BLADEZ QUANTUM User manual

OWNER’S MANUAL
ASSEMBLY OPERATION MAINTENANCE
WARRANTY PARTS ORDERING
CAUTION: Exercise of a strenuous nature, as is customarily done on this equipment, should not be
undertaken without first consulting a physician. No specific health claims are made or implied as they
relate to the equipment.
IMPORTANT: Read all instructions carefully before using this product. Retain this owner’s
manual for future reference.
QUANTUM

TABLE OF CONTENTS
Training…………….......................................2
Assembly Instructions…………………........9
Console Operations……..…..........................11
Exploded View ………....................................15
Parts List ………………….............................16
Safety………………..............................….....1
Warranty……..………………………...........17
Pre-Assembly Instructions…….....................7
Quantum

IMPORTANT SAFETY ADVICE
1
This machine has been designed and constructed to provide maximum safety.
Nevertheless, certain precautions should be taken when using exercise equipment. Read
the entire manual before assembling and using the machine. The following safety
precautions should also be observed.
1. Keep children or pet away from this equipment at all times. Do not leave them
unsupervised in the room where this machine is kept
2. It can only be used by one person at a time
3. If you experience dizziness, nausea, chest pains or any other symptom while using
this machine, STOP the exercise, SEEK MEDICAL ATTENTION IMMEDIATELY!
4. Use the unit on a place mat, level and on solid surface. Adjust footing for assured
stability if equipped
5. Keep hands well away from any of the moving parts
6. Wear clothing suitable for doing exercise. Do not use baggy clothing that might get
caught up in the machine. Always wear running shoes or trainers when using the
machine
7. This machine must only be used for the purposes described in this manual do not
use accessories that are not recommended by the manufacturer
8. Do not place sharp objects near the machine
9. People with physical limitation should not use the machine without the assistance
of a qualified person or a doctor
10. Do warm up stretching exercises before using the equipment
11. Do not use the machine if it is not working properly
12. Before using the machine, th oroug hly inspect the mach ine for proper assembly
13.A perimeter distance of 3 feet / 1 meter is required before operating the unit
14. This machine is not suitable for therapeutic use
15. This machine should only be used after a thorough review of the operation manual
and the warning labels. Illegible labels or warnings must be replaced and ordered
through BH North America Corporation
16. The weight of the user must not exceed 300 lbs. (136 kg)
CAUTION:Consult your doctor before beginning to use the machine. This advice is
especially important for those over 35 years of age or suffering from health problems.
Read all of the instructions before using any exercise equipment
KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE
Quantum

2
EXERCISE INSTRUCTIONS
Exercise offers various benefits; it will improve fitness, muscle tone and when used in conjunction with a calorie
controlled diet, it will help you to lose weight.
TRAINING GUIDELINES
Exercise is one of the most important factors in the overall health of an individual. Listed among its benefits are:
Increased capacity for physical work (strength endurance)
Increased cardiovascular (heart and arteries/veins) and respiratory efficiency
Decreased risk of coronary heart disease
Changes in body metabolism, e.g. los ing weight
Delaying the physiological effects of age
Physiological effects, e.g. reduction in stress, increase in self-confidence, etc.
Basic Components of Physical Fitness
There are 4 all encompassing components of physical fitness and we need to briefly define and clarify their roles:
STRENGTH
Is the capacity of a muscle to exert a force against resistance. Strength contributes to power and speed and is of great
importance to a majority of sports people.
MUSCULAR ENDURANCE
Is the capacity to exert a force repeatedly over a period of time, e.g. it is the ability of your legs to carry you 10 Km
without stopping.
FLEXIBI LITY
Is the range of motion about a joint. Improving flexibility involves the stretching of muscles and tendons to maintain
or increase suppleness, and provides increased resistance to muscle injury or soreness.
CARDIO-RESPIRATORY ENDURANCE
Is the mos t essential component of phys ical fitness. It is the efficient functioning of the heart and lungs.
AEROBIC FITNESS
The largest amount of oxygen that you can us e per minute during exercise is called your maximum oxygen uptake
(MVo2). This is often referred to as your aerobic capacity
OXYGEN UPTAKE
The effort that you can exert over a prolonged period of time is limited by your ability to deliver oxygen to
the working muscles. Regular vigorous exercise produces a training effect that can increas e your aerobic capacity by
as much as 20 to 30%. An increased MVO2 indicates an increased ability of the heart to pump
blood, of the lungs to ventilate oxygen and of the muscles to take up oxygen.
ANAEROBIC TRAINING
This means “without oxygen” and is the output of energy when the oxygen supply is insufficient to meet
the body’s long term ener gy dema nds. (For exa mple, 100 meter sprint).
THE TRAINING THRESHOLD
This is the minimum level of exercise which is required to produce significant improvements in any
physical fitness parameter.
PROGRESSION
As your become more fit, a higher intensity of exercise is required to create an overload and therefore provide
continuous improvement
Quantum

3
TRAINING GUIDELINES (cont’d)
OVERLOAD
This is where you exercise at a level above that which can be carried out comfortably. The intensity, duration
and frequency of exercise should be above the training threshold and should be gradually increased as the body
adapts to the increasing demands. As your fitness level improves, the training threshold should be raised.
Working through your program and gradually increasing the overload factor is important.
SPECIFICS
Different forms of exercise produce different results. The type of exercise that is carried out is specific both to
the muscle groups being used and to the energy s ource involved.
There is little transfer of the effects of exercise, i.e. from strength training to cardiovascular fitness. That is why
it is important to have an exercise program tailored to your specific needs.
REVERSIBILITY
If you stop exercising or do not do your program often enough, you will lose thebenefits you have gained.
Regular workouts are the key to success.
WARM UP
Every exercis e program should start with a warm up where the body is prepared for the effort to come. It should
be gentle and preferably use the muscles to be involved later.
Stretching should be included in both your warm up and cool down, and should be performed after 3-5 minutes
of low intensity aerobic activity or callisthenic type exercise.
WARM DOWN OR COOL DOWN
This involves a gradual decrease in the intensity of the exercise session. Following exercise, a large supply of
blood remains in the working muscles. If it is not returned promptly to the central circulation, pooling of blood
may occur in the muscles.
HEART RATE
As you exercise, the rate at which your heart beat increases. This is often used as a measure of the required
intensity of exercise. You need to exercise hard enough to condition your circulatory system, and increase your
pulse rate, but not enough to strain your heart.
Your initial level of fitness is important in developing an exercise program for you. If you are starting off you
can get a good training effect with a heart rate of 110-120 beats per minute (BPM). If you are more fit, you will
need a higher threshold of stimulation.
To begin with, you should exercise at a level that elevates your heart rate to about 65 to 70% of your maximum.
If you find this is too easy, you may want to increase it, but it is better to lean on the conservative side.
As a rule of thumb, the maximum heart rate is 220 minus your age. As you increase in age, your heart, like other
muscles, loses some of its efficiency. Some of its natural loss is won back as fitness improves. The following
table is a guide to those who are “starting fitness”.
Age
TargetheartRate 25 3035404550556065
10SecondCount 232222212019191818
Beats per Minute 138 132 132 126 120 114 114 108 108
Quantum

4
TRAINING GUIDELINES (cont’d)
Pulse Count
The pulse count (on your wrist or carotid artery in the neck, taken with two index fingers) is done for ten
seconds, taken a few seconds after you stop exercising. This is for two reasons: (a) 10 seconds is long
enough for accuracy, (b) the pulse count is to approximate your BPM rate at the time you are exercising.
Since heart rate slows as you recover, a longer count is not as accurate.
The target is not a magic number, but a general guide. If you’re above average fitness, you may work quite
comfortably a little above that suggested for your age group.
The following table is a guide to those who are keeping fit. Here we are working at about 80% of maximum.
Age 253035404550556065
Target heart Rate
10SecondCount 262625242322222120
Beats per Minute 156 156 150 144 138 132 132 126 120
Don’t push yourself too hard to reach the figures on this table. It can be very uncomfortable if you overdo it.
Let it happen naturally as you work through your program. Remember, the target is a guide - not a rule, a
little above or below is just fine. Besides, heart rate measure through the devices on this machine including
the wireless receiver is not exact to a single beat of your heart but rather a rough guide. Do not use this
heart rate reading for medical purpose.
Two final comments:(1) don’t be concerned with da y to day variations in your pulse rate, being under
pressure or not enough sleep can affect it;(2) your pulse rate is a guide, don’t become a slave to it.
Muscle Soreness
For the first week or so, this may be the only indication you have that you are on an exercise program. This,
of course, does depend on your overall fitness level. A confirmation that you are on the correct program is a
very slight soreness in most major muscle groups. This is quite normal and will disappear in a matter of
days. If you experience major discomfort, you may be on a program that is too advanced or you have
increased your program too rapidly.
If you experience PAIN during or after exercise, your body is telling you something. Stop exercising and
consult your doctor.
What to Wear
Wear clothing that will not restrict your movement in any way while exercising. Clothes should be light
enough to allow the body to cool. Excessive clothing that causes you to perspire more than you normally
would while exercising, gives you no advantage. The extra weight you lose is body fluid and will be replaced
with the next glass of water you drink. It is advisable to wear a pair of gym or running shoes or “sneakers”.
Breathing during Exercise
Do not hold your breath while exercising. Breathe normally as much as possible. Remember, breathing
involves the intake and distribution of oxygen, which feeds the working muscles.
Rest periods
Once you start your exercise program, you should continue through to the end. Do not break off halfway
through and then restart at the same place later on without going through the warm-up stage again. The rest
period required between strength training exercises may vary from person to person. This will depend mostly
on your level of fitness and the program you have chosen. Rest between exercises by all means, but do not
allow this to exceed two minutes. Most people manage with half minute to one minute rest periods.
Quantum

STRETCHING
Stretching should be included in both your warm up and cool down, and should be performed after 3-5
minutes of low intensity aerobic activity or callisthenic type exercise. Movements should be performed
slowly and smoothly, with no bouncing or jerking. Move into the stretch until slight tension, not pain, is
Felt in the muscle and hold for 20-30 seconds. Breathing should be slow, rhythmical and under control,
making sure never to hold your breath.
5
TRAINING GUIDELINES (cont’d)
Head Roll
Rotate your head to the right for one count,
feeling the stretch up the side of your neck.
Next, rotate your head back for one count,
stretching your chin to the ceiling and letting
your mouth open. Rotate your head to the left
for one count, and finally, drop your head to
your chest for one count
Shoulder Lifts
Lift your right shoulder up toward your ear
for one count. Then lift your left shoulder
up for one count as you lower your right
shoulder.
Side Stretches
Open your arms to the side and continue lifting
them until they are over your head. Reach your
right arm as far upward toward the ceiling as
you can for one count. Feel the stretch up your
right side. Repeat this action with your left arm
Quadriceps Stretch
With one hand against a wall for balance,
reach behind you and pull your right foot
up. Bring your right heel as close to your
buttock as possible. Hold for 15 counts
and repeat with left foot up
Quantum

6
TRAINING GUIDELINES (cont’d)
Inner Thigh Stretch
Sit with the soles of your feet together with
your knees pointing outward. Put your feet
as close into your groin as possible. Gently
push your knees towards the floor. Hold
your mouth open. Rotate your head to the left
for 15 counts.
Toe Touches
Slowly bend forward from your waist,
lettingyour back and shoulder relax as
you stretchtoward your toes. Reach down
as far as you can and hold for 15 counts.
Hamstring Stretches
Sit with your right leg extended. Rest the sole
of your left foot against your right inner thigh.
Stretch toward your toe as far as possible.
Hold for 15 counts. Relax and then repeat
with left leg extended
Calf/Achilles Stretch
Lean against a wall with your left leg in
front of the right and your arms forward.
Keep your right leg straight and the left
foot on the floor then bend the left leg
and lean forward by moving your hips
toward the wall. Hold, then repeat on the
other side for 15 counts.
Quantum

7
If you are missing parts or require information on how to
operate this product please call 866-325-2339
Notice: Line sketches used in this section are for reference only. They do not
reflect the actual unit in detail.necessarily
PRE-ASSEMBLY
Quantum

8
PRE-ASSEMBLY (cont’d)
Hardware Pack
Quantum

ASSEMBLY INSTRUCTIONS
Main Frame Assembly
1. Slide the Upright Cap (M-7) into the
upper Upright assembly.
2. Attach the connector (L-4) to the main
connector (C-4) from the Upright
assembly
3. Insert the Upright assembly to the
base (be careful not to pinch wires)
4. Secure with bolts, washers and lock
washers (C-1, C-3, C-5) then slide the
cap down to cover the joint
Pedal & Accessory Assembly
1. Attach the Pedal tube to the Swing
Arm bracket
2. Secure the joint with bolts (H-6)
washers (H-5) and Nuts (H-4)
3. Slide the accessory tray (M-11) down
the Upright tube and secure with
screw (D-7) and screw (D-5)
9
Note: Assembly of this unit should take TWO persons about 45 minutes to properly assemble.
Quantum

ASSEMBLY INSTRUCTIONS (cont’d)
Decorative Covers & Console
1. Snap the decorative covers (M-9 & M-10) onto
the pedal joint and secure with screws (H-8)
and screws (D-5)
2. Mate all cables to their prospective connectors
as keyed
3. Attachtheconsole(A)tothebracketonthe
Upright and secure with bolts(C-2), lock
washers (C-3) and washers (C-1)
Moving & Storage
This unit is provided with moving wheels on the
Front Stabilizer to make it easier to move. To
move the machine about, lift from the rear of
the machine until the weight is transferred or
rested on to the wheels then push.
10
Moving Wheels
Quantum

11
CONSOLE OPERATIONS
As soon as the pedals are in motion, the console is powered by the chassis backup battery and instantly lit up.
The AC adaptor provided must be plugged in to power the console as well as to charge the chassis battery.
As power applied, the console displays U4 (flashing)
1. To set personal data, use UP or DOWN buttons on the console (see note immediately below) to select
U1 (User number 1) to U4 (User number 4) as the user's identification and press ENTER to accept.
2. Training selection of Manual, Program, User & Target Heart Rate will flash. Press UP or DOWN to
select the desired training mode in MANUAL or PROGRAM (12 different profiles) or USER or TARGET
HEART RATE control (4 dif ferent options for training). If training with TARGET HEART RATE control
mode, you need to input AGE data, and press ENTER proceed to next step.
3. Use UP or DOWN to adjust the training LOAD RESISTANCE level from 1to 16 under MANUAL,
PROGRAM and USER mode.
4. Use UP or DOWN to preset training function data, when each function data has been preset, press
MODE/ENTER.
Console
Hand Pulse Sensors
Wireless Heart Rate Receiver Module
Wireless Heart Rate
Receiver Plug-In
Quantum

12
Available preset training functions:
·TIME: Range 00:00 to 99:00, increment by 1:00 (minute).
·DISTANCE: Range 00:00 to 99:00, increment by 0.10 mi.
·CALORIES: Range 0 to 990, incre me nt by 1 0 c al.
·WATTS: Range 10 to 350, increment by 5 watt (WATT can be preset
under MANUAL mode only)
·PULSE Range 30 to 240, increment by 1 BPM (not applicable in
TARGET H.R control mode)
1. Press START/STOP button to start training.
Training Mode Instruction:
As soon as you press START/STOP button, the computer starts the workout:
A. Training with PRESET TIME:
If you have preset TIME, this time is divided into 16 equal parts for each segment of the profile.
B. Training without preset time:
If you do not set TIME, each segment of the profile progresses to the next every 0.1 mi.
C. Training in MANUAL :
You may adjust the load (resistance) level from 1 to 16 during training if you did not preset WATT
parameter. On the other hand, if you have preset WATT, load level will auto-adjust depending on
current speed and Watt values you are exercising at.
There are four different symbols on the display associated with your training:
: WATT measured too high; you need to slow down the training speed.
: WATT measured as preset; you can keep current training speed.
: WATT measured too low. You need to speed up the training speed.
: Heart rate is not detected. You need to either hold on to the Hand
Grips or plug in the wireless receiver and wear chest strap*.
* Optional Heart Rate Chest Strap not included (available for purchase through BH North America Corp.)
When the WATT is out of spec, the computer sounds 3 audible beeps/second as a reminder of the Watt value.
If you keep training under this mode for over 3 minutes, the audible alarm doubles up to 6 beeps for 30
seconds, and the system STOP automatically. At this moment, LOAD level is down to 1, and preset WATT data
is zero. During the ALARM period, you can stop ALARM by pressing any function buttons.
D. Training with 12 profiles
You can adjust the load difficulty during training any time.
CONSOLE OPERATIONS (cont’d)
Wearing Chest Strap*
for Wireless Heart Rate
Quantum

13
CONSOLE OPERATIONS (cont’d)
E. Training in TARGET H.R. control
The load difficulty will be auto-adjusted according to the current heart rate received. There are 2
ways the console receives your heart rate:
·Through both of the Hand Grip Sensor handles at the bottom of the console
·Through the console plug-in Wireless Receiver Module. A heart rate chest strap (optional
accessory available for purchase) must be worn throughout the workout
If your heart rate is under the targeted value, the load difficulty will increase one level each 30
seconds, up to the maximum level 16. As soon as your heart rate is achieved at the target pulse,
load difficulty will decrease one level immediately, and keep decreasing one level each 15
seconds until level reaching level 1.
If the heart rate received is still over (or equal to) the targeted value for 30 seconds when tension
is already at level 1, the console will STOP and sounds 6 audible beeps to remind you as the
training protection.
To stop your training:
F. Training with PRESET function data:
As soon as the preset function data counting down to zero, the console sounds 8 beeps as a
reminder. At this moment, the console will stop the workout. You may press START/STOP
button to start the workout and counting up from the previous data.
G. Interrupt training:
During the workout, you may press START/STOP button to stop the training any time.
H. To reset program:
You may press RESET but ton to re se t the PROGRAM and select the training mode and load
difficulties under STOP mode. By pressing and holding the RESET button for 2 seconds, all data
(including personal data) will be reset completely to factory default.
Button Functions
START/STOP: to start or stop training
MODE: to select each function of Time, Distance, Pulse presetting
UP:toincreaseortoscrollup
DOWN:todecreaseorscrolldown
RESET: 1. To reset each function of Time, Distance, Pulse function figures.
2. To reset program setting and back to initial selection mode with Manual, Program,
User, or Target Heart Rate all blinking display.
RECOVERY: to check pulse recovery status – User must use Hand Grip sensors or wears chest strap
TOTAL RESET: to clear all setting to the monitor.
Quantum

14
Functions:
TIME: Count Up - The computer starts counting up from 00:00 up to 99:59 during training.
Count Down - The computer will count down from the preset time to 00:00.
SPEED: Displays the current SPEED from 0.0 to maximum 99.9 mi.
DISTANCE: Count Up - The computer accumulates total workout distance from 0.00 to the max. 99.90 mi.
during training.
Count Down - The computer will count down from the preset Distance to 0.00.
CALORIES: Count Up- The computer accumulates the calories consumption from 0 to the max 999 cal
during training.
Count Down - The computer will count down from the preset Calories to 0.
This data is a rough guide for comparison of different exercise sessions that should not be used
for medical treatment purposes.
PULSE: Heart rate can be measured at anytime during the workout. A profile of a heart starts flashing
when the user starts placing both hands on the grips or wears a chest strap (optional accessory
available for purchase from BH North America) during the workout with the wireless receiver
module plugged in. The heart rate display ranges from 0 to 240 BPM. You may preset target
heart rate to assist with the training. The options you may have are as the following:
Alarm - If you set the target pulse in Manual or Program 1, the console will
alarm to remind as soon as your measured heart rate matches that of the set value.
Load adjustment - If you set the target heart rate in program 2, the load difficulty will be
controlled by your current heart rate value compared with the targeted value (refer to the
Training in program 2)
RECOVERY: After exercising for a period of time, press "RECOVERY" on the console then hold on to the grips,
all display function will stop except for "Time". Time starts counting down. When the time
expired, the display will report your heart rate recovery status with the grade F1 to F6 with F1
being the best, and F6 being the worst. You may keep exercising to improve the heart rate
recovery status daily from F6 up to F1. Press the RECOVERY button again to return to the main
display.
Additional Operating Instructions:
1. Stop pedaling for 90 seconds, console will turn off to conserve battery power, pressing any key will not
wake up the console.
2. Start pedaling above 15 RPM, the console will wake up.
3. After 90 seconds, user may press RECOVERY button to test heart rate recovery status and place hands
on the hand grips or wear chest strap with the wireless module plugged in at the console.
4. Plug in the AC adaptor to operate the unit and to charge the chassis battery as needed
5. To safely use this product do not exceed 120 RPM cadence; it is not recommended.
CONSOLE OPERATIONS (cont’d)
Quantum

15
EXPLODED VIEW
(Use key numbers to reference the part numbers.)
M-20
M-19
Quantum

PARTS LIST
16
Item Description Specifications Qty.
AConsole LCD 1pc
B Fixed handlebar 1 st
B-1 Handlebar fixed base 1 pc
B-2 Cone cros s s cre w M4x12L 8mm 4 pcs
B-3 Cone hex.s crew M8xP1.25x20L(6mm) 2 pcs
B-4 Spring washer φ8 2 pcs
B-5 Fl a t wa s he r φ8xφ16x2t 2 pcs
B-6 Monitor lower cover
B-7 Round cros s s crew M3x40L 11 pcs
B-8 End cap φ1"(STR) 2 pcs
C Handlebar post 1 pc
C-1 Fl a t wa s he r φ8xφ19x2t 7 pcs
C-2 Cone hex.s crew M8xP1.25x20L(6m/m) 11 pcs
C-3 Spring washer φ8 11 pcs
C-4 Ca ble 50L12P+12P 1 pc
C-5 Se mi ci rcul a r wa s he r φ8xφ19x2t Q235 4 pcs
D-L Upper Swing 1 st
D-R Upper Swing 1 st
D-1 Bus hi ng φ26.7xφ17.12x15L 2 pcs
D-2 Bea ri ng 6003RS 4 pcs
D-3 Bus hi ng φ17.2xφ23x52L 2 pcs
D-4 Ha ndl eba r fixed cl a mp φ17x364L(M8x23L)(45＃)1pc
D-5 Cone cros s s cre w M5xP0.8x20L 12 pcs
D-6 Se mi ci rcul a r wa s he r φ8xφ16x2t 8 pcs
D-7 Cone cros s s cre w M5xP0.8x40L 30# 1 p c
D-8 Spring washer φ8 8 pcs
D-9 Hex. Screw M8*P1.25*12L 8 pcs
E-1 Adjustable end cap (PVC)φ50 4 pcs
E-2 Round cros s s cre w M3x20L 16 pcs
F-L Peda l a rm (le ft) 30x70x1.5tx1116.7L（90°) 1 pc
F-R Peda l a rm (right) 30x70x1.5tx1116.7L（90°) 1 pc
F-1 Bushing φ8.2xφ12x80L 2 pcs
F-2 Bea ri ng 6001RS 4 pcs
F-3 C ring φ12(65Mn) 4 pcs
F-4 Cone cros s s crew M5xP0.8x14L 30# 6 pcs
F-5 Nylon nut 3/8"x7t 14 2 pcs
F-6 Fl a t wa s her φ10xφ30x2t 2 pcs
F-7 Plastic spacer 4 pcs
F-8 Cone cros s s cre w M5xP0.8x45L 6 pcs
G Axle φ20*165L FP-954 1 pc
G-1 Pul ley φ289*9 φ20 1 pc
G-2 Bea ring 6004RS 2 pcs
G-3 Hex. Screw M8xP1.25x12Lx5t 13 3 pcs
G-4 Bel t J8 1143m/m(J8 450) 1 pc
G-5 Crank G244 2 pcs
G-6 Nut M10xP1.25x10T 2 pcs
G-7 Bus hi ng φ17.2xφ23x52L 2 pcs
G-8 Peda l a rm conne ct φ31.8*32L 2 pcs
G-9 Nyl ok s crew M8xP1.0x20L(30#) 2 pcs
G-10 Fl a t wa s he r φ10xφ20x2t 2 pcs
H-1 Bus hi ng φ17.2xφ23x8L 2 pcs
H-2 Nyl ok s crew M8xP1.0x20L(30#):8.8 2 pcs
H-3 Fl a t wa s her φ10xφ20x2t 2 pcs
H-4 Nylon nut M8 30# 4 pcs
H-5 Flat wa s her φ8xφ16x1t Q235 2 pcs
H-6 Cone hex.s crew M8xP1.25x100L 6,21 2 pcs
Item Description Specifications Qty.
H-7 Roun d cros s s cre w M4x40L 8 pcs
H-8 Roun d cros s s cre w M3x40L 4 pcs
I-1 Cone hex.s crew M8xP1.25x35L 2 pcs
I-2 Transportation wheel φ57xφ8x20 2 pcs
I-3 Fl a t hea d cros s s cre w 3/16"(#10)x3/4" 35# 4 pcs
J Fl ywhe el s e t φ277.2*32W(9kg)(φ34) 1 pc
J-1 Fl ywheel a xl e 3/8"-26x128L 1 pc
J-2 Sl eeve φ10xφ14x6mmL(Q235) 1 pc
J-3 Nut 3/8"-26x4.5t 30# 4 pcs
J-4 Nut 3/8"-26 30# 1 pc
J-5 Wa s her φ10xφ17x1t 30# 2 pcs
KMagneticset 10 1pc
K-1 Fl a t wa s he r φ8xφ19x2t 1 pc
K-2 Sl e eve φ10xφ14x6mmL(Q235) 1 pc
K-3 Chain M6*φ18*63L 1 pc
K-4 Screw for gear box M8*22L（13L）1pcs
K-5 Hex. Nut M6 2 pcs
K-6 Spring washer φ6 65Mn 2 pcs
K-7 Fl a t wa s her φ6xφ13x1t Q235 2 pcs
K-8 He x. Screw M6xP1.0*16L 30# 2 pcs
LMainframe 1pc
L-1 Cone cros s s cre w M4x50L 3 pcs
L-2 Cone cross screw 3/16
?（#10）x3/4?11 pcs
L-3 Cone cros s s cre w M3x10L 10 pcs
L-4 Ca ble l ower 12P +7 2P,3P 1 pc
L-5 Cone cros s s cre w M3x10 14 pcs
M Chai n cover(Ri ght) (ABS) 1327.7g 1 pc
M-1 Cha i n cover(Left) (ABS)1327.7g 1 pc
M-2 End ca p (ri ght up) 432C（ABS)96.7g 2 pcs
M-3 End ca p (ri ght bottom) 432C（ABS)94.4g 2 pcs
M-4 End ca p (l eft up) 432C（ABS)96.7g 2 pcs
M-5 End ca p (l eft bottom) 432C（ABS)94.4g 2 pcs
M-6 Pedal (R+L) RLA7015(PP+TPR) 2 pcs
M-7 Ha ndl eba r Pos t Cover 877C(ABS) 1 pc
M-8 Upper cover (ABS) 1 pc
M-9 Lowe r Ri ght （ABS）75.5g 2 pcs
M-10 Lower Left Handlebar （ABS）77.3g 2 pcs
M-11 Bottl e 877C(ABS) 1 s t
M-12 Cove r (ABS) 1 pc
M-13 Cover (ABS)135.7g 1 pc
M-14 Cover (ABS)134g 1 pc
M-15 Front Right Ha ndl ebar (ABS)60.1g 1 pc
M-16 Ba ck Ri ght Ha ndl ebar (ABS)50.2g 1 pc
M-17 Ba ck Left Ha ndl eba r (ABS)50.2g 1 pc
M-18 Front Le ft Ha ndl eba r (ABS)60.1g 1 pc
M-19 Decora ti ve 877C(ABS)190g 1 pc
M-20 Decora ti ve cove r(Left) 877C(ABS)190g 1 pc
NIdlerclamp 1pc
N-1 Fl a t wa s her φ10xφ18x1t 1 pc
N-2 I dler wheel φ24xφ37x24.5mmL 1 pc
N-3 Nylon nut M8 30# 1 pc
N-4 Sle eve φ10xφ14x6mmL(Q235) 1 pc
N-5 Wa ve wa s her φ10.5xφ15x0.3t 2 pcs
N-6 Fl a t wa s her φ10xφ18x2t 1 pc
O Adaptor 120V 60HZ,9VDC 1A 1 pc
P-L Lo wer Swing Handlebar(Left) φ38.1*2t*655L(90°) 1 s t
P-R Lo wer Swing Handlebar(Right) φ38.1*2t*655L(90°) 1 s t
Quantum

17
WARRANTY
LIMITED ONE (1) YEAR LABOR; FIVE (5) YEAR PARTS
From date of purchase, by original consumer purchaser, BH North America will repair or replace,
at its option, free of charge ONE (1) YEAR labor and /or FIVE (5) YEAR parts which are defective
as a result of material or workmanship with the exception of any cosmetic component which will be
covered for NINETY (90) DAYS from the date of purchase. Any component that is a customer
point of assembly will only be replaced; labor is not covered.
FRAME
BH North America warrants a lifetime replacement of the frame should it deem defective as a
result of material or workmanship from date of purchase by original consumer purchaser
COMMERCIAL OR RENTAL USE
If a Bladez product is used for commercial or rental purposes the warranty is void.
THIS WARRANT Y DO ES NOT COVER
·Pre-delivery set-up
·Components that require replacement due to dirt or lack of regular maintenance
·Expendable items which become worn during normal use.
·Repairs necessary because of operator abuse or negligence or the failure to operate
and maintain the equipment according to the instructions contained in the Owner’s
Manual.
BH North America Corporation
20155 Ellipse
Foothill Ranch, CA 92610
Phone: [phone]
Fax: [phone]
Email: [e-mail]
Web: www.bhnorthamerica.com
Toll Free: 866-325-2339
Mon - Fri 8am - 5pm PST
This warranty applies only while this product is in use in the Canada.
This warranty is in addition to any statutory warranty and does not exclude or limit legal rights you
may have but shall run concurrently with applicable provincial legislation. Furthermore, some
provinces do NOT allow limitation on how long an implied warranty will last so the above limitations
may not apply.
FOR WARRANTY REPAIRS, PLEASE DO NOT TAKE
YOUR MACHINE BACK TO THE RETAIL STORES.
CONTACT BLADEZ FITNESS FIRST!
Quantum
