Bluebird SF650 User manual

SF650 Quick
Guide

This user manual is protected by copyright.
Copyright © 2020 Bluebird Inc. All rights reserved.
Bluebird Inc. is the designer and manufacturer of Bluebird handheld mobiles.
This manual and the programs in this device are protected under international copyright laws, and may not
be copied, distributed, translated, or removed by any means.
Registered Trademark
BLUEBIRD is an emerging global brand, striving to lead the market in performance
and mobility. Their products represent reliability, innovation, and innovative technology.
Bluebird is a registered trademark from the global brand of Bluebird Inc. and is
copyright protected.
•Bluebird and stylized Bluebird Logo are registered trademarks and symbols of Bluebird Inc.
•Qualcomm® IZat™ is a registered trademark of Qualcomm Atheros, Inc.trademark of Qualcomm Atheros, Inc.
•Adobe® is a registered trademark of Adobe Systems Inc.
•All other trademarks and copyrights are the property of their respective owners.
User’s Guidance
Device type User’s guidance
Class B Device
(Household Information &
Communication)
This device has qualified the electromagnetic wave suitable registration
and can be used as a household device at a residential area as well as
any other areas.
Type Registration This wireless device may cause propagation interference, and so, it
cannot be used for life-saving services.

1 SafetyInformation
1.1 Symbols
This manual uses the following symbols to indicate hazards and additional information.
Symbol Name Description
Warning Indicates situations that could cause injury to yourself or others.
Caution Indicates situations that could cause damage to your device or other equipment.
Note Indicates additional information that can help you get the most out of the device.
Please read this safety precaution information carefully. Failure to follow the information provided may
result in fire, electric shock, or other property damage or bodily injuries.
2. Device
•Do not press the Power button on the device if the device is wet or do not touch adapter or power
cord with wet hands. There is risk of electric shock.
•Do not use your device in an explosive danger zone.
•If your device becomes wet, do not put your device in heaters, microwaves, etc. todry it. There is a
risk of explosion or malfunction.
•Do not scratch the device’s touchscreen. Use only your fingers or a compatible pen. Never use an
actual pen, or any other sharp object on the touchscreen.
•Although this device is very sturdy, do not drop, hit, bend, or sit on it on purpose. It can be broken.
•Do not modify, take apart, or repair the device. Contact to your customer service center. Failure to do
so will void your warranty.
•Do not attempt to modify your hardware or software. It may cause device malfunction and void your
warranty.
•You may not be able to use this wireless device in basements, open fields, skyscrapers, or other
places where the signal is weak.
•Backup the data and information from your device. Your data, such as ringtones, texts, and voice
messages, may be erased during repairs or upgrades.
•Do not paint your device. It can damage your screen or your device’s exterior.
•Avoid using or storing this device at extreme temperatures. This device is designed to work at
temperatures between -20°C and 55°C (-4°F and 131°F), and humidity level 95%.
1

Safety Information
1.3 Environment
•Do not use the device while driving or operating heavy machinery. Doing so may result in death or
serious injury.
•Do not use the device in locations with combustible goods. Doing so may result inan explosion.
•Do not use the device in dusty or hot locations. Doing so may damage thedevice.
•Do not expose your device todirect sunlight such as on the dashboard of a car for extended periods
of time.
•Do not use the device in humid locations. Doing so may damage the device and void the warranty.
•Do not keep the device close to air conditioner vents. Corrosion within the device may occur due to
condensation from changes in temperature.
•Do not allow children to play with the device.
4. Charging
•Use only the approved charger. Using an incompatible charger may cause device malfunction or
other damage, such as fire.
•Charge the battery at least once a year. If you keep it without charging for a long time, it may cause
device malfunction.
5. Distraction
In some situations, using your device may distract you and cause serious injuries and damages. For ex
ample, avoid talking on the phone or texting while driving or riding a bicycle. It is strictly prohibited by la
w in some jurisdictions. If you cannot avoid using your device while driving, stop your vehicle or use ha
nd-free kit.
6. Frequency Interference
•This wireless device may cause radio frequency interference, so use Airplane mode or turn off the
device when prohibited.
•The device emits an electromagnetic fields. It may interfere with your medical devices.
•Do not place credit cards, phone cards, bankbook, and tickets next to the device. The magnetic field
of the device can damage their magneticstrips.
2

2 Overview
The illustrations may differ from your actual items.
SF650 Device USB Cable (Type-C) Charging Adapter
2.1 Package Contents
The package includes:
SF650
3

2.2.2 Back
- SF650
Function button
Reciever
Rearcamera
Cameraflash
Power button
Touchscreen
Volume up button
Volume down button
Charging Notification (Status LED)
Front Camera
4
Overview
2. Your Device
1. Front
- SF650
Proximity Sensor /
Light Sensor

C-type connector
Microphone(1)
Microphone(2)
Speaker
Overview
2.2.3 Top and Bottom
- SF650
Top View : SF650
Headset jack
5
Bottom View :SF650

3 Insert the Nano SIM into the place specified in the picture below.
3 GettingStarted
1. Installing the Cards
1. Insert a Nano SIMcard
1. Remove the BatteryCover.
2
Remove the Battery .
1
6
2

Getting Started
3.1.2 Inserting a Micro SD Card
1 Remove the BatteryCover.
2 Remove theBattery
3Insert the Micro SD card into the place specified in the picture below.
3.1.3 Removing theCards
1Remove the card slot .
2Remove nano SIM or SD cards on the card slot.
1
7
2

Getting Started
2. Battery
1. Installing theBattery
2 Place the battery into the device. Please make sure
to place the top portion of the battery before comp
letely inserting the battery into the device.
3 Gently press the bottom portion of the batt
ery to fully insert the battery into place
4 Press the battery cover evenly on all sides to connect
the battery cover back into place.
1
2
1 Remove the batterycover.
9

Getting Started
2. Removing the Battery
Slide up the battery lock to unlock the battery and pull the battery out.
Before removing the battery, turn off the power. Failure to do so it may cause damage to the device.
3. Charging the Battery
1 Plug the C-type end of the charger into the multi-purpose jack on the buttom of the device.
•The battery charging image appears on the screen.
2 Connect the USB cable with power adapter and then plug the charger into a power outlet.
10

4.1.2 Turning the DeviceOff
1Press and hold the Power button for a few seconds.
2Tap Power off.
•To turn the screen on or off, press the Powerbutton.
•Registering the accounts without turning on the Wi-Fi may incur extra charges depending on your
data plan.
4 Basics
1. Turning the Device On or Off
1. Turning the Device On
Press and hold the Power button for a few seconds.
11

Basic
2. Using the Touchscreen
Use finger gestures to use the touchscreen effectively.
•Do not touch the screen with any sharp objects.
•Do not apply too much pressure to the touchscreen.
Gesture Name Description
Tap Briefly touch an item to open, launch, or select it.
Zoom in or out
Place two fingers on the screen and spread them apart to zoom
in. Pull the fingers together to zoom out. You can also double-
tap the screen quickly to zoom in or out.
Tap and hold
Touch an item or the screen for a few seconds to access more
detailed menus or options.
Swipe
Touch the screen and quickly flick in any direction to scroll
through menus or pages.
Drag
Touch an item or the screen for a few seconds and move your
finger around the screen to move the item or move through
screens.
12

Basic
4.3 Using the Home Screen
The Home screen is the starting point for all apps and features. It displays icons, shortcuts, and widgets for
apps.
Drag upward from the bottom of the screen. Applications will be displayed on the screen.
To view other pages, swipe left or right.
13

Basic
4.4 Connecting to a Wi-Fi Network
Connecting to a Wi-Fi network is an easy way of accessing the Internet. When you are out, you can connect
to Wi-Fi networks in public places.
1On the Home screen, tap > Wi-Fi.
2Make sure to turn Wi-Fi on.
3Tap the network you want to join.
4If necessary, enter the password for the network and tap CONNECT.
To disconnect the network connection, turn Wi-Fi off.
Your device periodically checks for and notifies you of available connections. The notification appears
briefly at the top of the screen.
5. Connecting to a Bluetooth Device
You can connect wirelessly to various Bluetooth-compatible devices, such as phones, computers, headsets,
and car kits. You can also send your photos to Bluetooth-compatible phones or to your computer.
On the Home screen, tap > Bluetooth.
Because devices with Bluetooth wireless technology communicate using radio waves, they do not need t
o have a direct line of sight. However, they must be within 10 meters (33 feet) of each other, although the
connection may be subject to interference from obstructions, such as walls or from other electronic devices.
•Paired devices can be connected to your device when Bluetooth turns on.
•Other devices can detect your device only if the Bluetooth settings view is open.
Do not accept the requests from unknown devices and also do not try to pair with an unknown devices.
This helps to protect your device from harmfulcontent.
14

5 DeviceSpecification
Physical Characteristics
Dimensions (W x H x D) 169 x 77.8 x 9.9mm
16
Weight 210g
Display 6.5” HD+ (720 x1600)
Touchpanel Capacitive multi-touch Stylus
Backlight LED backlight
Power
User replaceable Battery
3.85V / 5,000mAh
BOS™ PowerManager Station
Expansion Slot MicroSD, up to512GB
SIM / SAM 1 Nano SIM is supported by micro SD Card Slot
Interface USB Type C Connector (USB 2.0)
Notification Audible tone; multi-color LEDs; (ch
arging, events indicator) vibration
Keypad
On-screen keypad and Enterprise Keyboard;
power button;
volume up/down buttons'
Programmable Side key
Voice and Audio Dual noise-cancelling microphones; vibrate alert;
High-quality speaker phone; 3.5mm headset jack
Function Key Supported
- available Programmable side key

Device Specification
Performance Characteristics
CPU 2.0 GHz Octa Core Processor
Operating System Android 12 ; upgradeable
to Android 13
Memory 4GB RAM / 32GB UFS Flash
3GB RAM / 32GB Flash (Optional)
User Environment Characteristics
Operating Temp -20°C to 55°C / -4°F to131°F
17
Storage Temp -40°C to +70°C / -40°F to +158°F
Humidity 95% non-condensing
Vibration 4G peak, 5 Hz to 2 kHz, 1 Hour duration per axis
Thermal Shock -40° C to 70° C / -40° F to 158° F rapid transition 24 cycles
(1 cycle = 1.25 hours at -40°C and 1.25 hours at 70°C)
Electrostatic Di
scharge(ESD)
+/-15kVdc air discharge
+/-8kVdc direct discharge
+/-8kVdc indirectdischarge

Device Specification
Communication Options
Please ask your sales representative for the specifications not listed above or for the future upgradeable
specifications.
WWAN Radio
18
WLAN Radio
WiFi: 802.11 a/b/g/n/ac; 1x1 MU-MIMO
Wi-Fi™ certified;
Wi-Fi hotspot
WLAN Data Rates 5GHz: 802.11 a/n/ac — up to 433Mbps
2.4GHz: 802.11 b/g/n — up to 150 Mb
ps
WPAN Radio Bluetooth V5.0 BLE/EDR
Worldwide :
LTE-FDD: B1, B2, B3, B4, B5, B7,
B8, B12, B13, B14, B20, B28, B66,
LTE-TDD: B38/B40
WCDMA : B1, B2, B4, B5, B8
GSM : 850/900/1800/1900
supports VoLTE.

6 Troubleshooting
19
The battery does not charge properly.
•Ensure that your device and the charging cable are connected and the charging LED is functioning
correctly.
•If the battery does not charge completely, it may be dead or defective. Contact our service center.
(The warranty period for battery replacement is six months.)
The battery life got shorter.
When you use network data or peripheral device such as wireless LAN or Bluetooth that require more
power, your device may use more battery than usual. If it happens for an extended period of time, your
battery may be dead. Then replace it with a new battery.
I dropped the device in the water.
Turn off the device. Place the device in a dry place. Let it dry completely for a considerable period of time,
and then turn the device back on. If it does not turn back on, contact our service center.
My device gets too hot totouch.
It is normal for the device to warm up while it is receiving a poor signal, performing an intense workload, or
charging. It should cool down if you stop using the device for a certain amount of time. If the problem conti
nues, contact the manufacturer. It may result in a burst battery or fire.
How do I get the repair service?
You can contact your local sales representative or you can send the device via a delivery service to Blue
bird’s Korean headquarters. When sending the package, make sure you pay for the shipping fee in adv
ance. When the repair is finished, Bluebird will cover the shipping cost.

7 Warranty andSupport
Customer support
Before asking for after-sales service, please back up the data on the device. We do not back up data from t
he products sent to the Customer Service Center. Therefore, we assume no responsibility for loss/deletion o
f data.
Customer Service Center
#1103, Gplus Kolon Digital Tower 11F,
Digital-ro 26-gil 123, Guro-gu, Seoul, Republic of Korea(08390)
•Fax: [phone]
•Email: [e-mail]
•Hours: 9:30 a.m. - 6:30 p.m. (GMT Time: +9 Hours)
The center is closed on Saturdays, Sundays, and Korean national holidays.
Registering for After-Sales Service
•We receive the products for our after-sales service through mail, delivery services and hand delivery only in
principle.
•If you bought the product from a party other than Bluebird or an authorized Bluebird reseller, you need to
register the product before using our after-salesservice.
•Please enclose an evidence of purchase or the product receipt for our after-salesservice.
•Please enclose your name, telephone number, address and details of the problem for a prompt service.
•You can ask for our after-sales service by contacting your authorized Bluebird dealer or the Customer
Service Center in the head office.
•Do not intentionally damage the label on the product.
•A damaged label may result in a disadvantage to the customer.
•When you return the product to Bluebird for service, please put the product in a protective box.
•The warranty will not cover any damage which occurs during delivery. We advise you to use the box and
protective cover supplied with the product.
•Make sure to deliver the product in a safe way. Bluebird assumes no responsibility for the loss of the
product during delivery.
20
