BONFIGLIOLI Active ACT 201-05 Reference guide

www.bonfiglioli.com
Bonfiglioli Riduttori S.p.A.
Via Giovanni XXIII, 7/A
40012 Lippo di Calderara di Reno
Bologna, Italy
tel: [phone]
fax: [phone]
bonfiglioli@bonfiglioli.com
www.bonfiglioli.com
VEC 210 R1
ACTIVE
Brief manual
Frequency Inverter 230 V / 400 V
0.55 kW ... 30.0 kW
Bonfiglioli has been designing and developing innovative
and reliable power transmission and control solutions
for industry, mobile machinery and renewable energy
applications since 1956.

06/05 1
06/05 1
General Information about the Documentation
The present documentation refers to the frequency inverters ACT 201 and ACT 401
series. With their factory settings, both series of devices are suited for a wide range
of applications. The modular hardware and software structure enables customer-
specific adaptation of the frequency inverters. Applications with high functionality and
dynamism requirements can be realized easily.
In order to make it as easy as possible for the user to find his/her way through the
documentation, it is structured according to the customer-specific demands made of
the frequency inverter.
Brief Instructions
The Brief Instructions describe the basic steps required for mechanical and electrical
installation of the frequency inverter. The guided commissioning supports you in the
selection of necessary parameters and the configuration of the frequency inverter by
the software.
Operating Instructions
The Operating Instructions describe and document all functions of the frequency
inverter. The parameters required for adapting the frequency inverter to specific
applications as well as the wide range of additional functions are described in detail.
Application Manual
The Application Manual contains additional information facilitating the installation and
commissioning of the frequency inverter, i.e. information on the different issues
relating to the specific application realized by the frequency inverter.
Installation Instructions
Complementing the Brief Instructions and the Operating Instructions, the Installation
Instructions provide information on how to install and use the additional/optional
components.
If you need a copy of the documentation or additional information, contact your
representative of BONFIGLIOLI.
The following pictograms and signal words are used in the documentation:
Danger!
Danger refers to an immediate threat. Non-compliance with the precaution described
will result in death, serious injury or material damage.
Warning!
Warning refers to a possible threat. Non-compliance with the warning may result in
death, serious injury or material damage.
Caution!
Caution refers to an immediate hazard. Non-compliance may result in personal or
material damage.
Attention!
Attention and the related text refer to a possible behavior or an undesired condition
which can occur during operation.
Note
Note and the related text provide useful information which supplements the corre-
sponding part of the documentation.

06/052
2 06/05
TABLE OF CONTENTS
TABLE OF CONTENTS ............................................................................................................ 2
1 General Safety Instructions and Information on Use.................................................... 4
1.1 General Information ................................................................................................ 4
1.2 Purpose of the Frequency Inverters........................................................................ 5
1.3 Transport and Storage............................................................................................. 5
1.4 Handling and Installation ........................................................................................ 5
1.5 Electrical Connection ............................................................................................... 6
1.6 Information on Use.................................................................................................. 6
1.7 Maintenance and Service......................................................................................... 6
2Scope of Supply.............................................................................................................. 7
2.1 Frequency Inverter (0.55 to 4.0 kW)....................................................................... 7
2.2 Frequency Inverter (5.5 to 15 kW).......................................................................... 8
2.3 Frequency Inverter (18.5 to 30 kW)........................................................................ 9
3Technical Data.............................................................................................................. 10
3.1 Frequency Inverter 230 V (0.55 to 3.0 kW) .......................................................... 10
3.2 Frequency Inverter 400 V (0.55 to 4.0 kW) .......................................................... 11
3.3 Frequency Inverter 400 V (5.5 to 15.0 kW) .......................................................... 12
3.4 Frequency Inverter 400 V (18.5 up to 30 kW) ...................................................... 13
3.5 Operation diagrams ............................................................................................... 14
4Mechanical Installation................................................................................................ 15
4.1 Frequency Inverter (0.55 to 4.0 kW)..................................................................... 16
4.2 Frequency Inverter (5.5 to 15 kW)........................................................................ 17
4.3 Frequency Inverter (18.5 to 30 kW)...................................................................... 18
5Electrical Installation ................................................................................................... 19
5.1 EMC Information.................................................................................................... 20
5.2 Block diagram ........................................................................................................ 21
5.3 Mains Connection .................................................................................................. 22
5.3.1 Frequency Inverter (0.55 to 4.0 kW) ....................................................................... 22
5.3.2 Frequency Inverter (5.5 to 15.0 kW) ....................................................................... 23
5.3.3 Frequency Inverter (18.5 to 30 kW) ........................................................................ 24
5.4 Motor Connection .................................................................................................. 24
5.4.1 Frequency Inverter (0.55 to 4.0 kW) ....................................................................... 25
5.4.2 Frequency Inverter (5.5 to 15 kW) .......................................................................... 26
5.4.3 Frequency Inverter (18.5 to 30 kW) ........................................................................ 27
5.5 Connection of a Brake Resistor ............................................................................. 28
5.5.1 Frequency Inverter (0.55 to 4.0 kW) ....................................................................... 28
5.5.2 Frequency Inverter (5.5 to 15 kW) .......................................................................... 28
5.5.3 Frequency Inverter (18.5 to 30 kW) ........................................................................ 29

06/05 3
06/05 3
TABLE OF CONTENTS
5.6 Control Terminals .................................................................................................. 29
5.6.1 Relay Output ......................................................................................................... 30
5.6.2 Control Terminals – Terminal Diagram..................................................................... 31
5.6.2.1 Configuration 110 – Sensorless Control ............................................................. 31
5.6.2.2 Configuration 410 – Sensorless Field-Oriented Control........................................ 32
5.7 Optional Components ............................................................................................ 33
6Control Unit KP500 ...................................................................................................... 34
6.1 Actual Value Menu (VAL) ....................................................................................... 35
6.2 Parameter Menu (PARA)........................................................................................ 36
6.3 Controlling the Motor via the Control Unit ............................................................ 37
7 Commissioning of the Frequency Inverter................................................................... 39
7.1 Switching on Mains Voltage .................................................................................. 39
7.2 Setup Using the Control Unit ................................................................................. 39
7.2.1 Configuration ........................................................................................................ 40
7.2.2 Data Set ............................................................................................................... 40
7.2.3 Motor Type ........................................................................................................... 40
7.2.4 Machine Data ........................................................................................................ 41
7.2.5 Plausibility check ................................................................................................... 41
7.2.6 Parameter identification ......................................................................................... 43
7.2.7 Application data..................................................................................................... 45
7.2.7.1 Acceleration and deceleration........................................................................... 45
7.2.7.2 Set points at multi-functional input ................................................................... 45
7.2.8 Selection of an actual value for display .................................................................... 46
7.3 Check direction of rotation .................................................................................... 46
8Basic parameters.......................................................................................................... 47
8.1 Menu branch PARA ................................................................................................ 47
8.2 Menu branch VAL................................................................................................... 50
9 Operational and error diagnosis .................................................................................. 51
9.1 Status message...................................................................................................... 51
9.2 Warning message .................................................................................................. 51
9.3 Fault message........................................................................................................ 52

06/054
4 06/05
1General Safety Instructions and Information on Use
Warning! The specifications and instructions contained in the documentation must
be complied with strictly during installation and commissioning. Only
qualified staff who has read the documentation and, in particular, the
safety instructions carefully is allowed to carry out installation or
commissioning work or to operate the frequency inverters. The term
„Qualified Staff“ refers to anybody who is familiar with the installation,
assembly, commissioning and operation of the frequency inverter and
has the proper qualification for the job.
The present documentation was prepared with great care and it was subjected to
extensive and repeated reviews. For reasons of clarity, it was not possible to include
all details of all the different types of the product in the documentation. Neither was
it possible to consider all conceivable installation, operation or maintenance
situations. If you require further information or if you meet with specific problems
which are not dealt with in sufficient detail in the documentation, contact your local
BONFIGLIOLI agent.
We would also like to point out that the contents of this documentation do not form
part of any previous or existing agreement, assurance or legal relationship. Neither
are they intended to supplement or replace such agreements, assurances or legal
relationships. The manufacturer's obligations are exclusively specified in the relevant
purchase contract. This contract also contains all and any warranty regulations which
may apply to the relevant scope of supply. These contractual warranty provisions are
neither extended nor limited by the specifications contained in this documentation.
The manufacturer reserves the right to correct or amend the specifications, product
information and omissions in these operating instructions without notice. The
manufacturer shall not be liable for any damage, injuries or costs which may be
caused by the aforementioned reasons.
1.1 General Information
Warning! The DC-link circuit of the frequency inverter is charged during operation,
i.e. there is always the risk of contact with high voltage. Frequency
inverters are used for driving moving parts and they may become hot at
the surface during operation.
Any unauthorized removal of the necessary covers, improper use, wrong
installation or operation may result in serious injuries or material
damage.
In order to avoid such injuries or damage, only qualified staff may carry
out the transport, installation, setup or maintenance work required. The
standards EN 50178, IEC 60364 (Cenelec HD 384 or DIN VDE 0100),
IEC 60664-1 (Cenelec HD 625 or VDE 0110-1), BGV A2 (VBG 4) as well
as the applicable national regulations must be complied with. The term
„Qualified Staff“ refers to anybody who is familiar with the installation,
assembly, commissioning and operation of the frequency inverter as well
as the possible hazards and has the proper qualification for the job.

06/05 5
06/05 5
1.2 Purpose of the Frequency Inverters
Warning! The frequency inverters are electrical drive components intended for
installation in industrial plants or machines. Commissioning and start of
operation is not allowed until it has been verified that the machine meets
the requirements of the EC Machinery Directive 98/37/EEC and
EN 60204. In accordance with the CE marking requirements, the
frequency inverters comply with the Low Voltage Directive 72/23/EEC as
well as EN 50178 / DIN VDE 0160 and EN 61800-2. The user shall be
responsible for making sure that the requirements of the EMC Directive
89/336/EEC are met. Frequency inverters are only available at specialized
dealers and are exclusively intended for professional use as per EN
61000-3-2.
The frequency inverters are also marked with the UL label according to
UL508c, which proves that they also meet the requirements of the CSA
Standard C22.2-No. 14-95.
The technical data, connection specifications and information on ambient
conditions are indicated on the name plate and in the documentation and
must be complied with in any case. Anyone involved in any kind of work
at the device must have read the instructions carefully and understood
them before starting the work.
1.3 Transport and Storage
The frequency inverters must be transported and stored in an appropriate way.
During transport and storage the devices must remain in their original packaging.
The units may only be stored in dry rooms which are protected against dust and
moisture and are exposed to small temperature deviations only. Observe the climatic
conditions according to EN 50178 and the marking on the packaging. The units must
not be stored for more than one year without connecting them to the rated mains
voltage.
1.4 Handling and Installation
Warning! Damaged or destroyed components must not be put into operation
because they may be a health hazard.
The frequency inverters are to be used in accordance with the documentation as well
as the applicable directives and standards. They must be handled carefully and
protected against mechanical stress. Do not bend any components or change the
isolating distances. Do not touch electronic components or contacts. The devices are
equipped with components which are sensitive to electrostatic energy and can easily
be damaged if handled improperly. Any use of damaged or destroyed components
shall be considered as a non-compliance with the applicable standards. Do not
remove any warning signs from the device.

06/056
6 06/05
1.5 Electrical Connection
Warning! Before any assembly or connection work, discharge the frequency
inverter. Verify that the frequency inverter is discharged.
Do not touch the terminals because the capacitors may still be charged.
Comply with the information given in the operating instructions and on
the frequency inverter label.
When working at the frequency inverters, comply with the applicable standards BGV
A2 (VBG 4), VDE 0100 and other national directives. Comply with the electrical
installation instructions given in the documentation as well as the relevant directives.
Responsibility for compliance with and examination of the limit values of the EMC
product norm EN 61800-3 for variable-speed electrical drive mechanisms is with the
manufacturer of the industrial plant or machine.
The documentation contains information on EMC-conforming installation. The cables
connected to the frequency inverters may not be subjected to high-voltage insulation
tests unless appropriate circuitry measures are taken before. Otherwise the
frequency inverter may be damaged.
1.6 Information on Use
Warning! The frequency inverter may be connected to power supply every 60 s
only. Otherwise the unit may be damaged. For this reason, a jog
operation of a mains contactor is not permissible. For commissioning or
after an emergency stop, a non-recurrent, direct restart is permissible.
After a failure and restoration of the power supply, the motor may start
unexpectedly if the Auto-Start function is activated.
Before commissioning and the start of the operation fix all covers and
check the terminals. Check the additional monitoring and protective
devices according to EN 60204 and applicable the safety directives (e.g.
Working Machines Act, Accident Prevention Directives etc.).
No connection work may be performed, while the system is in operation.
1.7 Maintenance and Service
Warning! Unauthorized opening and improper interventions can lead to personal
injury or material damage. Repairs on the frequency inverters may only
be carried out by the manufacturer or persons authorized by the
manufacturer. Check protective equipment regularly.

06/05 7
06/05 7
2Scope of Supply
Thanks to the modular hardware components, the frequency inverters can be
integrated in the automation concept easily. The scope of delivery described can be
supplemented by optional components and adapted to the customer-specific
requirements. The plug-in type connection terminals enable a safe function and an
economical assembly.
2.1 Frequency Inverter (0.55 to 4.0 kW)
ACT 201 (230 V) and ACT 401 (400 V)
Power range 0.55 kW to 4.0 kW
Scope of Supply
A
Frequency inverter
B
Terminal strip X1 (Phoenix ZEC 1,5/ST7,5)
Plug-in terminals for mains connection and DC linking
C
Terminal strip X10 (Phoenix ZEC 1.5/3ST5.0)
Plug-in terminals for the relay output
D
Standard fixtures for vertical assembly
E
Brief Instructions and manuals on CD
F
Terminal strip X2 (Phoenix ZEC 1,5/ST7,5)
Plug-in terminal for brake resistor and motor connection
G
Control terminals X210A / X210B (Wieland DST85 / RM3.5)
Plug-in terminal for connection of the control signals
Note: Please check incoming goods for quality, quantity and nature without
delay. Obvious defects such as exterior damage of the packing and/or
the unit must be notified to the sender within seven days for insurance
reasons.

06/058
8 06/05
2.2 Frequency Inverter (5.5 to 15.0 kW)
ACT 401 (400 V)
Power range 5.5 kW to 15 kW
Scope of Supply
A
Frequency inverter
B
Terminal strip X10 (Phoenix ZEC 1.5/3ST5.0)
Plug-in terminals for the relay output
C
Standard fixtures with fixing bolts (M4x20, M4x60)
for vertical assembly
D
Brief Instructions and manuals on CD
E
Control terminals X210A / X210B (Wieland DST85 / RM3.5)
Plug-in terminal for connection of the control signals
Note: Please check incoming goods for quality, quantity and nature without
delay. Obvious defects such as exterior damage of the packing and/or the
unit must be notified to the sender within seven days for insurance
reasons.

06/05 9
06/05 9
2.3 Frequency Inverter (18.5 to 30.0 kW)
ACT 401 (400 V)
Power range 18.5 kW to 30 kW
Scope of Supply
A
Frequency inverter
B
Terminal strip X10 (Phoenix ZEC 1.5/3ST5.0)
Plug-in terminals for the relay output
C
Standard fixtures with fixing bolts (M4x20, M4x70)
for vertical assembly
D
Brief Instructions and manuals on CD
E
Control terminals X210A / X210B (Wieland DST85 / RM3.5)
Plug-in terminal for connection of the control signals
Note: Please check incoming goods for quality, quantity and nature without
delay. Obvious defects such as exterior damage of the packing and/or the
unit must be notified to the sender within seven days for insurance
reasons.

06/0510
10 06/05
3Technical Data
3.1 Frequency Inverter 230 V (0.55 to 3.0 kW)
Type
ACT 201 -05 -07 -09 -11 -13 -15
Output, motor side
Recommended shaft output P kW 0.55 0.75 1.1 1.5 2.2 3.0
4)
Output current I A 3.0 4.0 5.4 5) 7.0 9.5 12.5
4) 5)
Overload current (60 s) I A 4.5 6.0 7.3 10.5 14.3 16.2
Overload current (1 s) I A 6.0 8.0 8.0 14.0 19.0 19.0
Output voltage U V 3 x 0 ... mains voltage
Protection - - Short circuit / earth fault proof
Rotary field frequency f Hz 0 ... 1000, depending on switching frequency
Switching frequency f kHz 2, 4, 8 (nom. operat. point), 12, 16
Output, brake resistor
min. brake resistor (UdBC = 385 V) R Ω230 160 115 75 55 37
Input, mains side
Mains current 3) , 3ph/PE
1ph/N/PE ; 2ph/PE I A
3.0
5.4
4.0
7.2
5.5 1)
9.5 2)
7.0
13.2
9.5
16.5 2)
10.5 1)
16.5 2) 4)
Mains voltage U V 184 ... 264
Mains frequency f Hz 45 ... 66
Fuse 3ph/PE
1ph/N/PE ; 2ph/PE I A 6
10
10
16
16
20
16
20
UL type 250 VAC RK5, 3ph/PE
1ph/N/PE; 2ph/PE I A 6 10
10
15
15
20
15
20
Mechanics
Dimensions: HxWxD mm 190x60x175 250x60x175
Weight (approx.) m kg 1.2 1.6
Degree of protection - - IP20 (EN60529)
Terminals A
mm20.2 ... 1.5
Form of assembly - - vertical
Ambient conditions
Energy dissipation
(2 kHz switching frequency) P W 43 53 73 84 115 170
Coolant temperature Tn°C 0 ... 40 (3K3 DIN IEC 721-3-3)
Storage temperature TL°C -25 ... 55
Transport temperature TT°C -25 ... 70
Rel. air humidity - % 15 ... 85; not condensing
If required by the customer, the switching frequency may be increased if the output current is
reduced at the same time. Comply with the applicable standards and regulations for this operating
point.
Output current
Switching frequency
Frequency inverter nominal power 2 kHz 4 kHz 8 kHz 12 kHz 16 kHz
0.55 kW 3.0 A 3.0 A 3.0 A 2.5 A 2.0 A
0.75 kW 4.0 A 4.0 A 4.0 A 3.4 A 2.7 A
1.1 kW 5.5 A 2) 5.5 A 2) 5) 5.4 A 2) 5) 4.5 A 2) 5) 3.7 A 5)
1.5 kW 7.0 A 7.0 A 7.0 A 5.9 A 4.8 A
2.2 kW 9.5 A 2) 9.5 A 2) 9.5 A 2) 8.0 A 2) 6.5 A
3.0 kW 2) 4) 12.5 A 1) 12.5 A 1) 5) 12.5 A 1) 5) 10.5 A 1) 5) 8.5 A 5)
1) Three-phase connection requires a commutating choke.
2) One- and two-phase connection requires a commutating choke.
3) Mains current with relative mains impedance 1% (see chapter„Electrical installation“)
4) Maximum output current is 9.5 A for one- and two-phase connection.
5)’ Switching frequency is reduced in thermal limit range

06/05 11
06/05 11
3.2 Frequency Inverter 400 V (0.55 to 4.0 kW)
Type
ACT 401 -05 -07 -09 -11 -12 -13 -15 -18
Output, motor side
Recommended shaft output P kW 0.55 0.75 1.1 1.5 1.85 2.2 3.0 4.0
Output current I A 1.8 2.4 3.2 3.8
3) 4.2 5.8 7.8 9.0 3)
Overload current (60 s) I A 2.7 3.6 4.8 5.7 6.3 8.7 11.7 13.5
Overload current (1 s) I A 3.6 4.8 6.4 7.6 8.4 11.6 15.6 18.0
Output voltage U V 3 x 0 ... mains voltage
Protection - - Short circuit / earth fault proof
Rotary field frequency f Hz 0 ... 1000, depending on switching frequency
Switching frequency f kHz 2, 4, 8 (nom. operat. point), 12, 16
Output, brake resistor
Min. brake resistor (UdBC = 770 V) R Ω930 634 462 300 300 220 148 106
Input, mains side
Mains current 2) 3ph/PE I A 1.8 2.4 2.8 1) 3.3 1) 4.2 5.8 6.8
1) 7.8 1)
Mains voltage U V 320 ... 528
Mains frequency f Hz 45 ... 66
Fuses 3ph/PE I A 6 10
UL type 600 VAC RK5, 3ph/PE I A 6 10
Mechanics
Dimensions: HxWxD mm 190x60x175 250x60x175
Weight (approx.) m kg 1.2 1.6
Degree of protection - - IP20 (EN60529)
Terminals A
mm20.2 ... 1.5
Form of assembly - - vertical
Ambient conditions
Energy dissipation
(2 kHz switching frequency) P W 40 46 58 68 68 87 115 130
Coolant temperature Tn°C 0 ... 40 (3K3 DIN IEC 721-3-3)
Storage temperature TL°C -25 ... 55
Transport temperature TT°C -25 ... 70
Rel. air humidity - % 15 ... 85, not condensing
If required by the customer, the switchingfrequency may be increased if the output current is
reduced at the same time. Comply with the applicable standards and regulations for this operating
point.
Output current
Switching frequency
Frequency inverter nominal power 2 kHz 4 kHz 8 kHz 12 kHz 16 kHz
0.55 kW 1.8 A 1.8 A 1.8 A 1.5 A 1.2 A
0.75 kW 2.4 A 2.4 A 2.4 A 2.0 A 1.6 A
1.1 kW 3.2 A 1) 3.2 A 1) 3.2 A 1) 2.7 A 1) 2.2 A
1.5 kW 1) 3.8 A 3.8 A 3) 3.8 A 3) 3.2 A 3) 2.6 A 3)
1.85 kW 4.2 A 4.2 A 4.2 A 3.5 A 2.9 A
2.2 kW 5.8 A 5.8 A 5.8 A 4.9 A 3.9 A
3.0 kW 7.8 A 1) 7.8 A 1) 7.8 A 1) 6.6 A 1) 5.3 A
4.0 kW 9.0 A 1) 9.0 A 1) 3) 9.0 A 1) 3) 7.6 A 1) 3) 6.1 A 3)
1) Three-phase connection requires a commutating choke.
2) Mains current with relative mains impedance 1% (see chapter„Electrical installation“)
3) Switching frequency is reduced in thermal limit range

06/0512
12 06/05
3.3 Frequency Inverter 400 V (5.5 to 15.0 kW)
Type
ACT 401 -19 -21 -22 -23 -25
Output, motor side
Recommended shaft output P kW 5.5 7.5 9.2 11.0 15.0
Output current I A 14 18 22 3) 25 32
Overload current (60 s) I A 21.0 26.3 30.3 37.5 44.5
Overload current (1 s) I A 28.0 33.0 33.0 50.0 64.0
Output voltage U V 3 x 0 ... mains voltage
Protection - - Short circuit / earth fault proof
Rotary field frequency f Hz 0 ... 1000, depending on switching frequency
Switching frequency f kHz 2, 4, 8 (nom. operat. point), 12, 16
Output, brake resistor
Min. brake resistor (UdBC = 770 V) R Ω80 58 48 48 32
Input, mains side
Mains current 2) 3ph/PE I A 14.2 15.8 1) 20.0
1) 26.0 28.2 1)
Mains voltage U V 320 ... 528
Mains frequency f Hz 45 ... 66
Fuses 3ph/PE I A 16 25 35
UL type 600 VAC RK5, 3ph/PE I A 20 30 40
Mechanics
Dimensions HxWxD mm 250x100x200 250x125x200
Weight (approx.) m kg 3.0 3.7
Degree of protection - - IP20 (EN60529)
Terminals A mm20.2 ... 6 0.2 ... 16
Form of assembly - - vertical
Ambient conditions
Energy dissipation
(2 kHz switching frequency) P W 145 200 225 240 310
Coolant temperature Tn°C 0 ... 40 (3K3 DIN IEC 721-3-3)
Storage temperature TL°C -25 ... 55
Transport temperature TT°C -25 ... 70
Rel. air humidity - % 15 ... 85, not condensing
If required by the customer, the switching frequency may be increased if the output current is
reduced at the same time. Comply with the applicable standards and regulations for this operating
point.
Output current
Switching frequency
Frequency inverter nominal power 2 kHz 4 kHz 8 kHz 12 kHz 16 kHz
5.5 kW 14.0 A 14.0 A 14.0 A 11.8 A 9.5 A
7.5 kW 18.0 A 1) 18.0 A 1) 18.0 A 1) 15.1 A 1) 12.2 A
9.2 kW 1) 23.0 A 22.7 A 3) 22.0 A 3) 18.5 A 3) 15.0 A 3)
11 kW 25.0 A 25.0 A 25.0 A 21.0 A 17.0 A
15 kW 32.0 A 1) 32.0 A 1) 32.0 A 1) 26.9 A 1) 21.8 A
1) Three-phase connection requires a commutating choke.
2) Mains current with relative mains impedance 1% (see chapter„Electrical installation“)
3) Switching frequency is reduced in thermal limit range

06/05 13
06/05 13
3.4 Frequency Inverter 400 V (18.5 up to 30 kW)
Type
ACT 401 -27 -29 -31
Motor-side output
Recommended motor shaft output P kW 18.5 22 30
Output current I A 40.0 45.0 60.0
Overload current (60 s) I A 60.0 67.5 90.0
Overload current (1 s) I A 80.0 90.0 120.0
Output voltage U V 3 x 0 ... mains voltage
Protection - - Short circuit / earth fault proof
Rotary field frequency f Hz 0 ... 1000, depending on switching frequency
Switching frequency f kHz 2, 4, 8 (nom. operat. point)
Brake resistor output
Min. brake resistor (UdBC = 770 V) R Ω24 16
Mains-side input
Mains current 2) 3ph/PE I A 42.0 50.0 58.0 1)
Mains voltage U V 320 ... 528
Mains frequency f Hz 45 ... 66
Fuses 3ph/PE I A 50 50 63
UL type 600 VAC RK5, 3ph/PE I A 40 50 60
Mechanical
Dimensions HxWxD mm 250x200x290
Weight (approx.) m kg 8
Degree of protection - - IP20 (EN60529)
Terminals A mm2up to 25
Form of assembly - - vertical
Environmental conditions
Energy dissipation
(2 kHz switching frequency) P W 420 470 750
Coolant temperature Tn °C 0 ... 40 (3K3 DIN IEC 721-3-3)
Storage temperature TL°C -25 ... 55
Transport temperature TT°C -25 ... 70
Rel. air humidity - % 15 ... 85, not condensing
Depending on the customer-specific requirements, an increase of the switchingfrequency is
permissible if the output current is reduced. Comply with the applicable standards and regulations
for this operating point.
Output current
Switching frequency
Frequency inverter nominal power 2 kHz 4 kHz 8 kHz
18.5 kW 40.0 A 40.0 A 40.0 A
22 kW 45.0 A 45.0 A 45.0 A
30 kW 60.0 A 1) 60.0 A 1) 60.0 A 1)
1) Three-phase connection requires a commutating choke.
2) Mains current with relative mains impedance 1% (see chapter "Electrical installation")

06/0514
14 06/05
3.5 Operation diagrams
The technical data of the frequency inverters refer to the nominal point which was
selected to enable a wide range of applications. A functionally and efficient
dimensioning (derating) of the frequency inverters is possible based on the following
diagrams.
Site altitude
100
85
60
40
20
55
45
3000
1000 2000 4000
3000
1000 2000 4000
Power reduction (Derating),
5%/1000 m above sea level,
h = 4000 m
max
max. coolant temperature,
3.3 °C/1000 m above sea level,
Mounting altitude in m above sea level Mounting altitude in m above sea level
Output current in %
Coolant temperature in °C
Coolant temperature
100
80
63
40
20
0 10 20 30 40 50 55
Power reduction (Derating)
2.5%/K upper 40 °C, T = 55 °C
max
Output current in
%
Coolant temperature in °C
Mains voltage
100
83
63
40
20
0 400 420 440 460 480
reduction of output current at constant power (Derating
)
0.22%/ V upper 400 V, U = 480 V
max
O
utput current in
%
Mains voltage in V

06/05 15
06/05 15
4Mechanical Installation
The frequency inverters of degree of protection IP20 are designed, as a standard, for
installation in electrical cabinets.
•During installation, both the installation and the safety instructions as well as the
device specifications must be complied with.
Warning! To avoid serious physical injuries or major material damage, only
qualified persons are allowed to work on the devices.
Warning! During assembly, make sure that no foreign particles (e.g. filings, dust,
wires, screws, tools) can get inside the frequency inverter. Otherwise
there is the risk of short circuits and fire.
The frequency inverters comply with protection class IP20 only if the
covers and terminals are mounted properly.
The units may only be used if these requirements are met.
Caution! Mount the devices with sufficient clearance to other components so that
the cooling air can circulate freely. Avoid soiling by grease and air
pollution by dust, aggressive gases, etc.

06/0516
16 06/05
4.1 Frequency Inverter (0.55 to 4.0 kW)
The frequency inverter is mounted in a vertical position on the assembly panel by
means of the standard fittings.
The following illustration shows the different mounting possibilities.
Standard installation
b
b1
a1
aa2
c
c1
x
x
x 100 mm
≥
b1
Assembly is effected by inserting the long side of the fixing plate in the heat sink and
screwing it to the mounting plate.
The dimensions of the device and the installation dimensions are those of the
standard device without optional components and are given in millimeters.
Dimensions in mm Installation dimensions in mm
Frequency inverter a b c a1 a2 b1 c1
0.55 kW ... 1.1 kW 190 60 175 210 ... 230 255 30 130
ACT 201 1.5 kW ... 3.0 kW 250 60 175 270 ... 290 315 30 130
0.55 kW ... 1.5 kW 190 60 175 210 ... 230 255 30 130
ACT 401 1.85 kW ... 4.0 kW 250 60 175 270 ... 290 315 30 130

06/05 17
06/05 17
4.2 Frequency Inverter (5.5 to 15 kW)
The frequency inverter is mounted in a vertical position on the assembly panel by
means of the standard fittings. The following illustration shows the standard fitting.
Standard installation
b
b1
a
a1 a2
c
x
x
c1
x 100 mm ≥
fixing bracket bottom
(fixing with screws )
M4x60
fixing bracket top
(fixing with screws )
M4x20
Assembly is done by screwing the two fixing brackets to the heat sink of the
frequency inverter and the assembly panel.
The frequency inverters are provided with fixing brackets, which are fitted using four
thread-cutting screws.
The dimensions of the device and the installation dimensions are those of the
standard device without optional components and are given in millimeters.
Dimensions in mm Installation dimensions in mm
Frequency inverter a b c a1 a2 b1 c1
5.5 kW ... 9.2 kW 250 100 200 270 ... 290 315 12 133
11.0 kW ... 15.0 kW 250 125 200 270 ... 290 315 17.5 133

06/0518
18 06/05
4.3 Frequency Inverter (18.5 to 30 kW)
The frequency inverter is mounted in a vertical position on the assembly panel by
means of the standard fittings. The following illustration shows the standard fitting.
Standard installation
c
c1
x 100 mm ≥
x
a
a1 a2
b
b1
x
fixing bracket top
(fixing with screws )
M4x20
fixing bracket bottom
(fixing with screws )
M4x70
Assembly is done by screwing the two fixing brackets to the heat sink of the frequency
inverter and the assembly panel.
The frequency inverters are provided with fixing brackets, which are fitted using four
thread-cutting screws. The dimensions of the device and the installation dimensions
are those of the standard device without optional components and are given in
millimeters.
Dimensions in mm Installation dimensions in mm
Frequency inverter a b c a1 a2 b1 c1
18.5 kW ... 30 kW 250 200 290 270 … 290 315 20 165
