Blackmagicdesign Video Recorder User manual

Operation Manual
Video Recorder
Mac OS X™
January 2009
USO RESTRITO

2Contents
Welcome 3
Contents of Package 4
Video Recorder at a Glance 5
Software Installation 6
Hardware Installation 7
Testing the Installation 8
Connections 9
Record 13
Playback 18
Help 19
Support 27
Warranty 28
Video Recorder Operation Manual
USO RESTRITO

3Welcome Thank you for purchasing Video Recorder. We hope you have a lot of fun taking your old
videos and turning them into modern digital video and audio. Then share your movies
with anyone via iPod™, iPhone™, YouTube™, AppleTV™or even watch full resolution
video on your computer!
Video Recorder can convert your old NTSC, PAL or SECAM videos in to modern digital
video using high quality H.264 encoding. Previously H.264 encoding was either a very
slow software process or required fast, expensive computer hardware. Video Recorder
does all the encoding work in real time so you don’t need an expensive computer to
convert your precious video archives in to H.264 digital video.
Video Recorder produces stunning quality digital video from the highest quality
component analog video as well as regular composite analog video. It can even work
with S-Video via a third party S-Video breakout cable (not included).
We think it should take you approximately 5 minutes to complete the
installation. Before you install Video Recorder, please check our website at
www.blackmagic-design.com/videorecorder and click the support page to download
the latest updates to this manual and Video Recorder software. Lastly, please register
your Video Recorder when downloading software updates. We would love to keep you
updated on new software updates and new features for your Video Recorder. We are
constantly working on new features and improvements, so we would love to hear your
suggestions for improvements to the software!
Grant Petty
CEO Blackmagic Design
USO RESTRITO

4Contents of Package
1. Video Recorder 2. USB Extension Cable 3. CD Software
USO RESTRITO

5Video Recorder at a Glance
USB 2.0 Connection to Computer
Audio Right
Audio Left
Analog Video
Analog Video
Analog Video
(Red)
(White)
(Red)
(Green)
(Blue)
USO RESTRITO

6Software
Installation
Please install the Video Recorder software before using your Video Recorder. We always
recommend that you visit the support page on our website and download the latest
Video Recorder software from www.blackmagic-design.com/videorecorder/support.
If you don’t have Internet access, you can use the Software CD, which is included in the
box, but do check for the latest version on the Internet when you can.
To install the software, open the
Software CD or the downloaded
disk image.
Drag the Blackmagic Video Recorder icon … ... to your Applications folder.
USO RESTRITO

7Hardware
Installation
To install the hardware, simply connect Video Recorder to the included USB extension
cable and then connect the cable to a USB 2.0 port on your computer. While you can
connect the Video Recorder directly to a USB port on your computer, it is safer and
more convenient to use the short USB extension cable. This minimizes the possibility
of damaging the Video Recorder, or the computer, should the Video Recorder be
accidentally bumped.
Video Recorder may not work reliably when connected to a USB hub, especially a hub
which is sharing a single USB connection with several USB devices. We recommend
the Video Recorder be connected to a dedicated USB 2.0 port on your computer,
preferably using the included USB extension cable.
USO RESTRITO

8Testing the
Installation
It’s a good idea to test that your Video Recorder is working when you’ve finished
installing the software and hardware. To do so, open the Applications folder and launch
the Blackmagic Video Recorder software. If the software and hardware are both installed
and working, the Record button should be a bright red color. If the Video Recorder
is not connected or not working, the Record button will be a gray color. Try unplugging
and reinserting the Video Recorder USB connector and see if the Record button becomes
red. If not, try another USB port or test the Video Recorder on another computer. Once
the Record button shows red, you’re ready to start recording. Congratulations!
The gray Record button indicates that
Video Recorder is not working
The red Record button indicates that
Video Recorder is successfully working
USO RESTRITO

9Connections Video Device Compatibility
You can connect many different kinds of video devices to your Video Recorder including
Hi8, Betamax, VHS, S-VHS and MiniDV video cameras as well as VHS tape players,
DVD players and digital set top boxes.
If you have been given a DVD of a special event, such as a wedding or birthday, you
can use Video Recorder to capture the movie off DVD for playback on your iPod
or to share on the Internet via your own website or even on YouTube. Make sure
you have permission to make copies of the DVD. Copy-protected, commercial DVD’s
should never be copied and most DVD players will prevent you from doing this.
It is also possible to record the analog output of some digital set top boxes. Some
channels might be free to copy and others might be copy-protected. You can use
Video Recorder to capture the free to copy channels but do ensure you don’t copy
Copyright material.
No matter from which kind of video device you want to record, the procedure will be
the same so it’s always easy. There are three kinds of analog video supported by Video
Recorder: Composite, S-Video and Component.
In the Video Recorder software, click on the icon for Component, Composite or S-Video
to match your video source. Connect the video and audio cables, as shown in the
following pages of this manual, and you will be ready to record.
Most video devices include the video and audio cables you will need. They can also be
purchased at electronic stores or supermarkets, as well as video and audio resellers.
Video Device
Compatibility
Video camera
Video Tape
Player
DVD Player
Set Top Box
USO RESTRITO

Composite — Good analog video
Composite is the oldest and most common analog video format and is often regarded
as “regular video”. You are likely to find it on almost any video device. Composite video
uses a single cable and is usually identified by a single, yellow connector. It should be
connected to the green input on Video Recorder.
AUDIO
OUT
VIDEO
OUT S-VIDEO
COMPONENT VIDEO OUT
RL
AUDIO
OUT
VIDEO
OUT S-VIDEO
COMPONENT VIDEO OUT
RL
AUDIO
OUT
VIDEO
OUT S-VIDEO
COMPONENT VIDEO OUT
RL
10 Connections
USO RESTRITO

S-Video — Better analog video
S-Video is higher quality than composite video and became popular in homes during
the late 1980’s and 90’s. When connecting S-Video to Video Recorder, an inexpensive,
third party, breakout cable (not included) is required. The breakout cable adapts a
single, S-Video connector to two RCA connectors which can be connected to the green
and blue inputs on Video Recorder. The two RCA connectors are usually white and
some other color, typically yellow or red. They should be connected to the blue and
green inputs on Video Recorder respectively.
AUDIO
OUT
VIDEO
OUT S-VIDEO
COMPONENT VIDEO OUT
RL
AUDIO
OUT
VIDEO
OUT S-VIDEO
COMPONENT VIDEO OUT
RL
AUDIO
OUT
VIDEO
OUT S-VIDEO
COMPONENT VIDEO OUT
RL
11 Connections
USO RESTRITO

Component — Best analog video
Component is the newest and highest quality analog video connection and has
become popular in homes during the 2000’s. It uses three cables to transmit all
of the color information. The connectors on the three cables are usually colored red,
green and blue.
AUDIO
OUT
VIDEO
OUT S-VIDEO
COMPONENT VIDEO OUT
RL
AUDIO
OUT
VIDEO
OUT S-VIDEO
COMPONENT VIDEO OUT
RL
AUDIO
OUT
VIDEO
OUT S-VIDEO
COMPONENT VIDEO OUT
RL
12 Connections
USO RESTRITO

13 Record Overview
The terms “capture” and “record” have the same meaning when using Video Recorder
and both are used in this manual. Before clicking the large, red Record button, there
are a few options you might like to choose.
Video Recorder automatically detects if it is receiving a NTSC, PAL or SECAM video
signal so you don’t have to set these options.
Cropping
You can use the cropping handles around the picture to cut off video you don’t want to
capture. In the example on this page, the black bars above and below the picture have
been cropped so that only the active picture is recorded.
USO RESTRITO

14 Record Select a Device
Select the device on which you want to play back your video. The Device buttons will
then set the resolution at which the movie files will be recorded. You can choose Full
Resolution if you want the maximum quality picture to be preserved. Simply click on the
icons for iPod Small, iPod Large, YouTube, iPhone, AppleTV or Full Resolution video.
The data rate will automatically be set to an appropriate quality for playback on your
chosen device. You can manually change the data rate if you prefer.
If you can’t see your video device pictured, don’t worry! If your iPod has a touchscreen
display, click the iPhone icon as it has the same display resolution as the iPod Touch.
All conventional iPods support the iPod Small setting and we recommend you choose
this setting so you can fit a lot of movies on your iPod. Newer versions of conventional
iPods can play back higher resolution video but there is usually little point in choosing
iPod Large as the iPod screens are still the same resolution as earlier iPods.
If you’ve got both an AppleTV, and one of the newer conventional iPods, choose the
iPod Large setting as the one movie file will play on both devices. This is great because
you don’t have to capture your movie twice to work on the two different devices.
Enter the File Name which you want to give to your captured video. The video will be
captured to your desktop.
iPhone Apple TV
tv
Full Res
iPod Small YouTubeiPod Large
iPhone Apple TV
tv
Full Res
iPod Small YouTubeiPod Large
USO RESTRITO

15 Record Select Recording Options
You might also wish to “Select Recording Options” but this is entirely optional and you
don’t have to use them:
1. Enable this option if you want to upload files to web sites and restrict the length to
several minutes. Many files on YouTube have a maximum length of 10 minutes.
Video Recorder will split the recording into seperate movie files of the specified
number of minutes.
2. Enable this option if you want to save files which will be copied to removable
media such as CD’s or DVD’s. Video Recorder will split the recording into seperate
movie files of the specified file size.
3. Enable this option if you want Video Recorder to automatically stop
recording after a specified number of minutes. This could be useful if
your Video Recorder will be left unattended and you don’t want it to
record forever!
4. Enable this option if you want your captured videos to be copied to your iTunes
library for copying to your iPod, iPhone or AppleTV.
If you enable more than one of the “Select Recording Options” 1, 2 or 3, the option
which takes priority will be the one which occurs first and produces the smallest files.
Save videos into minute files
Save videos into MB files
Stop recording in minutes
Load into iTunes
USO RESTRITO

16 Record Audio/Video Controls
Look at the video preview in Video Recorder and see if your video looks as clear as you
would expect. If the picture looks overly dull, vivid, bright or dark, or if the audio is too
low or high, click on the A/V Controls button to the left of the audio level meter.
Adjust the sliders for Brightness, Contrast, Color and Audio and you will immediately
observe the change in the video preview.
Tip: When recording old VHS tapes, you will often find the colors look overly saturated
and noisy. The noise is contained within the color so it can be a good idea to reduce the
color until it looks “normal” and the noise will also be reduced in the picture.
Brightness
Contrast
Audio
Reset
A/V Controls
Color
Click on the A/V Controls
button to reveal the A/V
Controls window.
USO RESTRITO

17 Record Recording!
You are almost ready to record your video. If the video preview looks blocky or
unclear, click the Quality popup menu above the Record button and increase the
Quality setting to a higher data rate. Once you are happy with the quality of the video
preview, click the red Record button or alternatively go to the Recording menu and
select Start Recording (zR). The Record button will change from being a solid, red
button to an illuminated, red button. When you want to stop the recording, click the
same button again.
100 kb/s
200 kb/s
300 kb/s
400 kb/s
500 kb/s
1.0 Mb/s
1.5 Mb/s
2.0 Mb/s
2.5 Mb/s
3.0 Mb/s
3.5 Mb/s
100 kb/s
200 kb/s
300 kb/s
400 kb/s
500 kb/s
1.5 Mb/s
2.0 Mb/s
2.5 Mb/s
3.0 Mb/s
3.5 Mb/s
1.0 Mb/s
100 kb/s
200 kb/s
300 kb/s
400 kb/s
500 kb/s
1.5 Mb/s
2.0 Mb/s
2.5 Mb/s
3.0 Mb/s
3.5 Mb/s
1.0 Mb/s
Click on the triangle to open the
Quality setting popup menu and
adjust the data rate if desired.
Then click the red Record button.
The Record button becomes
illuminated when recording.
Push it again to stop recording.
USO RESTRITO

18 Playback When your recording has finished, you will find the movie files saved to your desktop.
They will open in QuickTime Player unless you have changed the default player to
another application such as VLC Player or iTunes. If you chose the option to load into
iTunes, you will find your movies ready to play from within iTunes and to send to your
AppleTV, iPod or iPhone.
VLC PlayerQuickTime Player iTunes
USO RESTRITO

Audio output while recording
If Video Recorder is recording, and you then bring some other application to the
foreground, you will no longer be able to hear the audio being captured. If you wish
to hear audio even when Video Recorder is in the background, go to the Recording
menu and select “Audio output in Background”.
Avoiding video tearing during playback
If you find that areas of fast movement in your recorded video show horizontal, tearing
lines, this will be caused by the interlaced video you are attempting to capture.
Most NTSC, PAL and SECAM video is made from two, interlaced fields of video.
Go to the Recording menu and enable “Remove Fields”. Repeat the capture and see
if this helps to avoid the tearing problem.
“Remove Fields” cannot be used with the YouTube setting and so the menu option is
grayed out when using the YouTube setting.
19 Help
USO RESTRITO

20 Help Blackmagic Video Recorder will not open
If the Blackmagic Video Recorder software will not open, or reports an error while
opening, it is possible that a component of the software is missing and there are a
range of rare scenarios which could explain this. The quickest and most likely solution
is to visit our website at www.blackmagic-design.com/videorecorder/support and
download the latest Blackmagic Video Recorder software from the software downloads
area in the support pages. Install the software and then restart your computer.
Blackmagic Video Recorder should now work.
Record button is gray
If you find the Record button is gray, and the Blackmagic Video Recorder software will
not record, make sure that Video Recorder is directly connected to a USB port on your
computer using the included USB cable. Avoid connecting via a USB hub as Video
Recorder might not work correctly.
Try unplugging and reinserting the Video Recorder USB connector and observe
if the Record button becomes red. If the Record button remains gray, try another
USB port on the same computer or test the Video Recorder on another computer.
This test will tell you whether the problem is with the USB port, the computer or the
Video Recorder unit itself.
USO RESTRITO
