Bort BSS-1415-W User manual

230 V
50 Hz
1400
W
2520
L/min 15 L 10 kg
Wet
and dry
cleaning
Blower
function

Caution
1. The vacuum has multi functions, please read the manual carefully before operating and select
suitable accessories for different cleaning purposes.
2. Don’t leave when the vacuum is running. Please power off and take off the plug after the
cleaning.
3. Home use and indoor use only.
4. The vacuum is not suitable for children.
5. Only supplied accessories can be used.
6. Any damage, please contact after sales office for professional service.
7. Check the suction hose if any blockage before operation.
8. Please power off the vacuum immediately if any accidents.
9. Make sure the filtrations are fixed correctly before vacuuming.
Cleaning operation
Carpet cleaner version˖
1. Remove the dust bag.
2. Don’t shake the vacuum hardly. Use on flat surface.
3. Stop the vacuum immediately if any water or solution bubble sprays out. Check if too much
water or solution is collected in. Clean the water tank and floater assembly.
4. Only low bubble or no bubble solution can be used.
5. Solution tank capacity is about 3.5L.
6. Full tank solution can last working for 20-25 minutes. Please care about the solution level.
Operation process:
1. Release tank buckle, take out the top cover and remove the dust bag.
t ake out t he dust bag
don't put the dust bag when use t he washi ng f unct i on.

2. Hold the top hand, take off the floater frame as per direction instruction, check the floater
frame, strainer, filter, floater bottom, HEPA and check whether all are fixed in right position.
hol d t hi s pl ace
HEPA
st r ai ner
f l oat er
f l oat er f r ame
sponge f i l t er
floater bottombowl

3. Assemble the floater frame according to direction instruction. Put the top onto the water tank,
fix the tank buckle.
al i gn t he " open" l i ne
hol d t hi s pl ace

4. Insert the main hose adapter, rotate according to direction instruction and fix firmly. Then fix
the front solution nozzle in anticlockwise.
sol ut i on hol e
5. Connect two parts aluminum tubes together with the solution nozzles.

6. Connect the solution/water floor brush/solution nozzle with the aluminum tube/solution
nozzle.
7. Release solution tank buckle and take off the solution tank. Read the solution IM and fill the
solution and water in.
8.
sol ut i on t ank
cover
solution tank
buckle

9. Park the solution tank onto the vacuum bottom.
sol ut i on t ank
buckle

10. Plug and power on the vacuum first, then switch on solution pump. Power is adjustable.
power on vacuum
cl eaner f i r st
t hen st ar t sol ut i on
pump button
power cont r ol
button

11. When vacuuming, check if solution pump working, solution speed, floater protection,
water/solution bubble level (no exceeding the MAX line)
12. Full solution tank can last 20-25 minutes working. Check often the solution level as per the tank
scale. Power off the pump for 30 seconds before switching off the vacuum.
st op vacuum cl eaner wor ki ng
af t er 30 seconds
st ut of sol ut i on pump
first

13. After vacuuming, take out the solution nozzles and solution tank for cleaning.
solution hole
14. Take out the top vacuum part, hold the handle and take off the floater frame.
hol d t hi s pl ace
15. Take out the HEPA, strainer and floater, take off the floater bottom anticlockwise. Clean the
water in the floater bottom if any. Wash the sponge filter and HEPA, then dry in the sunshine
for next use. Wash the floater assembly and water tank.

HEPA
st r ai ner
floater
floater frame
sponge f i l t er
f l oat er bot t om bowl
16. Once floater is sucked up to the top, power off the machine and clean the floater frame, filters
and water tank before next use.
17. Airflow adjustable on hose handle.

18. Clean away the balance solution after cleaning is finished.
19. Take off the rear blow window and clean the exhaust sponge filter.
exhaust f i l t er
cover
exhaust f i l t er
20. Disassemble all the accessories from the machine after use. Clean and dry for next use.
Rear blow function:
Caution˖Don’t switch on solution pump to avoid pump overheating.
1. Take out solution tank and take off exhaust filter cover.

exhaust f i l t er
cover
2. Fix the hose in.
r ear bl ow wi ndow

3. Plug and switch on the machine for blowing.
power on bl ow
power cont r ol
button

4. Take out the hose and fix the exhaust filter cover after use.
r ear bl ow wi ndow
exhaust f i l t er
cover
Wet & Dry vacuum caution
˖
1. Don’t switch on solution pump.
2. Better take off the solution tank.
3. Don’t shake the vacuum hardly. Use on flat surface.
4. Stop the vacuum immediately if any water sprays out. Check if too much water is collected in.
Clean the water tank and floater assembly.
5. Change the dust bag if it’s broken.

Wet & Dry vacuum instruction:
1. Take out top vacuum part and fix the dust bag.
2. Hold the top hand, take off the floater frame as per direction instruction, check the floater
frame, strainer, filter, floater bottom, HEPA and check whether all are fixed in right position.
hol d t hi s pl ace
HEPA
st r ai ner
f l oat er
f l oat er f r ame
