BLADEZ BLADEZ T6 PRO Setup guide

ILLUSTRATED PARTS MANUAL
Model Number:
Revised 12-11-06
BLADEZ T6 PRO
TREADMILL
Bladez Corp. 20155 Ellipse Foothill Ranch, CA 92610 Phone: [phone] Fax: [phone]
www.ebladez.com Email: [email protected]

BLADEZ T6 PRO
TREADMILL
PARTS INFORMATION
www.ebladez.com Email:[email protected]
Page 1
• FIGURE 1
132

BLADEZ T6 PRO
TREADMILL
PARTS INFORMATION
www.ebladez.com Email:[email protected]
Page 2
• FIGURE 2
ITEM # PART # DESCRIPTION TOTAL QTY
1-1 T6P001 Computer Console 1
1-1-1 T6P001-1 Bottle Holder 1
1-1-2 T6P001-2 Bottle Holder Set 1
1-2 T6P002 Bolt K-299 4
1-4 T6P004 Handrail Upper Cover (L) 1
1-4-1 T6P004-1 Handrail Upper Cover (R) 1
1-6 T6P006 Console Rear Cover 1
1-7 T6P007 Handrail Lower Cover (L) 1
1-7-1 T6P007-1 Handrail Lower Cover (R) 1
1-8 T6P008 Handle Pipe (L) 1
1-8-1 T6P008-1 Handle Pipe (R) 1
1-9 T6P009 Curved Pipe Cap 1-1/2”x1.5t 2
1-10 T6P010 PVC Foam Tube 2
1-11 T6P011 Upright Pipe (L) 1
1-11-1 T6P011-1 Upright Pipe (R) 1
1-13A T6P013A Bolt M4xP0.7x8 4
1-20A T6P020A Bolt K-415 8
1-25 T6P025 Bolt 5x25 2
1-37 T6P037 Safety Key 1
1-39 T6P039 Water Bottle 1
1-61A T6P061A Bolt M5xP0.8x15 8
1-87 T6P087 Controller Cable 1
1-89A T6P089A Elliptical Pipe Cap 2
1-90 T6P090 Cable (yellow, green) 14AWGx130mmx1T1R 1
1-91 T6P091 Cable (white) 14AWGx90mmx2T 1
1-92 T6P092 Cable (black) 14AWGx90mmx2T 2
1-93 T6P093 Cable (white) 14AWGx170mmx2T 1
1-94 T6P094 Cable (black) 14AWGx170mmx2T 1
1-112A T6P112A Bolt 4x12 2
1-118 T6P118 Wrench 6mmx80mmx80mm 1
1-119 T6P119 Wrench 5mm 1
1-120 T6P120 Screwdriver 1
1-132 T6P132 Chest Belt 1
1-135 T6P135 Nut M6xP1.0 4

BLADEZ T6 PRO
TREADMILL
PARTS INFORMATION
www.ebladez.com Email:[email protected]
Page 3
• FIGURE 3
40
88
88
88-1
40
98
98
43
44

BLADEZ T6 PRO
TREADMILL
PARTS INFORMATION
www.ebladez.com Email:[email protected]
Page 4
•FIGURE 4
ITEM # PART # DESCRIPTION TOTAL QTY
2-14 T6P014 Spring Washer M8 10
2-18 T6P018 Incline Frame 1
2-19A T6P019A Roller 60x10x30t 2
2-21A T6P021A Bolt M8xP1.25x25 4
2-22A T6P022A Plastic Sleeve 2
2-23A T6P023A Incline Frame Fixity 2
2-29A T6P029A Bolt M10xP1.5x60 2
2-30 T6P030 Nut M10xP1.5 3
2-34 T6P034 Nut M8xP1.25 8
2-40 T6P040 Bolt M5xP0.8x10 6
2-43 T6P043 Motor Cover (lower) 1
2-44 T6P044 Bolt M6xP1.0x10 13
2-45 T6P045 Motor 1
2-46 T6P046 Ribbed Belt 1
2-47 T6P047 Bolt M8xP1.25x20 4
2-48 T6P048 washer 8x19x3.0t 4
2-49 T6P049 Bolt M8xP1.25x15 2
2-50 T6P050 Motor Mounting Board 1
2-51 T6P051 Incline Motor 1
2-52A T6P052A Bolt M10xP1.5x40 1
2-53 T6P053 U-Shaped Pin 2
2-54 T6P054 R pin 10x2.0 2
2-55 T6P055 Controller 1
2-56 T6P056 Frame 1
2-57 T6P057 Power Socket 1
2-58 T6P058 Power Switch 1
2-59 T6P059 Circuit Breaker 1
2-60 T6P060 Sensor (round) 1
2-64 T6P064 Bolt M8xP1.25x35 6
2-67 T6P067 Cushion 6
2-68 T6P068 Bolt M4xP0.7x10 8
2-68A T6P068A Bolt M4xP0.7x15 1
2-69 T6P069 Deck Fixing Plastic 8
2-71 T6P071 Bolt M8xP1.25x55 3
2-72 T6P072 Washer 8x16x1.5t 3
2-73 T6P073 Bolt M8xP1.25x45 1
2-74 T6P074 Nut M8xP1.25 2
2-75 T6P075 Rear Adjustment Box (L) 1
2-76 T6P076 Rear Adjustment Box (R) 1
2-77 T6P077 Bolt M4xP0.7x20 2
2-78 T6P078 Upper Cover 1
2-79 T6P079 Front Roller Set 1
2-80 T6P080 Belt 1

BLADEZ T6 PRO
TREADMILL
PARTS INFORMATION
www.ebladez.com Email:[email protected]
Page 5
• FIGURE 5
ITEM # PART # DESCRIPTION TOTAL QTY
2-81 T6P081 Deck 2
2-82 T6P082 Rear Roller Set 1
2-83 T6P083 Bolt M8xP1.25x40 2
2-84 T6P084 Shock-Absorbing Foam 2
2-85 T6P085 Running Board 1
2-86 T6P086 Power Cable 1
2-88 T6P088 Cable Fixity UC-0 2
2-88-1 T6P088-1 Cable Fixity UC-1 2
2-97A T6P097A Rubber Pad 2
2-98 T6P098 Bolt M4xP0.7x16 6
2-103 T6P103 Sensor Fixity 1
2-105 T6P105 Bolt M5xP0.8x8 1
2-105A T6P105A Bolt M5xP0.8x10 2
2-141 T6P141 Sound Insulation Pad 2

BLADEZ T6 PRO
TREADMILL
PARTS INFORMATION
www.ebladez.com Email:[email protected]
Page 6
• FIGURE 6
40
132
BLADEZ T4-T6 PRO TREADMILL
88
88
88-1
40
98
98
43
44
