PARTS LIST
GAS CONVECTION STEAMER
MODELS: SC-7G
SC-10G
October 9, 2006

FIGURE 1

PARTS LIST, GAS CONVECTION STEAMER, MODELS SC-7G, SC-10G
FIGURE 1
ITEM Part # DESCRIPTION SC-7G SC-10G
1. 40543 Hinge Rod 1
40544 Hinge Rod 1
2. 42137 Door Switch 1 2
42285 Switch Actuator 2 2
3. 41631 Striker 2 2
41632 Washer 2 2
40112 Lock Washer 2 2
40112 Hex Nut 2 2
42322 Washer 2 2
4. 40945 Pilot Light - Green 2 2
5. 40945 Pilot Light - Green 2 2
6. 40950 Pilot Light - Red 2 2
** 7. 42456 Dial - 60 Minutes 2 2
42456 Dial - 120 Minutes, Optional 2 2
8. 43174 Power Switch 2 2
9. 42455 Control Decal 1
42895 Control Decal 1
10. 41190 Component Mounting Board 2 2
** 11. 42452 Level Control 10K OHM 2 2
41063 Level Control 1M OHM, Optional 4 4
12. 40707 End Section 1 1
13. 40708 Terminal Block 2 2
14. 40840 Ground Lug 1 1
15. 40441 Elbow 1/4c x 1/8 MPT 2 2
16. 41036 Solenoid Valve 4 4
17. 40443 Elbow 3/8c x 1/8 MPT 4 4

PARTS LIST, GAS CONVECTION STEAMER, MODELS SC-7G, SC-10G
ITEM Part # DESCRIPTION SC-7G SC-10G
18. 42093 Relay 120V 2 2
19. 41093 Ignition Module (3 Trial) 2 2
40871 Wire Harness 2 2
20. 40450 Elbow 1/2c x 3/4 MPT 2 2
21. 40601 Blowdown Solenoid 2 2
22. 40421 Connector 5/8 c x 3/4 MPT 2 2
23. 40424 Connector 1/4 C x 1/8 MPT 2 2
24. 42706 Cord Set, 120V 1 1
25. 40877 Hi Limit Sensor 2 2
26. 41887 Thermostat Operating 2 2
27. 40447 Elbow 1/2C x 1/4 MPT 4 4
28. 42095 Relay 120V 4 4
29. 40484 Buzzer 2 2
30. 41358 Generator Tank - Bottom 1 1
** 31. 40972 Timer, 60 Minutes 2 2
43275 Timer, 120 Minutes, Optional 2 2
43274 Overlay, 120 Minutes 2 2
32. 41052 Right Hand Steam Jet Tube 2
41051 Right Hand Steam Jet Tube Bottom 1
41049 Steam Jet Tube - Right & Left Hand Top 2
33. 41053 Left Hand Steam Jet Tube 2
41050 Left Hand Steam Jet Tube Bottom 1
34. 40472 Probe - Low Level Cut Off 2 2
35. 40471 Probe - Low Level 2 2
36. 40470 Probe - High Level 2 2
37. 41359 Generator Tank-Top 1 1
38. 40406 Union Connector ½ C 2 2

PARTS LIST, GAS CONVECTION STEAMER, MODELS SC-7G, SC-10G
ITEM Part # DESCRIPTION SC-7G SC-10G
39. 43276 Plug 3/4 2 2
40. 43277 Tee 3/4 2 2
41. 41044 Down Tube 2 2
42. 43278 Close Nipple 3/4 2 2
43. 41078 Relief Valve 5 psi 2 2
44. 43279 Nipple 3/4 x 2 ½ 2 2
45. 43280 Elbow 3/4 2 2
* 46. 40369 Steam Diverter 4 4
* 47. 40205 Thermostat Fitting 3/8 C x 3/8 MPT 2 2
* 48. 40475 Water Connection 3/8 C 2 2
* 49. 40411 Elbow - ½ C Tank Left Hand 2 2
* 50. 40199 Pan Rack - Top 2
40200 Pan Rack - Bottom 2
40201 Pan Rack 4
* 51. 41633 Perforated Door Trough 1 1
* 52. 41195 Right Hand Side Panel 1
41188 Right Hand Side Panel 1
* 53. 41196 Left Hand Side Panel 1
41189 Left Hand Side Panel 1
* 54. 40794 Top Cover 1 1
55. 43287 Bottom Flue 1 1
43288 Top Flue 1 1
* 56. 43281 Flue Assembly 1 1
* 57. 41194 Right Hand Side Riser 1 1
* 58. 41193 Left Hand Side Riser 1 1
* 59. 41191 Front Side Riser 1 1
* 60. 41210 Rear Side Riser 1 1

PARTS LIST, GAS CONVECTION STEAMER, MODELS SC-7G, SC-10G
ITEM Part # DESCRIPTION SC-7G SC-10G
* 61. 41844 Fuse Holder 2 2
* 62. 41860 Fuse 2A 250V (120V only) 2 2
41859 Fuse 1A 250V (220V only) 2 2
* 63. 41142 Wire Harness 2 2
* 64. 41182 Operation Instruction Decal 1
43282 Operation Instruction Decal 1
* NOT SHOWN.
** SELECT AS REQUIRED.

PARTS LIST, GAS CONVECTION STEAMER, MODELS SC-7G, SC-10G

PARTS LIST, GAS CONVECTION STEAMER, MODELS SC-7G, SC-10G
FIGURE 2
PARTS LIST
ITEM Part # DESCRIPTION SC-7G SC-10G
1. 42641 Door ( Top ) 1
42640 Door ( Lower) 1
43283 Door Frame, Bottom 1
42638 Door Frame, Top 1
2. 42676 Door Handle Assembly 2 2
42454 Door Handle Decal 2 2
3. 41679 Latch Assembly 2 2
4. 41699 Bushing 8 8
5. 43264 Spacer 4 4
6. 41671 Door Panel 2
41670 Door Panel, Bottom 1
41672 Door Panel, Top 1
7. 41657 Door Gasket 2
41656 Door Gasket, Bottom 1
41658 Door Gasket, Top 1
8. 41664 Gasket Plate 2
41663 Gasket Plate, Bottom 1
41665 Gasket Plate, Top 1
9. 41875 Gasket Panel Screws 14 16
10. 42682 Door Assembly (Top) 2
42681 Door Assembly (Bottom) 2
42679 Door Assembly ( Top) 1
42678 Door Assembly, (Bottom) 1

PARTS LIST, GAS CONVECTION STEAMER, MODELS SC-7G, SC-10G
BURNER PARTS, NATURAL GAS ONLY FIGURE 3
ITEM Part # DESCRIPTION SC-7G SC-10G
1. 41035 Spark Electrode 2 2
2. 41033 Spark Electrode Bracket 2 2
3. 41184 Gas Manifold Assembly 2 2
4. 40386 Orifice #43 4 4
5. 41813 Plug 1/8 NPT 2 2
6. 41185 Burner Mounting Bracket 2 2
7. 41183 Burner 4 4
8. 41056 Burner Support 2 2
9. 40270 Fender Washer 1/4 4 4
10. 43015 Hex Cap Screw 1/4-20 x 1 ½ 2 2
11. 43005 Machine Screw 10-32 x 3/8 4 4
12. 43013 Machine Screw 1/4-20 x ½ 2 2
43284 Lock Washer 1/4 2 2
13. 43285 Machine Screw 8-32 x 3/8 8 8
14. 43006 Machine Screw 6-32 x 3/8 2 2

PARTS LIST, GAS CONVECTION STEAMER, MODELS SC-7G, SC-10G
ITEM Part # DESCRIPTION SC-7G SC-10G
1. 43286 Hex Screw 8-32 x 1/4 8 8
2. 41094 Pilot Burner 2 2
3. 41237 Burner Mounting Bracket 2 2
4. 43010 Machine Screw 4 4
5. 42446 Spark Electrode 2 2
6. 42805 Pilot Tube 2 2
7. 43013 Machine Bolt 4 4
8. 41813 Plug 1/8 NPT 2 2
9. 41298 Gas Manifold Assembly 2 2
10
.
40441 Elbow 1/4C x 1/8 MPT 2 2
11
.
42736 Orifice #63 8 8
12
.
41238 Twin Burners 4 4
13
.
43002 Sheet Metal Screw 8 8
14
.
43011 Machine Screw 4 4
*15
.
41362 Burner Kit 2 2
* NOT SHOWN.

PARTS LIST, GAS CONVECTION STEAMER, MODELS SC-7G, SC-10G
FIGURE 5

PARTS LIST, GAS CONVECTION STEAMER, MODELS SC-7G, SC-10G
FIGURE 5
ITEM Part # DESCRIPTION SC-7G SC-10G
1. 41186 Gas Supply Pipe Assembly 1 1
2. 43017 Screw, #10 - 32 x 2 2 2
3. 40785 Bracket 1
40784 Bracket 1
4. 43018 Screw, 1/4" - 20 x 2 2 2
5. 41812 Reducing Coupling 3/4" x ½" 1 1
6. 41790 90 Degree Street Elbow, ½" 3 3
7. 41773 Close Nipple, ½" 3 3
8. 41793 Tee, ½" x ½" x ½" 1 1
9. 41775 Nipple, ½ x 2 1 1
10
.
41788 90 Degree Elbow, ½" 1 1
11
.
40616 Union Elbow, ½" 2 2
** 12
.
41045 Combination Gas Control - Natural 2 2
41046 Combination Gas Control - L.P. 2 2
13
.
41805 Flex Tube, ½" x 36" 1 1
14
.
41806 Flex Tube, ½" x 48" 1 1
** SELECT AS REQUIRED.
