Bodyguard T240 User manual

BODYGUARD®FITNESS, division of Procycle
CANADA
9095, 25th Avenue, Saint-Georges
(Québec) Canada G6A 1A1
The name “Bodyguard Fitness®” and heart logo are
registered trademarks of Procycle Group Inc.
T240 – T260
TREADMILLS
OWNER’S MANUAL
R0 07 / 2005
591157

TABLE OF CONTENTS
IMPORTANT SAFETY NOTICE ....................................................................................................................................... 3
WARRANTY INFORMATION ......................................................................................................................................... 5
1. OPERATING YOUR T240 – T260 ................................................................................................................................6
1.1 Getting to Know the T240 – T260 Computer Display Monitor ........................................................................... 6
1.2 Pausing During an Exercise .................................................................................................................................. 8
1.3 Saving an Exercise ................................................................................................................................................. 8
1.4 Viewing Exercise Parameters ............................................................................................................................... 9
2. SETTING UP THE COMPUTER TO YOUR ENVIRONMENT................................................................................... 9
2.1 Access to “Settings Menu”.................................................................................................................................... 9
2.2 Language Feature.................................................................................................................................................. 9
2.3 Weight Unit Feature ........................................................................................................................................... 10
2.4 User Identification Feature ................................................................................................................................. 10
2.5 Distance Unit Feature.......................................................................................................................................... 12
2.6 Time, Distance or Calories Feature ..................................................................................................................... 12
2.7 Warm Up and Cool Down Feature .................................................................................................................... 12
2.8 Heart Rate Control Options Feature ................................................................................................................. 13
2.9 Heart Rate Access Options Feature ................................................................................................................... 13
2.10 Beeper Feature ................................................................................................................................................... 14
2.11 Speed Limits ........................................................................................................................................................ 14
2.12 Big Number Option ............................................................................................................................................ 14
2.13 Learn Program .................................................................................................................................................... 14
214 Heart Rate Recovery ........................................................................................................................................... 15
3. T240 – T260 EXERCISE PROGRAMS ...................................................................................................................... 15
4. USING A HEART RATE RECEIVER .......................................................................................................................... 21
Possible Chest Strap Heart Rate Problems ................................................................................................................. 22
5. COMPUTER DIAGNOTICS........................................................................................................................................ 22
Acess to”Diagnostics” menu....................................................................................................................................... 22
6. MAINTENANCE INFORMATION ............................................................................................................................. 27
General Care ................................................................................................................................................................ 27
Belt and Running Deck ............................................................................................................................................... 28
Quick Troubleshooting Check List ............................................................................................................................. 29
Error Codes .................................................................................................................................................................. 30
2
TTaabblleeooffCCoonntteennttss
Table of Contents

IMPORTANT SAFETY NOTICE
READ THIS MANUAL THOROUGHLY BEFORE ATTEMPTING
TO ASSEMBLE OR USE THIS EXERCISE EQUIPMENT.
To ensure that you get the maximum benefit from the engineering that has gone into your machine, we recommend
that you read this manual carefully before attempting to assemble and use the T240–T260. Save these instructions and refer
to this manual if you are unfamiliar with operation of the T240 – T260.
WARNING – Before attempting to use any of this equipment you should read this instruction manual carefully. Use of
this equipment by persons with heart or other medical problems may result in serious injury. You should consult with a
physician prior to using this equipment. It is recommended to periodically consult your physician as you continue to use this
equipment. Immediately cease exercise if you feel dizzy, faint or short of breath. Use of this equipment in a manner other
than as prescribed by the instructions herewith may result in serious injury.
AVERTISSEMENT – Une lecture attentive de ce manuel d’instructions est recommandée avant de commencer à utiliser cet
appareil. Son utilisation peut provoquer des blessures sérieuses chez les personnes souffrant de troubles cardiaques ou
autres problèmes médicaux. Il est recommandé à ces personnes de consulter leur médecin avant d’utiliser cet appareil. Il est
aussi recommandé de consulter régulièrement le médecin au cours de la période d’entraînement. Si vous êtes pris de
vertiges ou d’étourdissements, si vous vous sentez défaillir ou avez le souffle court, cessez immédiatement l’exercice.
L’utilisation de cet appareil d’une manière inadéquate ou autre à celle décrite dans ce manuel d’instructions peut entraîner
des blessures sérieuses.
For Your Personal Safety
Do not place towels or clothing on any part of the treadmill.
Do not place liquids near the computer console, electrical power plug, ON/OFF switch or any part of the treadmill.
Before attempting to disconnect the power, exit the program screen, then turn power OFF. To reduce any risks of electrical
shock, do not pull the power cord from the cable. Gently remove the power cable by the head from the wall outlet.
Do not operate the treadmill if the power cord is damaged or if the treadmill is not working correctly. If the power cord
is damaged, please contact your distributor or manufacturer to get it replaced. The rating of the new power cord must be
15 amps (125 volts AC).
For the International version of the T240–T260, note that the power cord to be used for replacement must be rated 10 Amps
(250 Volts AC) and must be 2.5 meters (or 8 feet) long minimum.
Keep the power cord away from all moving parts of the treadmill, such as the elevation arm assembly and front transport wheels.
Do not use an extension cord that is not properly grounded. Keep all extension cords clear of all moving parts of the treadmill.
Place the equipment in a way that the power can be easily interrupted by pulling the power cord.
Do not allow children near the treadmill when in operation. Do not allow children unsupervised near the treadmill and keep
the safety key in a safe place away from children.
Wear proper exercise footwear when using the treadmill. Do not use the treadmill in bare feet or in socks. It is normal for
the treadmill belt to discharge soil or rocks that are on the sole of your shoes. It is always good practice to clean the soles
of your shoes before using the treadmill.
Never use the treadmill with more than one person on the belt.
Never try accelerate or decelerate the speed of the running belt by pushing on or trying to stop it, with power or not.
Always face towards the computer display and do not run backwards on the belt.
The treadmill should not be boxed in with other furniture or obstacles. Keep the rear and side of the treadmill clear of any
obstructions.
3
IImmppoottaannttSSaaffeettyyNNoottiiccee
Important Safety Notice

Electrical Information
CAUTION – This equipment is intended to be electrically grounded. The three-wire grounding plug (polarized) will fit
only a grounded AC outlet. Do not use an extension cord or outlet if it does not accept three-wire grounding plugs.
Contact a licensed electrician to replace the outlet with a properly grounded outlet.
WARNING – To prevent the risk of fire or electrical shock, do not expose this machine to rain or moisture. Do not place
machine outdoors. Do not place machine near swimming pools, sauna rooms or high humidity environments. Refer
servicing to qualified Bodyguard®Service personnel only.
MISE EN GARDE – Cet appareil est conçu pour une installation électrique avec fil de terre. La fiche à trois fils ne s’adaptera
qu’à une prise C.A. avec fil de terre. L’appareil ne doit pas être branché à un fil de rallonge ou une prise de courant qui
n’accepte pas les fiches à trois fils. Faites appel à un électricien qualifié pour le remplacement de la prise de courant par une
prise avec fil de terre.
ATTENTION – Afin de prévenir les risques d’incendie ou de chocs électriques, l’appareil ne doit pas être exposé à la pluie ou
à l’humidité. En confier l’entretien à une personne qualifiée de Bodyguard®uniquement.
If you have any questions about the assembly, proper use or repair of your treadmill, please call your local Bodyguard®
Dealer. All necessary adjustments or repairs during the warranty period must be made by an Authorized Bodyguard®
Dealer.
IMPORTANT NOTICE : This treadmill should be connected in a dedicated circuit in order to avoid functional problems.
NOTICE IMPORTANTE : Cet appareil est conçu pour être branché dans un circuit dédié pour éviter des problèmes
fonctionnels.
Should you need more information, you can call our Customer Service Department at:
1-418-228-8934
Know Your Heart Rate
4
To determine your recommended heart rate level, select the type of exercise
program you wish to follow. Your MAXIMUM HEART RATE (MHR)
is calculated as follows:
MHR = 220 – Age
It is not recommended to exercise above 90% of your MHR.
Exercise in 70-80% MHR area for an aerobic exercise.
Exercise in 60-70% MHR area for a moderate, healthy heart zone.
Exercise in 50-60% MHR area if you wish to train in a fat burning zone.
Difficult to achieve exercise benefit below 50% MHR.
20 30 40 50 60 70 80
Your Age
200
180
160
140
120
100
80
60
Your Heart Rate (beats/minute)

BODYGUARD®FITNESS
T240 – T260 Limited Warranty
Bodyguard®Fitness warrants that product is in good working order and free of manufacturing defects in workmanship and
materials.
The T240 – T260 are warranted for a period of :
• Lifetime on main frame and motor
• 10 years on parts
• 3 years on belt/deck/rollers (wear)
• 3 years on labor
In a residential (home) application only.
This warranty is non-transferable and applies to the original owner of the unit only.
Responsibility of the User
The following items are not included in the Warranty since they are not considered manufacturing defects.
1. Damage resulting from any accidental use, disaster, misuse and abuse.
2. Service and parts required due to improper fusing or wiring.
3. Service and parts required as a result of improper servicing or from an unauthorized dealer.
4. Service and parts required as a result of flood, fire, vandalism or acts of Gods.
5. Labor to correct installation of the unit or instructing owners on how to use and install the unit.
6. Wear items such as handle bar foam coverings, drive belts and paint finish corrosion or discoloration resulting from
improper cleaning of the unit.
7. Do not put any lubricant product of any type (except the Bodyguard®Fitness lubricant) on the running belt. Using a
lubricant not approved by Bodyguard®will void the belt/deck warranty.
This Warranty is in addition to any statutory warranty. This Warranty supersedes all other written or expressed warranties.
In the event your T240 – T260 treadmill should require service, you must contact the Authorized Bodyguard®Dealer where
you purchased your machine or the nearest Authorized Bodyguard®Dealer.
5
WWaarrrraannttyyIInnffoorrmmaattiioonn
Warranty Information

Each T240 –T260 treadmill contains a L.E.D. (light emitting diode) computer display monitor. The control functions, unique
programs and features have been designed with you in mind, to offer the best possible exercise by displaying important and
clear information regarding your excercise progress.
Please familiarize yourself with the functions of the computer display monitor and each program to allow you to have the
best possible exercise.
The T240-T260 comes with a magnetic security key. The key’s magnet must be inserted in the appropriate slot in the
console for the treadmill to be functional. For security purposes, make sure to attach the key’s clip to your clothes prior to
starting an exercise.
1.1 Getting to know the T240 – T260
Computer display Monitor
The computer display monitor consists of a main viewing screen, a central informational window and two additional
informational windows.
Each exercise program starts from the left part of the screen and terminates when it reaches the right part of the screen.
A flashing dot will indicate your progression in the program.
As the speed and elevation increase, the corresponding profile will move towards the top of the viewing screen. At the top
of the screen, a scrolling message center displays all your exercise parameters from the start of the program.
The two informational windows will display SPEED, DISTANCE, CALORIES, ELAPSED TIME, PACE and ELEVATION.
6
PAUS E
Central information window
Speed profile (bright green)
Elevation profile (light green)
Flashing dot under indicates your progress in a program.
The program starts from the left and ends at the extreme
right side
Vertical squares represent speed and elevation values. Each tick represents either
1 mph (1.6 km/h) or 1.5% elevation change. The minimum values start from
0,5 mph (0,8 km/h) and 0% elevation at the bottom,
and the maximum values end at 10 mph (16.0 km/h) and 15% elevation to the
top of the scale (12% for T240).
T240 – T260 COMPUTER DISPLAY MONITOR
Main viewing display screen of an exercise with a predetermined speed and elevation profiles.
Note that the T240 does not show the speed and elevation profiles. It shows big numbers only.
figure 6
OOppeerraattiinnggyyoouurr
TT224400––TT226600
Operating your
T240 – T260
1

7
SPEED indicates the treadmill belt speed in miles per hour or kilometers per hour, ranging from 0.50 to 10.00 mph or
0.80 to 16.00 km/h.
DISTANCE displays the total distance in miles or kilometers from the start of the exercise, ranging from 0.00 to 99.00
miles or 0.00 to 99.00 km.
CALORIES will indicate total of your caloric expenditure from the start of the exercise.
ELAPSED TIME indicates the amount of time accumulated from the start of any program. The time will range from
0 to a maximum of 99 minutes.
PACE indicates how long it will take to complete one mile or one kilometer at that current speed. Pace per mile or
kilometer is shown in minutes and seconds.
ELEVATION will display the slope of the running belt in terms of percentage. As an example, one percent (1%) slope is
equal to one foot (or one meter) climbed for each 100 feet (or 100 meters) covered. The maximum elevation is 12% on
the T240 model and 15% on the T260 model.
NOTE – The parameter like calories displays an evaluation of the real values of your exercise parameters. The evaluations
are based on formal information, tests and are supported by specialists and physicians.
Keys
During an exercise, you can change the value shown on each informational window by pressing the adjacent round select
key once. If you wish to have the information displayed in a scanning mode, simply hold down the round select key for three
seconds and release it. You can also activate any window to scan by repeating the above sequence. To remove the scan, just
press the round select key once again.
The INCREASE and DECREASE Speed keys allow you to modify the speed of the running belt during an exercise. These
keys also allow you to select the programs and parameters prior to each exercise. During any exercise program, you can
modify the speed of the belt by pressing or holding either the INCREASE or DECREASE Speed key. If you continuously
hold down a Speed key, the speed display will change by a tenth of a mile (or kilometer) per hour (0.1 mph or 0.1 km/h).
Release the Speed key when you have selected your desired exercise speed.
You notice that the treadmill belt will slowly change to your desired speed. The desired SPEED L.E.D. will be
displayed flashing on the display window on the left, while the actual belt speed slowly ramps up to your
target speed. Once the speed has been attained the SPEED L.E.D. will stop flashing.
The CLEAR/STOP key allows you to cancel a program selection or temporarily pause an exercise for any reason.
NOTE – Use the CLEAR/STOP key to stop the running belt should you encounter difficulty or need to stop quickly during an
exercise.
Scanning Feature
During an exercise you will be able to view nine scanning exercise parameters on the central informational window along
with the exercise program. The parameters that will be displayed are :
• DISTANCE is shown in miles or kilometers for the entire exercise.
• CALORIES indicates the caloric expenditure based on your actual exercise.
• PACE is shown in minutes and seconds.
• ELEVATION is shown % elevation.
• HEART RATE displays your actual heart rate if the optional chest strap is used. The display is shown in beats per
minute.

• TREM (time remaning) indicates the amount of time left once a program has started.
or DIST. REM (distance remaining) if you chose distance in your settings
or CAL. REM (calories remaining) if you chose calories in your settings.
• CAL./HOUR (calories per hour) indicates the hourly caloric expenditure based on your actual exercise.
• SPEED displays the actual speed in miles per hour or kilometers per hour.
All these parameters scroll on the central informational window.
NOTE – The T240 will not scan the following parameters: PACE, ELEVATION, TREM AND CAL/HOUR.
1.2 Pausing During an Exercise
You can pause any exercise by pressing the CLEAR/STOP key. When this key is pressed during an exercise, the motor will stop
and the running belt will slow down to 0 mph (0 km/h) within a few seconds. The stop is gradual, allowing the user to come
safely to a complete stop. The elevation will remain at the level just prior to the pause.
To pause an exercise:
1. Press the CLEAR/STOP key whenever you feel the need to stop the exercise or if you need to momentarily pause the
exercise. A message will appear on the screen indicating the amount of time remaining in the pause. The pause
countdown will only start once the running belt has come to a complete stop.
2. If you wish to continue the exercise, simply press the JustGo®/ENTER key to start the running belt.
3. If you wish to cancel the exercise during the pause, simply press the CLEAR/STOP key. The exercise will be terminated and
a summary of your exercise parameters plus the option to save the exercise will be displayed. If your pause is over the
duration of the pause time, the exercise will terminate automatically.
1.3 Saving an Exercise (custom programs)
Once any program has finished or is prematurely terminated, the user has the option to save 15 elevations and speed
levels and recall it at a later date. This feature is very useful when a particular exercise is interesting and motivational. With
the T240 – T260, you have the ability to create or modify an existing program and save it with the ability to recall it
including the heart rate control program. The T240–T260 has the unique feature of saving a heart rate control program and
being able to recall this exercise and do it without the chest strap.
Saving an exercise program allows the computer to store 15 speed and elevation changes made during your exercise. The
speed and elevation levels saved are the ones before it moves to the next segment. With the T240–T260, you have the ability
to create or modify an existing program (personalize) and save it with the ability to recall it.
When any program has finished or is prematurely terminated, the exercise parameters will first appear and then a menu will
be displayed in which you have the option to save the exercise. The option will be displayed as “TO SAVE THIS EXERCISE
PRESS ENTER IF NOT PRESS STOP”.
If you wish to save the exercise at the end of program: (The T240 treadmill has two custom program slots and the T260 has
four.)
1. Press the JustGo®/ENTER key while your parameters are scrolling.
2. The T240 – T260 will indicate to you under which CUSTOM number it has been saved.
NOTE – If the memory is full press the INCREASE or DECREASE keys to select the CUSTOM program you would like to
overwrite. Press the JustGo®/ENTER key to accept.
If you do not wish to save the exercise, press the CLEAR/STOP key to return to the welcome screen.
8

SSeettttiinnggUUpptthheeCCoommppuutteerr
ttooYYoouurrEEnnvviirroonnmmeenntt
1.4 Viewing Exercise Parameters
At the end of each exercise program, the computer will display four exercise parameters. These parameters will be TOTAL
DISTANCE, CALORIES BURNED, TOTAL EXERCISE TIME, and AVERAGE SPEED.
• TOTAL DISTANCE displays the distance travelled for the entire exercise.
• CALORIES BURNED displays the approximated caloric expenditure for the entire exercise.
• TOTAL EXERCISE TIME displays the length of the exercise in minutes and seconds.
• AVERAGE SPEED displays the average speed value for the entire exercise.
The total exercise parameters on the T240 – T260 will loop for 2 minutes, showing your exercise parameters until you press
CLEAR/STOP to exit back to the welcome screen. If you do not wish to view the exercise parameters, press the CLEAR/STOP
key to return to the welcome screen.
The T240 – T260 treadmills offer unique features that allow the user to tailor the treadmill to its current environment.
The treadmill computer can also display a series of diagnostic features and calibration features.
T240 – T260 treadmills allow you to select and modify the following settings :
• Language (English, French, Spanish)
• Weight Unit (Pounds or Kilograms)
• User ID
• Distance Unit (Miles or Kilometers)
• Time, Distance or Calories
• Warm Up (On or Off)
• Cool Down (On or Off)
2.1 Access to ”Settings Menu”
To view the above settings, you must enter into the “SETTINGS MENU” as followed:
1. Turn power ON.
2. While the introduction screens are displayed, simultaneously hold down the elevation INCREASE and the SELECT TOP
keys.
3. Release the ELEVATION INCREASE and the SELECT TOP keys once entered into the Settings menu.
2.2 Language Feature
You can display all the instructions and information on the computer display screen in a choice of three languages.
To select a language: Enter into the Settings menu, see Section 2.1.
1. Select the LANGUAGE option, and press the JustGo®/ENTER key to accept.
2. Select the language you wish to be displayed on the screen. Choose from English, French and Spanish. Press the INCREASE
or DECREASE keys to select the language.
3. Press the JustGo®/ENTER key to accept.
From now on, all text will be displayed in the language you selected.
9
Setting Up the Computer
to Your Environment
2
• Heart Rate Control Options
• Heart Rate Access Options
• Beeper
(On or Off)
• Speed Limits
• Big Number Option
• Learn Program (T260 only)
• Heart Rate Recovery (T260 only)

2.3 Weight Unit Feature
The weight unit can be selected to display in pounds or kilograms.
To select a weight unit: Enter into the Settings menu, see Section 2.1.
1. Select the WEIGHT UNIT option, and press the JustGo®/ENTER key to accept.
2. Select the weight unit you wish to be displayed on the screen. Choose from POUNDS or KILOGRAMS. Press the INCREASE
or DECREASE keys to select.
3. Press the JustGo®/ENTER key to accept.
From now on, weight values entered will be in the selected units.
2.4 User Identification Feature
The User Identification feature allows the treadmill to recognize individuals and automatically enter their weight along with
additional information. The T240 will recognize two and the T260 will recognize four.
Whenever the User Identification feature is used, the weight will be automatically entered at each exercise program.
Therefore, user weight will not be asked during the program set up. Also, the user’s age will be automatically entered during
the Heart Rate Control program to calculate the maximum heart rate.
The User ID feature gives access to the following options:
• ACTIVATE USER ID
• CREATE USER ID
• VIEW STATISTICS
• EDIT USER ID
• RESET STATISTICS
• DELETE USER ID
Activate User
To activate the User Identification feature: Enter into the Settings menu, see Section 2.1.
1. Select the USER ID option and press the JustGo®/ENTER key to accept.
2. Select the ACTIVATE USER ID option and press JustGo®/ENTER key to accept.
3. Press INCREASE or DECREASE key to choose ON or OFF to activate or deactivate it and then press the JustGo®/ENTER key
to accept.
Now that the User ID feature is activated; you will be prompted, at the beginning of each program, to select a User
Identification.
Create User
To create a User ID’s:
1. Enter into the Settings menu, see Section 2.1.
2. Select the USER ID option and press the JustGo®/ENTER key to accept.
3. Select the CREATE USER option and press JustGo®/ENTER key to accept.
4. You will immediately be sent to the lowest empty location, if the MEMORY is full you will have to go to the DELETE USER
option.
5. A total of six alpha-numeric characters can be used to name the USER ID. Use the INCREASE or DECREASE keys to select
any letter from A to Z or number from 0 to 9 as the first character. If you wish to leave a space between characters, simply
10

select SPACE (blank character) between the 9 and the A characters. Press the JustGo®/ENTER key to accept this character.
Now the second character must be selected. Repeat this procedure until you have selected a USER ID name.
If you wish to modify a character before all six spaces are accepted, press the CLEAR/STOP key to backspace.
6. Now you have to enter your age. Simply use the INCREASE or DECREASE key to select your age. Press the JustGo®/
ENTER key to accept your age.
7. Enter your weight, press the INCREASE or DECREASE key to select your weight from 50 to 400 pounds (23 to
182 kilograms) and then press the JustGo®/ENTER key to accept it.
8. Then press the CLEAR/STOP key to go back to the USER ID main menu.
Edit User
To edit the different User ID’s: Select the USER ID option and press the JustGo®/ENTER key to accept.
1. Select the user you want to edit by using the INCREASE or DECREASE key and press the JustGo®/ENTER key to accept it.
2. Enter your weight, press the INCREASE or DECREASE key to select your weight from 50 to 400 pounds (23 to 182 kg) and
then press the JustGo®/ENTER key to accept it.
3. Now you have to enter your age. Simply use the INCREASE or DECREASE key to select your age. Press the JustGo®/ENTER
key to accept your age.
4. Press the CLEAR/STOP key to go back to the USER ID main menu.
View Statistics
To view the statistics of a User Identification: Select the VIEW STATISTICS option and press JustGo®/ENTER key to accept.
Select the User Identification for which you wish to see the statistics. These parameters represent the accumulated values
of all the exercises of a user while the User Identification feature was activated.
• TOTAL DISTANCE displays the distance traveled in miles (or in kilometers depending on your settings).
• TOTAL CALORIES displays the accumulated calories expended.
• TOTAL TIME displays the total exercise time.
Reset Statistics
To reset the statistics of a User Identification: Select the RESET STATISTICS option and press JustGo®/ENTER key to accept.
Select the User Identification for which you wish to reset the statistics. Press the JustGo®/ENTER key to reset the statistics of
this User Identification.
If you do not wish to reset the statistics of this User Identification, press the CLEAR/STOP key. The Reset Statistics feature can
help to monitor your progress week after week or between seasons.
Delete User
To delete a User Identification: Select the DELETE USER option and press JustGo®/ENTER key to accept.
Select the User Identification you wish to delete. Press the JustGo®/ENTER key to delete this User Identification.
If you do not wish to delete this User Identification, press the CLEAR/STOP key.
NOTE – If you choose to delete a user, you will clear all saved parameters under that user’s name.
11

12
2.5 Distance Unit Feature
The distance unit can be selected to display in miles or kilometers.
To select a distance unit: Enter into the Settings menu, see Section 2.1.
1. Select the DISTANCE UNIT option, and press the JustGo®/ENTER key to accept.
2. Select the distance unit you wish to be displayed on the screen. Choose from MILES or KILOMETERS. Press the INCREASE
or DECREASE keys to select the distance unit.
3. Press the JustGo®/ENTER key to accept.
From now on, distance and speed values entered will be in the selected units.
2.6 Time, Distance or Calories Feature
The TIME, DISTANCE or CALORIES feature allows you to select either time, distance or calories as your exercise target.
To access TIME, DISTANCE or CALORIES: Enter into the Settings menu, see Section 2.1.
1. Select the TIME, DISTANCE or CALORIES menu with the INCREASE or DECREASE keys and press the JustGo®/ENTER key to
enter it.
2. Make your choice between time, distance or calories with the INCREASE or DECREASE keys and press the JustGo®/ENTER
key to accept it.
From now on, the new value of your exercise will be in the selected value.
Table of minimum and maximum values
Here’s a table of the minimum and the maximum values that you can choose as a duration depending on your Settings
choice.
TIME DISTANCE CALORIES
MIN 5 minutes 1 mile or 1 km 25 calories
MAX 99 minutes 99 miles or 99 km 2000 calories
2.7 Warm Up and Cool Down Feature
Doing a warm up period before an exercise and a cool down period after an exercise is strongly recommended for your
safety. In your T240-T260, you have a feature that will allow you to warm up and cool down on your treadmill.
If the warm up or cool down option is activated, a warm up screen will be displayed prior to each exercise as well as a cool
down screen after each exercise. Be aware that the warm up and cool down screens are not available for the JustGo®
program in which you need to establish your own warm up and cool down periods.
The warm up has an adjustable duration of one to four minutes and that period is divided in 3 parts.
Warm up:
Part 1: Is 40% in intensity of the first segment exercise.
Part 2: Is 60% in intensity of the first segment exercise.
Part 3: Is 80% in intensity of the first segment exercise.

The cool down has an adjustable duration of one to four minutes and has only one part.
Cool down:
Part 1: Is a half in intensity of the last segment exercise with a maximum of 3.5 mph (5.6 km/h).
The calories, time and the distance are not accumulated in the “WARM UP OR COOL DOWN” modes.
The warm up or cool down option can be activated or deactivated separately.
To activate or deactivate the warm up or cool down option: Enter into the Settings menu, See Section 2.1.
1. Select the WARM UP OR COOL DOWN option, and press the JustGoTM/ENTER key to accept.
2. Choose from ON or OFF. Press the speed INCREASE or DECREASE to choose and press the JustGo®/ENTER key to accept.
3. To adjust the duration of the warm up or cool down, use the speed keys.
From now on, the warm up or cool down option will be in the selected mode.
NOTE – If you wish to cancel the warm up or cool down while you perform it, simply press the CLEAR/STOP key to interrupt
the feature.
2.8 Heart Rate Control Options Feature
The heart rate control feature lets you choose from three different operating modes. The first mode is “SPEED AND
ELEVATION MODE”. In this mode, the machine will bring you to your target heart rate by doing changes in speed and
elevation, but you can make your own changes at anytime. The second mode is “SPEED MODE”. In this mode, the machine
will bring you to your target heart rate by changing the speed but it will let you do any change manually at any time. The
computer will adjust the speed to keep you in your target heart rate. The third mode is “ELEVATION MODE”. In this mode,
the machine will bring you to your target heart rate by changing the elevation but it will let you do any change manually at
any time. The computer will adjust the elevation to keep you in your target heart rate. Note that the default mode is
“SPEED AND ELEVATION MODE”.
NOTE – The T240 has only one mode and it is speed only.
To select the mode you want to choose: Enter into the Settings menu, see Section 2.1.
1. Select HEART RATE CONTROL option and press the JustGo®/ENTER key to accept.
2. Press the INCREASE or DECREASE keys to select the mode you want to choose and press the JustGo®/ENTER key to accept.
The computer will indicate you the mode you just chosen and will be active from that moment.
2.9 Heart Rate Access Options Feature
The Heart Rate Access Options feature lets you choose from two different operating modes. The first mode is “SPEED
MODE”. In this mode, the machine will bring you to your target heart rate by changing the speed but it will let you do any
change manually at any time. The computer will adjust the speed to keep you in your target heart rate. The second mode is
“ELEVATION MODE”. In this mode, the machine will bring you to your target heart rate by changing the elevation but it will
let you do any change manually at any time. The computer will adjust the elevation to keep you in your target heart rate.
Note that the default mode is “SPEED MODE”.
NOTE – The T240 has only one mode and it is speed only.
To select the mode you want to choose: Enter into the Settings menu, see Section 2.1.
1. Select HEART RATE ACCESS OPTIONS and press the JustGo®/ENTER key to accept.
2. Press the INCREASE or DECREASE keys to select the mode you want to choose and press the JustGo®/ENTER key to
accept. The computer will indicate you the mode you have just chosen and will be active from that moment.
13

2.10 Beeper Feature
The beeper can be activated or deactivated.
To activate or deactivate the beeper:
1. Enter into the Settings menu, see Section 2.1.
2. Select the BEEPER option, and press the JustGo®/ENTER key to accept.
3. Select the mode in which you wish the beeper to be. Choose ON or OFF with the SPEED keys and press JustGo®/ENTER
to accept.
From now on, the beeper will be in the selected mode.
2.11 Speed Limits
The MINIMUM and MAXIMUM speeds can be set into the treadmill.
To select this option: Enter into the Settings menu, see Section 2.1.
1. Select the SPEED LIMITS option, and press the JustGo/ENTER key
to accept.
2. Select the MINIMUM OR MAXIMUM value with the ELEVATION INCREASE AND ELEVATION DECREASE keys. To modify
the value, use the SPEED INCREASE OR DECREASE keys. Press the JustGo/Enter key to accept (the values will not be
considered if you don’t press the ENTER key to accept).
Please refer to the following values to know the possible range of values.
2.12 Big Number Option
The big number option can be to selected to display on the main screen a choice of 7 options.
To select a big number option: Enter into the Setting menu, see section 2.1.
1. Select the BIG NUMBER OPTION, and press the JustGo/ENTER key to accept.
2. Select the option you wish to be displayed on the screen. Choose from, NONE, All, Speed, Distance, Calories, Time or
Heart Rate. Press the INCREASE or DECREASE key to select the option.
3. Press the JustGo®/ENTER key to accept.
From now on, all the information will be displayed on screen as the option you selected.
NOTE – The T240 does not allow to choose NONE since it will never display the speed or elevation profiles.
2.13 Learn Program (T260)
Bodyguard machines have the incredible ability to learn (pre-program) profiles. This is especially useful if you would like to
build a workout profile in advance. You now have the ability to build a program without actually doing it. This is great if
you are customizing a program for a client for example.
To use learn program: Enter into the Settings menu, see section 2.1.
1. You will be prompted to a screen that will ask you to increase or decrease either Speed and Elevation.
Adjust both parameters and see on the side select windows where you are going.
2. Once you are satisfied press ENTER to lock it and move to the next SEGMENT.
3. Repeat this procedure until the whole profile has been filled in.
- You can learn 4 programs in the T260. This option is not available in the T240.
- To use a LEARN program, choose LEARN from the program selection window.
14
Minimum: 0.5 MPH(0.8 KM/H)
Maximum: 10 MPH (16.0 KM/H)
Default: 0.5 to 10 MPH(0.8 to 16 KM/H)

2.14 Heart Rate Recovery (T260 only)
Your T260 is pre programmed with a unique and useful program that is used to help determine your fitness level. After a
program (workout) the T260 can be used to countdown towards your predetermined resting heart rate.
In order to use this program you will need to turn ON Heart Rate Recovery in the settings menu. Default this option is turned
off. You would need to enter in you resting heart rate.
Fit Levels
Although it is difficult to assess each individual based on a generic chart. It is agreed that a quicker time from an exercise
level heart rate to a resting (predetermined) heart rate is beneficial to cardio fitness. The best way to use this program is to
use it today.
Using Recovery
It will only work while using the optional chest strap. After your exercise is complete, stay on the machine with your chest
strap facing the console. Try not to move. It is best to keep your arms to your side as to not interfere with the signal. Stay
in this position until the computer has finished reading the heart rate signal. Depending on your fitness level this could be
a few minutes or longer.
NOTE – Using Heart Rate Recovery with Cool/Down. Note that the Heart Rate Recovery will start counting only after the
Cool/Down has ended. If you are using Warm/Up and Cool/Down your Heart Rate Recovery will only start at the end. In order
to benefit from Heart Rate Recovery we receommend that Cool/Down not be activated.
• Five Program Levels • One Heart Rate Control Program
• One JustGo® Program • One Weight Loss Program
• One Manual Program • One Cardiovascular Program
• One Hill Climb Program (T260 only) • Four Memory Programs for T260 / Two for T240
• One Speed Run Program (T260 only) • One Walk Program
• One Track Program (T260 only) • Heart Rate Access Feature
• Four Learn Programs for T260
A program is a pre-set hill pattern. You will get the same profile (hills and valleys) every time you select the same specific
exercise program. By increasing the levels you can change the predetermined hill profiles. The programs allow you to
monitor your progress and they add fun and interest to your exercise.
Each segment time is equal to the selected exercise time divided by 15 segments. Therefore, a 45 minute exercise results in
a 3 minute segment time.
NOTE – The T240 will never show the speed and elevation profiles since it displays only big numbers.
Program Levels
The Speed Run and Hill Climb programs have 5 individual exercise levels. LEVEL 1 is the easiest and LEVEL 5 is the most
difficult. This feature allows you to alter the intensity of your workout. Levels can be changed at anytime during your
workout by pressing the Elevation or Speed INCREASE and DECREASE keys.
15
TT224400––TT226600
EExxeerrcciisseePPrrooggrraammss
T240 – T260
Exercise Programs
3
WARNING
BEFORE SELECTING ANY EXERCISE PROGRAM, FIRST STRADDLE YOUR FEET
ON THE FOOT RESTS. NEVER START ANY EXERCISE PROGRAM
WITH ONE OR BOTH FEET ON THE RUNNING BELT.

JustGo®Program
The JustGo®program allows you to start a manual exercise with the push of one key. Since the JustGo®program is the initial
program, it will always be displayed first for easy selection. You have total control of the speed and elevation of the belt at
all times during this program. Use the JustGo®program if you like to walk or run at fairly constant speeds with little or no
changes during the exercise.
During the exercise, the speed and elevation that you select will remain for the entire exercise until the next change you
make. Your progression in the exercise is shown by one flashing dot.
To start exercising in the JustGo®program:
1. Press the JustGo®/ENTER key when the JustGo®program is displayed on the screen. The running belt will slowly start at
0.5 mph or 0.8 km/h and at 0% elevation with the exercise duration automatically set to the maximum.
The JustGo®program does not allow the user to predetermine the exercise duration or enter a weight amount.
Therefore, the caloric expenditure and calories per hour values will be based on a user of 150 pounds or 68 kilograms.
The calorie values should therefore be used only as references when in the JustGo®program.
2. Change the speed and elevation at all times by pressing the respective Speed and Elevation INCREASE and DECREASE keys.
3. You can pause, resume, end the program and save the program at anytime. It is not necessary to exercise the full
duration to save the program.
Manual Program
The Manual program allows you to create your own exercise as you progress in the program. The speed and elevation are
completely controlled by the user at all times. At a glance, the JustGo®and Manual programs seem very similar due to the
fact that the user controls both the speed and elevation at all times. The difference is that in the Manual program, you can
select your exercise duration and weight for a more accurate display of the calories.
During the exercise, the speed and elevation that you select will remain for the entire exercise until the next change you
make. Your progression in the exercise is shown by one flashing dot.
Hill Climb Program (T260 only)
The Hill Climb program provides both a programmed hill and speed profiles. The programmed hill profile will cause the
running belt to elevate and descend at various points during your exercise. The programmed speed profile will cause the
speed to change. You can change the speed and elevation during the exercise if you find it too easy or hard.
The speed and elevation will change as you progress into the program. Changing the speed manually will cause only that
segment to change. Changing the elevation manually will cause the entire elevation profile to change.
The following table shows the different elevations for each level.
Level Elevation %
1 0 to 3
2 1 to 4
3 2 to 6
4 3 to 7.5
5 4 to 10
16
PAUS E
figure 7

Speed Run Program (T260 only)
The Speed Run like the Hill Climb controls a certain parameter. Speed Run is speed changes. Selecting a higher level will
default a higher speed profile. Elevation changes are user controlled.
The speed will change as you progress into the program. Changing the speed or elevation manually will cause the rest of
the program to change.
To select the Speed Run program:
1. Press the DECREASE key to select Speed RUN. Press the JustGo®/ENTER key to accept the Speed Run program.
2. Select your weight. Press the speed INCREASE or DECREASE keys to select the appropriate weight. The weight will vary
from 50 to 400 pounds (23 to 182 kilograms). Press the JustGo®/ENTER key to accept.
3. Select the exercise duration. Press the speed INCREASE or DECREASE keys to select the appropriate exercise duration. Press
the JustGo®/ENTER key to accept.
4. Select the exercise level by pressing the speed INCREASE or DECREASE keys. The higher the level, the greater the speed
will be during the program. The speed changes that are made during each level are shown on Figure 17. Press the
JustGo®/ENTER key to accept and start the exercise.
Level Speed (mph) Speed (km/h)
1 1 to 4 1.6 to 6.4
2 1 to 5 1.6 to 8.1
3 2 to 6 3.2 to 9.7
4 3 to 7 4.8 to 11.3
5 4 to 8 6.4 to 12.9
Track Program (T260 only)
The Track program is one that enables you to choose from
1-99 laps of a 400 Meter (or about a 1/4 mile) Olympic track.
Each Track program allows the user to completely control their
speed from the start of the exercise until the end since there is
no automatic speed control during the Track program.
The Track program will display an oval track screen that will
show your progression on the track. The central information
window will show you how many laps have been done in your
workout. Elevation although not usually found on any track
can be used on the T240 – T260.
To select the Track program :
1. Press the DECREASE key to select TRACK. Press the JustGo®/ ENTER key to accept the Track program.
2. Select your weight. Press the speed INCREASE or DECREASE keys to select the appropriate weight. The weight will
vary from 50 to 400 pounds (23 to 182 kilograms). Press the JustGo®/ ENTER key to accept.
3. Select the number of laps. Press the speed INCREASE or DECREASE keys to select the appropriate number of laps.
Press the JustGo®/ ENTER key to accept.
4. To commence the exercise, press the JustGo®/ENTER key. A three second countdown will appear on the screen before
the running belt starts moving. Remember, that at the start of this exercise, the speed will always start at 0.5 mph
(0.8 km/h). You must press the Speed INCREASE or DECREASE keys if you wish to change the speed during the exercise.
17
PAUSE
figure 8

Heart Rate Control Program (HRC) and Weight Loss Program
The Heart Rate Control and Weight Loss Program allows you to exercise at a predetermined heart rate level. By selecting the
desired heart rate level (Weight Loss in Weight Loss program), the running belt and elevation will automatically adjust to
decrease or increase the exercise intensity.
By selecting your age, plus the intensity level that you want to work your heart at (Only HRC), a target heart rate level is
calculated by the computer.
NOTE – This program can only be used with the optional heart rate chest strap available from your Authorized Bodyguard®
Dealer. Use of the heart rate chest strap will allow the treadmill belt to change speed along with a change in elevation. To
achieve optimal results, it is recommended to place the chest strap directly over the skin. The strap should be very snug since
any significant amount of shock or impact due to fast running may temporarily produce wrong heart rate signals. You should
not be more than arm’s length from the front handle bar to achieve the best signal. If at anytime the heart rate receiver does
not detect a signal from the chest strap for more that a few seconds, the following message will appear ‘‘UNSTABLE HR
SIGNAL PLEASE CHECK CHEST STRAP’’.
WARNING – Before attempting to use any of this equipment, you should read the instruction manual carefully. Use of
this equipment by persons with heart or other medical problems may result in serious injury. You should consult with a
physician prior to using this equipment. It is recommended to periodically consult your physician as you continue to use this
equipment. Immediately cease exercise if you feel dizzy, faint or short of breath. Use of this equipment in a manner other
than as prescribed by these instructions herewith may result in serious injury.
To select the Heart Rate Control program or Weight Loss program:
1. Press the Speed DECREASE key to select HEART RATE or WEIGHT LOSS. Press the JustoGo®/Enter key to accept the
Heart Rate Control program or Weight Loss program.
2. Select the exercise duration. Press the Speed INCREASE or DECREASE keys to select the appropriate exercise duration.
Press the JustGo®/ENTER key to accept.
3. Select your weight. Press the Speed INCREASE or DECREASE keys to select the appropriate weight. The weight will
vary from 50 to 400 pounds (23 to 182 kilograms). Press the JustGo®/ENTER key to accept.
4. Select your age to allow the computer to indicate your maximum allowable heart rate level. Press the Speed INCREASE
or DECREASE keys to select your age. The age will vary from 10 to 100 years. Press the JustGo®/ENTER key to accept.
5. Select an exercise intensity based on your preferred level of exercise. The 60% level is a good guide for those interested
in training in the fat loss range. The 70% level is suitable for those interested in training in the cardiovascular range. The
80% level requires the most effort and is suitable for persons with a higher level of fitness. Press the JustGo®/ENTER key
to accept the intensity (60% is a default in Weight Loss Program).
6. You can modify the heart rate level suggested by the computer or press the JustGo®/ENTER key to accept it and start the
exercise.
7. To start the exercise, press the JustGo®/ENTER key.
During the Heart Rate Control or Weight Loss program, you can change the speed or elevation by pressing the Speed or
Elevation INCREASE or DECREASE keys. Keep in mind that the computer will then gradually readjust the speed and/or
elevation to compensate for the change in speed or elevation you made by gradually bringing your ACTUAL heart rate near
the TARGET heart rate level.
WARNING – If you feel that the running belt is moving too fast for your fitness level and you cannot keep up, press the
CLEAR/STOP key and terminate the exercise program. You can try the program again, but at a lower INTENSITY level
(60%). If this is still too fast for you, do not use the Heart Rate Control program until your fitness level allows you to
safely exercise at your TARGET heart rate level.
18

During the exercise, the main computer screen will show a speed or elevation profile like the other programs, but will display
your ACTUAL heart rate and your TARGET heart rate on the message center. Once the exercise has started, your ACTUAL
heart rate should be lower than the TARGET heart rate. The computer then will gradually regulate the speed and elevation
simultaneously to increase your exercise intensity level, resulting in a higher ACTUAL heart rate.
Your heart rate will be displayed on the message center as ACTUAL heart rate and TARGET heart rate (T). For example:
HRATE 110/115T.
NOTE – You can change your target heart rate while in the program by pressing the JustGo®/ENTER key and modify it by
using the Speed DECREASE or INCREASE keys and by pressing the JustGo®/ENTER key to accept it.
Cardiovascular Program
The Cardiovascular program has been designed to allow you to train at moderate intensity levels with short duration,
high intensity periods followed by a quick recovery period. The Cardiovascular program has predetermined speed and
elevation profiles according to the selected exercise levels. You can change the speed and elevation during the exercise if
you find it too easy or hard.
The speed profile has a set of high intensity segments to greater work your heart muscles. Changing the speed manually will
cause only that segment to change. Changing the elevation manually will cause the entire profile to change.
The following table shows the different speeds and elevation for each level.
Level Speed (mph) Speed (km/h) Elevation (%)
1 1.0 to 4 1.6 to 6.4 0.0 to 2.0
2 3.0 to 6 4.0 to 9.6 0.0 to 3.0
3 4.0 to 7 8.0 to 11.2 0.0 to 4.0
4 5.0 to 8 8.0 to 12.9 0.0 to 5.0
5 6.0 to 9 9.7 to 14.5 0.0 to 6.0
Memory & Learn Programs
These programs allow you to recall previously completed or edited exercises. After each exercise has finished, you are
prompted if you wish to save the current exercise or not. All programs, except the Track Program can be saved as Memory
Programs. The Learn Programs are the ones that were previously edited in the Settings menu under Learn Programs.
To select an exercise:
Press the Speed DECREASE key to select Memory or Learn Programs. Press the JustGo®/ENTER key to accept the program.
An edited program will appear on the screen. You can select a particular saved or edited exercise by pressing the Speed
INCREASE and DECREASE keys until the desired name is displayed.
NOTE – By selecting a saved or a Learn Program in memory, you cannot enter an exercise level.
Select the exercise duration. Press the Speed INCREASE or DECREASE keys to select the appropriate exercise duration.
Press the JustGo®/ENTER key to accept.
Select your weight. Press the Speed INCREASE or DECREASE keys to select the appropriate weight. The weight will vary from
50 to 400 pounds (23 to 182 kilograms). Press the JustGo®/ENTER key to accept and start the exercise.
Walk Program
The Walk program allows you to create your own exercise as you progress in the program. The speed and elevation are
completely controlled by the user at all times. At a glance, Manual and Walk programs seem very similar due to the fact that
the user controls both the speed and elevation at all times. The difference is that in the Walk program, you can’t go over
4.0 MPH (6.4 KM/H) and 6% of elevation.
During the exercise, the speed and elevation that you select will remain for the entire exercise until the next change you
make. Your progression in the exercise is shown by the flashing dot.
19

Heart Rate Access Feature
The Heart Rate Access feature allows you to selectively enter into a Heart Rate Control program without quitting your
exercise. It will allow you to choose, when you are ready, to change your current workout to a Heart Rate Control. You will
need to be wearing the optional wireless chest strap when choosing to use this feature.
The Heart Rate Access feature allows the user to change any program at any time during the selected workout to Heart Rate
Control. On screen, you will see the program remaining change to a flat-line as it would look like in a normal Heart Rate
Control program. The part of the program that you just did though would remain unchanged.
How to Use Heart Rate Access™
While in a program you would press the JustGo®/ENTER key. On screen you would see the message “Heart Rate Control
Activated” followed by a screen showing your target Heart Rate. Once your Heart Rate has been confirmed, the remainder
of the selected workout time would be in the form of a normal Heart Rate Control. If you pressed the button and were not
wearing a chest strap, the unit will disregard the button push and continue in the normal selected program.
1. JustGo®, Manual, Walk and Cardiovascular programs
• These programs would change SPEED only or ELEVATION only, depending on your selected SETTINGS in
Heart Rate Access options.
NOTE – On the T240, it will make speed changes only.
2. Speed Run and Track programs
• These programs will make SPEED changes only.
3. Hill Climb program
• This program will make ELEVATION changes only.
4. Memory programs
•These programs will make changes according to the type of changes that were done in the program
that has been recalled from memory. For example, if you did a Speed Run program and you press the
JustGo®/ENTER key, you would get SPEED changes only.
NOTE – On the T240, il will make speed changes only.
5. Override
• In all programs, you can make SPEED and ELEVATION changes manually.
6. Saving
• You will also be able to save any program at the end except the TRACK program.
7. Profile
• You will also be able to see the profile and where the unit made a change to Heart Rate Access.
NOTE – This is not available on the T240.
Changing Your Target Heart Rate in a Program
The normal Heart Rate Control program allows you to make Target Heart Rate changes at anytime while in a program by
pressing the JustGo®/ENTER key. The difference is now that by pressing the JustGo®/ENTER key, it will bring you into
Heart Rate Access; by pressing the JustGo®/ENTER key again, you will be asked to make a new Target Heart Rate change.
20
