Owner’s Manual
Model: 31828
Rev.2
16” x 12” Skillet
MEDLEY® XL DIGITAL SKILLET

2| nuwavenow.com
PRODUCT REGISTRATION
Thank you for purchasing the NuWave Medley® XL Digital
Skillet and welcome to the NuWave Family!
Congratulations on getting your new Medley
XL Digital Skillet! We are incredibly excited
for you and want to make sure you get the
most out of your new skillet and your cook-
ing experience.
That’s what this manual is all about.
In it, we have provided detailed operating
and care instructions covering every aspect
of your new skillet to make sure it fully
meets your needs.
NuWave prides itself on the relationships
it builds with its customers - a relationship
that only begins with the purchase. So,
if you have any questions, comments, or
concerns, please don’t hesitate to contact
Customer Service. We’ll take good care of
you!
We’re glad you’re with us, and we know that
you will be, too!
The NuWave Team
REGISTER YOUR PURCHASE
1. Scan the QR code or visit
www.nuwavenow.com/QR to Register.
2. Have your proof of purchase! you will
need it to register your product.
3. Locate your serial and model numbers
to have ready.
TECHNICAL SPECIFICATIONS
Voltage: 120V, 60Hz
Wattage: 1500 watts
Note: You can locate the model and serial
numbers, as well as the QR code, on the
label on the back of the unit.
WELCOME
REGISTER
NOW!
CUSTOMER SERVICE
Email: [e-mail]
Connect with Us!
#nuwavenow
Visit nuwavenow.com to see other
great products and accessories.

4| nuwavenow.com
READ ALL INSTRUCTIONS and WARNINGS The failure to follow any of the important
safeguards, warnings, or instructions for safe use is a misuse of the Medley XL that can
void your warranty and create the risk of serious injury. When using Medley XL, only use
the appliance as intended and for no other use, and always follow basic safety precautions.
WARNING: When using your unit, basic
safety precautions should always be
followed:
1. Read all instructions, safeguards, and
warnings before using the appliance.
2. Do not touch hot surfaces. Use
handles or knobs.
3. To protect against electrical shock,
do not immerse cord, plugs, or digital
temperature control in water or other
liquids.
4. Close supervision is necessary
when the Medley XL is used by or
near children. The Medley XL is not
intended for use by children, persons
with reduced physical, sensory, or
mental capabilities or those with lack of
expertise or knowledge of this unit.
5. Unplug the Medley XL from outlet when
not in use and before cleaning. Allow
the Medley XL to cool before cleaning,
putting on or taking off parts.
6. Do not operate any appliance with
a damaged cord or plug, after the
appliance malfunctions, or has been
damaged in any manner. Return
appliance to the nearest authorized
service facility for examination, repair,
or adjustment.
7. The use of other accessories that are
not intended to be used with the Medley
XL is not recommended. Doing so may
damage the Medley XL and can cause
accidents.
8. NOT INTENDED FOR OUTDOOR
USE. HOUSEHOLD USE ONLY.
9. Do not let cord hang over edge of table
or counter or touch hot surfaces.
10. Do not place on or near a hot gas,
electric burner, or in a heated oven.
SEE ASSEMBLY INSTRUCTIONS
BEFORE USE
SAFEGUARDS & INFORMATION
ALWAYS KEEP THIS MANUAL HANDY FOR FUTURE REFERENCE.
11. Exercise extreme caution when
moving any appliance containing hot
oil or other hot liquids.
12. Never put the Medley XL against the
wall or other appliances. There should
be at least 3 inches of free space for
the back side, left/right sides, and the
upper side of the Medley XL.
13. Do not place anything on top of the
Medley XL.
14. To disconnect, turn the temperature
control “OFF”, and then remove plug
from the wall outlet.
15. Do not use Medley XL for other than
intended use.
16. Do not clean with metal scouring
pads. Pieces can break off the pad
and touch electrical parts, creating a
risk of electric shock.
17. Use extreme caution when removing or
disposing of hot grease.
18. The Medley XL is not intended to be
operated by means of an external
timer or separate remote-control
system.
19. Keep manual handy for future
reference.

nuwavenow.com | 5
WARNING
While the Medley XL is in operation,
do not touch the appliance’s surface
as it may become very hot, leading to
the risk of burns.
Digital temperature control may
retain residual heat after it has been
removed.
SAFEGUARDS & INFORMATION
ALWAYS KEEP THIS MANUAL HANDY FOR FUTURE REFERENCE.
Electrical Information
1. A short power-supply cord (or
detachable power supply cord) is
provided to reduce the risk resulting
from becoming entangled in or
tripping over a longer cord.
2. The Medley XL should be operated
on a separate electrical outlet from
other operating appliances due to
wattage limitations. The appliance
has a polarized plug (one blade is
wider than the other). To reduce the
risk of electric shock, this plug is
intended to fit into a polarized outlet
only one way. If the plug does not
fit fully into the outlet, reverse the
plug. If it still does not fit, contact a
qualified electrician. Do not attempt
to modify the plug in any way.
3. If the appliance is of the grounded
type, the cord set or extension cord
should be a grounding type 3-wire
cord.
Read and understand the entire
manual before using the Medley XL.
NOTICE: THE FAILURE TO
FOLLOW ANY OF THE IMPORTANT
SAFEGUARDS, ADDITIONAL
SAFEGUARDS, OR THE
INSTRUCTIONS FOR SAFE USE IS A
MISUSE OF YOUR MEDLEY XL THAT
CAN VOID YOUR WARRANTY AND
CREATE THE RISK OF SERIOUS
INJURY.
SAVE THESE
INSTRUCTIONS
DO NOT USE THE MEDLEY XL FOR
ANYTHING OTHER THAN INTENDED
USE.
Note: Place the Medley XL on a surface
that is horizontal, even, and stable.
The Medley XL is intended for normal
household use. It is NOT intended to
be used in environments such as staff
kitchens of shops, offices, farms, or
other work environments. It is NOT
intended to be used by clients in hotels,
motels, bed and breakfasts and other
non-residential environments.
Question about your Medley XL ?
Contact our friendly customer service staff
via email anytime at help@nuwavenow.
com

6| nuwavenow.com
WARNING
All items in the Medley XL can get
very hot during cooking. Please be
careful when removing these items
from the unit. Always wear oven mitts
or use pot holders. Skillet may retain
residual heat after food has been
removed. Allow everything to cool
completely before cleaning.
ADDITIONAL SAFEGUARDS
1. Add only enough oil to coat the bottom
of the Medley XL. Do not use larger
amounts of oil.
2. The steam vent on the lid should always
be positioned away and at the back of
the skillet. Lift the lid from the back to the
front to prevent steam burns.
3. Use pot holders to lift lid or move skillet.
4. Do not lift or move skillet while cooking.
5. The display on the temperature control
must always show “OFF” before the unit
is unplugged.
6. Do not knock or drop the temperature
control as this can damage the control.
NOTE: Temperature control can be hot.
7. Place the Medley XL on a stable, level
surface.
8. Never use the Medley XL on a
flammable surface (e.g., tablecloth,
carpet, etc.).
9. Maintain a minimum distance of 3-5
inches from walls and other objects,
appliances, etc.
10. Ensure that the power cable is not
compressed beneath the Medley XL.
11. The power cable must not come into
contact with sharp edges.
12. Before using the Medley XL, confirm
that the outlet’s voltage supply meets
the unit’s voltage needs. Failure to do so
may result in damage to the Medley XL,
physical damage, or bodily harm.
13. In the event the Medley XL is damaged,
immediately disconnect from the power
supply.
Question about your Medley XL ?
Contact our friendly customer service staff
via email anytime at help@nuwavenow.
com
SAFEGUARDS & INFORMATION
ALWAYS KEEP THIS MANUAL HANDY FOR FUTURE REFERENCE.
14. Do not place on a stovetop.
15. Do not use the Medley Skillet in the
proximity of open fires, heaters, or other
sources.
16. Never immerse the temperature probe”
in water or liquid.

nuwavenow.com | 7
PARTS & ACCESSORIES
1
2
3
Vented Tempered Glass
Lid with Cool-to-Touch
Handle
Part #: MSA1
16” x 12” Base with
Duralon Blue Healthy
Ceramic Non-Stick
Coating
Part #: MSA2
Digital Temperature
Control
Part #: MSA3
1
2
3
Over the lifetime of your Medley XL, you may nd yourself needing a new part or accesso-
ry, and if you do, NuWave has you covered.
Ordering new parts and accessories is quick and easy. Have ready down the name and
number for the part you want, then contact Customer Service Email:
[e-mail]
You can even order directly online. Just visit www.nuwavenow.com
ORDERING PARTS

8| nuwavenow.com
Before First Use
1. Read all safeguards and instructions in the manual
2. Remove all packaging materials, labels, and stickers.
3. Clean all non-electrical parts with hot soapy water.
4. Wipe the Digital Temperature Control with a damp cloth. Can see "Care and Mainte-
nance" for more instruction.
ASSEMBLY GUIDE
If using oil, do not exceed the oil’s smoke
point.
The smoke point of oil is the temperature
at which it begins to break down to glycerol
and free fatty acids, producing bluish
smoke. The smoke point also signies
the beginning of avor and nutritional
degradation.
Smoke points can vary dependent upon
many different factors. Consult the list of
common oil types (right) and their median
smoke point. Always practice caution when
cooking with oil.
Smoke Point
The NuWave Culinary Team recommends
the use of high-heat-rated, silicone-based
tools for cooking foods. Do not use metal
utensils while cooking. Never attempt to
cut foods while they are in the skillet. Any
misuse of the coating will void the warranty;
refer to the Limited Warranty.
Recommended Heating
Your NuWave Duralon® Blue Ceramic Non-
Stick Coating can handle high heat. It has
been tested at temperatures up to 900ºF,
coming out unscathed.
However, long-term or repeated exposure to
such heat can cause food to scorch, burn,
or discolor the skillet and potentially damage
the coating. You may sear foods in your
skillet at high heat for short periods of time
but note that keeping the temperature down
to 450°F or below will increase the useful
life of the ceramic coating from 30%–50%.
For best results, allow skillet to heat
between 280ºF~300ºF for up to 1 minute
before inserting and cooking foods. Avoid
preheating empty skillet above 300º F.
Utensils
Oil Type Smoke Point
Rice Bran Oil 490°F
Grapeseed Oil 485°F
Canola Oil 435°F
Extra-Virgin Olive Oil 405°F
Peanut Oil 440°F
Sesame Oil 410°F
Sunower Oil 440°F
Almond Oil 420°F
COOKING

nuwavenow.com | 9
1. Set the Medley XL base on a clean, at
surface.
2. Insert the Digital Temperature Con-
trol by gripping each side rmly and
pushing it into the receptacle until it will
no longer slide in. Ensure the display is
facing upwards when inserting.
3. Once secured, plug the Control into an
electrical outlet. “OFF” will be shown on
the display.
4. Press the ON/OFF button once. The
default temperature of 350°F will ap-
pear on the display.
5. Turn the dial to set your desired tem-
perature. The Medley XL will immedi-
ately preheat to the selected tempera-
ture. The temperature will ash on the
display until until the Medley XL nishes
preheating at which point cooking will
begin.
6. Once the Medley XL nishes preheat-
ing, press the ON/OFF button to switch
the display from the temperature to
time. Turn the dial to select your de-
sired cooking time.
Turn on.
OFF
Caution: Allow all parts to cool
off before handling.
350
Default temperature appears
0:30
NOTE:
• When the cooking time has nished, the unit
will display “OFF”.
• Allow the unit and the Digital Temperature
Control to cool before moving or disconnect-
ing.
• You can turn the Medley XL at any point by
pressing and holding the ON/OFF button
until “OFF” appears on the display.
• The default time of 0:30 will begin counting
down as soon as the preheat starts.
• When the temperature changes the unit will
start to preheat again.
OPERATING DIGITAL TEMPERATURE CONTROL
The temperature range is 100°F-425°F, adjustable in 5° increments. The timer range is
0:01-9:59, adjustable in 1-minute increments.
• Turn the dial clockwise towards the (+) to increase the temperature or time.
• Turn the dial counterclockwise towards the (-) to decrease the temperature or time.

10 | nuwavenow.com
CAUTION: To prevent personal injury or
electric shock, unplug rst, and ALWAYS
remove the digital temperature control BE-
FORE cleaning. Do not immerse tempera-
ture control, cord, or plug in water or other
liquids.
1. Allow the Medley XL to cool before
cleaning.
2. Once unit has cooled, remove the digi-
tal temperature control.
3. The temperature control should not
be immersed in water or other liquids.
Remove and wipe down with a clean,
slightly damp cloth.
4. To clean the skillet, rst remove excess
food and oil with a clean cloth. Wash
with warm soapy water, using a non-
abrasive cloth.
5. Dry thoroughly before each use, in-
cluding the area surrounding the digital
control receivers.
NOTE: DO NOT USE HARSH ABRA-
SIVES. THE SKILLET AND ALL REMOV-
ABLE PARTS ARE NOT DISHWASHER
SAFE.
Caution: Do not submerge
the Control in water or clean
in a dishwasher. Wipe with
damp cloth.
CARE & MAINTENANCE
OFF
OFF

nuwavenow.com | 11
The Skillet is not turning on or working.
1. The unit is not plugged in.
2. Did not press “ON/OFF” button.
3. Insert the Digital Temperature Control properly into the unit.
The ingredients are not completely cooked.
1. The cooking temperature is too low.
2. The cooking time is too short.
3. Set to cook for a longer time.
White smoke is coming out of the product.
1. You are frying greasy foods. The skillet may contain greasy residue from previous
uses.
2. When preparing greasy ingredients, large amounts of oil can cause smoke. Oil can
produce white smoke and might become hotter than usual. This will not affect the
nal cooking result.
3. Clean the skillet properly after each use.
Error Message: Solution(s):
Er1 Digital Temperature Control not properly connected to the unit.
Er2 Digital Temperature Control
Contact Customer Service Department at [e-mail].
Er3 Temperature Sensor overheated. Turn unit off to cool. If the unit is
not working after it cools down, contact Customer Service.
TROUBLESHOOT GUIDE
