BlueEyes DDS User manual

Operation manual
2016/05/25
www.BlueEyestech.com

BlueEyes Technology
1
www.BlueEyestech.com
Operation manual
BlueEyes DDS
Thank you for using the product of BlueEyes Technology.
The manual will introduce the product of BlueEyes Technology. Please read the manual
before you start using the product.
Though the information in the manual has been verified before publish, the actual
specification should be based on the actual shipment. BlueEyes Technology doesn’t
have to guarantee, proclaim or declare for the content, along with other purpose. In
addition, the product specification and information that mentioned in the manual is for
reference only. The content might be update at any time without notice. If there is any
mistake of the information, including software, firmware, and hardware that mentioned
in the manual BlueEyes Technology has no responsibility for the mistake.
Please reach BlueEyes website to get the upgrade of the product specifica tion, our
company will not notice you. If you want to get the latest product information, operation
manual, firmware, or you have any question to the products of BlueEyes Technology,
please contact your local agent or go to the official website of BlueEyes Technology for
further information.
It is not allowed to copy/ use the content or to change the information and publishing of
the manual without BlueEyes Technology’s written consent.
Copyright 2015 BlueEyes Technology Inc. All Rights Reserved.
BlueEyes Technology Corp.
Add: 7F-3, No.200, Sec. 4, Wenxin Rd., North District, Taichung
City 40462, Taiwan
TEL: [phone]
Fax: [phone]
E-mail：[e-mail]
Website: www.BlueEyestech.com

BlueEyes Technology
2
www.BlueEyestech.com
Index
1. Introduction..................................................................................................................5
1.1 About the manual..............................................................................................................................5
1.2 Intellectual Property Rights...............................................................................................................5
1.3 Notices before use.............................................................................................................................5
1.4 Connect to wifi ..................................................................................................................................8
2. Customized pattern ....................................................................................................10
2.1 Pattern.............................................................................................................................................10
2.1.1 First pattern ...........................................................................................................................................11
2.1.2 Second pattern ......................................................................................................................................11
2.1.3 Third pattern..........................................................................................................................................12
2.1.4 Fourth pattern .......................................................................................................................................12
2.1.5 Fifth pattern...........................................................................................................................................13
2.1.6 Sixth pattern ..........................................................................................................................................13
2.1.7 Seventh pattern.....................................................................................................................................14
2.1.8 Eighth pattern........................................................................................................................................14
2.1.9 Ninth pattern .........................................................................................................................................15
2.1.10 Tenth pattern.......................................................................................................................................15
2.1.11 Eleventh pattern..................................................................................................................................16
2.1.12 Twelfth pattern....................................................................................................................................16
2.2 Website............................................................................................................................................17
2.2.1 Connect to website................................................................................................................................17
2.2.2 Status.....................................................................................................................................................17
2.2.3 Banner LOGO.........................................................................................................................................18
2.2.3.1 Upload picture....................................................................................................................................19
2.2.3.2 Add texting .........................................................................................................................................19
2.2.3.3 Picture on banner...............................................................................................................................20
2.2.4 Scrolling text marquee...........................................................................................................................20
2.2.5 Main screen ...........................................................................................................................................21
2.2.5.1 Add texting .........................................................................................................................................21
2.2.5.2 Publish picture/ video.........................................................................................................................22
2.2.5.3 Hide picture/ video.............................................................................................................................23
2.2.6 Top vice-screen......................................................................................................................................23

BlueEyes Technology
3
www.BlueEyestech.com
2.2.6.1 Add texting .........................................................................................................................................24
2.2.6.2 Publish picture....................................................................................................................................25
2.2.6.3 Hide picture ........................................................................................................................................26
2.2.7 Foot sub-screen .....................................................................................................................................26
2.2.7.1 Add texting .........................................................................................................................................27
2.2.7.2 Publish picture....................................................................................................................................28
2.2.7.3 Hide picture ........................................................................................................................................29
2.2.8 Setting....................................................................................................................................................29
2.2.8.1 Weather..............................................................................................................................................31
2.2.8.2 Date & time ........................................................................................................................................32
2.2.9 System maintaining ...............................................................................................................................32
2.2.10 Revise password ..................................................................................................................................33
2.2.11 Logout..................................................................................................................................................33
2.3 USB (prepare in advance)................................................................................................................33
2.3.1 Folder.....................................................................................................................................................34
2.3.2 Playing order..........................................................................................................................................34
2.3.3 Hide file..................................................................................................................................................35
3. Content style .............................................................................................................. 36
3.1 Content............................................................................................................................................36
3.2 Category of content.........................................................................................................................36
3.3 Scrolling text marquee ....................................................................................................................37
3.4 Photo/ picture .................................................................................................................................37
3.5 Size...................................................................................................................................................37
3.5.1 Paint.......................................................................................................................................................38
3.5.2 XnView software....................................................................................................................................42
3.5.3 Picture (photo) add with music .............................................................................................................44
3.5.4 Film editing............................................................................................................................................45
3.6 Create announcement or notification.............................................................................................45
3.6.1 Picture output........................................................................................................................................45
3.6.2 Film output ............................................................................................................................................45
3.7 Record film／micro film／testimony film.......................................................................................46
3.7.1 SES lecture recording system.................................................................................................................46
3.7.2 DV camera .............................................................................................................................................46
3.7.3 Camera...................................................................................................................................................46

BlueEyes Technology
4
www.BlueEyestech.com
3.7.4 Smartphone...........................................................................................................................................46
3.7.5 Film editing............................................................................................................................................46
4. APK ............................................................................................................................. 47
5. Q&A............................................................................................................................ 48
【Question 1】How to shut down or reboot? .....................................................................................48
【Question 2】Can I set the timer for boot and shut down DDS automatically?................................48
【Question 3】The terminal of TV is VGA, not HDMI. .........................................................................48
【Question 4】Can I play with mute? ..................................................................................................48
【Question 5】Forget the password....................................................................................................48
【Question 6】How to adjust the size of TV screen?...........................................................................49
【Question 7】There is no frame on DDS............................................................................................51

BlueEyes Technology
5
www.BlueEyestech.com
1. Introduction
1.1 About the manual
The manual can help you understand the function and operation methods of DDS player
The company suggested you that if you store all written records of important
information, in some cases, it may cause data loss and change in the electrica l
storage. Therefore the company is not responsible for the data loss that is caused
by improper use, maintenance, defects, expire or any other reason.
The company is not responsible for the economy loss that is caused by the third party
or other function, such as the DIY firmware, the information loss or change.
The pictures of operation manual may be different from the actual product, this is
because of the software version changes.
If there are changes of the information in the manual, we would not notice you. Please
go to the official website of BlueEyes Technology.
The company would not be responsible for the information downloaded from the
website.
1.2 Intellectual Property Rights
According to the Intellectual Property Rights, the copy, changes, or usage of copyrighted pictures
and music are only for personal or private use. If the user does not have a wider range of
copyright or not explicit consent of the copyright owner and unauthorized copying, change or
use the copies of this way to change or make or amendment, then it would be viewed as violating
copyright laws. The copyright owner is entitled to claim for loss. For this reason, do not illegally
use copyrighted materials.
1.3 Notices before use
★To make sure the accessories can use properly, understand the notices below★
Please read the instructions, the company would not be responsible for the product
misuse problems caused by human.
To avoid fire, electric shock or damage, please do not wet the machine by rain or
water drops. Do not put the vase on the machine.
To make sure good ventilation, do not put the machine on the bookshelf, or in the
built-in cabinets or other confined space. Keep curtains or any other object away
from the ventilation holes to avoid overheating and cause electric shock or fire.
Do not put the lighted candle or fire on the machine.

BlueEyes Technology
6
www.BlueEyestech.com
Do not open the machine to avoid electric shock. Only the maintenance staff who
was trained by the company and certificate qualified can open it.
Do not hot plugging the HDMI socket. It will shorten the life of the machine and
display of HDMI socket.
Placement
Please put the machine on the flat surface, and keep it far away from the direct
sunshine; also, prevent from high heat, humidity and frequent vibrate, or it may cause
the damage of body and internal parts, then shorten the life of the machine.
The place should be far away from the heat source, such as heating, heat regulator,
oven or other heating products.
Use the product in the dry and ventilated surrounding to avoid from breaking down.
To avoid distortion and abnormal sound, do not put heavy things on the machine.
When placing the machine, please maintain a minimum distance of 15 cm from the
wall.
Electrical source
Please do not use the too high voltage or the machine may cause fire. You should
correctly connect the AC power cord, and make sure the power cables are not
damaged. Do not pull, bend the power cord or place heavy objects on the power cord.
The power could not be over loaded on the socket. You should be careful about the
extended line and integrated socket. These may be the reasons that cause fire.
Please do not clamp the AC between the machine, wall and bookshelf.
To prevent damage caused by lightning, you should unplug the power when not using
the machine.
Cleaning
Before cleaning the machine, unplug the power cord.
Use the slightly damp, soft cloth, and do not use the liquid detergent and spray
cleaners. For stubborn stains, clean with a soft cloth moistened with water, wring
clean, and then wipe the machine with a soft, dry cloth.
Do not use any solvents, such as thinner and gasoline solvents, as these solvents
can damage the machine’s surface.
Moisture proof
When using this machine, you should try to avoid damp places, such as in a wet
basement.

BlueEyes Technology
7
www.BlueEyestech.com
In the following situations may cause condensation:
–When you suddenly move the machine from the freezing place to a warm place.
–When you are in the room that just turned on the heating, or the place the air
conditioner and heating would directly sweep through.
–In the hot summer, you move the machine from an air conditioned room to a hot
and damp place.
The moisture condensation would damage the machine. Imagine that on a hot day
you pour cold drink in the glass, the outer surface of the glass will appear drops.
Similarly, condensation will appear on the cover ,the cover is the most sensitive part
of the machine.
If it appears the condensation, plug the power cord into an electrical outlet, and use
the remote control to turn the switch on, make it operate two to three hours. In this
case, the condensation would evaporate when heating.
About the manual
Please read the instructions carefully before use, our company is not responsible for
the artificial problems caused by incorrect use of the product.
Read and keep instructions properly. Operate according to instructions in the
operation manual.
The pictures on the manual may be different from the pictures on the monitor. This
is because the software version is different.
Service
Do not attempt to repair the machine by yourself.
If not repaired, disassembled or assembled by the professional staff, it may cause
electric shock or damage of the machine.
When the machine has some abnormal phenomenon, this means that the machine
needs to be repaired.
If it needs to change parts, make sure the part has the same features as the original
one. If not, it may cause fire, electric shock, or other damage.
If it has the malfunction below or other malfunction not written, please plug the power
plug, and connect to the agent or the company service center.
–Output audio/video is not normal, the light doesn’t shine, emit smoke.
–The power cord or plug is damaged
–Liquid spilled into the machine or something enters in the body
–After the machine get wet because of the rain or water
–The machine fall from high place or other reasons to cause damage.
–Do as the manual but didn’t work

BlueEyes Technology
8
www.BlueEyestech.com
1.4 Connect to wifi
IP
192.168.1.159
SSID
blueeyes
password
No
DDS can update through wifi:
Follow the steps to connect wifi:
1. DDS will automatically boot up after power on. The time to boot up is about 60
seconds.
2. Prepare a new USB (for first time to set wifi)
3. Plug USB in DDS
4. Take out of USB after 10 seconds
5. Plug USB into computer
6. Use 「notebook」or 「Notepad++」to open the folder under USB 【main monitor】

BlueEyes Technology
9
www.BlueEyestech.com
Download website of Notepad++: http://notepad-plus-plus.org/zh/
7. Modify following value:
<book name="WiFi">
<value>on</value>
</book>
<book name="SSID">
<value>blueeyes</value> SSID name of wireless access point
</book>
<book name="Password">
<value>12345678</value> password of wireless access point
</book>
<book name="encryption">
<value>WPA</value> encryption of wireless access point: no, WEP, WPA
</book>
<book name="the way to get IP">
<value>STATIC</value> the way to get IP: STATIC, DHCP
</book>
<book name="IP">
<value>192.168.1.159</value> IP, use Chrome to connect
</book>
<book name="NetMask">
<value>255.255.255.0</value>
</book>
<book name="Gateway">
<value>192.168.1.1</value> IP of wireless access point
</book>
<book name="DNS1">
<value>8.8.8.8</value> DNS: 8.8.8.8、168.95.1.1
</book>
<book name="DNS2">
<value>8.8.4.4</value> DNS: 8.8.4.4、168.95.192.1
</book>
8. Save config.xml file
9. Plug USB into DDS again
10.Open Chrome and enter IP (http://192.168.1.159:8080). Make sure connection is ok
11.Take out of USB

BlueEyes Technology
10
www.BlueEyestech.com
2. Customized pattern
2.1 Pattern
There are 12 different kinds of patterns to meet various demands. You choose the pattern that
can display your information well.
Layout
Main screen
Banner
Vice-screen
Marquee
1
●
●
●(left)
●
2
●
●
●(right)
●
3
●
●(left)
●
4
●
●(right)
●
5
●
●
●(left)
6
●
●
●(right)
7
●
●(left)
8
●
●(right)
9
●
●
10
●
●
11
●
●
●
12
●

BlueEyes Technology
11
www.BlueEyestech.com
2.1.1 First pattern
Pattern
Main screen
Banner
Vice-screen
Marquee
1
●
●
●(left)
●
Illustrate
Example
2.1.2 Second pattern
Pattern
Main-screen
Banner
Vice-screen
Marquee
2
●
●
●(right)
●
Illustrate
Example

BlueEyes Technology
12
www.BlueEyestech.com
2.1.3 Third pattern
Pattern
Main screen
Banner
Vice-screen
Marquee
3
●
●(left)
●
Illustrate
Example
2.1.4 Fourth pattern
Pattern
Main screen
Banner
Vice-screen
Marquee
4
●
●(right)
●
Size (pixel)
-
Illustrate
Example

BlueEyes Technology
13
www.BlueEyestech.com
2.1.5 Fifth pattern
Pattern
Main screen
Banner
Vice-screen
Marquee
5
●
●
●(left)
Illustrate
Example
2.1.6 Sixth pattern
Pattern
Main screen
Banner
Vice-screen
Marquee
6
●
●
●(right)
Illustrate
Example

BlueEyes Technology
14
www.BlueEyestech.com
2.1.7 Seventh pattern
Pattern
Main screen
Banner
Vice-screen
Marquee
7
●
●(left)
Illustrate
Example
2.1.8 Eighth pattern
Pattern
Main screen
Banner
Vice-screen
Marquee
8
●
●(right)
Illustrate
Example

BlueEyes Technology
15
www.BlueEyestech.com
2.1.9 Ninth pattern
Pattern
Main screen
Banner
Vice-screen
Marquee
9
●
●
Illustrate
Example
2.1.10 Tenth pattern
Pattern
Main screen
Banner
Vice-screen
Marquee
10
●
●
Illustrate
Example

BlueEyes Technology
16
www.BlueEyestech.com
2.1.11 Eleventh pattern
Pattern
Main screen
Banner
Vice-screen
Marquee
11
●
●
●
Illustrate
Example
2.1.12 Twelfth pattern
Pattern
Main screen
Banner
Vice-screen
Marquee
12
●
Illustrate
Example

BlueEyes Technology
17
www.BlueEyestech.com
2.2 Website
2.2.1 Connect to website
Enter the IP of DDS and add 8080. We advise you use Google Chrome as your browser.
For example: http://192.168.0.100:8080
Default account is admin, default password is on default value of manufacturing list.
2.2.2 Status
It shows used memory, DDS version, memory, left memory, Wi-Fi MAC, Wi-Fi SSID, IP, mask,
Gateway, DNS1, DNS2.

BlueEyes Technology
18
www.BlueEyestech.com
Used memory
Used memory, you can save data at SD card or USB.
Version of DDS
Version information
Memory
Total memory
Left memory
Left memory
Wi-Fi MAC
Address of Wi-Fi MAC
Wi-Fi SSID
Name of Wi-Fi MAC SSID
IP
IP of DDS
Mask
Internet mask
Gateway
Default gateway
DNS1
DNS1
DNS2
DNS2
2.2.3 Banner LOGO
It shows uploading picture, add texting and banner picture. We recommend you the resolution
of uploading picture should be 1280x95.

BlueEyes Technology
19
www.BlueEyestech.com
Banner can only for picture, can not for video.
2.2.3.1 Upload picture
We recommend you the resolution of uploading picture should be 1280x95.
2.2.3.2 Add texting
You can enter number, Chinese, English, html. The texting can only be one sentence. For
Chinese, should less than 17 words; for English, should less than 34 words. Besides, the
background color can be changed (black, white, red, blue, yellow, green, dark red)
Format of Html:
<font color="red">this is (red) marquee!</font>
<font color="blue"> this is (blue) marquee!</font>
<font color="yellow"> this is (yellow) marquee!</font>
