BLAUBERG Lux 100 Operating instructions

EN
Lux
Glory
Service Instructions

BLAUBERG Company is happy to offer your attention new
generation products, the BLAUBERG Lux and Glory fans.
The solid team of high-qualified professionals with many years of
working experience, technological innovations in design and
production, high-quality components and materials from the top
worldwide producers have become the precondition for the best
fans in their class.
INTRODUCTION
The present service instruction contains a technical description, technical
data sheets, operation and mounting guidelines, safety precautions and
warnings for safe and correct operation of the fans BLAUBERG Lux and
Glory.
USE
The fan is designed for exhaust ventilation of residential and public
premises heated during winter season. The fan is designed for wall
mounting, fig. 3-5.
COMPLETE SET
- fan - 1 item;
- screws and dowels - 4 items;
- plastic screwdriver (for the models with timer) - 1 item;
- service instruction;
- packing box.
The fan design is regularly improved, so some models can slightly differ from
those ones described in this service instruction.
18

Table 1
The fan does not cause interference with radio-, TV- or video- equipment.
Service life is not less than 5 years.
19
BASIC CHARACTERISTICS
The fan designations, delivery set options, parameters, outer view, overall
and connecting dimensions are shown in tables 1, 2, 3 and in fig. 1 and 2.
The model without timer is shown in fig. 1.
Type Max. air flow
3
[m /h] Power [W] Noise level,
3 m [dBA]
-1
RPM [min ]
Lux/Glory 100 14 2300
89 33
Lux/Glory 125 16 2400164 34
Lux/Glory 150 24 2400
258 37
Fig. 1
1 - front panel (for Lux - polished stainless steel,
for Glory - frosted glass);
2 - cover, 3 - LED light;
4 - decorative fitting piece; 5 - casing;
6 - electric motor, 7 - impeller,
8 - cover cap (only for Lux/Glory 150).
8
7
6
5
4
3
2
1

Dimensions [mm]
Table 3
Type
Lux 100
Weight
[kg]
20
Fig. 2
Lux 125
Lux 150
Glory 100
Glory 125
Glory 150
183
205
233
120
140
165
145
146
169
100
125
150
58
58
58
Timer (T) - turn-off time range from 2 to 30 min;
Humidity sensor (H) - humidity level range from 60% to 90%.
Type
Lux/ Glory 100
Lux/ Glory 100 T
Lux/ Glory 100 H
Timer Humidity
sensor
Table 2
Lux/ Glory 125
Lux/ Glory 150
Lux 100 T/H
Glory 100 T/H 183 120 153,6 98 67
a
181
b
120
c
148
d
100
98
e
56
65
0,65
0,7
0,85
0,85
0,9
1,15
231 165 161 150 56 1,05
1,65
140
120
154
151,6
125 56
183
204

21
OPERATION RULES
The fan is rated for connection to 220...240 V / 50 Hz power mains and is
designed for continuous operation always connected to power mains.
The air motion direction in the system must match the pointer on the fan
casing.
The fan is rated for operation at ambient temperature from +1 °C up
to +45 °C.
The fan does not require grounding.
SAFETY RULES
All operations related to the fan electrical connections, servicing and repair
works are allowed only after the fan disconnection from power mains.
All mounting and servicing operations are allowed for duly qualified
electricians with valid electrical work permit for electric operations at the
units up to 1000 V after careful study of the present user's manual.
The single-phase power grid must comply with the acting local electrical
norms and standards. The fixed electrical wiring must be equipped with an
automatic switch that is used for connection of the fan to power mains with
gap on all poles at least 3 mm.
Make sure the impeller and the casing are not damaged before starting
installation. The casing internals must be free of any foreign objects which
can damage the impeller blades. Misuse of the product or any
unauthorized modification are not allowed.

22
The product is not allowed for use by children and persons with reduced
physical, mental or sensory capacities, without proper practical experience
or expertise, unless they are controlled or instructed on the product
operation by the person(s) responsible for their safety.
Supervise the children and do not let them play with the product.
Take steps to prevent ingress of smoke, carbon monoxide and other
combustion products into the room through open chimney flues or other
fire-protection devices. Sufficient air supply must be provided for proper
combustion and exhaust of gases through the chimney of fuel burning
equipment to prevent back drafting. The maximum permitted pressure
difference per living units is 4 Pa.
Transported medium must not contain any dust or other solid impurities,
sticky substances or fibrous materials.
The fan is not rated for operation in a media that contains hazardous or
explosive materials and vapours, i.e. spirits, gasoline, insecticides, etc.
Do not close or block the fan intake or exhaust vent not to disturb the
natural air passage.
Do not sit on the fan and do not put objects on the fan.
Follow the guidelines of this service instructions to ensure durable
operation of the product.

23
MOUNTING AND SETUP
The fan is designed for wall mounting to extract air into a ventilation shaft
or matching air duct of respective diameter (fig. 3-5).
The fan mounting sequence is shown in fig. 6.
The fan wiring diagrams are shown in fig.7-10.
Fig. 3 Fig. 4
Fig. 5

24
Fig. 6

25
WIRING DIAGRAMS AND FAN OPERATION LOGIC
LUX/GLORY 100/125/150
S - external switch
QF - automatic switch
S1 - external fan switch
S2 - external fan lamp switch
QF - automatic switch
Fig. 7
Fig. 8
S
QF
S1
LN
N
LL
S2
QF
S
LN
N
LL
Fan does not run
Switch is
closed
Light is off
Fan runs
Light is on
S1/S2S1/S2
Fan does not run
Switch S1 and S2
are closed
Light is off
Switch S1 is closed,
switch S2 is opened
Switch S2 is closed,
switch S1 is opened
Fan runs
Light is on
Fan runs
Light is off
Fan does not run
Light is on
PE
PE

26
Switch is
closed
Switch is
opened
Turn-off delay
timer starts
(2 to 30 min)
LUX/GLORY 100 T
S - external switch
QF - automatic switch
S
Fig. 9
+
-
2min 30min
T
QF S
L
N
SL
N
L
Fan does not run
Light is off
Fan runs
Light is on
PE

27
+
-
60% 90%
H
S
Fig. 10
+
-
2min 30min
T
QF S
L
N
SL
N
L
PE
LUX/GLORY 100 H
S - external switch
QF - automatic switch
Turn-off delay
timer starts
(2 to 30 min)
Humidity is below
set point
Humidity exceeds
set point
Switch is
closed
YesNo
Switch is
opened
Humidity is below
set point
Humidity exceeds
set point
YesNo
Fan does not run
Light is off
Fan runs
Light is on
Fan runs
Light is on
Fan runs
Light is on

28
Fig. 11
WARNING!
The timer circuit is under mains voltage!
Disconnect the fan from power mains prior to any adjustment operations.
The fan delivery set includes a specially designed plastic screwdriver for
fan settings adjustments. Use the screwdriver to adjust the turn-off delay
time or the humidity threshold.
Do not use a screwdriver, knife, etc. for adjustment operations not to
damage the circuit board.
+
-
2min 30min
T+
-
60% 90%
H

29
MAINTENANCE
Any servicing and maintenance operations of the fan are allowed after it is
disconnected from power mains only.
Maintenance means regular cleaning of the fan surfaces from dirt and dust.
To clean the fan, wipe its surfaces with a cloth wetted in a mild soap
solution, then wipe the surfaces dry.
Avoid water dripping on the motor and circuit board!
STORAGE AND TRANSPORTATION RULES
Transportation is allowed by any transportation vehicle provided that the
product is in the manufacturer's original package.
Store the delivered product in the manufacturer's original packing box in
a dry ventilated premise with the ambient temperature from +5°C up
to + 40°C and relative humidity less than 80%.
The storage environment must be free of dust, acid or alkali vapours to
prevent corrosion.
DISPOSAL
Do not dispose in domestic waste. The unit contains in part material that
can be recycled and in part substances that should not end up as
domestic waste.
Dispose of the unit once it has reached the end of its working life
according to the regulations valid where you are.

30
MANUFACTURER'S WARRANTY
The fan complies with the requirements according to the EU norms and
directives, to the relevant EU-Low Voltage Equipment Directives,
EU-Directives on Electromagnetic Compatibility.
We hereby declare that the following product complies with the essential
protection requirements of Electromagnetic Council Directive 2004/108/EC,
89/336/EEC and Low Voltage Directive 2006/95/EC, 73/23/EEC and
CE-marking Directive 93/68/EEC on the approximation of the laws of the
Member States relating to electromagnetic compatibility. This certificate is
issued following test carried out on samples of the product referred to
above. Assessment of compliance of the product with the requirements
relating to electromagnetic compatibility was based on the following
standards.
Protection degree index according to IP rating against access to
hazardous parts and water ingress - IP24.
The manufacturer hereby warrants normal operation of the fan over the
period of five years from the retail sale date provided observance of the
installation and operation regulations.
In case of failure due to faulty equipment during the warranty period the
consumer has the right to exchange it.
If case of no confirmation of the sale date, the warranty period shall be
calculated from the manufacturing date.
The replacement is offered by the Seller.
The MANUFACTURER shall not be liable for any damage resulting from
any misuse of or gross mechanic interference with the fan.
Please follow the applicable instructions.

31
WARRANTY CARD

MANUFACTURED ON (DATE):
SALES DATE
APPROVAL MARK
SOLD
model is recognized
as serviceable.
100
125
150
T
H
Lux
Glory
3
4
1
2
5
6
LUX-GLORY DE_EN
