Treadmill Owner’s Manual
Bladez T6-T8 15” ME
BLADEZ Corporation
20155 Ellipse
Foothill Ranch, CA 92610
Phone: [phone]
Fax: [phone]
Email: H[email protected]
Revision Date: 8/17/06

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610
www.ebladez.com • Phone [phone] • Fax [phone]
1
INTRODUCTION:
C ongratulations for selecting Bladez as your primary source of fitness.
BLADEZ treadmills offer many exercise programs that benefit users of all
levels and ages. This treadmill is designed to make your workouts more
effective and enjoyable.
Please read this manual carefully before using your treadmill. This will allow
you to get a full understanding of all the features BLADEZ’ treadmills
provide. If you have any questions or concerns, please contact BLADEZ
Corporation or any authorized BLADEZ FITNESS distributors in your area.
BLADEZ Corporation
20155 Ellipse
Foothill Ranch, CA 92610
Phone: [phone]
Fax: [phone]
Email: H[email protected]
BEFORE YOU BEGIN
It is very important to become familiar with the frequently used components
of your Bladez treadmill.

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610
www.ebladez.com • Phone [phone] • Fax [phone]
2
TABLE OF CONTENTS
SECTION PAGE
1. IMPORTANT SAFETY INSTRUCTIONS............................................................... 3
2. ASSEMBLY INSTRUCTIONS................................................................................. 5
3. GETTING STARTED................................................................................................15
4. PROGRAM DETAILS ..............................................................................................22
5. PREVENTIVE MAINTENANCE.............................................................................29
6. TROUBLESHOOTING.............................................................................................30
7. WARRANTY.............................................................................................................32

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610
www.ebladez.com • Phone [phone] • Fax [phone]
3
SECTION 1
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions before using the treadmill.
Notice: Consult your family physician or health care professional to develop a well
planned exercise program to fit your health needs. If you encounter any pain or
breathing discomfort while working out, STOP!, and consult a physician before
continuing
WARNING!
1. It is wise to always unplug this appliance from the electrical outlet immediately
after use.
2. Keep Children away from machine while in use.
3. Do not wear loose or dangling clothing while using the treadmill
4. Keep a minimum clearance of 18” on each side and 24” at the rear of the treadmill
for safety.
5. It is mandatory that you unplug the treadmill prior to cleaning to reduce the risk
of electric shock, serious burns, and the risk of injuries.
6. The treadmill should never be left unattended when in operation. Unplug the
treadmill from the outlet when not in use or when servicing the treadmill.
7. Close supervision is necessary when this appliance is used by or near children,
invalids, or disabled persons.
8. Use this appliance only for its intended use as described in this manual.
Do not use any attachment not recommended by the manufacturer.
9. Never operate this appliance if it has a damaged cord or plug, or if it is not
working properly. Call your service center for any service concerns before taking
your treadmill in for repair.
10. Keep the cord away from heated surfaces.
11. Never drop or insert any object into any opening.
12. Do not use outdoors.
13. Do not operate where aerosol (spray) products are being used or where oxygen is
being administered.
14. To disconnect, turn all controls to the off position, then remove plug from outlet.
15. Connect this appliance to a properly grounded outlet only.
16. This appliance is intended for household use only.
SAVE THESE INSTRUCTIONS

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610
www.ebladez.com • Phone [phone] • Fax [phone]
4
IMPORTANT SAFETY INSTRUCTIONS CONTINUED
GROUNDING INSTRUCTIONS
This product must be grounded. If it malfunctions or breaks down, grounding
provides a path of least resistance for electric currents, to reduce the risk of
electric shock. This product is equipped with a cord that has an equipment-
grounding conductor and a grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in accordance with
all local codes and ordinances.
WARNING! – An improper connection of the equipment grounding
conductor can result in a risk of an electrical shock. Check with a qualified
electrician if you are in doubt as to whether the product is properly grounded.
Do not modify the plug provided to you. If it does not fit the outlet, have a
proper outlet installed by a qualified electrician.
This product is for use on a nominal 110-120-volt circuit and has a grounding
plug that looks like the plug illustrated in the figure. Make sure that the
product is connected to an outlet having the same configuration as the plug.
No adapter or extension cord should be used with this product.
GROUNDING METHODS
GROUNDED
OUTLET
GROUNDING
PIN

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610
www.ebladez.com • Phone [phone] • Fax [phone]
5
SECTION 2
ASSEMBLY INSTRUCTIONS T6
ITEM DESCRIPTION QTY
A Computer Set 1
B Frame 1
C Left Upright 1
D Right Upright 1
E Computer Rack Assembly 1
F Left Handrail 1
G Right Handrail 1
H Water Bottle Mounting Cover 1
I Left Handrail cover 1
J Right Handrail cover 1
K Computer cover 1
L Water Bottle 1

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610
www.ebladez.com • Phone [phone] • Fax [phone]
6
ASSEMBLY INSTRUCTIONS T6 CONTINUED
ASSEMBLY PART LIST
ITEM NO. DESCRIPTION
Q
UANTITY
a Bolt M8xP1.25x50 8
b Bolt M8xP1.25x60 4
c Bolt ψ5x25 4
d Bolt ψ4x12 2
e Bolt M5xP0.8x15 2
f Nut M6 4
g Bolt M4x8 4
h Allen wrench 6mm 1
i Allen wrench 5mm 1
j. Silicone 1
k Safety Key 1
l Power Cord 1
m Box Spanner + Screw Driver 1
n TV Remote Control 1

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610
www.ebladez.com • Phone [phone] • Fax [phone]
7
ASSEMBLY INSTRUCTIONS T6 CONTINUED
A minimum of two people are required
to assemble this treadmill. Also, read
and understand all instructions
thoroughly before assembling the
treadmill.
1. First, pull the control cord
bottom from the right upright
insert (D) and connect it with
the cord connector from the
right upright frame base. Secure
the left and right upright inserts
onto the upright frame bases
with 8 (a) bolts.
Note: While assembling the uprights,
one person should hold the
upright and the other tighten the
bolts.
2. Connect the control wire pulled
out from the upright tubes to the
control wire on the computer.
Insert (F, G) into computer rack
(E). When you fasten the bolts,
make sure the holes of the
computer rack and handrails are
lined up.

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610
www.ebladez.com • Phone [phone] • Fax [phone]
8
ASSEMBLY INSTRUCTIONS T6 CONTINUED
3. Connect the control wire pulled
out from the upright tubes to the
control wire on the computer
rack. Then the computer rack can
be placed on the frame railers
and fastened by 4 Bolts (b).
NOTE: When you fasten the bolts,
please pay attention not to
press the control cable inside
the tube.
4. Place bottle holder (H) above the
computer rack，fasten the holder
with 2 bolts (d). Then fit rail cover
(I, J) to position indicated in the
right side drawing. Secure them
by bolts (c, e).
NOTE: When you fasten the bolts,
please pay attention not to press
the control cable inside the tube.

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610
www.ebladez.com • Phone [phone] • Fax [phone]
9
ASSEMBLY INSTRUCTIONS T6 CONTINUED
5. Place the computer (A) on top
of treadmill. All of the control
cables need to match with
corresponding cables. Fasten
TV cover (K). The connected
control cables can be arranged
to fit in the computer rack. Then
fit the computer on to the
computer rack and fasten it by 4
nuts (f).
Note: When you connect the cables,
please pay attention to the
colors).
Red to Red.
White to White.

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610
www.ebladez.com • Phone [phone] • Fax [phone]
10
ASSEMBLY INSTRUCTIONS T8
ITEM DESCRIPTION QTY
A Computer Set 1
B Frame 1
C Left Upright 1
D Right Upright 1
E Console Welding-Base 1
F Left Handrail 1
G Right Handrail 1
H Left Handrail Cover 1
I Right Handrail Cover 1
J Cup/Bottle Holder Cover 1
K Computer cover 1
L Bottle 1

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610
www.ebladez.com • Phone [phone] • Fax [phone]
11
ASSEMBLY INSTRUCTIONS T8 CONTINUED
ITEM DESCRIPTION QTY
a Bolt M8xP1.25x40 2
b Bolt M8xP1.25x75 4
c Bolt Cover 6
d Bolt M8xP1.25x60 4
e Screw ψ5x25 2
f Screw ψ4x12 2
g Nut 4
h Bolt M6x15L 2
i Screw ψ4x16 1
j Allen Wrench 6mm 1
k T-Wrench 1
l Power Cord 1
m Safety Key/Clip 1
n SILICON 1
o Bolt M4xP0.7x8 4
p TV remote controller 1

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610
www.ebladez.com • Phone [phone] • Fax [phone]
12
ASSEMBLY INSTRUCTIONS T8 CONTINUED
A minimum of two people are required
to assemble this treadmill. Also, READ
and understand ALL INSTRUCTIONS
thoroughly BEFORE ASSEMBLING
the treadmill
1. Pull out the main wire within left
upright (C) with attached guide
wire.
2. Insert both uprights (C, D) into the
frame (B), and tighten with socket
screws (a, b).
3. After tightening the screws, cover
the screws with bolt covers (c) as
shown in the drawing.
4. Next slide left hand rail (H) and
right hand rail (I) into the computer
rack assembly (E).

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610
www.ebladez.com • Phone [phone] • Fax [phone]
13
ASSEMBLY INSTRUCTIONS T8 CONTINUED
5. Connect the main wire through the console
welding-base and pull out the wire from the
upper holes of the computer rack assembly.
6. Place the completed computer rack
assembly on the uprights as the drawing
shows.
7. Attach the computer rack assembly to the
uprights with the 4 socket screws (d).
NOTE: When you fasten the bolts, please
ensure that the wires are not pinched
by the bolts when securing the upright
and handrail.
8. Place the bottle holder (J) on the computer
rack assembly, and tighten with Allen-head
screws (f).
9. Assemble the right and left handrails covers
(F, G) with Allen-head self-tapping screws
(e, h, i).
NOTE: When you fasten the screws, please
ensure that the wires are not pinched.

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610
www.ebladez.com • Phone [phone] • Fax [phone]
14
ASSEMBLY INSTRUCTIONS T8 CONTINUED
11. Connect all the wire harnesses and
cables from the bottle holder
mounting cover onto the TV
console (A).
12. Secure console cover, rear (K) with
4 bolts (o).
13. Place the TV display console on the
bottle holder mounting cover and
fasten with 4 nuts (g) as shown.
* Ensure that all wiring is clear of any
‘pinch points’ when securing the
console.

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610
www.ebladez.com • Phone [phone] • Fax [phone]
15
SECTION 3
GETTING STARTED
MOVING THE TREADMILL
The treadmill has wheels located at the front as part of the elevation assembly. Elevate
the treadmill up to 10% or greater then unplug. Next, lift the rear of the treadmill and
push the treadmill using the front wheels.

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610
www.ebladez.com • Phone [phone] • Fax [phone]
16
GETTING STARTED CONTINUED
REMOTE CONTROL T6-T8 15” ME
SAFETY KEY & CLIP
Your Bladez treadmill is equipped with a safety key that will disable the treadmill if it is
not in place. You should attach the clip end to your clothing. The magnet end goes into
the recess of the console. If at any time you need to stop the treadmill quickly simply pull
the safety key off the console, you will see on the screen. This will cut all power
to the treadmill and it will come to a complete stop. To resume your workout, place the
safety key back in place. You will then need to program your workout again.
BEFORE STARTING
Straddle the running belt and stand on the side rails. Insert the safety key and attach the
clip to your clothing. Do not stand on the walking belt while starting or stopping the
treadmill.
TO STOP
1. Step off running belt onto the side rails.
2. Press STOP. The running belt will stop.
Note: For an immediate stop, pull out the safety key from the safety key
recess and the treadmill will stop abruptly.

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610
www.ebladez.com • Phone [phone] • Fax [phone]
17
GETTING STARTED CONTINUED
TV SYSTEM
SELECTION SETUP
1. Turn on POWER.
2. Main Screen Display on the
right will be shown after 20
seconds.
3. Press and hold button
on screen for about 10
seconds until you hear a beep,
then press “Speed ”.
4. TV System Selection window
will pop-up.
5. Press TV System Selection
button.
NOTE: You can switch the Speed
readout between Metric and
English while at this window.
Press ENTER and then press +
for Metric and – for English.
Press ENTER twice to exit.

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610
www.ebladez.com • Phone [phone] • Fax [phone]
18
GETTING STARTED CONTINUED
6. TV System Selection menu will
appear.
7. Press to pick the local TV
System in your area and the
previous menu will reappear.
8. Press ENTER three times to
end.
9. Power off and restart to put
new setting in effect.
TV/CATV/AV OPERATION
10. With the left button set to OFF, you can press
the right button to select among TV, CATV or
AV. When it is ON, then the Main Screen
Display is enabled.
11. Adjust volume or channel on screen.
QUICK START
1. Turn on POWER.
2. Press START on lower console or on screen. The running belt will start to
move at 0.5 MPH.
3. Adjust Speed with keys on lower console or on screen.
4. Adjust Incline with keys on lower console or on
screen.

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610
www.ebladez.com • Phone [phone] • Fax [phone]
19
GETTING STARTED CONTINUED
PROGRAM SETUP
1. Turn on POWER.
2. Main Screen Display on the
right will be shown after 20
seconds.
3. Press buttons on screen to
select any program.
4. Program submenu setup will appear.
5. Adjust input value by pressing or keys on screen.
6. Press ENTER to go to the next selection.
7. Repeat steps 5 and 6.
8. Press ENTER to begin.
9. Screen will display a workout
chart like the one shown on the
right.
Top: 1-hour workout profile -
Each grid represents a 5-minute
interval.
Bottom: Current workout profile
shown in a 5-minute interval.
Note: Blue line indicates elevation
and Light yellow line indicates
speed.
