Bluebird CT280 User manual

User Manual
Copyright (C) 2017 Bluebird Inc. All rights reserved www.mypidon.com
BLUEBIRD

CT280
BLUEBIRD
user
manual
version 1.1
Countertop Payment Terminal

About This manual 1
About This manual
The CT280 countertop payment terminal provides high quality features based on Blue-
bird’s creativity and technological expertise. This user manual is designed to help users
use the device effectively.
•Please read this manual carefully before using the device for safe and proper use.
•This device may only be used in countries where it is sold.
•The components and colors of the device described in this manual may differ from the
actual product.
•Features and specifications are subject to change without prior notice.
•Content may vary by device’s software version or by service provider or carrier.
•The program and features may vary by country or region.
•Certain features of this device may have performance issues due to user environment,
the program in use, or peripheral device usage. Bluebird is not liable for any issue
caused by the program or accessories from any provider other than Bluebird.
•Modifying the device’s operating system or installing software from unknown sources
may cause device malfunction or data loss. Improper or unauthorized use of the device
is a violation of Bluebird license agreement and void your one-year limited warranty.
Copyright
Copyright © 1995-2014 Bluebird Inc. All rights reserved.
Bluebird Inc. is the designer and manufacturer of Pidion handheld mobiles.
This manual and the programs in this device are protected under international copyright
laws and may not be copied, distributed, translated, or removed by any means.

2 About This manual
Trademarks
BLUEBIRD is an emerging global brand, striving to lead the
market in performance and mobility. Their products represent
reliability, innovation, and innovative technology.
BLUEBIRD is a registered trademark from the global brand of
Bluebird Inc. and is copyright protected.
•Pidion and stylized Pidion Logo are registered trademarks and symbols of Bluebird Inc.
•Qualcomm® IZat™ is a registered trademark of Qualcomm Atheros, Inc.
•Adobe® is a registered trademark of Adobe Systems Inc.
•Bluetooth® is a registered trademark of Bluetooth SIG, Inc.
•Wi-Fi® is a registered trademark of the Wi-Fi Alliance.
•All other trademarks and copyright are the property of their respective owners.
User’s guidance
Device type User’s guidance
Class B Device
(Household Information and
Communication Device)
This device has qualified the electromagnetic wave suitable
registration and can be used as a household device at a
residential area as well as any other areas.
Type registration This wireless device may cause propagation interference,
and so, it cannot be used for life-saving services.

Contents 3
Contents
About This manual 1
Overview 5
Package Contents............................................................................................................. 5
Terminal Overview ............................................................................................................. 6
Features............................................................................................................................. 7
Installation 8
Installation Location .......................................................................................................... 8
Installing the Battery (Optional) ......................................................................................... 9
Card Slots........................................................................................................................ 10
Installing the SIM or SAM Card....................................................................................... 10
Installing a microSD card ................................................................................................ 11
Connection Ports ............................................................................................................ 12
Connecting the Telephone Line....................................................................................... 12
Connecting the Power Adapter....................................................................................... 13
Installing a Paper Roll...................................................................................................... 13
Payment Card Transactions 14
Using the Smart Card Reader ......................................................................................... 14
Using the Magnetic Card Reader.................................................................................... 14
Cutting Off Receipts........................................................................................................ 15
Maintenance 16
Cleaning the Body........................................................................................................... 16
Cleaning the Smart Card Reader .................................................................................... 16
Technical Specifications 17
Troubleshooting 19
Power .............................................................................................................................. 19
Physical Condition........................................................................................................... 19

4 Contents
Operation......................................................................................................................... 19
Display............................................................................................................................. 20
Keypad ............................................................................................................................ 21
Printer.............................................................................................................................. 21
Safety and Handling 22
Warranty and Support 26

Overview 5
Overview
Package Contents
The following items are included in the package.
CT280 body Port cover
Power adapter Power cord
Battery cover
NOTE
To purchase optional accessories, contact your sales representative.
You can download the user manual from www.mypidion.com. However, the product
package may include a physical version in some regions.

6 Overview
Terminal Overview
Magnetic card reade
r
Batterycover
Port cover
Display
Keypad
Smart
card reader
Printer door

Overview 7
Features
CT280 has the following features:
•A backlit LCD display
•Three types of keys:
-12 numeric keys
-4 function keys, labeled F1 to F4
-Three color-coded function keys (from left to right: CANCEL, BACKSPACE/CLEAR,
ENTER)
•A magnetic card reader built into the right side
•A smart card reader built into the bottom
•A thermal printer built into the top
•3 SIM or 2 SAM and 1 SIM slots built into the back

8 Installation
Installation
Installation Location
Consider the following guidelines when choosing a location for the terminal.
•Ease of use
-Choose a location convenient for both merchants and card holders.
-Choose a flat surface, such as a countertop or table.
-Choose a location near a power outlet and a telephone line connection. For safety,
do not string the power cord in a walkway or place it across a walkway on the floor.
•Environmental factors
-Do not use the terminal in the place where there is high heat, dust, humidity, mois-
ture, or caustic chemicals or oils.
-Keep the terminal away from direct sunlight and anything that radiates heat, such
as a stove or motor.
-Do not use the terminal outdoors.
CAUTION
The terminal is not waterproof or dustproof, and is intended for indoor use only. Any dam-
age to the unit from exposure to rain or dust may void the warranty.
•Electrical considerations
-Avoid using this product during a thunderstorm.
-Avoid locations near electrical appliances or other devices that cause excessive volt-
age fluctuations or emit electrical noise, such as air conditioners or electric motors.
-Do not use the terminal near water or in moist conditions.
