BLADEZ Elliptical X-350p User manual

OWNER’S MANUAL
CAUTION: Exercise of a strenuous nature, as is customarily done on this equipment, should not be
undertaken without first consulting a physician. No specific health claims are made or implied as they
relate to the equipment.
IMPORTANT: Read all instructions carefully before using this product. Retain this owner’s
manual for future reference.
Elliptical X-350p
BH North America Foothill Ranch, California 92610

TABLE OF CONTENTS
Assembly Instructions…………………........4-9
Elliptical Operations……………..................10-11
Maintenance…………………………............12
Exploded View ………...................................13
Parts List ………………….............................14
Attachment - A- Safety……………….….....1
Warranty……..………………………............15
Hardware Package Contents………...............2
Pre-Assembly Instructions……......................3

IMPORTANT SAFETY ADVICE
PRECAUTIONS
This elliptical has been designed and constructed to provide maximum safety. Nevertheless,
certain precautions should be taken when using exercise equipment. Read the whole manual
before assembling and using the elliptical. The following safety precautions should also be
observed:
1. Keep children or pets away from this equipment at all times. DO NOT leave them
unsupervised in the room where this elliptical is kept.
2. It can only be used by one person at a time.
3. If you experience dizziness, nausea, chest pains or any other symptom while using this
appliance the exercise.STOP SEEK MEDICAL ATTENTION IMMEDIATELY!
4. Use the unit on a mat placed level, solid surface. Adjust the stabilizer for assure stability.
5. Keep your hands well away from any of the moving parts.
6. Wear clothing suitable for doing exercise. Do not use baggy clothing that might get caught
up in the elliptical. Always wear running shoes or trainers when using the machine.
7. This appliance must only be used for the purposes described in this manual. DO NOT use
accessories that are not recommended by the manufacturer.
8. Do not place sharp objects near the machine.
9. Disabled people should not use the machine without the assistance of a qualified person or
a doctor.
10. Do warm up stretching exercises before using the equipment.
11. Do not use the elliptical if it is not working correctly.
KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE
ATTACHMENT - A
12. A parameter distance of 3 feet / 1meter is required before operating the unit.
13.This elliptical is not suitable for therapeutic use. Consult a physician prior to starting an exercise
program.
14.This elliptical should only be used after a through review of the operation manual and the warning
label.
Caution: Consult your doctor before beginning to use the . This advice iselliptical
especially important for those over 35 years of age or suffering from health problems. Read all of the
instructions before using any exercise equipment.
1

HARDWARE PACKAGE /PARTS/ TOOLS
Note: Use the tools only for this elliptical.
Base Frame
1
Upright Tube
Console
Pedal Support (right)
Pedal Support (left)
Pedals
Front stabilizer
Rear stabilizer
Swing arm handlebar
Fixed handlebar
Screw driver
M8 * 15/Allen head bolt
Wrench
Plastic cap/M8
M10/End cap
Bushing/15MM
Bushing/57.6MM
Screw M8*72
Washer 5/16 *16
10mm Washer
Screw M8*20
M8 Nylock nut
M3 Self tapping
M10 Nylock nut
Lubricant
Power adapter
1
1
1
1
2
1
1
1
2
1
1
1
1
2
14
8
4
2
2
4
2
4
8
12
2
1
1
1
Water Bottle Holder 1
Hex head bolt
Handlebar attachment cover
2

GENERAL INSTRUCTIONS
Carefully read through the instructions contained in this manual. It provides you with important
information about assembly, safety and use of the machine.
1. This unit has been designed for home use. The weight of the user must not exceed 255 lbs.
(116 kg.)
2. Keep your hands well away from any of the moving parts.
3. Parents and/or those responsible for children should always take their curious nature into
account and how this can often lead to hazardous situations and behavior resulting in
accidents. Under no circumstances should this appliance be used as a toy.
4. The owner is responsible for ensuring that anyone who uses the machine is duly informed
about the necessary precautions.
5. Your unit can only be used by one person at a time.
6. Use suitable clothing and footwear. Make sure all laces/cords are tied correctly.
BH North America Corporation
20155 Ellipse
Foothill Ranch, CA 92610
Phone: [phone]
Fax: [phone]
Email: [email protected]
Web: www.bhnorthamerica.com
Toll Free: [phone]
Mon - Fri 8am - 5pm PST
PRE-ASSEMBLY INSTRUCTIONS
FOR WARRANTY REPAIR
PLEASE DO NOT TAKE YOUR ELLIPTICAL
BACK TO CANADIAN TIRE COMPANY!
CONTACT BH FITNESS FIRST
3

ASSEMBLY
4

ASSEMBLY INSTRUCTIONS
19
74
64
62
20
21
STEP #1.
Attach the Front Stabilizer (73) to the bottom
front portion of the Base Frame (64) using
the screw (19), washer (62), nylock nut (20),
and plastic cap (21) combination, as shown
in illustration #1.
Illustration #1
Illustration #2
STEP #2.
Attach the Rear Stabilizer (74) to the bottom
back portion of the Base Frame (64) using
the screw (19), washer (62), nylock nut (20),
and plastic cap (21) combination, as shown
in illustration #2.
19
73
64
62
20
21
5

ASSEMBLY INSTRUCTIONS
52
20
22
71
Illustration #3
Illustration #4
STEP #3.
This step may require the assistance of an
additional person.
Join the male and female connectors ends that
attach the console control wire to the Base
Frame (64). Now slide the Upright Tube (65)
into the Base Frame (64), paying close attention
not cut or pinch the control wires. Secure both
section members using the Allen head bolts (18)
provided, as shown in illustration #3.
STEP #4.
Now mount the Left Pedal (52) to the Left
Pedal Tube (71). Securing the two members with
the screws (22) provided, as shown in
Illustration #3. Apply the same steps to the
Right Pedal.
18
65
64
6

71
512 80
17 79
18
71
ASSEMBLY INSTRUCTIONS
Illustration #5
Illustration #6
STEP #5.
Attach the Left Pedal Tube (71) to the Flywheel
Shaft using the bushings (79&80), washer (17),
nylock nut (12), and plastic cap (5) combination,
as shown in illustration #5. Now repeat the
process for the Right Pedal tube using the
same steps.
STEP #6.
Attach the bottom potion of the left and right
swivel tube to the corresponding Pedal Tube
using the Allen head Bolts (18) provided,
as shown on Illustration #6.
7

70 69
18
ASSEMBLY INSTRUCTIONS
Illustration #7
STEP #7.
Attach the (left) handlebar (69) and (right)
handlebar (70) to the top of the
corresponding swivel tube. Secure the
attached members using the screws (18)
supplied, as shown in Illustration #7.
84B
65
6
84A
59
Illustration #8
68
STEP #8.
Pull the pulse sensor cable up to the console mount
using the pull wire, which is secured to the top of the
Upright Tube (65). Mount the Fixed Handlebar (68)
to the mounting bracket using the hex head bolts (6)
supplied. Enclose the mounting holes and bolts by
interlocking the Upper cover (84A) and lower
cover (84B),securing them both using the screw
(59) provided, as shown in Illustration #8.
PULL
WIRE
8
PULSE SENSOR CABLES
