All data is shown per oven section, unless otherwise indicated.
Model SN-5G (5 pan gas convection steamer)
EXTERIOR CONSTRUCTION
304 satin finish stainless steel
Welded stainless steel door with removable inner stainless steel liner
Full perimeter door gasket
Positive lock and seam mechanism with spring release on door
Stainless steel control housing
INTERIOR CONSTRUCTION
One piece welded 316 stainless steel cooking chamber
Coved corners
Stainless steel pan supports
Stainless steel drip trough integrally connected to drain
OPERATION
Pressureless steam operation
Delime mode power switch
Full access removable control panel
Illuminated on/off/delime power switch
Ready indicator light
Cooking indicator light
60 minute electric timer with audible alarm to signal end of cook cycle
Solid state generator controls with electronic ignition
Steam flow to the cooking chamber is cut off when the door is opened
during the cooking cycle and reactivated when the door is closed
CAPACITY
BLODGETT
44 Lakeside Avenue, Burlington, VT 05401
Toll Free: [phone] • Phone: [phone] • Fax: [phone]
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
220 VAC, 1 phase, 60 Hz
34” (864 mm) stainless steel stand
120 minute timer
Correctional package
One year extended warranty
SN-G
Gas Table Top Convection Steamer
SN-G CONVECTION STEAMER
Model Pan Depth
1” 2.5” 4” 6”
SN-5G 10 532
STANDARD FEATURES
Deliming port located inside of the top right side panel
Electromechanical controls
Split water line
4” (102mm) stainless steel legs
120 VAC, 1 phase, 60 hz
45,000 BTU natural gas or propane
One year parts and labor steamer warranty*
Five year limited steamer door warranty*
* For all international markets, contact your local distributor.

BLODGETT
44 Lakeside Avenue, Burlington, VT 05401
Toll Free: [phone] • Phone: [phone] • Fax: [phone]
SN-G CONVECTION STEAMER
SHORT FORM SPECIFICATIONS
Provide Blodgett model SN-5G (5 pan) countertop convection steamer with gas steam generator. Unit shall be constructed of satin finish 304 stainless steel with a one piece welded 316
stainless steel cooking chamber with coved corners. The door shall have a removable inner liner of stainless steel with full perimeter gasket seal, an outer liner of one-piece all welded
stainless steel, and a positive lock and seal mechanism with spring release. The steamer shall have removable stainless steel pan supports and a stainless steel drip trough integrally
connected to collect and drain condensate with the door is open. The control housing shall be constructed of stainless steel with a full access removable panel. The controls shall include
an illuminated on/off/delime power switch, delime power mode setting, a ready indicator light, cooking indicator light, 60 minute electric timer with audible alarm that signals the end of the
cook cycle, and solid state generator controls. Steam flow shall be cut off when the door is opened during the cook cycle and shall be reactivated when the door is closed. Unit shall have
a deliming port located the right side panel. Provide options and accessories as indicated.
WATER SUPPLY:
Water quality is a major factor affecting the performance of your steamer. If you are unsure
of water quality, consult a local water treatment specialist and have the water analyzed.
Your water supply must be within these general guidelines:
Total dissolved solids: Less than 60 PPM Total alkalinity: Less than 20 PPM
Silica: Less than 13 PPM Chlorine: Less than 1.5 PPM
pH Factor: 7.0 - 8.5
Water which fails to meet these standards should be treated by installation of a water
conditioner. Failure or malfunction of this steamer due to poor water quality is not covered
under warranty.
WATER & DRAIN CONNECTIONS:
Drain 1” (25mm) IPS piped to open floor drain. No solid connection.
24” length before open air opening (no bends or elbows)
Cold Water 3/8” (10mm) tubing at 25-50 PSI (170-345 kPa)
MAXIMUM INPUT:
SN-5G 42,000 BTU/hr
GAS SUPPLY:
3/4" IPS supply line required
Minimum Inlet Pressure:
Natural 6.0" W.C. static to unit
Propane 11.0" W.C. static to unit
POWER SUPPLY:
120VAC, 2 amp, 1 phase, 60 Hz., 2-wire w/ground
6' (1.8m) electric cord set furnished.
SHIPPING INFORMATION:
Approx. Weight:
SN-5G 280 lbs. (127 kg)
Printed in U.S.A. NOTE: FOR COMMERCIAL USE ONLY
NOTE: The company reserves the right to make substitutions of components without prior notice.
APPROVAL/STAMP
P/N S00008 Rev F (4/08)
