Black Box KVX Series Instructions for use

24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.COM
KVX SERIES
DVI KVM
EXTENDER
KVXLC-100, KVXLCF-100, KVXLC-200, KVXLCF-200
QUICK INSTALL GUIDE AND USER MANUAL
PWR
PWR
Serial over IP
DVI KVM Extender Transmitter
Serial over IP
DVI KVM Extender Receiver

2
TABLE OF CONTENTS
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
QUICK INSTALLATION GUIDE.......................................................................................................................................................... 3
1. SPECIFICATIONS........................................................................................................................................................................... 4
2. OVERVIEW...................................................................................................................................................................................... 6
2.1 Introduction...............................................................................................................................................................................................6
2.2 Features ....................................................................................................................................................................................................6
2.3 What’s Included........................................................................................................................................................................................6
2.4 Hardware Description..............................................................................................................................................................................7
2.4.1 Transmitter ..........................................................................................................................................................................................................7
2.4.2 Receiver..............................................................................................................................................................................................................10
3. CONNECTION DIAGRAM ............................................................................................................................................................ 13
4. INSTALL ATION ............................................................................................................................................................................ 14
4.1 Factory Default Settings ........................................................................................................................................................................14
APPENDIX A. REGULATORY INFORMATION ................................................................................................................................ 15
A.1 FCC Statement .......................................................................................................................................................................................15
A.2 NOM Statement .....................................................................................................................................................................................16
APPENDIX B. DISCLAIMER/TRADEMARKS ................................................................................................................................. 17
B.1 Disclaimer ............................................................................................................................................................................................... 17
B.2 Trademarks.............................................................................................................................................................................................17

3
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
QUICK INSTALLATION GUIDE
Follow these steps to install the extender:
1. If you have the fiber models, install the SFPs in the transmitter and receiver. Compatible SFPs from Black Box are listed in the table
below.
COMPATIBLE SFP MODULES
PART NUMBER DESCRIPTION DISTANCE
1-GBPS CONNECTIONS
LFP441 SFP 1.25-Gb, 850-nm Multimode Fiber, LC 550 m
LFP442 SFP 1.25-Gb, 1310-nm Single-mode Fiber, LC 20 km
LFP412 SFP with Extended Diagnostics - 1250-Mbps Multimode Fiber, 1310-nm 2 km
LFP413 SFP with Extended Diagnostics - 1250-Mbps Single-Mode Fiber, 1310-nm 10 km
LFP414 SFP with Extended Diagnostics - 1250-Mbps, Singlemode Fiber, 1310-nm 30 km
LFP416 SFP 1250-Mbps, Extended Diagnostics, 10/100/1000BASE-T, SGMII Interface, RJ-45 100 m
NOTE: Other SFPs may work but have not been validated by Black Box, we recommend you use the suggested SFPs to avoid
technical incompatibilities.
NOTE: SFP is not included, must be ordered separately.
2. Connect the video source(s) to the Transmitter (Computer Unit).
3. Connect the monitor(s) to the Receiver unit.
4. Use CATx cables (EIA/TIA 568B industry standard compliant) or fiber cables for connection between Transmitter/Receiver.
5. Apply the proper power to all connecting devices.
NOTES:
a. We recommend using the highest quality materials (cables, SFP, etc.) to ensure optimal transmission quality.
b. If the screen does not display when you connect the computer:
1. Make sure the device cables are correctly and firmly attached.
2. Set your display device’s (TV, monitor, etc.) input source as DVI.
3. Check the PC BIOS configuration of the video output setting.
4. Connect your video source to the Display DIRECTLY to check if the video signal gets through.

41. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
CHAPTER 1: SPECIFICATIONS
TABLE 1-1. TRANSMITTER SPECIFICATIONS
Console Connection
Video Output N/A
Serial Control Port N/A
Host Connection
Video Input KVXLC-100, KVXLCF-100: (1) DVI-I female;
KVXLC-200, KVXLCF-200: (2) DVI-I female
Local Out Video Connection
Local Out KVXLC-100, KVXLCF-100: (1) DVI-I female;
KVXLC-200, KVXLCF-200: (2) DVI-I female
Link Port
RJ-45 KVXLC-100: (1) RJ-45 using CATx cable – max. length: 330 feet (100 meters);
KVXLC-200: (2) RJ-45 using CATx cable – max. length: 330 feet (100 meters)
SFP
KVXLCF-100: (1) SFP cage using Fiberoptic cable – max. length: 18.6 miles (30 km), depending on SFP;
KVXLCF-200: (2) SFP cages using Fiberoptic cable – max. length: 18.6 miles (30 km), depending on SFP
NOTE: SFP is not included. Must be ordered separately.
USB Interface
Host (1) USB Type B female
Device N/A
Audio
2-way analog audio (1) Line In, (1) Line Out
General
LED indicator Power: White LED
DDC Supported DDC, DDC2, DDC2B
Max. Video Resolution 1920 x 1200 @ 60 Hz
OS Compatibility OS Independent
Housing material Chassis Metal
Operating Temperature 32 to 122° F (0 to 50° C)
Storage Temperature -4 to +140° F (-20 to +60° C)
Relative Humidity 0 to 80%
Power Supply External 5-VDC, 2-A power supply
Dimensions KVXLC-100, KVXLCF-100 transmitters: 1.06" H x 7.09" W x 3.27" D (2.7 x 18.0 x 8.3 cm);
KVXLC-200, KVXLCF-200 transmitters: 1.71" H x 7.09" W x 3.27" D (4.4 x 18.0 x 8.3 cm)
Weight
KVXLC-100 transmitter: 0.79 lb. (0.36 kg);
KVXLCF-100 transmitter: 0.77 lb. (0.35 kg);
KVXLC-200, KVXLCF-200 transmitter: 1.12 lb. (0.51 kg)

5
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
CHAPTER 1: SPECIFICATIONS
TABLE 1-2. RECEIVER SPECIFICATIONS
Console Connection
Video Output KVXLC-100, KVXLCF-100: (1) DVI-I female;
KVXLC-200, KVXLCF-200: (2) DVI-I female
Serial Control Port (1) DB9 male
Host Connection
Video Input N/A
Link Port
RJ-45 KVXLC-100: (1) RJ-45 using CATx cable – max. length: 330 feet (100 meters);
KVXLC-200: (2) RJ-45 using CATx cable – max. length: 330 feet (100 meters)
SFP
KVXLCF-100: (1) SFP cage using Fiberoptic cable – max. length: 18.6 miles (30 km), depending on SFP;
KVXLCF-200: (2) SFP cages using Fiberoptic cable – max. length: 18.6 miles (30 km), depending on SFP
NOTE: SFP is not included. Must be ordered separately.
USB Interface
Host N/A
Device (2) USB 2.0 Type A female for USB device extension;
(2) USB HID ports for keyboard and mouse
Audio
2-way analog audio (1) MIC In, (1) Speaker Out
General
LED indicator Power: White LED
DDC Supported DDC, DDC2, DDC2B
Max. Video Resolution 1920 x 1200 @ 60 Hz
OS Compatibility OS Independent
Housing material Chassis Metal
Operating Temperature 32 to 122° F (0 to 50° C)
Storage Temperature -4 to +140° F (-20 to +60° C)
Relative Humidity 0 to 80%
Power Supply External 5-VDC, 2-A power supply
Dimensions KVXLC-100, KVXLCF-100 receivers: 1.06” H x 7.09” W x 3.27” D (2.7 x 18.0 x 8.3 cm);
KVXLC-200, KVXLCF-200 receivers: 1.71” H x 7.09” W x 3.27” D (4.4 x 18.0 x 8.3 cm)
Weight
KVXLC-100 receiver: 0.84 lb. (0.38 kg);
KVXLCF-100 receiver: 0.81 lb. (0.37 kg);
KVXLC-200, KVXLCF-200 receiver: 1.12 lb. (0.51 kg)

61. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
CHAPTER 2: OVERVIEW
2.1 INTRODUCTION
The KVX Series DVI KVM Extender enables you to locally use one or two DVI/VGA monitors, USB keyboard/mouse/other devices,
speaker, and microphone to operate a remote computer, server or other IT device.
There are four models of the KVX Series DVI KVM Extender: a single-head KVXLC-100 and dual-head KVXLC-200 version via a CATx link,
and a single-head KVXLCF-100 and dual-head KVXLCF-200 version via a fiberoptic link. Each extender consists of a transmitter (TX) and
a receiver (RX).
2.2 FEATURES
Supports DVI and VGA input/output video quality up to 1920 x 1200 @ 60 Hz.
Provides remote access for video/USB/RS-232/audio extension distance up to 330 feet (100 meters) over CATx cable for model
KVXLC-100 or KVXLC-200; up to 18.6 miles (30 km) over fiberoptic cable for model KVXLCF-100 or KVXLCF-200, depending
on the SFP used.
The DVI KVM Console Extender lets you control a server, or computer over single-mode or multimode fiber optic cable at distances
of up to 30 km (depending on the SFP used, fiber type, and fiber bandwidth*).
Single-head models with (1) DVI connector and dual-head models with (2) DVI connectors are available.
Offers transparent USB 2.0/1.1 extension.
Uses analog audio LINE-IN/LINE-OUT extension.
Supports bi-directional RS-232 control communication.
Firmware upgradable.
*NOTE: Reference the supported SFP chart on page 3.
2.3 WHAT’S INCLUDED
KVXLC-100:
(1) Single-Head DVI KVM CATx Extender Transmitter (TX)
(1) Single-Head DVI KVM CATx Extender Receiver (RX)
(2) Power Supplies (includes US, EU, UK plug types)
(1) DVI-I cable (6-ft./1.8-m)
(1) 3.5-mm audio cable (6-ft./1.8-m)
(1) USB-B to USB-A cable (6-ft./1.8-m)
KVXLCF-100:
(1) Single-Head DVI KVM Fiber Extender Transmitter (TX)
(1) Single-Head DVI KVM Fiber Extender Receiver (RX)
(2) Power Supplies (includes US, EU, UK plug types)
(1) DVI-I cable (6-ft./1.8-m)
(1) 3.5-mm audio cable (6-ft./1.8-m)
(1) USB-B to USB-A cable (6-ft./1.8-m)
KVXLC-200:
(1) Dual-Head DVI KVM CATx Extender Transmitter (TX)
(1) Dual-Head DVI KVM CATx Extender Receiver (RX)
(2) Power Supplies (includes US, EU, UK plug types)
(2) DVI-I cables (6-ft./1.8-m)
(1) 3.5-mm audio cable (6-ft./1.8-m)
(1) USB-B to USB-A cable (6-ft./1.8-m)
KVXLCF-200:
(1) Dual-Head DVI KVM Fiber Extender Transmitter (TX)
(1) Dual-Head DVI KVM Fiber Extender Receiver (RX)
(2) Power Supplies (includes US, EU, UK plug types)
(2) DVI-I cables (6-ft./1.8-m)
(1) 3.5-mm audio cable (6-ft./1.8-m)
(1) USB-B to USB-A cable (6-ft./1.8-m)

7
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
CHAPTER 2: OVERVIEW
2.4 HARDWARE DESCRIPTION
2.4.1 TRANSMITTER
FRONT PANEL
Figure 2-1 shows the front panel that is common to the single-head CATx and fiber transmitters. Table 2-1 describes its components.
1 2 3 4
FIGURE 2-1. TRANSMITTER FRONT PANEL
Figure 2-2 shows the front panel that is common to the dual-head CATx and fiber transmitters. Table 2-1 describes its components.
1 5 2 3 4
FIGURE 2-2. DUAL-HEAD TRANSMITTER FRONT PANEL
TABLE 2-1. TRANSMITTER FRONT-PANEL COMPONENTS
NUMBER IN FIGURE 2-1 OR 2-2 COMPONENT DESCRIPTION
1PWR LED Lights when power to the transmitter is ON
2Audio jack Connects to analog audio input for audio extension
3Audio jack Connects to analog audio output for audio extension
4DB9 female connector Connects to source device’s RS-232 port for serial extension
5 Link LED Lights when the TX/RX link is active

81. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
CHAPTER 2: OVERVIEW
BACK PANEL
Figures 2-3 and 2-4 show the back panels of the single-head CATx and fiber transmitters. Table 2-2 describes their components.
1 2 3 4 5 6
FIGURE 2-3. SINGLE-HEAD CATX TRANSMITTER BACK PANEL
1 2 3 4 5 6
FIGURE 2-4. SINGLE-HEAD FIBER TRANSMITTER BACK PANEL
TABLE 2-2. SINGLE-HEAD TRANSMITTER BACK-PANEL COMPONENTS
NUMBER IN FIGURE 2-3 OR 2-4 COMPONENT DESCRIPTION
1Ground screw Links to ground
2For CATx model: RJ-45 connector
For Fiber model: SFP cage
For CATx Model: CATx link
For Fiber model: Install fiber SFP module here
3 USB Type B connector Connects to source device’s USB port
4 DVI In port Connects to source device’s signal for DVI/VGA extension
5 DVI Out port Connects to local out
6Power connector Links to 5-VDC power supply

9
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
CHAPTER 2: OVERVIEW
Figures 2-5 and 2-6 show the back panels of the dual-head CATx and fiber transmitters. Table 2-3 describes their components.
1 2 3 4 5 6
FIGURE 2-5. DUAL-HEAD CATX TRANSMITTER BACK PANEL
1 2 3 4 5 6
FIGURE 2-6. DUAL-HEAD FIBER TRANSMITTER BACK PANEL
TABLE 2-3. DUAL-HEAD TRANSMITTER BACK-PANEL COMPONENTS
NUMBER IN FIGURE 2-5 OR 2-6 COMPONENT DESCRIPTION
1Ground screw Links to ground
2For CATx model: (2) RJ-45 connectors
For Fiber model: (2) SFP cages
For CATx Model: CATx links
For Fiber model: Install fiber SFP modules here
3 USB Type B connector Connects to source device’s USB port
4 (2) DVI In ports Connect to source devices’ signals for DVI/VGA extension
5 (2) DVI Out ports Connect to local out
6Power connector Links to 5-VDC power supply

10 1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
CHAPTER 2: OVERVIEW
2.4.2 RECEIVER
FRONT PANEL
Figure 2-7 shows the front panel that is common to the single-head CATx and fiber receivers. Figure 2-8 shows the front panel that is
common to the dual-head CATx and fiber receivers. Table 2-4 describes the components.
1 2
FIGURE 2-7. SINGLE-HEAD RECEIVER FRONT PANEL
1 3 2
FIGURE 2-8. DUAL-HEAD RECEIVER FRONT PANEL
TABLE 2-4. RECEIVER FRONT-PANEL COMPONENTS
NUMBER IN FIGURE 2-7 OR 2-8 COMPONENT DESCRIPTION
1PWR LED Lights when power to the receiver is ON
2DB9 male connector Connects to sink device’s RS-232 port for serial extension
3 Link LED Lights when the TX/RX link is active

11
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
CHAPTER 2: OVERVIEW
BACK PANEL
Figures 2-9 and 2-10 show the back panels of the single-head CATx and fiber receivers. Table 2-5 describes their components.
1 2 3 4 5 6 7 8
FIGURE 2-9. SINGLE-HEAD CATX RECEIVER BACK PANEL
1 2 3 4 5 6 7 8
FIGURE 2-10. SINGLE-HEAD FIBER RECEIVER BACK PANEL
TABLE 2-5. SINGLE-HEAD RECEIVER BACK-PANEL COMPONENTS
NUMBER IN FIGURE 2-9 OR 2-10 COMPONENT DESCRIPTION
1Ground screw Links to ground
2For CATx model: (1) RJ-45 connector
For Fiber model: (1) SFP cage
For CATx Model: CATx link
For Fiber model: Install fiber SFP module here
3 (2) USB 2.0 ports Connects to USB device’s ports for extension
4 (2) USB HID ports Connects to USB keyboard and mouse
5 DVI Out port Connects to sink device’s signal for DVI/VGA extension
6Audio jack Links to analog audio input for audio extension
7Audio jack Links to analog audio output for audio extension
8Power connector Links to 5-VDC power supply

12 1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
CHAPTER 2: OVERVIEW
Figures 2-11 and 2-12 show the back panels of the dual-head CATx and fiber receivers. Table 2-6 describes their components.
1 2 3 4 5 6 7 8
FIGURE 2-11. DUAL-HEAD CATX RECEIVER BACK PANEL
1 2 3 4 5 6 7 8
FIGURE 2-12. DUAL-HEAD FIBER RECEIVER BACK PANEL
TABLE 2-6. DUAL-HEAD RECEIVER BACK-PANEL COMPONENTS
NUMBER IN FIGURE 2-11 OR 2-12 COMPONENT DESCRIPTION
1Ground screw Links to ground
2For CATx model: (2) RJ-45 connectors
For Fiber model: (2) SFP cages
For CATx Model: CATx links
For Fiber model: Install fiber SFP modules here
3 (2) USB 2.0 ports Connects to USB device’s ports for extension
4 (2) USB HID ports Connects to USB keyboard and mouse
5 (2) DVI Out ports Connect to sink devices’ signals for DVI/VGA extension
6Audio jack Links to analog audio input for audio extension
7Audio jack Links to analog audio output for audio extension
8Power connector Links to 5-VDC power supply

13
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
CHAPTER 3: CONNECTION DIAGRAM
Figure 3-1 shows a typical connection.
Source Console
TX RX
CATx UTP/STP Cable
Fiberoptic Cable
OR
FIGURE 3-1. CONNECTION DIAGRAM

14 1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
CHAPTER 4: INSTALLATION
4.1 FACTORY DEFAULT SETTINGS
Below are the factory default baud rate settings for the DVI KVM Extender’s serial ports.
Baud rate: 115,200 bps
Data bits: 8
Parity: None
Stop bits: 1

15
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
APPENDIX A: REGULATORY INFORMATION
A.1 FCC CLASS A STATEMENT
This equipment generates, uses, and can radiate radio-frequency energy, and if not installed and used properly, that is, in strict
accordance with the manufacturer’s instructions, may cause interference to radio communication. It has been tested and found to
comply with the limits for a Class A computing device in accordance with the specifications in Subpart B of Part 15 of FCC rules,
which are designed to provide reasonable protection against such interference when the equipment is operated in a commercial
environment. Operation of this equipment in a residential area is likely to cause interference, in which case the user at his own
expense will be required to take whatever measures may be necessary to correct the interference.
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate
the equipment.
This digital apparatus does not exceed the Class A limits for radio noise emission from digital apparatus set out in the Radio
Interference Regulation of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de
la classe A prescrites dans le Règlement sur le brouillage radioélectrique publié par Industrie Canada.

16 1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
APPENDIX A: REGULATORY INFORMATION
A.2 NOM STATEMENT
1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de operación deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca de la tina de baño, lavabo, sótano mojado o cerca de
una alberca, etc.
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales que sean recomendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea recomendado por el fabricante.
8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá a lo descrito en las instrucciones de operación.
Todo otro servicio deberá ser referido a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no interfiera su uso. La colocación del aparato eléctrico
sobre una cama, sofá, alfombra o superficie similar puede bloquea la ventilación, no se debe colocar en libreros o gabinetes que
impidan el flujo de aire por los orificios de ventilación.
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor como radiadores, registros de calor, estufas u otros
aparatos (incluyendo amplificadores) que producen calor.
11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del tipo descrito en el instructivo de operación, o como
se indique en el aparato.
12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización del equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que no sean pisados ni pellizcados por objetos colocados
sobre o contra ellos, poniendo particular atención a los contactos y receptáculos donde salen del aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las recomendaciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las lineas de energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no sea usado por un largo periodo de tiempo.
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean derramados sobre la cubierta u orificios de ventilación.
18. Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del aparato;o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en su desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.

17
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
APPENDIX B: DISCLAIMER/TRADEMARKS
B.1 DISCLAIMER
Black Box Corporation shall not be liable for damages of any kind, including, but not limited to, punitive, consequential or cost of cover
damages, resulting from any errors in the product information or specifications set forth in this document and Black Box Corporation
may revise this document at any time without notice.
B.2 TRADEMARKS USED IN THIS MANUAL
Black Box and the Black Box logo type and mark are registered trademarks of Black Box Corporation.
Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners.

18 1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
NOTES
__________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________
_
_________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________
_
_________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________
_
_________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________
_
_________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________

19
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
NOTES
__________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________
_
_________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________
_
_________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________
_
_________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________
_
_________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________

NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.877.87 7.2269
© COPYRIGHT 2020. BLACK BOX CORPORATION. ALL RIGHTS RESERVED.
KVXLC-100_200_QIG-USER_REV5.PDF
