BLADEZ BLADEZ T8 PRO Setup guide

ILLUSTRATED PARTS MANUAL
Model Number:
Revised 12-12-06
BLADEZ T8 PRO
TREADMILL
Bladez Corp. 20155 Ellipse Foothill Ranch, CA 92610 Phone: [phone] Fax: [phone]
www.ebladez.com Email: [email protected]

BLADEZ T8 PRO
TREADMILL
PARTS INFORMATION
www.ebladez.com Email:[email protected]
Page 1
• FIGURE 1

BLADEZ T8 PRO
TREADMILL
PARTS INFORMATION
www.ebladez.com Email:[email protected]
Page 2
• FIGURE 2
ITEM # PART # DESCRIPTION TOTAL QTY
1-1 T8P001 Computer Console 1
1-1-1 T8P001-1 Water Bottle Holder 1
1-1-2 T8P001-2 Bottle Holder Weld 1
1-2 T8P002 Safety Key P-1044 1
1-3 T8P003 Bolt K-299 4
1-4 T8P004 Controller Cable 1
1-5 T8P005 Handrail Upper Cover (L) 1
1-6 T8P006 Handrail Upper Cover (R) 1
1-7 T8P007 Handle Pipe (L) 1
1-7-1 T8P007-1 Handle Pipe (R) 1
1-8 T8P008 Curved Pipe Cap Ø1-1/2”x1.5t 2
1-9 T8P009 PVC Foam Tube 2
1-10 T8P010 Handrail Lower Cover (L) 1
1-11 T8P011 Handrail Lower Cover (R) 1
1-13 T8P013 Bolt Ø5x25 2
1-13A T8P013-A Bolt M4xP0.7x8 4
1-14 T8P014 Upright Pipe (L) 1
1-15 T8P015 Upright Pipe (R) 1
1-16 T8P016 Console Rear Cover 1
1-36 T8P036 Power Cable 1
1-61A T8P061A Bolt M6xP1.0x15 2
1-75 T8P075 Cable (white) 14AWGx90x2T 2
1-76 T8P076 Cable (black) 14AWGx90x2T 1
1-77 T8P077 Cable (white) 14AWGx200x2T 1
1-78 T8P078 Cable (black) 14AWGx200x2T 1
1-79 T8P079 Cable (yellow/green) 14AWGx130x1T1R 1
1-81 T8P081 Wrench 5mm80mmx80mm 1
1-83 T8P083 Chest Belt 1
1-91 T8P091 T Wrench 8mmx200mm 1
1-102 T8P102 Bolt M5xP0.8x12 4
1-109 T8P109 Water Bottle 1
1-112A T8P112A Bolt 4x12 2
1-112B T8P112B Bolt 4x16 2
1-120 T8P120 Wrench 1
1-135 T8P135 Nut M6xP1.0 4

BLADEZ T8 PRO
TREADMILL
PARTS INFORMATION
www.ebladez.com Email:[email protected]
Page 3
• FIGURE 3

BLADEZ T8 PRO
TREADMILL
PARTS INFORMATION
www.ebladez.com Email:[email protected]
Page 4
•FIGURE 4
ITEM # PART # DESCRIPTION TOTAL QTY
2-12 T8P012 Bolt Ø4x16 5
2-20 T8P020 Upper Cover 1
2-21 T8P021 Screw Plastic Cover 6
2-22 T8P022 Motor Set 1
2-23 T8P023 Bolt M10xP1.5x25 4
2-24 T8P024 Spring Washer M10 4
2-25 T8P025 Washer Ø10xØ20x3.0t 4
2-26 T8P026 Incline Motor 1
2-27 T8P027 Bolt M10xP1.5x40 1
2-28 T8P028 Nut M10xP1.5 3
2-29 T8P029 Ribbed Belt 1
2-30 T8P030 Controller Set 1
2-31 T8P031 Bolt M5xP0.8x12 3
2-33 T8P033 Nut M10xP1.5 1
2-34 T8P034 Bolt M8xP1.25x40 2
2-35 T8P035 Bolt M5xP0.8x15 4
2-37 T8P037 Power Socket 1
2-38 T8P038 Power Switch 1
2-39 T8P039 Circuit Breaker 1
2-40 T8P040 Sensor (cylindrical) 1
2-41 T8P041 Bolt M4xP0.7x15 1
2-42 T8P042 Sensor Fixity NO.2399 1
2-43 T8P043 KSS Cable Fixity HC-101S 2
2-44 T8P044 Bolt M8xP1.25x75 1
2-45 T8P045 Nut M8xP1.25 1
2-46 T8P046 Frame 1
2-47 T8P047 Cushion 6
2-48 T8P048 Front Roller Set 1
2-49 T8P049 Running Board 1
2-50 T8P050 Bolt M8xP1.25x40 2
2-51 T8P051 Running Belt 1
2-52 T8P052 Bolt M8xP1.25x35 8
2-53 T8P053 Deck Fixing Plastic P-1034 8
2-54 T8P054 Bolt M4xP0.7x10 8
2-55 T8P055 Aluminum Deck 2
2-56 T8P056 Rear Roller Set 1
2-57 T8P057 Washer 10x20x2.0t 3
2-58 T8P058 Bolt M10xP1.5x110 2
2-59 T8P059 Rear Adjustment Box (L) P-1096L 1
2-60 T8P060 Rear Adjustment Box (R) P-1096R 1
2-61 T8P061 Bolt M5xP0.8x15 2
2-62 T8P062 Rubber Pad P-1032 2
2-63 T8P063 Bolt M6xP1.0x10 4

BLADEZ T8 PRO
TREADMILL
PARTS INFORMATION
www.ebladez.com Email:[email protected]
Page 5
• FIGURE 5
ITEM # PART # DESCRIPTION TOTAL QTY
2-64 T8P064 Incline Frame 1
2-66 T8P066 Incline Frame Fixity T*1000 2
2-69 T8P069 Plastic Sleeve P-1037 2
2-70 T8P070 Roller Ø10xØ60x30t 2
2-71 T8P071 Bolt M10xP1.5x60 2
2-72 T8P072 U-Shaped Pin 2
2-73 T8P073 Rpin 10x2.0 2
2-74 T8P074 Bolt M10xP1.5x100 1
2-84 T8P084 Bolt Ø5x38 8
2-85 T8P085 Cable Fixity UC-2 1
2-88 T8P088 Bolt M5xP0.8x8 4
2-89 T8P089 Washer Ø5xØ13x1.0t 8
2-90 T8P090 Rubber Pad 20x120x1.5t 8
2-93 T8P093 Rubber Pad P-1155A 3
2-94 T8P094 Washer Ø6xØ16x1.0t 5
2-95 T8P095 Feet Pad P-1155 2
2-96 T8P096 Bolt Ø4x15 2
2-97 T8P097 Sensor Fixity P-1152 1
2-99 T8P099 Spring Washer M8 4
2-100 T8P100 Bolt M8xP1.25x25 4
2-101 T8P101 Nut M8xP1.25 8
2-103 T8P103 Bolt K-298A 4
2-132 T8P132 Sound Insulation Pad 2

BLADEZ T8 PRO
TREADMILL
PARTS INFORMATION
www.ebladez.com Email:[email protected]
Page 6
• FIGURE 6
83
BLADEZ T8 PRO TREADMILL
