Blaupunkt SM 02 User manual

User manual
Mobile phone SM 02

1
Table of Contents
1. Safety instructions.......................................................................3
2. Technical Specifications ..............................................................6
3. Getting started ............................................................................8
3.1 Insert the memory card and SIM card .................................8
3.2 Removing the memory card and the SIM card....................8
3.3 Unlock the device..................................................................9
4. Charging the battery .................................................................10
5. Switch the device on and off ....................................................10
6. Using the Touch screen.............................................................10
7. Using the Phone’s Buttons........................................................12
7.1 Virtual buttons.....................................................................12
7.2 Menu icons ..........................................................................12
8. Manage calls..............................................................................13
8.1 Make calls ............................................................................13
8.2 Airplane mode .....................................................................13
8.3 Receive a call .......................................................................13
8.4 Emergency calls...................................................................13
9. The Home screen ......................................................................14
9.1 Notification bar....................................................................14
9.2 Application Launcher ..........................................................15
9.3 Customize your home screen .............................................15
10. Connecting to the Internet.....................................................16
10.1 Configure the Internet: .....................................................16
10.2 Access Internet via Wi-Fi: .................................................17
11. Messaging ...............................................................................17
12. Multimedia..............................................................................18

2
12.1 Camera...............................................................................18
12.2 Photos................................................................................18
12.3 Music..................................................................................19
13. Contacts...................................................................................20
14. Phone.......................................................................................21
15. Search ......................................................................................22
16. Google Play Store....................................................................22
17. More applications ...................................................................22
17.1 Clock...................................................................................22
17.2 E-mail .................................................................................23
17.3 File manager / Files Go .....................................................23
17.4 Voice recorder...................................................................23
18. Settings....................................................................................23
18.1 Network & Internet...........................................................23
18.2 Connected devices ............................................................25
18.3 Applications and Notifications..........................................25
18.4 Battery ...............................................................................26
18.5 Display................................................................................26
18.6 Sound .................................................................................26
18.7 Security and location ........................................................26
18.8 Users and Accounts...........................................................27
18.9 System................................................................................27
19. Handling and maintenance ....................................................27
20. Recycling your device..............................................................29
21. Declaration of Compliance .....................................................29

3
1. Safety instructions
ATTENTION: Please read this guide carefully. Failure to comply with
the safety regulations may be dangerous or illegal, and the
manufacturer can not be held liable for any malfunction resulting
from improper use.
Safe switch-on
The owner of the device is responsible for the use of the device.
Never switch the device on in areas where wireless devices are
prohibited or radio interference may be dangerous.
Road safety
Observe the local laws and regulations regarding smartphone
usage while driving. If you make a phone call while driving,
observe the following rules: Focus on driving to become aware of
traffic conditions; If the device has a hands-free function, use
handsfree. If the traffic situation requires, stop the car before you
pick up the phone.
Interference
Wireless devices may be sensitive to interference that affects
performance.
Electronic devices
To avoid demagnetisation, do not leave your device for a long time
close to electronic devices.

4
Use in hospitals
Hospitals and other healthcare facilities can use devices that are
particularly sensitive to RF signals. Switch off your phone if
prohibited signals are instructed to do so, or hospital staff ask for
it.
Electrical medical devices
Your phone is a radio transmitter that can interfere with electronic
medical devices or implants such as hearing aids, pacemakers,
insulin pumps, and so on. We recommend that you keep a
distance of at least 15 cm between the implant and the device,
never wear your phone in the breast pocket. Follow the
instructions of the manufacturer of the medical device. If you have
a medical implant and have any other questions about using
mobile or wireless devices, ask your doctor.
Use on the airplane
Your device supports flying mode, please use this feature on the
airplane. Follow the instructions on the airplane.
Explosion hazards and restricted areas
Turn off the device in explosion hazardous areas. Sparks in such
places may lead to an explosion or fire that may result in serious
injury or death. Turn off the device at gasoline or gas filling
stations, especially near the fuel pumps. Follow the instructions
strictly in locations such as fuel tanks, chemical plants, and
explosive substances.
Use environment
The device complies with the recommended emission values for
radio waves when kept at a minimum distance of 1.5 cm from the
ear. When carrying the phone in a case, belt clip or holder, make

5
sure that it does not contain metal and that the phone is slightly
distracted from the body. When using other accessories, it is not
possible to operate in accordance with radio frequency guidelines.
If you do not use a case and do not hold the phone on your ear,
keep it at least 2.5 cm away from your body, especially during data
transfer.
Proper use
Please do not attempt to disassemble the device. If the product is
defective, contact your distributor.
Battery and other accessories
Only use parts and accessories approved by the manufacturer.
Using non-factory accessories and spare parts may result in
warranty loss. Please do not charge the device before inserting the
battery. Do not short-circuit the battery.
Charge the appliance in a well-ventilated and suitable temperature
environment away from flammable and explosive materials.
Handle the used battery according to local regulations and do not
throw it into household trash.
Water resistance
The appliance is not waterproof. Precipitation, fog, and other
liquids can corrode electronic circuits. If moisture has reached the
phone, remove the battery and contact the dealer.
Backup
Make a backup of all the data stored on your device.
Connect to another device
Before connecting an external device, read the safety instructions
in this manual. Do not connect an incompatible device.

6
2. Technical Specifications
Basic Features
•AndroidTM 8.1 Go edition
•4.95” FWVGA+ display, 480x960 pixel
•5 MP front camera
•8 MP back camera
•1.28 GHz Quad Core processor
•1 GB RAM + 8 GB ROM memory
•microSD card up to 32 GB
•1 NanoSIM + 1 Micro SIM card slot
•Multimedia functions
•Wi-fi
•Bluetooth
•2100 mAh battery
•GSM 900 / 1800 MHz
•WCDMA 900 / 2100 MHz
Power Supply Features:
• Input: AC 100-240V~50/60Hz 0.15 A
• Output: DC 5.0V –1.0 A

7
Battery:
•2100 mAh; 3.8 V
SAR value:
• 0.319 W/Kg (Head)
• 1.770 W/Kg (Body)
The mains power socket used must be close to the charger/holder
and easily accessible, so that it can be used as an on/off facility.
Phone layout
The following illustration of the phone is for informational
purposes only; your device may be different.

8
3. Getting started
3.1 Insert the memory card and SIM card
When subscribing to a service provider, they provides a SIM card
to use the network. Your SIM card has a phone number and
various services, but you can store data on it, for example. phone
numbers.
Turn off the power and remove the back cover and battery. Insert
the SIM card according to the mark on the device. Make sure that
the chip contact and the cut edge of the card are aligned in the
correct direction. Slide the card into the slot until it stops. The
device handles Nano SIM + Micro SIM + Micro SD cards.
Tip: Insert an SD card to store more media.
Caution: Do not scratch or bend the SIM card. Take care not to get
dust or water. Keep away from children.
3.2 Removing the memory card and the SIM card
Note: If the device is turned on, press the Off / Power button for 3
seconds until Turn Off appears on the screen. Select it and then

9
press the OK button. If the device is turned off, remove the
memory card and the SIM card. Do not try to remove the memory
card while it is booting because the data may be corrupted.
3.3 Unlock the device
To unlock the device, you may need the PIN
(not the SIM card PIN), password, or pattern
drawing.
Unlock the screen:
1. Press the power key to wake up
the phone.
2. Hold and drag the unlock icon to
the upward to unlock.
The process of unlocking depends on the
pre-configured unlock method.
To set the unlock method:
▪On the main menu, touch Settings > Security & Location.
▪Touch Set up screen lock.
▪Choose the type of locking as desired. You can set your
screen lock on the basis of Pattern, PIN, Password, Swipe
or None.

10
4. Charging the battery
➢Connect one end of the charger to the device.
➢Connect the charger to the power outlet.
➢Charging will start regardless of whether the device is
turned on or not.
➢When the phone is turned on, the movement of the
battery icon in the upper right corner indicates charging.
When the motion stops, the phone is charged.
➢When the phone is turned off, the movement of the
battery icon on the screen indicates charging. When the
motion stops, the phone is charged.
➢Disconnect the charger from the power outlet.
➢Disconnect the charger from the phone.
5. Switch the device on and off
Press and hold the Power button to turn on the power.
Press and hold the power button and select “Power off” from the
Options menu.
6. Using the Touch screen
You can use the touch screen in the following ways:
•Touch: Acts on items on the screen, such as application and
settings icons, to type letters and symbols using the onscreen
keyboard, or to press onscreen buttons.

11
•Touch and hold: Touch and hold an item on the screen until an
action occurs.
•Drag: Touch and hold an item and move your finger on the
screen until you reach the target position.
•Swipe or slide: Quickly slide your finger across the surface of
the screen, (without dragging an item). For example, slide the
screen up or down to scroll a list,
•Double-tap: Tap quickly twice on a webpage, map, or other
screen to zoom. For example, double-tap a section of a
webpage in Browser to zoom that section to fit the width of
the screen. You can also double-tap to control the zoom, in
Maps, and in other applications.
•Pinch: In some applications (Such as Maps, Browser, and
Gallery) you can zoom in and out by placing two fingers on the
screen at once and pinching them together (to zoom out) or
spreading them apart (to zoom in).
•Rotate the screen: On most screens, the orientation of the
screen changes as you rotate it. You can turn this feature on
and off.

12
7. Using the Phone’s Buttons
7.1 Virtual buttons
Button
Description
Apps: Opens the list of recent
applications.
Home: returns to Home screen.
Pressed long opens the Google
AssistantTM
Back: returns to the previous screen
you were working in
7.2 Menu icons
Dialer
Messaging
Camera
Browser (Chrome)

13
8. Manage calls
8.1 Make calls
▪Tap the icon on main menu or the home screen to dial the
desired number.
▪To dial an international number, touch and hold the 0 key to
enter the Plus (+) symbol, and then enter the international
country prefix, followed by the phone number.
▪Press the icon to dial.
▪You can control the volume using the Volume up /
down buttons on the side of the unit.
▪Dialer can also open Call log and Contacts.
▪While during a call, touch the icon to end a call.
8.2 Airplane mode
Some locations like airplanes may require you to turn off your
mobile, Wi-Fi, and Bluetooth wireless connections.
▪Press and hold the Power button.
▪Touch the Airplane mode.
8.3 Receive a call
In an incoming call, you can choose from the following options:
▪Drag the icon to up to receive the call.
▪Drag the icon to down to reject the call.
8.4 Emergency calls
You can also make emergency calls without a SIM card. For more
information, contact your network service provider.

14
9. The Home screen
When you sign in, the home screen
opens.
The Home screen is your starting point to
access all the features on your phone.
Touch the main menu icon at the bottom
of the screen to view all installed
applications.
9.1 Notification bar
The notification bar shows your device status and notifications.
Notification icons indicate new messages and events. When a new
notification arrives, its icon appears in the Notification Bar.
Notification Icons Status Icons
To see more information about notifications, open the notification
panel by swiping your finger over the top of the screen.
The status bar shows the time, signal
strength, battery
Touch and hold an empty spot to
change wallpaper.

15
Close the notification bar:
Drag the bottom of the notification panel to the top of the screen
or simply press the back button. The notification panel will also
close when responding to a notification.
9.2 Application Launcher
Drag up the Main Menu arrow at the
bottom of the screen to view all installed
apps. From here, you can access all
installed apps and widgets.
Touch the app to start.
Add an app to the Home screen:
To add an application shortcut to the
desktop screen, press and hold it until it
vibrates and enters Home screen. Place it
and release your finger.
Slide the Launcher up or down to bring
more icons into view.
9.3 Customize your home screen
You can add apps, widgets, other links to
your Home screens and change the
wallpaper.
Set up a wallpaper:
You can add a wallpaper from the Gallery,
which includes live wallpapers and
pre-installed wallpapers.
Tap on the Home screen anywhere, on an
empty surface. From the list that appears,
select Wallpapers. Choose an image from
the viewer or choose My Photos from other
sources in My Photos. Select the photo you

16
want to set up and confirm it by pressing the Wallpaper Setup at
the top of the screen. You can set the selected image to the
background of the Home screen, the Background screen of the
Lock screen, or both.
Creating folders:
Easily group your apps on the Home screen by creating folders.
Besides grouping, you can save space in folders by sorting.
Press the application icon and hold it to move the application.
Drag to the icon you want to sort into a folder. This creates a folder
to add additional apps.
To rename the folder, click the folder and then type the name on
the popup screen keyboard.
10. Connecting to the Internet
Your device has pre-installed browsers to access websites through
your mobile device. Open your browser and enter the URL of the
page you want to access in the address bar. You must have a
subscription to access the web pages, and you must complete the
appropriate configuration settings on your device.
10.1 Configure the Internet
Go to Settings > Network & Internet > Data usage > Tap Data
Enabled.
By default, your network provider sends the Access Point Name
settings via SMS, or it comes automatically with your SIM card. You
may need to install these settings. After this, you can choose from
the listed access point names. If the access point names are not

17
listed by default, please contact your network provider for the
same.
To add any operator Access point Name, go to Settings Network &
Internet > Mobile network > Access Point Name.
10.2 Access Internet via Wi-Fi
Go to Settings > Network & Internet > Wi-Fi, then enable Wi-Fi.
Next, select the WIFI connection listed under Wi-Fi networks.
11. Messaging
Select Messages in the Main Menu or the Standby screen.
11.1 Send Message
To send a new message, tap the + icon in the right corner of the
screen.
Enter the recipient's phone number or select from the Contacts
list.
If you have selected the recipients, confirm the arrow icon at the
top right of the screen.
Enter the text of the message and press the send key.
To add an attachment, press the +icon on the left.

18
When you edit a message, the default message type is SMS. As
soon as you add an attachment or reach 10 SMS messages, the
phone automatically switches to MMS.
11.2 Input methods
The device contains various input modes. In Editing mode, press
and hold [,] to display Input Options and to set the keyboard.
•Writing Numbers
Press to display the number keys directly. You can also enter a
number with the letters containing the numbers: press and hold,
then swipe to the desired character.
•Writing Symbols
Press to open the list of symbols. Press the symbol you want to
enter.
Press and hold [. ] to display the list of symbols, slide your finger to
the symbol you want to enter.
12. Multimedia
12.1 Camera
Use the camera to take photos and video clips. To open the
camera, press the Camera icon in the main menu. To take a
photo or video, press the recording icon . To set the
camera parameters, press the Settings icon in the bottom left
corner of the screen.
12.2 Photos
In the Google Photos app, you can view pictures and videos taken
with your camera, or those stored on your SD card.

19
12.3 Music
To play music, on the Applications screen, select Play Music:
In the Music Library, you can switch between the following
categories:
During music playback, you can scroll through the tracks forward,
backward, pause playback, or press Options to add to the Playlist.
During playback, you can use the following functions:
Repeat
Shuffle Play.
Note: The default music player application is Play Music. Additional
playlists can be downloaded from the Play Store.
The Play Music application from the SD card plays the music stored
when you save them to My Music. You can play music files stored
in your device's internal memory from any directory.
12.4 FM Radio
Connect the headset, then press the FM Radio icon in the main
menu. By opening the channel list, the machine automatically
searches for and stores available stations.
FM Radio Channel list Radio on Radio off
You can move forward or backward through the channels and add
the currently listened channel to Favorites:
