Blaupunkt New Orleans 900 DSP User manual

VELOCITY POWER
MULTIMEDIA NAVIGATION
NEW ORLEANS 900 DSP
NEW ORLEANS 1000 DSP
NEW ORLEANS 900 DSP
NEW ORLEANS 1000 DSP
Operating and Installation Instructions
10.1 ”
9.0”

CAUTIONS
Safety Notes
This car radio has been manufactured according to
established safety guidelines. However, dangers may still
occur if the safety notes in this manual is not observed.
This manual is intended to familiarize the user with the
car radio’s important functions. Read this carefully, prior
to using the car radio. Keep this manual in an easily
accessible location. In addition, do observe the
instructions of the devices used in conjunction with this
car radio
Road Safety
Always observe the following notes for road safety:
•
•
•
General Safety Notes:
Observe the following for protection against injuries:
•
•
•
•
•
•
•
This manual may be updated from time to time without
any notice.
Disclaimer
In no event shall Blaupunkt be liable for any direct,
indirect, punitive, incidental, special consequential
damages to property or life and whatsoever arising out
of or connected with the use or misuse of our products.
USA & CANADA: This product is not intended for sale in
the United States and Canada. If purchased in the U.S. or
Canada, this product is purchased on as-is basis. No
warranty, whether expressed or implied is provided in
the U.S. or Canada.
Disposal Notes
Do not dispose of your old unit in the
household trash!
Use the return and collection systems
available to dispose of the old device.
Radios with Detachable Panel - Damage to the
control panel
•
•
•
•
Scope of Delivery
•
•
•
•
•
•
•
•
1 2
CAUTIONS
Car radio must be used in a way that compliments
safety of the user when driving the vehicle. It is
recommended for the user to park at an appropriate
location when operating the car radio. While
driving, user is not recommended to use
applications that can be prone to distraction e.g.
streaming to medias etc.
Radios with Navigation : User is recommended to
proceed with proposed driving routes only if it does
not violate any trac regulations. Local tracc signs
and regulations always prevail over the routes
proposed.
User is advised to keep the volume of the car radio
to a moderate level for the protection of the ears
and to increase the ability to hear any emergency
warning signals (e.g. police and ambulance sirens).
Do not increase the car radio volume while the car
radio is muted as it is not audible. The car radio
volume can be too loud when the car radio is
unmuted.
This car radio is intended for installation and
operation in a vehicle with 12V vehicle system
outage, hence the radio unit must be installed in a
DIN slot. Observe the output limits of the car radio.
Do not dismantle or modify the car radio.
Installation and repairs, if necessary, should be
performed by a specialist. We are not liable for any
loss or damage caused or resulting from
unauthorized disassembly or modication to the
product.
This car radio’s core components may result to
damage when the car is driven on bumpy roads for
a prolonged period of time or if it is used to play
non-standard or severely damaged discs.
Please do not operate the car radio under extreme
temperature conditions (extremely high
temperature or extremely low temperature); make
sure that temperature within the car ranges from
-20°C to 70°C before you connect the car radio to
the power supply.
For abnormalities, please refer to the
“Troubleshooting”section. If the problem cannot be
resolved, please press the Reset button to recover
its factory settings. Otherwise, please contact
respective installer/seller directly for help.
As SD/USB le formats, codecs, bitrate, resolution
and other parameters available in the market are
not all the same, there is no guarantee that this car
radio can play all media le formats.
Dierent cars may have dierent congurations. It is
normal that some CAN-Bus functions cannot be
enabled because it is not supported by the user’s
car or this car radio.
Solvents, cleaning and scouring agents as well as
dashboard spray and plastics care products may
contain materials which can damage the surface
and screen of the car radio. Use only dry or slightly
moistened cloth to clean the car radio surface and
screen.
Never drop the control panel.
Transport the control panel so that it is protected
against impacts and the contacts cannot become
dirty.
Do not expose the control panel to direct sunlight
or another heat source.
Avoid direct skin contact
User Manual
Connecting cables
AVN harness
360 AVM (Optional)
USB cables
External Microphone
GPS Antenna
4G Antenna

HOME PAGE
BT
•
•
PHONELINK
Android - Support iOS & Android
•
•
Pre-pair BT
Ensure mobile phone supports Bluetooth function
before pairing. Dierent mobile phone will have
dierent emissive power. To get the best connection,
the recommended distance range is 3m without any
object obstruction.
Pairing
•
•
Pre-pair PhoneLink
iOS : Supported 1 way control
•
Android : Supported 2 way control
•
Pairing
iOS : Supported 1 way control
•
Android : Supported 2 way control
•
KEY FUNCTIONS OPERATION
Mircophone
RESET Button
Power Button
• Press and hold turn on or turn o
• Press to mute or unmute
Home Page
Return Button
Increase Volume
Decrease Volume
Functions
1.
2.
3.
4.
5.
6.
7.
Turn on mobile phone’s Bluetooth to set up.
(Please refer to the instruction manual of the
mobile phone on how to operate Bluetooth)
“NEW ORLEANS 900 DSP” or “NEW ORLEANS
1000 DSP” should appear on your available
Bluetooth scanning list.
Select “NEW ORLEANS 900 DSP” or “NEW
ORLEANS 1000 DSP” then insert password“0000”,
if password is required. Select conrm buttons
when pairing prompt message appear. will
appear in white colour in the Home Page when
pairing successful.
Go to mobile phone’s Settings to turn on the
personal hotspot.
Go to mobile phone’s Settings to connect to car
radio’s Bluetooth (for audio output) and enable
USB debugging (Please refer to the instruction
manual of mobile phone on how to operate USB
debugging and Bluetooth setting).
GENERAL
Power supply (12V)
Current consumption
Max. power output
Dimension (WxLxH)
Weight
Operation temperature
Screen size
Resolution
Aspect ratio
FM Stereo Radio
Frequency range
Preset memory stations
AM/MW Radio
Frequency range
Preset memory stations
Audio Specication
Frequency response
Parametric Equalizer
Input
USB 2.0
Aux-in
BT
Hands-Free Calling : Accept/ Hang Up/ Reject Call
Phone Book Access
Audio Streaming
Streaming Audio/ Video Control
Support for Bluetooth Headset
Serial Port Prole
.............................................10 V ~ 16 V DC
.............................................. max. 10 mA
.......................................................... 4 x 50W
.............................229 x 130 x 45mm (9”)
252 x 147 x 47mm (10.1”)
.............................................................................0.82kg (9”)
0.93kg (10.1”)
........................................ -20°C ~ 60°C
......................................................... 9 inch/ 10.1 inch
.......................................................... 1280 x 720 pixel
..................................................................... 4:3 / 16:9
................................................. 87.5 - 108MHz
.............................................................18
................................................. 522 - 1620kHz
........................................................... 12
................................................32Hz-16kHz
.......................................................48-Band
............................................................. Audio : MP3, FLAC
Video : AVI, MP4
Image : JPG
........................................................................................... RCA
.......HFP
................................................................PBAP
....................................................................A2DP
....................................AVRCP
...........................................HSP
........................................................................SPP
3 4
1
2
3
4
5
6
7
Connect the unit with smartphone using iOS
hotspot, activate the screen sharing from
smartphone & project smartphone’s display when
pairing successful.
Connect the unit with smartphone using USB cable.
The unit will begin to project smartphone’s display
when pairing successful.

TROUBLESHOOTING WIRING DIAGRAM
Problems
Unable to start up
No sound
No rear-view reverse
Unable to search
radio stations
Possible Causes
The car key is not inserted into the
ignition; ignition is o
Power Cable is not inserted into the
main body.
Burnt power fuse .
Drained car battery.
Audio cables are not properly connected
to the unit.
Mute setting is on.
Low volume.
No sound from front, rear, left & right
speakers due to Fade-Balance settings.
The rear camera is not appropriately
connected with power supply.
Camera’s signal line not plugged in.
Radio’s antenna is not well inserted.
Solutions
Insert the car key and turn on the ignition.
Insert the power cable.
Replace it with a new fuse.
Charge or replace the car battery.
Ensure proper connection of the audio cables.
Unmute the volume.
Adjust the volume.
Select Equalizer from Home Page to adjust setting.
Examine the camera’s power supply connectivity.
Insert the camera’s signal line into the interface
port of this unit.
Ensure radio antenna is properly installed.
If any of the following problem occur, please resort to Troubleshooting for the possible solutions. Consult Blaupunkt
authorized dealer if problem persist.
NO.
1
2
3
4
WIRE
RED
BLACK
GREEN
WHITE
E
USB_PWR
GND
USB_DP0
USB_DN0
NO.
1
2
3
4
WIRE
RED
BLACK
GREEN
WHITE
F
USB_PWR
GND
USB_DP2
USB_DN2
NO.
1
2
3
WIRE
RED
YELLOW
BLACK
G
SW_B+
BACK_CAMERA
GND
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
WIRE
PURPLE/ BLACK
PURPLE
GREEN
GREEN/ BLACK
-
-
-
YELLOW
WHITE
WHITE/ BLACK
GREY
GREY/ BLACK
-
-
RED
BLACK
A
RR-
RR+
RL+
RL-
ANT.PWR
SW2
ILL
B+
FL+
FL-
FR+
FR-
SW1
BACK
ACC
GND
NO.
1
2
3
4
5
6
7
8
9
10
11
12
WIRE
-
BLACK
BLACK
BLACK
BLACK
RED
-
YELLOW
YELLOW
YELLOW
YELLOW
RED
B
LEFT_DET
GND
GND
GND
GND
360_VDD
RIGHT_DET
VIN_FRONT
VIN_RIGHT
VIN_REAR
VIN_LEFT
360_VDD
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
WIRE
RED
WHITE
-
-
-
-
RED
BLACK
BLACK
WHITE
RED
BLACK
BLACK
BLACK
-
YELLOW
-
C
AUX_R
AUX_L
SIM1_DA
SIM1_DET
SIM1_CLK
SIM1_RST
VDD_SIM1
GND
GND
RCA-FL-OUT
RCA-FR-OUT
GND
GND
GND
SUB_OUT
AUX_CVBS
MIC1_P
NO.
1
2
3
4
5
6
7
8
WIRE
BLACK
WHITE
-
-
-
RED
-
-
D
GND
RCA-RL-OUT
SPDIF_OUT1
UART5_RXD
RCA-CENTER-OUT
RCA-RR-OUT
SPDIF_OUT2
UART5_TXD
5 6

Designed and engineered by Blaupunkt Competence Centre
NEW ORLEANS 900 DSP
1 104 21 034 20 01
NEW ORLEANS 900 DSP
1 104 21 035 20 01
