Black Box LRXI User manual

®
®LRXI Industrial Fiber Extender
Welcome
Thank you for choosing the Black Box LRXI Industrial Fiber Extender units. Using ber optic links,
these compact units allow you to transfer multiple connections (including dual link DVI-D and HD
video) up to 2.5 miles (4 kilometers) from a host computer.
The high grade screening employed within the metal cased enclosures combined with the immunity
from interference of the ber optic links make the Black Box LRXI Industrial Fiber Extender units
highly suitable for use in ‘noisy’ industrial environments.
Quick Start
What’s in the box
• Local and Remote units
• 2 x Power adapters with locking connectors and country specic power cords
• 2 x matched SFP ber optic modules (multi-mode or single-mode)
• Combined dual-link DVI-D video plus USB cable (2m)
• 2 x 3.5mm jack audio cables (3m)
• Information wallet
continued overleaf
Local unit
(connect to host computer)
Remote unit
(connect to console peripherals)
PWRUSB VIDLNK
LRXI Fiber Extender
FIBER KVM EXTENSION
REMOTE
PWRUSB VIDLNK
LINK
LRXI Fiber Extender
FIBER KVM EXTENSION
LOCAL
Accessing the management application
Black Box LRXI Industrial Fiber Extender units generally congure themselves automatically, collecting
EDID information from the attached monitor and passing it to the host computer. In most cases
the units will begin working together correctly as soon as they are connected. Where conguration
changes are required (or remote monitoring is required), the management application provides an
intuitive user interface.
To access the management application
1 Use a computer that is directly or indirectly (i.e. via a network switch) connected to the Ethernet
management port on the LRXI Local unit.
2 Run a web browser on your computer and enter the IP address of the Local unit. Run a web
browser on your computer and enter the IP address of the Local unit. By default, the IP address
is set to 192.168.1.22. If required, you can change the default IP address or alternatively, choose
automated address selection by DHCP server.
3 If requested, enter the registered user name and password to log on (the default user name and
password are ‘admin’ and ‘password’ respectively).
 The Dashboard page should be displayed, which shows a real-time representation of the LRXI
Industrial Fiber Extender installation.
 Use the menu on the left side to display other pages.
Use the Online Support option to make contact with Black Box through the main website.

Local unit
(connect to host computer)
OPTIONS
12V 1.5A
INDOOR USEONLY
USB
port
Audio
line in
jack
Options
port
(RS232)
Audio
line out
jack
Ethernet
management
port
DVI-D dual-link
video input
port
12VDC
power
port
OPTIONS
12V 1.5A
INDOOR USEONLY
LINK
SFP
module
slot
Audio
line in
jack
Options
port
(RS232)
Audio
line out
jack
2 x
USB ports
DVI-D dual-link
video output
port
12VDC
power
port
PWRUSB VIDLNK
LINK
LRXI Fiber Extender
FIBERKVM EXTENSION
LOCAL
SFP
module
slot
Status
indicators
Recessed
reset
button
FRONT
REAR REAR
Status indicators (both units)
LNK On once the ber optic link is
established. Flashes if a non-approved
SFP module is inserted.
USB On once the USB link is established.
Flashes if USB enters suspend mode.
VID On once the video signal is detected.
PWR On when power is applied.
PWRUSB VIDLNK
LINK
12V 1.5A
INDOOR USE ONLY
LINK
SFP
module
SFP
module Fiber optic
link
Remote unit
Local unit
Remote unit
(connect to console peripherals)
IMPORTANT
Ensure that power is isolated when connecting
and disconnecting items, particularly when
inserting or removing SFP modules.
PWRUSB VIDLNK
LRXI Fiber Extender
FIBERKVM EXTENSION
REMOTE
Headphone
jack
Microphone
jack
Status
indicators
2 x USB
ports
FRONT
Recessed reset button
ACU5600A-QS Rev 0.1a
