicates normal operation.
Collision: Flashing red indicates collision on Ethernet segment.
Rx: Flashing amber indicates data received from Ethernet segment. Steady
amber indicates that the SDSL connection is not present.
Tx: Flashing amber indicates data transmitted to Ethernet segment. Steady
amber indicates that the SDSL connection is not present.
Lnk: Steady green indicates that an Ethernet link has been established. Steady
green (if accompanied by corresponding steady amber Tx and Rx LEDs)
indicates that the SDSL connection is not present.

10
IDSL AND SDSL NETWORK EXTENDERS
LR0006A-AC/DC
Power: Steady green indicates normal operation.
WAN: Pulsing green (once per second) indicates that the SDSL connection is
operational and the unit is receiving either valid data packets or status packets
from the remote unit on the other side of the SDSL connection.
Rx: Flashing amber indicates data received from Ethernet segment. Steady
amber indicates that the SDSL connection is not present.
Tx: Flashing amber indicates data transmitted to Ethernet segment. Steady
amber indicates that the SDSL connection is not present.
Lnk: Steady green indicates that an Ethernet link has been established. Steady
green (if accompanied by corresponding steady amber Tx and Rx LEDs)
indicates that the SDSL connection is not present.
NOTE
The SDSL connection may take several minutes to establish full
connectivity at the desired bandwidth setting. During connection setup,
the SDSL line will come up briefly (indicated by WAN LED), but will then
shut down and retrain at the appropriate bandwidth setting indicated by
the front-panel switches. Once the connection has been established, the
WAN LED will function as described above.
LR0007A
SDSL LED: Steady pulsing green (once per second) indicates that the SDSL
connection is operational and the unit is receiving either status packets from
the SDSL Network Extender on the opposite side of the link or valid data
packets across the link.
Power: Steady green indicates normal operation.
Collision: Flashing red indicates collision on Ethernet segment.
Rx: Flashing amber indicates data received from Ethernet segment.
Tx: Flashing amber indicates data transmitted to Ethernet segment.
Lnk: Steady green indicates that an Ethernet link has been established.

11
CHAPTER 2: Introduction
LR0010A-KIT (P ROVIDER U NIT ; S UBSCRIBER U NIT F UNCTIONS AS LR0012A)
IDSL LED: Pulsing green (once per second) indicates that the IDSL
connection is operational and the unit is receiving either valid data packets or
status packets from the remote unit on the other side of the IDSL connection.
Power: Steady green indicates normal operation.
Collision: Flashing red indicates collision on Ethernet segment.
Rx: Flashing amber indicates data received from Ethernet segment. Steady
amber indicates that the IDSL connection is not present.
Tx: Flashing amber indicates data transmitted to Ethernet segment. Steady
amber indicates that the IDSL connection is not present.
Lnk: Steady green indicates that an Ethernet link has been established. Steady
green (if accompanied by corresponding steady amber Tx and Rx LEDs)
indicates that the IDSL connection is not present.
NOTE
The SDSL connection may take several minutes to establish full
connectivity at the desired bandwidth setting. During connection setup,
the SDSL line will come up briefly (indicated by IDSL LED), but will then
shut down and retrain at the appropriate bandwidth setting indicated by
the front-panel switches. Once the connection has been established, the
IDSL LED will function as described above.
LR0011A-AC/DC
Power: Steady green indicates normal operation.
WAN: Pulsing green (once per second) indicates that the IDSL connection is
operational and unit is receiving either valid data packets or status packets
from the remote unit on the other side of the IDSL connection.
Rx: Flashing amber indicates data received from Ethernet segment. Steady
amber indicates that the IDSL connection is not present.
Tx: Flashing amber indicates data transmitted to Ethernet segment. Steady
amber indicates that the IDSL connection is not present.
Lnk: Steady green indicates that an Ethernet link has been established. This
LED will also glow steadily if the IDSL connection is not present.

12
IDSL AND SDSL NETWORK EXTENDERS
LR0012A
IDSL LED: Steady pulsing green (once per second) indicates that the IDSL
connection is operational and the unit is receiving either status packets from
the IDSL Network Extender on the opposite side of the link or valid data
packets across the link.
Power: Steady green indicates normal operation.
Collision: Flashing red indicates collision on Ethernet segment.
Rx: Flashing amber indicates data received from Ethernet segment.
Tx: Flashing amber indicates data transmitted to Ethernet segment.
Lnk: Steady green indicates that an Ethernet link has been established.

13
CHAPTER 3: Installation
3. Installation
This chapter provides basic installation procedures. We strongly recommend using
proper static-protection techniques when installing and handling the equipment.
3.1 Installation for LR0005A-KIT, LR0007A, LR0010A-KIT, and LR0012A
NOTE
A Network Extender Subscriber Unit must be connected (via the DSL
line) to a Network Extender Provider. Two Subscriber Units cannot be
connected back-to-back.
1. Unpack the Network Extender and power supply.
2. Plug the power supply into both the power source and back of the unit. (It
doesn’t matter which order.) Verify that the Power LED is lit. On the IDSL
Network Extender and SDSL Network Extender Provider Units, the Lnk, Tx,
and Rx LEDs will also be lit.
3. Plug in the DSL connection (see the Appendix for SDSL connection pinout
information). On the Provider Units, verify that the switches on the back of the
unit are in the appropriate position (see below).
LR0010A-Kit (Provider Unit) Switch Configuration
Switch #1: Not used.
Switch #2 Bandwidth Distance (in feet)
Down 144 kbps 18,000
Up 128 kbps 18,000
LR0005A-Kit (Provider Unit) Switch Configuration
Distance Supported (in feet)
Switch #1 Switch #2 Bandwidth 26 AWG 24 AWG
Down Down 1.168 Mbps 9,000 12,000
Down Up 784 kbps 11,000 13,000
Up Down 528 kbps 13,000 15,000
Up Up 272 kbps 15,000 17,000
The IDSL and SDSL Subscriber Units (LR0010A-KIT, LR0012A, LR0005A-KIT,
LR0007A) do not use these switches.

14
IDSL AND SDSL NETWORK EXTENDERS
NOTE
The distance of the copper cable between the local Network Extender
and the remote Network Extender will affect the linking of the DSL
connection. If the distance is greater than a particular speed will
support, the units will not link up. Note that it may take anywhere
between 1 and 5 minutes for the DSL connection to link up, depending
on cable quality and distance.
4. Verify the DSL connection via the DSL LED on the front of the unit. A steadily
pulsing LED (once per second) indicates that the DSL connection is established
and operational. On the Network Extender Provider Units, the Lnk, Tx, and Rx
LEDs will not be lit once the DSL link is operational.
5. Plug in the local Ethernet connection and verify physical link by the Lnk LED
on the front of the unit. See the Appendix for Ethernet connection pinout
information.
Once the units have established both DSL and Ethernet link on both sides of the
connection, normal data communication will flow through the units, essentially
providing a very long Ethernet connection at DSL speeds.
3.2 Installation for LR0006A-AC/DC and LR0011A-AC/DC
1. Unpack the Network Extender and power cord (AC only). Attach the included
rubber feet for stackable installations or attach rackmount brackets and mount
the Network Extender in an equipment rack. When mounting unit in an
equipment rack, please adhere to the following:
a. Maximum recommended ambient temperature is 86°F (30°C). Internal
temperatures of rack should be considered for continued safe operation.
b. Do not block power-supply vents or otherwise restrict airflow when installing
unit in rack.
c. Mechanical loading of rack should be considered so that the rack remains
stable and unlikely to tip over.
d. Consideration of the overall loading of the branch circuit should be given
before installing any equipment in a rack environment.
e. Make sure that a reliable grounding path is maintained in the rack system.
This unit is intended for a grounded connection.

15
CHAPTER 3: Installation
2. For AC units, plug the power cord into both the power source and the back of
the unit. (It doesn’t matter which order.) For DC units, attach the DC power
leads and ground connection to the appropriate terminals indicated on the
back of the unit and supply power to the unit. Verify that the Power LED is lit.
Until the DSL link is established, the Lnk, Tx, and Rx LEDs will also be lit on
each port. When the DSL link has been established, the Tx and Rx LEDs will
function normally, indicating activity on the Ethernet segment.
3. Attach the RJ-21 connector/cable to the DSL connector on the unit. This
connection is typically made to a punchdown block for copper wire cross
connects in a telco office/room, or with an RJ-21 to RJ-45 breakout cable (see
the Appendix for SDSL connection pinout information).
4. Verify that the switches on the front of the unit are in the appropriate position
for each port (see below).
LR0011A-AC/DC Switch Configuration (per port pairing)
Switch #1: Not used.
Switch #2 Bandwidth Distance (in feet)
Down 144 kbps 18,000
Up 128 kbps 18,000
LR0011A-AC/DC Switch Configuration (per port pairing)
Distance Supported (in feet)
Switch #1 Switch #2 Bandwidth 26 AWG 24 AWG
Down Down 1.168 Mbps 9,000 11,000
Down Up 784 kbps 11,000 13,000
Up Down 528 kbps 13,000 15,000
Up Up 272 kbps 15,000 17,000
NOTE
The distance of the copper cable between the local Network Extender
and the remote Network Extender will affect the linking of the DSL
connection. If the distance is greater than a particular speed will
support, the units will not link up. Additionally, it may take anywhere
between 1 and 5 minutes for the DSL connection to link up, depending
on cable quality and distance.

16
IDSL AND SDSL NETWORK EXTENDERS
5. Verify the DSL connection via the DSL LED on the front of the unit. A steadily
pulsing LED (once per second) indicates that the DSL connection is established
and operational.
6. Connect the local RJ-21 Ethernet connector/cable to network equipment (such
as an Ethernet switch) and verify physical link by the Lnk LED on the front of
the unit. See the Appendix for Ethernet connection pinout information.
NOTE
The Network Extender Provider Units do not present Ethernet link (Lnk)
to the Ethernet network equipment if the DSL connection is not present.
This feature allows for remote monitoring of the DSL line by simply
monitoring the Ethernet port for link status.
Once the units have established both DSL and Ethernet link on both sides of the
connection, normal data communication will flow through the units, essentially
providing a very long Ethernet connection at DSL speeds.

17
APPENDIX: Port Pinouts
Appendix: Port Pinouts
A.1 LR0005A-KIT, LR0007A, LR0010A-KIT, and LR0012A
Ethernet Pinout SDSL or IDSL Pinout
Pin 1 RX+ Pin 1
Pin 2 RX- Pin 2
Pin 3 TX+ Pin 3
Pin 4 Pin 4 Ring
Pin 5 Pin 5 Tip
Pin 6 TX- Pin 6
Pin 7 Pin 7
Pin 8 Pin 8
A.2 LR0006A-AC/DC and LR0011A-AC/DC
Ethernet RJ-21 SDSL or IDSL RJ-21
Port Pin Port Pin
1 26 TX1+ 1 26 Tip
1 TX1- 1 Ring
27 RX1+ 2 27 Tip
2 RX1- 2 Ring
2 28 TX2+ 3 28 Tip
3 TX2- 3 Ring
29 RX2+ 4 29 Tip
4 RX2- 4 Ring
3 30 TX3+ 5 30 Tip
5 TX3- 5 Ring
31 RX3+ 6 31 Tip
6 RX3- 6 Ring
4 32 TX4+ 7 32 Tip
7 TX4- 7 Ring
33 RX4+ 8 33 Tip
8 RX4- 8 Ring
5 34 TX5+ 9 34 Tip
9 TX5- 9 Ring
35 RX5+ 10 35 Tip

18
IDSL AND SDSL NETWORK EXTENDERS
LR0006A-AC/DC (continued)
Ethernet RJ-21 SDSL or IDSL RJ-21
Port Pin Port Pin
10 RX5- 10 Ring
6 36 TX6+ 11 36 Tip
11 TX6- 11 Ring
37 RX6+ 12 37 Tip
12 RX6- 12 Ring
7 38 TX7+
13 TX7-
39 RX7+
14 RX7-
8 40 TX8+
15 TX8-
41 RX8+
16 RX8-
9 42 TX9+
17 TX9-
43 RX9+
18 RX9-
10 44 TX10+
19 TX10-
45 RX10+
20 RX10-
11 46 TX11+
21 TX11-
47 RX11+
22 RX11-
12 48 TX12+
23 TX12-
49 RX12+
24 RX12-
