Blaupunkt BS 02 Instruction manual

Quick User Guide
Mobile phone BS 02

EN
1
Contents
1. Safety ........................................................................................... 2
2. Product specifications................................................................. 3
3. Keys and device appearance ...................................................... 3
4. Getting Started............................................................................ 5
4.1. Insert a SIM card ............................................................... 5
4.2. Insert a memory card........................................................ 5
4.3. Insert battery..................................................................... 5
4.4. Remove the battery ........................................................... 5
4.5. Charging the battery ......................................................... 6
4.6. Maintaining the battery .................................................... 6
5. Use this unit................................................................................. 7
5.1. Power On/Off..................................................................... 7
5.2. Make a call......................................................................... 7
5.3. Receive call ........................................................................ 7
5.4. Emergency calls................................................................. 8
6. Menu functions........................................................................... 8
6.1. Messaging ......................................................................... 8
6.2. Camera .............................................................................. 9
6.3. SOS function settings ........................................................ 9
6.4. Phone password .............................................................. 10
7. Declaration of Conformity ........................................................10

EN
2
1. Safety
Please read the safety instructions carefully, as ignoring it may be
dangerous or illegal.
The owner of the device is responsible for the use of this appliance.
Explosion hazards and restricted areas
Turn off the device in explosion hazardous areas. Sparks in such
places may lead to an explosion or fire that may result in serious
injury or death. Turn off the devicce at gasoline or gas filling
stations, especially near the fuel pumps. Follow the instructions
strictly in locations such as fuel tanks, chemical plants, and
explosive substances.
Road safety
Observe the local laws and regulations regarding smartphone
usage while driving. If you make a phone call while driving,
observe the following rules: Focus on driving to become aware of
traffic conditions; If the device has a hands-free function, use
handsfree. If the traffic situation requires, stop the car before you
pick up the phone.
Interference
Do not switch on the device, where it is prohibited to use a mobile
phone or to interfere with radio waves.
Qualified service
The product can only be repaired by a qualified person.
Charger, battery and other accessories
Only use a battery, charger and other accessories approved by the
manufacturer. Do not connect incompatible products.
Hearing protection
To avoid hearing loss, do not listen to music or radio for a long time
at high volume.
Water resistance
The appliance is not waterproof, so keep it dry.

EN
3
Use environment
The device complies with the recommended emission values for
radio waves when kept at a minimum distance of 1.5 cm from the
ear. When carrying the phone in a case, belt clip or holder, make
sure that it does not contain metal and that the phone is slightly
distracted from the body. When using other accessories, it is not
possible to operate in accordance with radio frequency guidelines.
If you do not use a case and do not hold the phone on your ear,
keep it at least 2.5 cm away from your body, especially during data
transfer.
2. Product specifications
The device handles a standard (Mini) SIM card.
Power Supply Features:
•Input: (AC), 100-240 V - 50/60 Hz – 0.1 A
•Output: (DC), 5 V - 500 mA
Battery Type and Voltage: Li-ion battery, 3.7 V, 1000 mAh
Network type: GSM 900/1800 MHz
SAR values: 0.731 W/Kg (Head) - 0.626 W/Kg (Body)
Note: Actual operating conditions depend on local conditions,
network environment, and user habits.
3. Keys and device appearance
Right softkey: In standby mode, enter Names. In Menu mode: to
return to the home screen
Left softkey: In standby mode: enter the Main menu and select
"OK" button in other menus
Call (Dial) button: Dialing and Receiving calls. In Idle mode, open
the Call list
Call End Button: Press and hold to turn on/off the phone
Arrow keys (scroll in the menu): In standby mode, various functions
can be set in the directions.
Flashlight button: Turning the flashlight on and off.

EN
4
SOS: In emergency, by pressing this button, alarms the previously
set contacts for this function.
Volume button: Increase and decrease the volume during calls
0-9 alphanumeric keypad: Press the corresponding keys to enter
numbers when dialing or the characters of the numbers when
writing text.
* (Star) button: in standby mode press and hold * to display the
international prefix '+'.
# (Dual Cross) button: in standby mode, press and hold to activate
/ deactivate Silent mode.

EN
5
4. Getting Started
4.1. Insert a SIM card
To use your phone, you need to insert a valid SIM card to connect
to the GSM network.
To avoid missing or damaged the contents of the SIM card, please
DO NOT hold the metal part of the SIM card with your hands free
and keep it away from electromagnetic devices. If the SIM card is
damaged, it can not be connected to the GSM network. Before
inserting or removing the SIM card, make sure that the device is
turned off and removed from the back of the device.
Note: Locate the SIM card slot on the back of the device and in the
direction of the signal, with the collisions slide the card.
4.2. Insert a memory card
The memory card is not part of the basic package, but the memory
of the device can be expanded with an SD card. Please make sure
that the memory card is inserted correctly before use.
Note that the device may shake, the memory card may slide out
of the slot, so please do not bend it, scratch the memory card or
expose it to static electricity or dust, do not immerse it in water.
Place the memory card in the slot on the back of the machine,
with a chip down, as shown on the device.
Please be careful when using a memory card, especially when it is
removed. Some memory cards must be formatted with a
computer before use.
4.3. Insert battery
1. Insert the battery chip into the protruding metal point in the
battery slot, insert the battery, and push the top down until the
battery engages in the recess.
2. Put back the back cover.
4.4. Remove the battery
To remove the battery, turn off the device, remove the cover, and

EN
6
then remove the battery.
Note:
Please remove the battery when it is switched off, as it may cause
abnormal operation.
4.5. Charging the battery
Connect the charger to the appliance and plug the other end into
the socket. If the device is turned on while charging, the battery
icon will move in the right corner of the display. Charging is
completed when the charging indicator on the top right is lit. If
charging is switched off, a charging indicator appears on the
display. When charging is complete, unplug the charger from the
unit.
Note: When the battery voltage is low, a warning message is
displayed on the display. Charge the battery as soon as you can, to
avoid any inconvenience, the device can be switched off during a
telephone conversation. Your device can automatically turn off
when the power level is too low.
1. If you use the battery at a persistently low charge, it may
adversely affect the battery life and quality.
2. Use only the charger approved by the manufacturer for proper
operation.
3. Do not remove the battery during charging.
4. Fill the unit for at least 4 hours before first use. This can increase
the efficiency of the multiple charge and discharge cycles.
4.6. Maintaining the battery
The device has a rechargeable battery. When not using the charger,
disconnect it from the power source. For more than a week, do
not leave the phone charging. Temperature influences battery
capacity. Battery may need to be cooled or warmed up before
charging. If the battery temperature is lower than 0 ° C or higher
than 45 ° C, do not charge the battery. Use the battery according
to its intended purpose. Do not short-circuit the battery terminals.

EN
7
Do not use a damaged battery. If you are using an appliance under
extreme temperature conditions, the battery will not work
properly and its life span will be reduced. DO NOT throw the
battery into fire, follow local laws and regulations regarding the
disposal of the spent battery.
5. Use this unit
5.1. Power On/Off
Press and hold the End / On-Off button to turn the unit on or off.
1. If a SIM card is not inserted, it is defective or not fit correctly, a
warning message will be displayed after switching on the display.
Turn off your readiness and make sure the SIM card is inserted
correctly.
2. If you insert the SIM card into the device, the PIN request and
the phone password are active, the device prompts you for the
password and PIN code and switches to standby mode.
After switching on, the phone automatically searches for the
network. If the device has found the allowed network, it will
display its name and signal strength.
If your device does not find a suitable network, you can only make
an emergency call or access non-network services on your phone
5.2. Make a call
When the network service provider name appears on the display,
the phone is ready to make and receive calls.
In Standby mode, press the number keys to enter the number you
want to call, press the right soft key to clear the wrong numbers,
press the left soft key or the dial key to start the call if the specified
number is correct.
To enter an international phone number format, press and hold
the [*] key until "+" international call sign appears on the display.
5.3. Receive call
When an incoming call is alerted to your device if your service

EN
8
provider supports the number display, the display shows the
caller's number or the caller's name (depending on whether you
have saved it in the phone book).
1. Press the dial key or the left soft key and answer [Answer] to
the incoming call.
2. If Any key responds function is active, [Settings / Call Settings /
Advanced Settings / Answer Mode / Anykey], you can answer any
call using any key except the Right softkey and the End / Off button.
3. When the headset is connected to the unit and [Headset] is
activated [Settings / Call settings / Advanced settings / Answering
mode / Automatic receiving in headset mode], incoming calls will
be automatically received by your phone after 5 seconds of
vibration or ringing.
4. If you do not want to answer the call, press the End / Off button
to reject the call.
The End / Off button can also be used to disconnect the call.
5. During a call, press the down / up navigation keys to reduce or
increase the loudspeaker volume.
5.4. Emergency calls
You can immediately make an emergency call without a SIM card.
Different networks can use different emergency numbers, so
please contact your network operator.
6. Menu functions
6.1. Messaging
Message service is a network-dependent service that allows you
to send and receive SMS. For more information, contact your
network provider.
Write a message
In Menu mode, select Messages> Write message.
Note: To send the SMS, you must have the correct message center
number from your network service provider. You can check and

EN
9
change the message center in Menu> Messaging> SMS settings>
SIM> Profile>SMSC address settings.
While writing a message, press # to switch between input modes.
Press the left soft key [Options] during message editing to access
the following functions:
Send to: You can specify the recipient of the message manually or
select it from Names.
Incoming messages
You can store received messages on your device or on the SIM
card and access it.
When you receive a message, a beep or vibration (as previously
configured in the menu) will alert you to this, or a graphic will
appear on the display. Press the left soft key [View] or OK to view
the message, and the right soft key to return to the SMS menu to
read other incoming messages.
6.2. Camera
In Menu mode, select Camera to open the camera.
• Point the lens towards the object and adjust the image.
• Take the photo with the „0” key.
Attention! To save the images, you need a memory card.
6.3. SOS function settings
To set the SOS function, go to Menu> Settings> SOS Settings.
•Status: activates the function (SOS button on the back of the
device).
•SOS numbers: dial the numbers listed here by pressing the SOS
button or sending an SMS message (if active) to the numbers in
the list. The alarm chain lasts until one of the numbers in the
list answers the call. Attention! Do not enter a number where
call reception is automatic.
•SOS SMS on / off: Enable or disable SOS SMS function.
•SOS SMS: In this menu item, you can edit the text of an
