User Manual
QL/DMS.X6-C
Massage Gun

1
Maintenance
The battery in this device is not designed to be removed or exchanged
by the user. If any problem with the power supply occurs, please contact
us directly.
Do not try to open the device, repair it, or fix it by taking the device
apart yourself. Tampering with the device's mechanics in any way will
result in the automatic voiding of the product's warranty.
Warnings and Safety Concerns
Before connecting the device to the power supply, please ensure that
the supply voltage stated on the rating plate is compatible with the unit.
Please fully charge the new batteries before the first use.
Do not submerge the device in water or any other liquid.
Do not use the device for more than 30 minutes at a time. Wait 5
minutes prior to using the device again, following a 30-minute session
with the device.
Do not apply to or near your head or genitals.
Do not use the device to supplement or replace any medical treatment.
Please consult your physician before using the device if you are
experiencing unexplained pain, receiving medical treatment, or using
medical equipment.
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
FCC Statement NOTE:
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
This device may not cause harmful interference.
This device must accept any interference received, including
interference that may cause an undesired operation.
(1)
(2)

2
will not occur in a particular installation. If this equipment does cause any
harmful interference to radio or television receptions, which can be
determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following
measures:
•
•
•
•
FCC Statement NOTE:
Disclaimer
Please contact your physician before using the Bob and Brad X6 PRO if
you have any health concerns or have any of the following conditions:
Pregnancy, diabetes, epilepsy, migraines, herniated disks,
spondylolisthesis, recent joint replacements, or IUDs. Please also contact
your physician before using if you’ve had a recent surgery or have any
metal pins or plates in your body.
Relocate the receiving antenna.
Increase the separation area between the equipment and receiver.
Connect the equipment to an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help
with the supplied fastener. Do not hang the unit by the power cord.

3
Main Structure and the fittings
Removeable and repalceable massage head
On/off/ gear
Gear indicator
Silicone handle
Battery Indicator
DC Charging Port
Bottom
LED1 LED2 LED3 LED4
25% 50% 75% 100%
LED1 flashes means battery is
running down to less than 10%
2. Metal Flat Head 3. Air Cushion Head1. Bullet Head
4. Ball Head 5. Fork Head

4
Operation Steps
Connect the massage head when the device is turned off. Insert the
massage head completely with pressure and pull it out when
removing the vibrating head (note: The Fork head should be
positioned for installation. When the buckle is inserted into the slot,
it means the installation is in place. If the massage head is not
installed in place, there will be a risk of falling out while in use.)
Turning the device ON/OFF: Press and hold the “ ” power button
for 2 seconds.
To change the percussion massage frequency when the device is on,
press the button “ ”to turn on the first setting. If you would like to
advance to a higher setting, press the power button “ ”again. The
backlight will indicate the active setting. To pause the massage gun,
press the power button for 2 seconds. Press for 2 seconds again to
resume.
Note:
After 10 minutes of operation, the device will automatically turn off.
The LED light indicates the corresponding strike frequency level, the
lowest at level 1 and the highest at level 5.
When the device is in standby mode (level 0), it will automatically
shut down without any operation for 20 seconds.
1.
3.
A.
B.
C.
2.

5
When the first indicator light is on, it’s indicating 25% of the battery is
remaining.
When the second indicator light is on, it's indicating 50% of the battery is
remaining.
When the third indicator light is on, it's indicating 70% of the battery is
remaining.
When the fourth indicator light is on, it's indicating 100% of the battery is
remaining.
Note:
When the first indicator light flashes, the battery is less than 10%
charged and recharging is required.
It is not recommended that the battery power drop below 25% charge.
Battery Display
LED1 LED2 LED3 LED4
25% 50% 75% 100%
LED1 flashing means the battery is running down
to less than 10% and recharging is required.
Charging
Before the first use, please fully charge the device. To charge fully, it
takes about 3 hours.
Connect the output end of the connection line to the DC charging
port at the bottom of the device. Then, connect the input end of the
connection line to a power source via a power adapter or mobile
phone charger (5V/2A; if the charging current or voltage is less than
5V/2A charging time will be longer. Any regular phone adapter will
be able to charge the massage gun without a problem.)
The battery icon on the handle flickers regularly. The digital display
on the handle shows the battery power and indicates when the
battery is being charged and the power level remaining.
When the battery icon on the handle stops flickering and remains
on, the digital display shows that 100% of the battery is complete.
The battery can be recharged at any level of the battery power.
When charging, please ensure that the device is shut down.
1.
2.
3.
4.

6
Technical Details:
QL/DMS.X6-C Massage Gun
Speed: 2000-3200 r/min
Rated Power: 25W
Dimensions: 24.4 x 14.7 x 7.3cm / 9.6" x 5.7" x 2.9"
Battery Information:
Battery Rated Voltage: 14.8V
Battery Capacity: 2500mAh
Charging Time: 180 minutes
Guarantee
This product comes with a one-year warranty from the date of purchase.
Warranty will be voided due to any of the following:
Damage due to improper usage or storage.
Damaged by attempting to repair or disassemble the device.
Period of warranty exceeded.

7
Utilize the Bob and Brad massage gun before, during, or after your workout for maximum benefits. This
massage gun can help accelerate muscle tissue responsiveness by increasing hydration, range of motion, and
function to tight muscles.
Indication Action Speed Pressure Duration Muscle Position Movement
Warm-Up /
Activation
Activate and prime
muscles prior to exercise.
Reduce the riskof injury.
Level 3 Light to
Moderate
30 sec or
less
Relaxed. Move along
the muscle.
Quick, high
speed over
the area.
Mid Workout /
Myofascial
Mobility
Help muscle recovery and
reactivation. Level 4
Heavy
(especially
for large
muscle
groups)
8-12 sec Target specific area. Localized
Recovery
Relax muscles and aid
recovery.
Down-regulate or turn off
muscles.
Level 1
or 2
Moderate
to Heavy
90 sec or
more
Move along the
muscle.
Slow
movement
along with the
muscle.
Pain Modulation Reduction in pain to
increase movement. Level 1 Light 10 - 30
sec
Relaxed. Localized
spot.
Over painful
area.
Body
Awareness
Improve movement or
mechanics of a joint.
Activation of a muscle.
Draw attention to a muscle.
All
Levels
Light to
Moderate
10 - 20
sec
Relaxed or with
movement.
Over specific
target area or
movement
over the area.

8
ATTACHMENT:
PROTOCOL: Sweep from A to B on
each sice for 1 minute
BALL HEAD
DURATION: 2 minutes
2 Minutes
CHEST
ATTACHMENT:
PROTOCOL: Sweep from A to B on
each sice for 1 minute
BALL HEAD
DURATION: 2 minutes
2 Minutes
ABS

9
ATTACHMENT:
PROTOCOL: Sweep from A to B on each
side for 30 seconds
BALL HEAD
DURATION: 1 minute
1 Minute
UPPER TRAPS
ATTACHMENT: BALL HEAD
PROTOCOL: Sweep from A to B on
each side for 1 minute
STEP 1: Upper back
DURATION: 2 minutes
PROTOCOL: Sweep from A to B
on each side for 1 minute
STEP 2: Lower back
DURATION: 2 minutes
4 Minutes
UPPER BACK

10
ATTACHMENT:
PROTOCOL: Sweep from A to B on
each side for 1 minute
BALL HEAD
DURATION: 2 minutes
2 Minutes
SHOULDERS
ATTACHMENT:
PROTOCOL: Sweep from A to B on
each side for 1 minute
BALL HEAD
DURATION: 2 minutes
2 Minute
BICEPS

11
ATTACHMENT:
PROTOCOL: Sweep from A to B on each
side for 2 minutes
BALL HEAD
DURATION: 4 minutes
4 Minutes
TRICEPS
ATTACHMENT:
PROTOCOL: Sweep from A to B on
each sice for 1 minute
BALL HEAD
DURATION: 2 minutes
2 Minutes
FOREARM

12
ATTACHMENT:
PROTOCOL: Sweep from A to B on each
side for 30 seconds
BALL HEAD
DURATION: 1 minutes
1 Minute
HANDS
ATTACHMENT:
PROTOCOL: Sweep from A to B on
each sice for 1 minute
BALL HEAD
DURATION: 2 minutes
2 Minutes
HIP FLEXORS

13
ATTACHMENT:
PROTOCOL: Sweep from A to B on
each sice for 30 seconds
BALL HEAD
DURATION: 1 minute
1 Minute
SHINS
ATTACHMENT:
PROTOCOL: Sweep from A to B on
each side for 2 minutes
FLAT HEAD
DURATION: 4 minutes
4 Minutes
GLUTES

14
ATTACHMENT:
PROTOCOL: Sweep from A to B on
each sice for 1 minute
BALL HEAD
DURATION: 2 minutes
2 Minutes
HAMSTRINGS
ATTACHMENT:
PROTOCOL: Sweep from A to B on
each sice for 1 minute
BALL HEAD
DURATION: 2 minutes
2 Minutes
CALVES

15
ATTACHMENT:
PROTOCOL: Sweep from A to B on
each sice for 2 minutes
BALL HEAD
DURATION: 4 minutes
4 Minutes
FEET

16
Every Bob and Brad product is backed by a 1-year warranty and an
award-winning customer service team. If you are in any way dissatisfied
with a product you ordered, we’ll exchange it, replace it or refund your
money under the warranty. Simply email us the problem, and we’ll take
care of it.
A Dedicated Team Just For You
Answer questions about
your device and best
practices.
Product Knowledge
Place New Orders
Help you solve any
issues with your device.
Troubleshoot
Initiate Returns
Provide instructions for
replacements, returns
and refunds.
Help with placing
orders online and/or
authorized resellers.
Call: [phone] Mon-Fri 9:00AM-4:30PM (CST)
Email: [email protected]
FLIGE Products LLC
3001 Esperanza Crossing Austin,TX 78758
Get in Touch.
