BMW ONBOARD COMPUTER User manual

Operating
Instructions
for On-Board
Computer
Contents
A - Z
Online Edition for Part No. 01 41 0 156 676 - © 01/02 BMW AG

The on-board computer offers you a great many functions which will make your
journeys even safer and more of a pleasure.
The GPS navigation system renders it unnecessary to consult printed maps or
search for road signs and brings you accurately to any destination shown on the
map CD.
The radio and the cassette and CD players ensure the best possible signal recep-
tion, sound quality and choice of entertainment for all listeners' tastes, and take the
monotony out of even the longest journey.
The TV with teletext ensures a supply of topical information and provides in-car en-
tertainment while you are waiting.
The BMW car phones mean that you can always be contacted and make outgoing
telephone calls.
The computer calculates data relevant to the journey – average fuel consumption,
range and estimated time of arrival. It also provides additional safety both before
the engine can be started – for instance by demanding a code input for the engine
immobiliser – and when driving, for example by supplying a warning signal to make
sure that you do not drive faster than intended.
We wish you an enjoyable driving experience
BMW AG
Introduc-
Online Edition for Part No. 01 41 0 156 676 - © 01/02 BMW AG

© 2002 Bayerische Motoren Werke
Aktiengesellschaft
Munich, Germany
Not to be reproduced wholly or in
part without written permission from
BMW AG, Munich.
Order No. 01 41 0 156 676
English II/02
Printed in Germany
Printed on environmentally friendly paper
(bleached without chlorine, suitable for recycling).
Contents
The on-board computer at a
glance 8
Radio controls at a glance 10
Functions at a glance 12
Screen layout at a glance 14
Operating principle 16
How to select functions 18
Settings 19
Starting the System
Safety 22
GPS 22
Map CD 22
Starting GPS navigation 23
Selecting a destination
Selection options 23
Entering a destination address
manually 24
Selecting the destination from a
map 27
Selecting a destination via
Information 29
Last destinations 30
Returning to the starting
point 31
Selecting a route 32
Destination guidance
Starting destination guidance 33
Displaying route 34
Altering route 36
Traffic information 37
Speech output 40
Destination guidance 41
Ending/interrupting destination
guidance 41
Destination memory
Creating address book 42
Retrieving an address 43
Deleting an address 43
Other functions
Vehicle position 44
Wordmatch principle 45
Troubleshooting
What to do if … 46
Overview
Navigation
Online Edition for Part No. 01 41 0 156 676 - © 01/02 BMW AG

3n
OverviewNavigation
Entertainment
TelephoneComputerKeywords
Radio settings
Switching the radio on and
off 48
Varying volume 48
Tone control 49
Radio reception
Selecting waveband 50
Selecting a station 50
Programme type (PTY) 53
Memorising stations 54
Calling up stations 55
Traffic reports 56
Regional stations 58
Players
Starting and stopping
cassette 59
Reminder displays 59
Noise suppression 60
Music track search 60
CD changer 61
Starting and stopping a CD 62
Reminder displays 63
Music track search via
buttons 63
Music track search via menu
guidance 64
TV settings
Switching TV on/off 66
Adjusting the TV picture 66
Adjusting TV format 67
TV reception
Selecting TV channels 67
Memorising TV channels 69
Teletext 69
DSP sound system
Switching sound system on/
off 71
Selecting sample effects 71
Individual tone memories 72
Calling up tone memories 72
Using the phone in the car 74
Getting started 74
Emergency call 75
Entering PIN 75
Receiving calls 75
Dialling by entering phone
number 76
Ending a call 76
Dialling via directory 77
Dialling via TOP-8 78
Dialling via last numbers 79
SMS messages 80
Info 80
Entertainment
Telephone
Online Edition for Part No. 01 41 0 156 676 - © 01/02 BMW AG

Contents
Computer
Starting computer 82
Range 82
Outside temperature 82
Arrival time 83
Fuel consumption 83
Average speed 83
Speed limit 84
Distance 85
Stopwatch 86
Remote control 86
Code
Defining and activating code 87
De-activating the code 88
Auxialiary fuel-burning heater/
independent ventilation control
Setting timeswitch 89
Switching direct mode on/off 90
From A to Z 92
Computer
Index
Online Edition for Part No. 01 41 0 156 676 - © 01/02 BMW AG

5n
OverviewNavigation
Entertainment
TelephoneComputerKeywords
Notes
Symbols
Your individual vehicle
Notes on these Operating Instruc-
tions
So that you can enjoy using your on-
board computer as soon as possible,
the first chapter provides an overview
of the displays and controls, and ex-
plains the operating principle.
You will in addition find
>
Full details of adjusting the screen
settings in the chapter "Overview"
>
All the information you need on the
GPS navigation system in the chapter
"Navigation"
>
All the information you need for
tuning and receiving radio and televi-
sion programmes* and for playing
cassettes and compact discs (CDs) in
the chapter entitled "Entertainment".
This chapter also contains informa-
tion on the "Digital Sound
Processing* (DSP)" sound system
>
Special information on how to
operate BMW car phones via the on-
board computer in the chapter "Tele-
phone". Since there are other
methods of operating the telephones
as well as via the on-board computer,
please also read the instructions in
the separate handbook provided.
>
Information on journey-related data
calculated by the on-board com-
puter in the chapter "Computer".
This chapter also provides informa-
tion on the code for the engine immo-
biliser and the settings for the
auxiliary heater/independent ventila-
tion control*.
You will find it easiest to locate certain
topics via the index.
All abbreviations appearing on the
screen are explained in the list at the
end of this handbook.
Should you sell your BMW at a later
date, please remember to pass this
handbook on to the next owner – it is an
important part of the vehicle's specifi-
cation.
Notes on care
For full details of how to care for cas-
settes, CDs and the set, see the sepa-
rate brochure "Looking after your car".
Online Edition for Part No. 01 41 0 156 676 - © 01/02 BMW AG

6n
Symbols used
indicates precautions that must
be followed precisely in order to
avoid the possibility of personal injury
and serious damage to the vehicle or to
the on-board computer.<
contains information that will
assist you in gaining the optimum
benefit from your on-board computer
and enable you to care more effectively
for your on-board computer.<
<
marks the end of a specific item of
information.
* identifies optional extras or specific
national-market items of equipment,
and also accessories.
If you have any queries, BMW Service
will be glad to advise you.
Status at time of printing
The advanced technological features
and high quality standard of BMW
equipment are maintained by an
ongoing development process. This
may lead to differences between these
instructions and the actual item fitted to
your car. Nor can errors and omissions
be entirely ruled out. You are therefore
asked to appreciate that no legal claims
can be entertained on the basis of the
data, illustrations or descriptions in this
handbook.
Software status
The version of the software in your car's
on-board computer is indicated at the
top right in the menu "Settings".
"SW 3-1/XX" means:
>
3: generation 3
>
1: top navigation
>
XX: current version.
These Operating Instructions are based
on the following version of the on-board
computer software: 5.0.
If you have any queries regarding
the software status of your set,
please contact BMW Service.<
Status at time of printing
For your own safety
Online Edition for Part No. 01 41 0 156 676 - © 01/02 BMW AG

7n
OverviewNavigation
Entertainment
TelephoneComputerKeywords
Overview
Navigation
Entertainment
Telephone
Index
Computer
Overview
Online Edition for Part No. 01 41 0 156 676 - © 01/02 BMW AG

8n
The on-board computer at a glance
Online Edition for Part No. 01 41 0 156 676 - © 01/02 BMW AG

9n
OverviewNavigation
Entertainment
TelephoneComputerKeywords
Displays and controls
1 Monitor screen
>
Display of functions
2 Indicator lights for telephone
* opera-
tion
>
Yellow:
Telephone logging onto another
network
>
Green:
Connected
>
Red:
No telephone operation possible
>
Flashing:
Telephone not registered for any
network
3 Receiver symbol
>
Dialling a telephone number 77
>
Ending a call 77
4 Clock symbol
>
To switch off direct operation of
auxiliary heater/independent venti-
lation control 90
>
To display the time when the igni-
tion is switched off (ignition key in
position 0 or removed)
5 MENU
>
Calling up top menu 16
6 Operating the on-board
computer 16
>
Turn: to mark a function or adjust a
value
>
Press: to confirm a selection or
memorise a setting
7 Indicator light for operation of auxil-
iary heater/independent ventilation
control
*
> Red:
Timeswitch activated
>
Flashing:
Direct operation switched on
8 Changeover of display to
>
Radio functions
>
On-board computer functions
Displays and controls for the ra-
dio, see page 10.<
The on-board computer at a glance
Online Edition for Part No. 01 41 0 156 676 - © 01/02 BMW AG

10n
Radio controls at a glance
Online Edition for Part No. 01 41 0 156 676 - © 01/02 BMW AG

11n
OverviewNavigation
Entertainment
TelephoneComputerKeywords
The radio controls at a glance
Displays and controls
1 INFO
>
Activating RDS functions 51
>
Activating traffic information
functions 56
>
Activating regional function 58
2 Waveband/memory level
>
FM/FMD (VHF) 50, 54
>
AM (LW/LWA, MW/MWA
and SW/SWA) 50, 54
3 Station/selection buttons
>
Radio
Station selection 55
>
CD changer *
Selecting a CD 63
4 Monitor screen
>
Display of functions
5 Changing tape track 59
6 Lowering cover, ejecting cassette 59
7 SELECT
>
Selecting station search functions
Manual station selection 52
Sample stations 52
Station search sensitive/non-
sensitive 53
>
Switching Dolby on/off 60
>
Music track search via menu
guidance 64
8 Station/title search
>
Station search 53
>
Fast forward/rewind 60
>
Music track search
Cassette 60
CD changer 63
9 TONE
>
Calling up the tone settings 49
10 Indicator light for radio operation
11 Changeover of display to
>
On-board computer functions
>
Radio functions
12 Operating the radio
>
Press: to switch the radio on and
off
>
Turn: to adjust the volume of the
radio and of navigation instruc-
tions
13 MODE
To change the audio source to
>
Radio
>
Cassette
>CD changer
14 Tape slot
If your car is equipped with a
multifunctional steering wheel*,
the controls on the wheel can also be
used to operate radio, CD changer*,
telephone*and voice input system*
functions, see the car's Owner's Hand-
book.
Instructions on operating the voice
input system are provided in a separate
operating instructions booklet.<
Online Edition for Part No. 01 41 0 156 676 - © 01/02 BMW AG

12nFunctions at a glance
Online Edition for Part No. 01 41 0 156 676 - © 01/02 BMW AG

13n
OverviewNavigation
Entertainment
TelephoneComputerKeywords
Functions at a glance
1 Computer
>Displaying range 82
>Displaying outside
temperature 82
>Displaying arrival time 83
>Calculating fuel consumption 83
>Calculating average speed 83
>Adjusting speed limit 84
>Adjusting/displaying distance 85
>Switching stopwatch on/off 86
2 GPS navigation
>Map CD: changing 22
>Selecting a destination 24
>Selecting a route 32
>Being guided to a destination 33
>Displaying route list 34
>Selecting traffic information 37
>Creating/calling up address
book 42
>Displaying current location 44
3TV
*
>Adjusting picture 66
>Adjusting format 67
>Selecting a programme 67
>Storing a station 69
>Calling up teletext 69
4 DSP*(Digital Sound Processing)
>Selecting sample effects 71
>Adjusting effects memory
individually 72
>Calling up tone control
memory 72
5 Auxiliary heating/independent venti-
lation control*
>Entering and memorising switch-
on times 89
>Switching heating and ventilation
on/off 90
6 Switching off the screen
7 Current date
8 Selectable settings; e.g.
>"RDS-TMC" function in
radio mode switched on 37
>"Memo" function
switched on via Set 19
9 BMW ASSIST*
To call up the emergency-call and in-
formation service (see the separate
supplementary operating instruc-
tions for notes on operation)
BMW ASSIST and roaming*are
only available if BMW Service
has been requested to register BMW
ASSIST.<
10 Telephone*
>Sending an emergency call 75
>Entering PIN 75
>Receiving calls 75
>Dialling a subscriber 76
>Reading SMS messages / calling
back sender 80
11 Code
>Defining and activating code 87
>De-activating the code 88
12 Settings
>Selecting screen settings 19
>Selecting form of expression of
date and time 19
>Determining volume of audio
sources in relation to the naviga-
tion instructions 19
>Selecting screen colours 19
>Selecting language 19
>Selecting units of
measurement 19
>Switching Memo on/off 19
>Initialising the BMW ASSIST
emergency-call and information
service 19
>Switching roaming on/off 19
13 Current time
Online Edition for Part No. 01 41 0 156 676 - © 01/02 BMW AG

14nScreen layout at a glance
Online Edition for Part No. 01 41 0 156 676 - © 01/02 BMW AG

15n
OverviewNavigation
Entertainment
TelephoneComputerKeywords
Screen layout at a glance
Split screen
Left half of screen
>Information on the audio source
(e.g. radio stations) 54
>Information on the computer (e.g.
momentary average
fuel consumption) 83
>Information on the route (e.g. map
section to scale) 34.
Right half of screen
>Information on current position
(degrees longitude/latitude and alti-
tude)
or
>Information for destination guidance
(e.g. turning direction) 33.
The calculation of altitude, which
only takes place when GPS recep-
tion is active, may deviate from the ac-
tual altitude of the car's current posi-
tion.<
Entire screen width
>Information for communication (e.g.
SMS messages) 80
>Information from BMW ASSIST*(e.g.
BMW Mobile Service)
>Information from the television sta-
tion*(e.g. news) 67
>Changes to the code, the settings,
the DSP*and the auxiliary heater/
independent ventilation control*.
Full screen
Whichever functions you choose, all in-
formation and selection options are dis-
played across the entire width of the
screen.
If you prefer this form of screen layout,
under MENU you can select the func-
tion "Set" to alter the standard setting
"Split", see page 19.
Online Edition for Part No. 01 41 0 156 676 - © 01/02 BMW AG

16nOperating principle
Calling up MENU
Various functions are integrated into the
on-board computer. If you call up the
top menu (MENU), these are displayed,
see page 12.
Call up "MENU"
If you select a function in MENU, you
are offered either adjustment options or
further menus:
>See "Selecting function" for details of
how to select functions
>See "More functions" for details of
how to display further functions
>For details of how to adjust the way
the computer switches between
menus, see "Last function memory"
on page 17
>For details of how to return to a
higher level, see "Selecting return
symbol" on page 17
>For details of how to call up further
entries in lists, see "Browsing forward
and back" on page 17.
To return to the main MENU level from
any other menu or function:
Selecting function
To select a function, please perform
two steps with the rotary control:
1. Mark a function
Turn right-hand rotary control until
the desired function is highlighted
2. Confirm the choice of function
Press right-hand rotary control.
These two steps are expressed collec-
tively on the following pages as:
Select "Function"
More functions
If the screen shows one of the above
symbols, you can call up more func-
tions on the menu you have chosen.
To do this, turn the right-hand rotary
control in the direction of the symbol in
question. You can now highlight and
select one of the functions shown, see
"Selecting function".
Depending on the extent of the
function, it may take a few
seconds for the screen to display the
additional functions.<
Online Edition for Part No. 01 41 0 156 676 - © 01/02 BMW AG

17n
OverviewNavigation
Entertainment
TelephoneComputerKeywords
Operating principle
Last function memory
This function makes it easier for you to
call up again the information that you
last had on the screen or the function
that you were last using before switch-
ing off the on-board computer or
changing to a different menu.
When you switch the on-board com-
puter back on or select the desired
function again in "MENU", the com-
puter immediately switches to the menu
level you were last using.
To interrupt this function if you would
like to enter the first menu level when
changing over:
Press twice briefly.
Selecting "return" symbol
To return to a previous menu or func-
tion level, perform the following action:
Select .
As described under "Selecting func-
tion", the "return" symbol can also be
highlighted with the right-hand rotary
control, then selected by pressing the
control.
Browsing forward and back
If the screen shows one of the above
symbols, you can call up more entries
in a list.
As described under "Selecting func-
tion", this symbol can also be high-
lighted with the right-hand rotary con-
trol, then selected by pressing the
control.
Online Edition for Part No. 01 41 0 156 676 - © 01/02 BMW AG

18nHow to select functions
To enable you to find your way round at
a glance, the individual steps to be per-
formed in making each selection are
shown beneath the illustration of the
corresponding menu.
Depending on the operation, the follow-
ing elements may be involved:
>Buttons to press
>Functions to select with the right-
hand rotary control. "Selecting func-
tion", see page 16
>The right-hand rotary control with ar-
rows, if it is to be only pressed or only
turned.
The individual steps are separated by
the symbol.
An example: adjusting date
The structure and operating principle
are illustrated here, using the proce-
dure for adjusting the date as an exam-
ple:
1. Call up "MENU"
2. Select "Set"
3. Select "Date"
4. Select "Set"
5. Select the year
6. Turn right-hand rotary control to
adjust the year
7. Press right-hand rotary control to
memorise the setting
8. Set the month and day in the same
way.
The date settings are retained
9. Select .
The last operation takes you out of
the date input routine.
You can also choose the order in which
the date is expressed: either the days
(dd) first, followed by the months (mm) -
or in the opposite order.
To exit a function or adjustment
option that has been selected in-
advertently, select it a further time. You
can now select any of the other func-
tions.<
Online Edition for Part No. 01 41 0 156 676 - © 01/02 BMW AG

19n
OverviewNavigation
Entertainment
TelephoneComputerKeywords
Settings
Selecting settings
Depending on the country for which
your vehicle is supplied, the on-board
computer has specific basic settings for
all displays. These settings can also be
made as preferred individually.
1. Call up "MENU"
2. Select "Set".
The adjustment options are dis-
played.
You can adjust the following:
>"Screen"
To select the screen layout (split or
full), see page 15
>"Clock"
>"Date"
To adjust the time and date and alter
their form of expression
>"Navi. volume"
To adjust the volume of the audio
source in relation to the navigation in-
structions (min to max)
>"Colour set"
To select a set of colours for the
screen display
>"Language"
To select the language of the display
texts.
For further settings, follow the sym-
bol.
You can now adjust:
>"Distance" (km or mls)
>"Consump." (l/100 km, mpg or km/l)
>"Temperature" (6or 7)
To alter the units of measurement for
distance, fuel consumption and tem-
perature
>"Memo"
To set a signal which sounds on the
hour
>"BMW ASSIST"*
You can initialise or update this emer-
gency-call and information service if
it has been arranged for you by BMW
Service
>"Roaming" (only with BMW ASSIST)
You can use the above service when
abroad (automatically or off).
For details of how to make the
settings, see page 18.<
Online Edition for Part No. 01 41 0 156 676 - © 01/02 BMW AG
