1. Specifications
Applications—RS-232 sync or async 2 sub-channel multiplexor
Capacity—(2) sync or (1) sync and (1) async RS-232 terminals, (1) sync RS-232
modem
Data Format—Data coding: synchronous or asynchronous
Data Rates—Async 600 bps to 19.2 kbps or sync up to 19.2 kbps with 38.4 kbps
composite
Data Interface—EIA RS-232C
Connectors—(3) DB25 female
Enclosure—Aluminum
Approvals—FCC Class A, UL®, CSA
Operating Temperature—32 to 122°F (0 to 50°C)
Relative Humidity—Up to 90% noncondensing
Altitude—Up to 10,000 feet (3048 m)
Power Requirements—110- or 220-VAC, 47-63 Hz, 5 W external wallmount
transformer
Size—2"H x 8.3"W x 6.1"D (5.1 x 21.1 x 15.5 cm)
Weight—2.25 lb. (1 kg)

7
TIME-DIVISION MULTIPLEXOR
2. Introduction
The Time-Division Multiplexor is a full-duplex, RS-232, 2-channel, time-division
multiplexor with an independent switch-selectable V.14/V.22-compliant
asynchronous-to-synchronous interface adapter on sub-channel 1. The composite
channel is designed to interface directly with a high-speed synchronous modem via
a straight-through cable. The unit operates by sequentially selecting a bit of data
from the sub-channel and then multiplexing it onto the composite channel. Each
sub-channel can operate at 1⁄2the composite channel rate. Standard DB25 female
connectors are provided on all sub-channels as well as the composite channel.
Power is provided by an external transformer connected through J1 (Power) on
the rear of the mutliplexor. The external power transformer is UL and CSA
approved.
Front-panel LEDs include SYNC and Power. When two TDMs are in sync with
each other and data transmission is possible, the SYNC LED should be lit. The
Power LED should be on at all times.
Three DB25 female connectors are provided for connecting the modem on the
composite port (J2) and two terminals. Channel 1 (J3) can be used for
synchronous or asynchronous operation. Channel 2 (J4) can be operated only as a
synchronous channel. Channel 1 must be used as either sync or async on both ends
of the circuit for the multiplexor to function properly.
Figure 2-1. Typical Application.
Async
Terminal
Sync
Terminal
Time-Division
Multiplexor
Time-Division
Multiplexor
Modem Modem
Host
Processor

8
TIME-DIVISION MULTIPLEXOR
3. Setup and Installation
3.1 Installation
Set switches to match the required configurations as described in Sections 3.2
through 3.5. The cabling between each device and the Time-Division Multiplexor
must be terminated with male connectors. Character length and stop-bit reduction
only apply to channel 1 when it is selected for asynchronous operation.
3.2 Character Length
SW1 positions 1 and 2 select the character length. The character length includes
the start, stop, and any parity bits. 10-bit length is 1 start bit, 8 data bits, and 1 stop
bit. Figure 3-1 outlines all the available character bit lengths available.
3.3 Stop-Bit Reduction
SW1 position 3 selects the percentage of stop-bit reduction to occur when the sync
rate is faster than the async rate. Setting SW1 position 3 to ON will select 25% stop-
bit reduction. Setting SW1 position 3 to OFF will select 12.5% stop-bit reduction.
3.4 Channel 1 Sync/Async
SW1 position 5 selects channel 1 as a sync or async channel. This selection must be
the same on both ends of the circuit for the units to operate correctly. Setting SW1
position 5 to ON will select asynchronous operation on channel 1. Setting SW1
position 5 to OFF will select synchronous operation on channel 1.
3.5 Equipment Grounding
SW1 position 6 connects Pin #1 (Chassis Ground) to Pin #7 (Signal Ground).
3.6 Factory Straps
SW1 position 4 is not used. It must be in the OFF position. Jumpers JP1 through
JP3 must be installed for proper operation.

9
TIME-DIVISION MULTIPLEXOR
3.7 Board Layout and Jumper Settings
Figure 3-1. Board Layout.
Power
Connector
J1
JP3
JP2 JP1
Power Sync
Factory Test
Jumpers
MUST BE IN
Character
Length
ON OFF
{
25% Stop Bit Reduction = ON/12.5% Stop Bit Reduction = OFF
Factory Test, MUST BE OFF
Chan 1 Async = ON/Chan 1 Sync = OFF
Signal Ground Connected to Chassis Ground = ON
J2 J3 J4
Composite
(Modem)
Channel 1
(Terminal)
Character Length — SW1
1 2 Length
OFF OFF 10 Bits
ON OFF 11 Bits
OFF ON 8 Bits
ON ON 9 Bits
Channel 2
(Terminal)
1 2 3 4 5 6
