BLADEZ Bladez T1 Basic Setup guide

ILLUSTRATED PARTS MANUAL
Model Number:
Revised 11-09-06
BLADEZ T1 BASIC
TREADMILL
Bladez Corp. 20155 Ellipse Foothill Ranch, CA 92610 Phone: [phone] Fax: [phone]
www.ebladez.com Email: [email protected]

BLADEZ T1 BASIC
TREADMILL
PARTS INFORMATION
www.ebladez.com Email:fi[email protected]
Page 1
• FIGURE 1
77
14
14
2
3
3
111
12
13
24
21
11
22
23
24
21
11
22
23
14
25 26

BLADEZ T1 BASIC
TREADMILL
PARTS INFORMATION
www.ebladez.com Email:fi[email protected]
Page 2
• FIGURE 2
ITEM # PART # DESCRIPTION TOTAL QTY
1-1 T1B001 Computer Console 1
1-1-1 T1B001-1 Computer Decal 1
1-1-2 T1B001-2 Computer Backboard 1
1-2 T1B002 Computer Shelf 1
1-3 T1B003 Protecting Cover 2
1-11 T1B011 Foam Grip 2
1-12 T1B012 Safety Switch Sensor 1
1-13 T1B013 Self Tapping Screw Ø3x8 2
1-14 T1B014 Allen Bolt 4
1-21 T1B021 Hand Pulse 2
1-22 T1B022 Hand Pulse Sensor Wire (L) 2
1-23 T1B023 Self Tapping Screw Ø4x25 2
1-24 T1B024 End Cap 2
1-25 T1B025 Upright (L) 1
1-26 T1B026 Upright (R) 1
1-28 T1B028 Self Tapping Screw Ø4x12 10
1-42 T1B042 Control Wire 1
1-77 T1B077 Guide Thread 1100mm 1
1-111 T1B111 Self Tapping Screw Ø4x16 10

BLADEZ T1 BASIC
TREADMILL
PARTS INFORMATION
www.ebladez.com Email:fi[email protected]
Page 3
• FIGURE 3
31
31
32
31
121
32
104
107
110
101
87
86
98
98
101

BLADEZ T1 BASIC
TREADMILL
PARTS INFORMATION
www.ebladez.com Email:fi[email protected]
Page 4
•FIGURE 4
ITEM # PART # DESCRIPTION TOTAL QTY
2-29 T1B029 Nylon Nut M8xP1.25 4
2-30 T1B030 Cylinder 1
2-31 T1B031 Allen Bolt M8xP1.25x15 10
2-32 T1B032 Washer Ø8xØ16x1.5t 11
2-68 T1B068 Self Tapping Screw Ø4x20 8
2-69 T1B069 Deck 1
2-70 T1B070 Rear Fixer 1
2-71 T1B071 Spring 1
2-72 T1B072 Plastic Pad 1
2-73 T1B073 Nylon Nut M10 4
2-74 T1B074 Base Frame 1
2-75 T1B075 End Cap 40x80x2.0t 2
2-76 T1B076 Foot Pad 4
2-78 T1B078 Folding Stop 1
2-79 T1B079 Wheel 2
2-80 T1B080 Incline Rod 1
2-81 T1B081 Screw M5x40 1
2-82 T1B082 Screw M5x35 1
2-83 T1B083 Nylon Nut M5 2
2-84 T1B084 Round Tube 1
2-85 T1B085 Post 1
2-86 T1B086 Incline Motor 1
2-87 T1B087 Allen Bolt 1
2-88 T1B088 Allen Bolt M6x45 4
2-89 T1B089 Bushing 21x16.2x310 1
2-93 T1B093 Allen Bolt M6x20 1
2-96 T1B096 Allen Bolt M8x32 2
2-97 T1B097 Allen Bolt M8xP1.25x25 2
2-98 T1B098 ㄇ Shaped Steel Pin 2
2-101 T1B101 R Ring Ø10xØ2.0 2
2-103 T1B103 Lift Plate 4
2-104 T1B104 Allen Bolt 4
2-106 T1B106 Allen Bolt 6
2-107 T1B107 Washer 10
2-110 T1B110 Nylon Nut M10xP1.5,8t 10
2-118 T1B118 Allen Bolt M10x52 2
2-120 T1B120 Plastic Post Pad 4
2-121 T1B121 Plastic Washer 2
2-122 T1B122 Allen Bolt M6x8 1

BLADEZ T1 BASIC
TREADMILL
PARTS INFORMATION
www.ebladez.com Email:fi[email protected]
Page 5
• FIGURE 5
106
9
95
94 10
10
10
10
40
41
67
105
105
29
29
102
40
40
53
33 34
35
36
37
40
40
47
48
49
50
51
52
54
55
59
59
60
60
61
62
62
63
64
64
64
65
64
64
64
65
66
66
66
91
90
92
67

BLADEZ T1 BASIC
TREADMILL
PARTS INFORMATION
www.ebladez.com Email:fi[email protected]
Page 6
• FIGURE 6
ITEM # PART # DESCRIPTION TOTAL QTY
3-6 T1B006 Extension Wire 90mm (white) 1
3-7 T1B007 Extension Wire 150mm (black) 1
3-9 T1B009 Bottle 1
3-10 T1B010 Screw M5xP0.8x18 4
3-27 T1B027 Wire Clip 1
3-29 T1B029 Nylon Nut M8xP1.25 4
3-32 T1B032 Washer Ø8xØ16x1.5t 11
3-33 T1B033 Allen Bolt M10xP1.5x18 4
3-34 T1B034 Spring Washer M10 4
3-35 T1B035 Washer Ø10.2xØ20x3t 4
3-36 T1B036 Motor 1
3-37 T1B037 Drive Belt 1
3-38 T1B038 Allen Bolt M8xP1.25x110 1
3-39 T1B039 Spring Washer M8 1
3-40 T1B040 Screw M5xP0.8x10 7
3-41 T1B041 Controller 1
3-44 T1B044 Wheel 2
3-45 T1B045 Allen Bolt 2
3-46 T1B046 Sensor (column) 1
3-47 T1B047 Power Cord Holder 1
3-48 T1B048 Circuit Breaker 1
3-49 T1B049 Power Switch 1
3-50 T1B050 Power Cord 1
3-51 T1B051 Wire Clip 1
3-52 T1B052 Main Frame 1
3-53 T1B053 Upper Motor Cover 1
3-54 T1B054 Front Roller 1
3-55 T1B055 Rear Roller 1
3-56 T1B056 Allen Bolt M6xP1.0x25 1
3-57 T1B057 Spring Washer M6 1
3-58 T1B058 Washer Ø6xØ13x1.0t 1
3-59 T1B059 Allen Bolt M8xP1.25x55 2
3-60 T1B060 Washer Ø8xØ19x1.5t 2
3-61 T1B061 Running Board 1
3-62 T1B062 Side Rail 2
3-63 T1B063 Running Belt 440x2768x1.6t 1
3-64 T1B064 Screw M6xP1.0x25 6
3-65 T1B065 Allen Bolt M8xP1.25x30 2
3-66 T1B066 Rubber Cushion 6
3-67 T1B067 Screw M5xP0.8x8 3
3-73 T1B073 Nylon Nut M10 4
3-90 T1B090 Rear End Cap (L) 1
3-91 T1B091 Rear End Cap (R) 1
3-92 T1B092 Self Tapping Screw Ø4x16 2
3-94 T1B094 Decorative Cover (L) 1
3-95 T1B095 Decorative Cover (R) 1
3-99 T1B099 Allen Key 6mm (80mmx80mm) 1
3-100 T1B100 Allen Key & Screwdriver 5mm 1
3-102 T1B102 Safety Key/Clip 1
3-105 T1B105 Double Sided Tape 15x1230x1.0t 4
3-106 T1B106 Allen Bolt 6
3-108 T1B108 Self Tapping Screw Ø4x16 2
3-109 T1B109 Wire Clip 1

BLADEZ T1 BASIC
TREADMILL
PARTS INFORMATION
www.ebladez.com Email:fi[email protected]
Page 7
• FIGURE 7
24
21
11
22
23
14
14
2
3
3
9
14-1
14-1
111
24
21
11
22
23
12
13
10
10
25 26
10
10
31
77
31
32
31
95
94
121
102
40
40
53
33 34
35
36
37
40
40
47
48
49
50
51
52
54
55
59
59
60
60
61
62
62
63
64
64
64
65
64
64
64
65
66
66
66
91
90
92
BLADEZ T1 BASIC
67
87
86
98
98 101
106
107
110
29
29
104
40
41
67
105
105
101
