Bosch Carephone 61 Installation and operating instructions

GSM external antenna
970.185 | V1 | 2015.04
en Installation addendum

GSM external antenna Safety Instructions | en 3
TeleAlarm Installation Addendum 970.185 | V1 | 2015.04
1 Safety Instructions
– Do not install the unit near a heating appliance.
– Do not expose the unit to direct sunlight.
– Do not install in a wet or humid environment.
– Do not attempt to disassemble the unit.
– It is recommended to maintain a minimum distance of 15
cm between a Carephone equipped with a GSM Module
and a pacemaker to avoid potential interference.
– Do not install a Carephone equipped with the GSM Module
and the external antenna in the proximity of DECT/GSM
telephones, TV sets, large metal objects, microwave
appliances or radio telephones. This will impair the
reception of signals from the wireless transmitter.
– Use only original equipment for the external antenna,
cables and power supply.
– Electrolytes or gases may be emitted from the GSM
Module battery should it leak under exceptional
circumstances. If this happens, deactivate the unit by
isolating it from the phone network and power supply.
Battery replacement must be carried out by trained service
personnel only.
CAUTION!
Read through these safety instructions carefully before
installing the external antenna in the GSM Module. They contain
important information about the connection, use and safety.
WARNING!
The GSM Module and the Carephone 62/61 contain highly
sensitive electronic components. The Carephone should be
opened only in an ESD protected environment with respect to
the following precautions. Discharge yourself from electrostatic
loads by touching a grounded conductive surface before
opening the unit.

4en | Installation GSM external antenna
970.185 | V1 | 2015.04 Installation Addendum TeleAlarm
2 Installation
1. Flip the Carephone so that you can see the backside.
Release the battery pack cover from the two clips, by
levering up with a screwdriver.
2. Open the battery pack cover.
3. Feed the antenna cable through the back of the
Carephone, on the right-hand side of the battery pack.
CAUTION!
Before starting the installation procedure, remove the power
plug from the Carephone. See the user manual of the Carephone.

GSM external antenna Installation | en 5
TeleAlarm Installation Addendum 970.185 | V1 | 2015.04
4. Open the cover of the Carephone to access the connection
compartment.
5. Feed the antenna cable up to the socket provided on the
top of the GSM Module and connect it.
6. Close the Carephone cover.
NOTICE!
If the GSM internal antenna is previously installed on the GSM
Module, disconnect and deinstall it before installing and
connecting the external antenna. Refer to the installation
addendum of the internal antenna.

6en | Installation GSM external antenna
970.185 | V1 | 2015.04 Installation Addendum TeleAlarm
7. Fasten the antenna cable carefully into the channel
provided in the middle of the battery pack cover and close
the battery pack cover.
8. Close the top cover and insert the power plug into the
Carephone.
9. Place the antenna at minimum 3 meters from the
Carephone. The antenna can be fixed with the magnetic
holder, with screws or with the integrated adhesive tape.
CAUTION!
Do not twist or trap the antenna cable in the cover. This could
damage the cable. Let the antenna cable leave the Carephone
from the back, using the cable channel.
CAUTION!
Perform a GSM signal strength test and place the antenna
where the signal is the strongest. Refer to the user manual of the
Carephone.

TeleAlarm SA
rue du Pont 23
2300 La Chaux-de-Fonds
Switzerland
www.telealarm.com
© TeleAlarm, 2015
