Blagdon Powersafe Switch box 2 Way User manual

2/3/4/5 way
Established over 50 years ago, Blagdon are
committed to producing a comprehensive range
of high quality and easy to use water gardening
equipment. We have an on-going programme
of research and development that ensures
excellent product performance and value for
money for our customers. Our products are
brought together with half a century of expertise
and knowledge so you can be assured of a
successful and creative water garden.
Interpet, Vincent Lane,
Dorking, Surrey, RH4 3YX
www.blagdonwatergardening.co.uk
www.pondaquariumproblemsolver.co.uk/blagdon
Leaflet Code: 25/7/17 AP
www.blagdonwatergardening.co.uk
www.pondaquariumproblemsolver.co.uk/blagdon
garden power
switch box
DESIGN
INNOVATIVE

IMPORTANT: PLEASE FOLLOW STEP BY
STEP INSTRUCTIONS ON PAGES 3 - 7.
ALWAYS SWITCH OFF THE MAINS POWER
AND ISOLATE THE SWITCH BOX BEFORE
REMOVING THE COVER.
garden power switch box wiring diagram
REMOVE CIRCUIT BOARD
LOCATING SCREW
1 2 3 4 5
5 AMP SPARE FUSES 1.5 AMP
5 AMP FUSE 1.5 AMP FUSE 1.5 AMP FUSE 1.5 AMP FUSE 1.5 AMP FUSE
INPUT MAINS
ONLY
OUTPUT 1
MAX 1000W
OUTPUT 2
MAX 300W
OUTPUT 3
MAX 300W
OUTPUT 4
MAX 300W
OUTPUT 5
MAX 300W
REMOVE CIRCUIT BOARD TO AID WIRING
CIRCUIT BOARD LOCATING SCREW
*5 WAY MODEL
SHOWN AS EXAMPLE
E N L
5mm
25mm
Earth (E) YELLOW/GREEN
Natural (N) BLUE
Live (L) BROWN
CABLE PREPARATION
CABLE LOCATION
CABLE BLOCK
EARTH
NEUTRAL
LIVE
CABLE CLAMP
CABLE SEALING
CABLE GLAND
SEAL GRIP
RUBBER SEAL
GLAND COVER
