Model BLP-30E (30 gallon electric braising pan with power tilt)
Model BLP-40E (40 gallon electric braising pan with power tilt)
CONSTRUCTION
#4 finish 10 gauge stainless steel pan with polished interior, front
hinged for easy tilting
Coved corners
5/8” thick stainless steel clad plate
Tubular heating elements clamped to underside of pan
Welded stainless steel pipe frame with bullet feet on front legs and
flanged adjustable feet on back legs
Front control console
OPERATION
Integrally mounted controls
Power switch
Thermostat
Cook indicator light
High temperature cut-off
Tilt switch
160-445°F (71-230°C) temperature range
STANDARD FEATURES
Electric motor driven screw jack for smooth and precise tilting
Spring assist hinged stainless steel cover with handle
No drip condensate guide
Removable pour strainer
Manual control
Standard voltage options
208 VAC, 1 phase, 60 Hz
240 VAC, 1 phase, 60 Hz
208 VAC, 3 phase, 60 Hz
240 VAC, 3 phase, 60 Hz
One year parts and labor warranty*
* For all international markets, contact your local distributor.
BLODGETT
44 Lakeside Avenue, Burlington, VT 05401
Toll Free: [phone] • Phone: [phone] • Fax: [phone]
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Voltage options
220 VAC, 1 phase, 60 Hz
220 VAC, 3 phase, 60 Hz
220/380 VAC, 3 phase, 60 Hz
240/415 VAC, 3 phase, 60 Hz
480 VAC, 3 phase, 60 Hz
600 VAC, 3 phase, 60 Hz
Faucets
Single pantry faucet with swing spout
Double pantry faucet with swing spout
Etched markings
Gallons
Litres
18 kW elements (40 gallon braising pans only)
Steam pan insert
Pan carrier
Correctional package
BLP-E
Electric Floor Model Braising Pan with
Power Tilt
BLP-E BRAISING PAN WITH POWER TILT

BLODGETT
44 Lakeside Avenue, Burlington, VT 05401 Toll Free: [phone] • Phone: [phone] • Fax: [phone]
BLP-E ELECTRIC BRAISING PAN
WITH POWER TILT
SHORT FORM SPECIFICATIONS
Provide Blodgett model BLP-30E, 30 gallon (114 litre) or BLP-40E (152 litre) electrical braising pan with power tilt. The unit shall have a one-piece coved corner, 10 gauge stainless steel
pan with #4 exterior finish and polished interior.The pan body shall be front hinged for tilting and easy pour control. Cooking surface shall be 5/8” thick stainless steel clad plate ensuring
even heat distribution over entire cookng surface.The pan shall be fitted with tubular heating elements clamped to the underside. Unit shall be mounted on stainless steel tubular legs with
front legs fitted with adjustable bullet feet and rear legs fitted with flange adjustable feet for securing to the floor. Tilting is controlled by an electric motor driven screw jack for smooth and
precise tilting action. The controls shall be integrally mounted in the right hand console and shall include a power switch, tilt switch, thermostat with range of 160-445°F (71-230°C), a
cook indicator light and high temperature cut-off. Unit shall include spring assisted hinged stainless steel cover, with handle, no drip condensate guide and removable pour strainer.
Provide options and accessories as indicated.
MAXIMUM INPUT:
BLP-30E 12 kW
BLP-40E 15 kW (18 kW option available)
POWER CONNECTION:
Refer to data plate.
WATER CONNECTION
Hot and Cold water 3/8” O.D. tubing to optional faucet
SHIPPING INFORMATION:
Approx. Weight:
BLP-30E 540 lbs. (245 kg)
BLP-40E 620 lbs. (281 kg)
Printed in U.S.A. NOTE: FOR COMMERCIAL USE ONLY
NOTE: The company reserves the right to make substitutions of components without prior notice.
APPROVAL/STAMP
P/N S00018 Rev E (12/06)
MODEL A B C D E
BLP-30E 36[914] 33.5[851] 74[1880] 33.5[851] 23.5[597]
BLP-40E 48[1219] 45.5[1156] 74[1880] 43.5[1105] 23[584]
VALVE DIAMETER F G
2” 3.6[92] 7.3[186]
3” 5.5[140] 13.1[333]
AMPS PER LINE
kW Phase 208V 220V 240V 380V 415V 480V 600V
12 kW 1 57.7 54.5 50 N/A N/A N/A N/A
3 33.3 31.5 28.9 18.2 16.7 14.4 11.5
15 kW 1 72.1 68.2 62.5 N/A N/A N/A N/A
3 41.6 39.4 36.1 22.8 20.9 18 14.4
18 kW
Option
1 86.5 81.8 75 N/A N/A N/A N/A
350 47.2 43.3 27.3 25.0 21.7 17.3
