Black Box VX-1002-TX User manual

Order toll-free in the U.S. or for FREE 24/7 technical support:
Call 877-877-BBOX (outside U.S. call 724-746-5500)
www.blackbox.com • [e-mail]
Contact
Information
Extend an HDMI or VGA signal up to 328 feet
(100 meters) over a single CATx cable.
• Wallplate transmitter design makes installation simple.
• Requires a compatible receiver at the other end of the link.
VX-1002-TX
VX1000 Series Wallplate Transmitter—HDMI, VGA

877-877-2269 | blackbox.com
Page 2
FCC and IC RFI Statements/NOM Statement
FEDERAL COMMUNICATIONS COMMISSION AND INDUSTRY
CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS
This equipment generates, uses, and can radiate radio-frequency energy, and if
not installed and used properly, that is, in strict accordance with the manufac-
turer’s instructions, may cause interference to radio communication.
It has been tested and found to comply with the limits for a Class A computing
device in accordance with the specifications in Subpart B of Part 15 of FCC
rules, which are designed to provide reasonable protection against such
interference when the equipment is operated in a commercial environment.
Operation of this equipment in a residential area is likely to cause interference,
in which case the user at his own expense will be required to take whatever
measures may be necessary to correct the interference.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
This digital apparatus does not exceed the Class A limits for radio noise emis-
sion from digital apparatus set out in the Radio Interference Regulation
of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques
dépassant les limites applicables aux appareils numériques de classe A prescrites
dans le Règlement sur le brouillage radioélectrique publié par Industrie Canada.
Normas Oficiales Mexicanas (NOM)
Electrical Safety Statement
INSTRUCCIONES DE SEGURIDAD
1. Todas las instrucciones de seguridad y operación deberán ser leídas
antes de que el aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas
para referencia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones
de operación deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.

877-877-2269 | blackbox.com Page 3
NOM Statement
5. El aparato eléctrico no deberá ser usado cerca del agua — por ejemplo,
cerca
de la tina de baño, lavabo, sótano mojado o cerca de una alberca, etc.
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales
que sean recomendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea
recomendado por el fabricante.
8. Servicio — El usuario no debe intentar dar servicio al equipo eléctrico más
allá a lo descrito en las instrucciones de operación. Todo otro servicio
deberá ser referido a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no
interfiera su uso. La colocación del aparato eléctrico sobre una cama, sofá,
alfombra o superficie similar puede bloquea la ventilación, no se debe
colocar en libreros o gabinetes que impidan el flujo de aire por los orificios
de ventilación.
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor
como radiadores, registros de calor, estufas u otros aparatos (incluyendo
amplificadores) que producen calor.
11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo
del tipo descrito en el instructivo de operación, o como se indique en el
aparato.
12. Precaución debe ser tomada de tal manera que la tierra fisica y la
polarización del equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que no
sean pisados ni pellizcados por objetos colocados sobre o contra ellos,
poniendo particular atención a los contactos y receptáculos donde salen
del aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las
recomendaciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las
lineas de energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no
sea usado por un largo periodo de tiempo.

877-877-2269 | blackbox.com
Page 4
NOM Statement
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean
derramados sobre la cubierta u orificios de ventilación.
18. Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en su
desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.

877-877-2269 | blackbox.com Page 5
Trademarks/Safety Instructions
TRADEMARKS USED IN THIS MANUAL
Black Box and the Double Diamond logo are registered trademarks of
BB Technologies, Inc.
Blu-ray™is a trademark of Blu-ray Disc Association.
Any other trademarks mentioned in this manual are acknowledged to be
the property of the trademark owners.
Important Safety Instructions
1. Do not expose this apparatus to rain, moisture, dripping or splashing water
and do not place objects filled with liquids, such as vases, on the apparatus.
2. Do not install or place this unit in a bookcase, built-in cabinet or in another
confined space. Make sure the unit is well ventilated.
3. To prevent risk of electric shock or fire hazard caused by overheating, do not
obstruct the unit’s ventilation openings with newspapers, tablecloths,
curtains, and similar items.
4. Do not install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
5. Do not place sources of flames, such as lighted candles, on the unit.
6. Clean this apparatus only with a dry cloth.
7. Unplug this apparatus during lightning storms or when unused for long
periods of time.
8. Protect the power cord from being walked on or pinched particularly at
plugs.
9. Only use attachments/accessories specified by the manufacturer.
10. Refer all servicing to qualified service personnel.
Disclaimer
Black Box Network Services shall not be liable for damages of any kind, includ-
ing, but not limited to, punitive, consequential or cost of cover damages, result-
ing from any errors in the product information or specifications set forth in this
document and Black Box Network Services may revise this document at any
time without notice.

877-877-2269 | blackbox.com
Page 6
Table of Contents
Table of Contents
1. Specifications........................................................................................ 7
2. Overview ............................................................................................ 10
2.1 Introduction ............................................................................. 10
2.2 Features.................................................................................... 10
2.3 What's Included........................................................................11
2.4 Hardware Description.............................................................. 12
3. Automatic Input Detection ................................................................ 14
4. EDID Presets ....................................................................................... 16
5. Hardware Installation ......................................................................... 17
6. Troubleshooting ................................................................................. 18

877-877-2269 | blackbox.com Page 7
Chapter 1: Specifications
1. Specifications
Wallplate Transmitter (VX-1002-TX)
Video
Input (1) HDMI IN, (1) VGA IN, (1) Audio IN
Input Signal Type HDMI 1.4 w/HDCP
Resolution
Support
VGA: 1920 x 1200, 1920 x 1080, 1680 x 1050,
1600 x 1200, 1600 x 900, 1400 x 1050, 1440 x 900,
1366 x 768, 1280 x 1024, 1280 x 800, 1280 x 768,
1280 x 720, 1024 x 768, 800 x 600, 640 x 480
@60 Hz;
HDMI: Up to 3840 x 2160
Input Video Level 0.5-1.0 Vp-p
Maximum Pixel
Clock
297 MHz
Output (1) HDBaseT Out
Output Signal
Type
HDBaseT
Video Impedance 100 ohms

877-877-2269 | blackbox.com
Page 8
Chapter 1: Specifications
Wallplate Transmitter (continued)
Audio
Input (1) 3.5-mm mini jack, stereo audio binding with VGA
input
Supported Audio
Format
HDMI: Stereo, LPCM 5.1 LPCM 7.1, Dolby True HD,
DTS-HD Master Audio;
VGA: Stereo
General
Environment
Operating
Temperature
32 to 113° F (0 to 45° C)
Storage
Temperature
-4 to +158° F (-20 to +70° C)
Humidity 10 to 90%, noncondensing
ESD Protection Human-body model
±8 kV (air-gap discharge)/4 kV (contact discharge)
Power
Power Supply 12 VDC, 1.5 A/PoH
Power
Consumption
(Maximum)
3.36 W, powered by HDBaseT receiver with POH
Mechanical
Dimensions 4.16"H x 3.58"W x 1.16"D (10.56 x 9.1 x 2.94 cm)
Weight 0.48 lb. (0.22 kg)
Approvals CE, FCC, RoHS, PoH

877-877-2269 | blackbox.com Page 9
Chapter 1: Specifications
Cable Specifications
Cable Type Range Supported Video
CAT5e/6 328 ft. (100 m) Up to 1080p @ 60 Hz, 36-bit
230 ft. (70 m) 3840 x 2160 @ 30 Hz, 4:4:4 bit
CAT6a/7 328 ft. (100 m) 1080p @ 60 Hz, 48-bit;
1080p @ 60 Hz, 3D;
3840 x 2160 @ 60 Hz, 4:2:0 bit
NOTE: We recommend using straight-through Category cables wired to T568B
standard.

877-877-2269 | blackbox.com
Page 10
Chapter 2: Overview
2. Overview
2.1 Introduction
The VX1000 Series Wallplate Transmitter - HDMI, VGA (VX-1002-TX) is a 2-to-1
wallplate HDBaseT transmitter with one HDMI input, one VGA input, and one
HDBaseT output. It enables transmission of an HDMI signal over a single
CAT5e/6 cable up to 328 feet (100 meters) for 1080p HD video and HD Audio
distribution, or 230 feet (70 meters) for 3840 x 2160 @60 4:2:0 8-bit HD video
and HD Audio distribution.
This wallplate HDBaseT transmitter simplifies installation and also creates a clean
seamless look with the décor.
VGA and HDMI inputs are automatically selected and switched when the unit
detects a signal. A smart detection feature prioritizes inputs. You can also switch
the inputs manually—just press the switch button on the front panel of the
transmitter.
The VX-1002-TX also supports bi-directional IR and Ethernet passthrough. It
offers an excellent solution to any commercial or residential environment where
switching between VGA with audio and HDMI over distance is required.
NOTES:
1. Must be used with a compatible receiver (VX-1003-RX or VX-1001-RX).
2. With 48-V PoH integrated inside, the extender pair needs just one power
supply connected to the RX unit to power both units.
2.2 Features
• Provides 2:1 switching between VGA and HDMI inputs to HDBaseT output.
• Robust HDBaseT technology distributes lossless 3840 x 2160 @ 30 Hz HD
video and audio.
• Transmits an HDMI signal over a single CAT5e/6 cable under recommended
conditions.*
*NOTES:
- 230 feet (70 meters): 3840 x 2160 @ 60 4:2:0 8-bit / 24-bit True Color with
Chroma subsampling color palette 4K @ 60 4:2:0.
- 328 feet (100 meters): 1920 x 1080p HD video @ 60 Hz / 36bit Deep Color
• Installed in a 2-gang US Decora wall plate.
• EDID management for VGA input.
• Automatic input detection.
• HDMI V1.4 compliant.

877-877-2269 | blackbox.com Page 11
Chapter 2: Overview
• 4K compatible—60 Hz, 4:2:0.
• HDCP compliant.
• Bi-directional IR supported.
• Supports Ethernet passthrough.
• Supports one-way PoH (Power over HDBaseT, can be powered by the HDBaseT
receivers with PSE (Power Sourcing Equipment).
• Compact size for convenient and unobtrusive installation.
2.3 What's Included
Your package should include the following items. If anything is missing
or damaged, contact Black Box Technical Support at 877-877-2269
or [e-mail].
• VX1000 Series Wallplate Transmitter - HDMI, VGA (VX-1002-TX)
• (1) 3.81-mm Phoenix male connector (9-pin)
• (1) cover with four screws
• This user manual
Additional items you will need:
• (1) VX1000 Series Receiver (VX-1001-RX or VX-1003-RX) or
(1) Presentation Switcher (AVSC-0802H).

877-877-2269 | blackbox.com
Page 12
Chapter 2: Overview
2.4 Hardware Description
Figures 2-1 and 2-2 illustrate the front and back panels of the transmitter.
Table 2-1 describes its components.
4 5 6 7
1
311 10
2
8
9
Figure 2-1. Transmitter front panel.
14 15 16
12 13
Figure 2-2. Transmitter back panel.

877-877-2269 | blackbox.com Page 13
Chapter 2: Overview
Table 2-1. Transmitter components.
Number Component Description
1VGA IN Connects to VGA source device.
2Audio Audio input (for use with VGA source)
3HDMI IN Connects to HDMI source device.
4HDMI LED ON: HDMI signal transmitted.
OFF: No HDMI signal transmitted or unstable.
5VGA LED ON: VGA signal transmitted.
OFF: No VGA signal transmitted or unstable.
6HDCP LED ON: HDMI video is being transmitted.
Blinking: Non-HDCP video is being transmitted.
OFF: No video is being transmitted.
7LINK LED ON: HDBaseT link is normal.
Blinking/OFF: No HDBaseT link or unstable.
8Select button Press this button to select the input source.
9IR sensor IR IN with built-in IR receiver (30 to 55 kHz).
10 USB Type A port Connect to USB/host device.
11 EDID DIP switch Used to select EDID presets.
12 (1) RJ-45 port Connects to Ethernet device.
13 (1) RJ-45
HDBaseT OUT
port
Connects to HDBaseT IN port of the receiver
(VX-1001-RX).
14 Power IN: Connects to 12 V power source.
OUT: Maximum power output is 12 V, 400 mA.
15 RS-232 RS-232 passthrough.
16 IR OUT Connects to IR emitter cable.

877-877-2269 | blackbox.com
Page 14
Chapter 3: Automatic Input Detection
3. Automatic Input Detection
• If the current signal is VGA input, the transmitter will not automatically switch
to HDMI input.
• The button switch will recognize the VGA and HDMI input signals only if they
are both valid. For example, if no HDMI input signal is present, the transmitter
cannot switch to HDMI input even using the button.
After power on, the input signal is automatically selected according to the
following tables.
Table 3-1. Power on to detect the input signal.
HDMI IN VGA IN Input Select
Yes No / Yes HDMI IN
No No HDMI IN
No Yes VGA IN
Table 3-2. After power on, press button to switch input.
Current Input HDMI IN VGA IN Button Select
HDMI IN No / Yes No HDMI IN
HDMI IN Yes Yes VGA IN
VGA IN Yes Yes HDMI IN
VGA IN No Yes VGA IN

877-877-2269 | blackbox.com Page 15
Chapter 3: Automatic Input Detection
Table 3-3. After power on, change the input signal state.
Current Input HDMI IN VGA IN Input Select
HDMI IN Yes No—>Yes /
Yes—>No
HDMI IN
HDMI IN No No —>Yes VGA IN
HDMI IN Yes—>No No HDMI IN
HDMI IN Yes—>No Yes VGA IN
VGA IN No —>Yes/
Yes—>No
Yes VGA IN
VGA IN No / Yes Yes —> N o HDMI IN

877-877-2269 | blackbox.com
Page 16
Chapter 4: EDiD Presets
4. EDID Presets
For VGA input, see the next table.
Table 4-1. Set EDID DIP switch for VGA input.
DIP Switch Setting VGA Input
1 = OFF (DOWN)
2 = OFF (DOWN)
3 = OFF (DOWN)
Select 1280 x 800 as native video
1 = OFF (DOWN)
2 = OFF (DOWN)
3 = ON (UP)
Select 1920 x 1200 as native video.
1 = OFF (DOWN)
2 = ON (UP)
3 = OFF (DOWN)
Select 1920 x 1080 as native video.
This is the default value.
1 = OFF (DOWN)
2 = ON (UP)
3 = ON (UP)
Select 1280 x 720 as native video.
1 = ON (UP)
2 = OFF (DOWN)
3 = OFF (DOWN)
Select 1024 x 768 as native video.
1 = ON (UP)
2 = OFF (DOWN)
3 = ON (UP)
Select 800 x 600 as native video.
1 = ON (UP)
2 = ON (UP)
3 = OFF (DOWN)
Reserved
1 = ON (UP)
2 = ON (UP)
3 = ON (UP)
Reserved
NOTE: To make the change effective, unplug the VGA cable and plug it in again.
For HDMI input:
Always passthrough copy from the detected sink.

877-877-2269 | blackbox.com Page 17
Chapter 5: Hardware Installation
5. Hardware Installation
1. Connect an HDMI or VGA input source (such as Blu-ray™) to the VX-1002-TX
transmitter.
NOTE: Be careful when connecting cables—do not force the cable ends into the
connectors.
2. Connect a good quality, well-terminal CAT5e/6 cable of no more than
230 feet (70 m) for 4K or 328 feet (100 m) for 1080p from the HDBaseT OUT
port of the Transmitter to HDBaseT IN Input of the HDBaseT receiver.
NOTE: 230 feet (70 m) @ 4K or 328 feet (100 m) @ 1080p video are maximum
recommended transmission distances for this model and denote perfect
transmission conditions—including straight cable runs with no electrical
interference, bends, kinks, patch panels, or wall outlets.
If either of the above is a factor in your installation, transmission range may be
affected—avoid where possible.
3. Connect an HDMI display device (LED/LCD display or projector) to the HDMI
OUT port on the HDBaseT receiver.
4. Connect the IR emitter cable to the IR OUT port of the VX-1002-TX, connect
the IR receiver cable to the IR RX port of the receiver, and connect the IR
emitter to the IR TX port of the receiver.
5. Power on the HDBaseT receiver. If the HDBaseT receiver doesn't support the
PSE function, connect a 12 V power supply to the VX-1002-TX transmitter.
Document camera
Ethernet switch
VGA IN
HDMI IN
Ethernet
PC
USB
HDBaseT
HDBaseT receiver
HDMI USB USB
Monitor
Keyboard and mouse
Figure 5-1. Typical application.

877-877-2269 | blackbox.com
Page 18
Chapter 6: Troubleshooting
6. Troubleshooting
The majority of HD distribution installation issues are either caused by minor
connection errors, communication problems between devices, or when the
transmission of high signal bandwidth is attempted using insufficient cable.
If you encounter any technical difficulties when installing and configuring the
matrix, refer to the following troubleshooting checklist. If you cannot resolve
your problem, contact Black Box Technical Support at 877-877-2269
or [e-mail].
Problem: No picture or poor-quality picture.
Possible Solutions:
1. Power—is your transmission device and receiver powered with correct LED
indication?
2. If possible, always use test equipment before installation and to troubleshoot
any problems.
3. Check that the display device supports HDCP, is switched to the correct
source input mode, and is compatible with the receiver—if you suspect any
issues, replace the display device with another model.
4. Distance—Is the cable too long for the signal to be transmitted effectively?
Make sure the cable distance matches the project requirements and is well
within the maximum transmission distance of the signal.
NOTE: If you need more distance than the transmitter can provide, use another
extender set to be sure that the signal reaches its destination effectively.
5. Cable joins—Joins in the cable run or RJ-45 connectors can impact signal
strength, resulting in reduced transmission that may manifest itself in
incorrect picture quality, picture dropping out, or no picture.
6. Cable choice and signal reduction—Are stranded patch leads used as
interconnects between patch panels or wall outlets? CCA (Copper Clad
aluminum) cables being used? These can reduce transmission rates by up to
40%—we recommend solid-core straightthrough cables with minimum con-
nections used wherever possible.
7. Correct connection— Double-check that all UTP, HDMI, power and IR cables
are connected to the correct ports.
NOTE: Even a fraction off target can make the difference between a perfect
picture and a blank screen. Double-check all connections are firmly made
in the correct ports.

877-877-2269 | blackbox.com Page 19
Chapter 6: Troubleshooting
8. Is the cable wired to 568B standard? Is the cable wired and terminated
correctly and are those terminations connected to the correct ports? Incorrect
wiring and termination will result in unstable operation or a blank screen.
9. Electrical interference—could any form of interference be generated? If so,
attempt to remove the source of electrical interference or move the cable run
to decrease the effects of the interference.
10. Is a picture displayed when connecting the source directly to the display? If
not, then the problem could be with the input or output device rather than
the cable or matrix itself.
11. HDMI lead condition and quality—HDMI cables and connectors are delicate
and can be damaged much easier than component or coax cable. Lead
quality varies dramatically, particularly in lower price brackets. Swap HDMI
leads and check operation—damage to or quality of your leads could be
the problem. If in doubt, swap them over. Be careful when inserting
and extracting your HDMI from matrix ports so you don’t damage the
connectors or ports.
12. Picture speckles/HD “noise”— A poorly established signal that may be
caused by poor quality or excessive HDMI cable lengths. Try swapping the
display adapters from a location that is functioning properly or swapping the
outputs of the matrix switch used.
If the problem remains on the same screen, this may be caused by a
connection problem between matrix and display—turn off all equipment
and swap the signal carrying cables at both ends to determine if the cable
or termination is at fault.
HD Noise (NO image) may be an HDCP Issue between the source and dis-
play, but poor cabling can also cause this via poor communication.
13. Blu-ray: 3D—Is the equipment used 3D enabled/compatible? Is a 3D disk
playing in a 3D-enabled Blu-ray player or through a compatible AV receiver?
14. Color distortion—a pink or green screen indicates an incompatibility
between color spacing formats —the commonly used RGB or YUV used by
older displays. Some sources allow switching between RGB and YUV which
may solve any color problems. If not, change the HDMI cable between the
source and the matrix to rule out defective cabling.

877-877-2269 | blackbox.com
Page 20
Chapter 6: Troubleshooting
Problem: No sound or poor-quality audio.
Possible Solutions:
Audio is transmitted within the video signal—there is no separate audio track—
so a problem with sound will be accompanied by a problem with picture. But
you might have technical issues with audio caused by problems communicating
between sources, displays, and/or AV receiver settings.
1. Have specific speaker sets or zones been enabled? Some AV receivers allow
individual speaker selections assigned to specific zones in the set up so check
the speakers used are fully connected to the amplifier and correctly assigned
within the system set up. An EDID issue might occur when the source reads
the audio EDID from the display and only requests two-channel audio. You
might need to copy EDID from the AV receiver or use an embedded EDID in
the AMP or matrix.
NOTE: If you have problems when using an AV receiver, the cause is usually
the settings of the AV receiver itself. Refer to the AVR manufacturer’s
guidelines for the correct settings to use for your requirements.
2. Consistency of audio output between devices—Is there any discrepancy
between the audio output of the source, the audio or zonal settings of the
AV receiver, and the speaker configuration used needed for successful audio
replication? If outputting 7.1, make sure all devices connected are also
outputting 7.1.
NOTE: Some source device settings might allow audio output through a TV
or an HDMI port. If using an AV receiver, be sure to select the HDMI
output option.
3. Do all the local sources work through the AV receiver? Check the operation
of each source individually.
4. Bandwidth—If using a graphics-based source (such as a PC/Mac/
media server), make sure the source resolution is set to a maximum of 1080p,
50 Hz. Higher resolutions available for graphics-based systems require higher
bandwidth that may affect transmission of signals as well as incompatibility
with devices.
