PARTS LIST
GAS TILTING SKILLETS
BLODGETT MODELS: BLP-30G
BLP-40G
Revised October 23, 2006
BLODGETT OVEN CO ▪44 lakeside Ave ▪Burlington, VT 05446
Tel. [phone] ▪Fax [phone] ▪www.blodgett.com

2
FIGURE 1

0
3
ITEM Part # DESCRIPTION QUANTITY
BLP-30G BLP-40G
1 41308 Pan Cover Assembly 1
41309 Pan Cover Assembly 1
2 42550 Burner 4 6
** 3 42349 Pilot Complete With Spark Ignitor, Nat. 1 1
42350 Pilot Complete With Spark Ignitor, LP 1 1
4 41039 Ignition Cable 1 1
5 41266 Flue Assembly 1
41265 Flue Assembly 1
6 42365 Compartment Spacer (3665) 1 1
7 41335 Right Hand Burner Compartment 1
41337 Right Hand Burner Compartment 1
8 41334 Left Hand Burner Compartment 1
41336 Left Hand Burner Compartment 1
9 40194 Back Panel 1
40195 Back Panel 1
10 41520 End Stop Plate 2 2
11 43107 Rotary Disc 2 2
12 41526 Spring 2 2
13 41100 Core 2 2
14 43106 Stationary Disc 2 2
15 41546 End Lock Plate 2 2
16 41543 Lock Pin 2 2
17 43299 Hinge Support Assembly 2
43300 Hinge Support Assembly 2
18 40098 Cap Screw 5/8-18 x 3/4 8 8
19 40859 Pilot Burner Tube, 30 gallon 1
19 43301 Pilot Burner Tube, 40 gallon 1
** 20 41108 Combination Gas Control, Nat 1 1
41109 Combination Gas Control, LP 1 1
21 40771 Union Elbow Assembly ½" 1 1
22 40164 Gas Manifold Assembly 1

4
ITEM Part # DESCRIPTION QUANTITY
BLP-30G BLP-40G
40065 Gas Manifold Assembly 1
23 40312 Orifice Nipple 4 6
** 24 42299 Burner Orifice, Natural Gas 4
42300 Burner Orifice, Natural Gas 6
42307 Burner Orifice, LP 4
42308 Burner Orifice, LP 6
25 41788 90EElbow ½” 11
26 43302 Pipe ½" x 27 ½" 1 1
27 41774 Nipple ½" x 1 ½" 1 1
28 41788 90EElbow ½ 11
29 41812 Reducing Coupling, 3/4" x ½" 1 1
30 41773 Close Nipple, ½" 1 1
31 41893 Gas Shut Off Valve 1 1
32 43303 Nipple with Flange, ½" x 2 ½" 1 1
33 40616 Union Elbow, ½" 1
** 34 41126 Ball Drive Actuator Assembly, 115V
(Includes 35, 36, 93)
11
41096 Ball Drive Actuator Assembly, 220V
(Includes 35, 36, 93)
11
** 35 42267 Motor 115V 1 1
42265 Motor 220V 1 1
36 40720 Motor Cover 1 1
37 40127 Retaining Ring 2 2
38 41932 Yoke Pin 1 1
39 43254 Adjustable Foot-Flanged 2 2
40 41131 Adjustable Foot 2 2
41 41883 Power Switch 1 1
42 41884 Up/Down Switch 1 1
43 41882 Rotary Shaft Seal 1 1
44 40181 Control Panel 1
40193 Control Panel 1

0
5
ITEM Part # DESCRIPTION QUANTITY
BLP-30G BLP-40G
45 41250 Control Panel Label 1
41251 Control Panel Label 1
46 41850 Washer, 1" Dia. X 3/8 OD 1 1
47 43304 Cotter Pin, 1/8 x 3/4 S.S. 1 1
48 43305 Pin Lower 1 1
49 42530 Pilot Light - Temp., Red 1 1
50 42529 Pilot Light - Ignition, Green 1 1
** 51 40740 Dial FE11
40828 Dial CE11
52 40438 Pot Spacer 1 1
53 40994 Bezel 1 1
** 54 42266 Capacitor 30 MFD, 120V 1 1
42264 Capacitor 10 MFD, 220V 1 1
55 41844 Fuse Holder 1 1
** 56 41885 Transformer, 115/230V-24V, 50 VA 1 1
** 57 41127 Temperature Control w/Potentiometer, 120V 1 1
41128 Temperature Control w/Potentiometer, 240V 1 1
58 40663 Power Cord - 120V Only 1 1
59 40840 Ground Lug 1 1
60 40488 Terminal Block Bracket 1 1
61 40708 Terminal Block Section 2 2
40707 End Section 1 1
62 43306 Switch Mounting Bracket 1 1
63 42137 Limit Micro Switch 1 1
64 42351 Ignition Module 1 1
65 43307 Switch Bracket 1 1
66 43308 Machine Screw, 10-24 x 3/8 2 2
67 43309 Spring 1 1
68 43310 Set Screw 8-32 x 3/16 1 1
69 41800 Gear Clamp 1 1
70 41859 Fuse - 1 amp, 250V 1 1

6
ITEM Part # DESCRIPTION QUANTITY
BLP-30G BLP-40G
71 40779 Control Mounting Plate 1 1
72 43311 Tilt Bracket Assembly 2 2
73 40452 Bushing 2 2
74 43312 Tilt Bracket 2 2
75 40162 Hi-Limit Box 1 1
76 41920 Hi-Limit Safety 1 1
77 40739 Thermocouple 1 1
78 42224 Strainer 1 1
79 43313 Hex Cap Screw 1/4-20 x ½ 2 2
80 43021 Lock Washer 1/4" 2 2
81 43314 Hex Nut, 1/4 - 20 2 2
82 40546 Lighter Orifice Bracket 1 1
83 40443 Elbow 3/8 cc x 1/8 MPT 1 1
84 40318 Bulk Head 1 1
** 85 42281 Lighter Orifice, Natural Gas 1 1
42282 Lighter Orifice, LP 1
42284 Lighter Orifice, LP 1
86 41149 Lighter Tube 1
86 41151 Lighter Tube 1
87 43315 Switch Actuator 1 1
88 43316 Actuator Rod 1 1
89 43317 Fan Bracket 1 1
90 43318 Deflector 2 2
** 91 42585 Box Fan, 120V 1 1
43319 Box Fan, 240V 1 1
92 43320 Machine Screw, 6-32 x 1/4 10 10
93 41096 Lift Jack Extension Shield 1 1
* NOT SHOWN.
** SELECT AS REQUIRED.
