Bosch VideoJet 8008 User manual

VideoJet 8008 / VideoJet 8004

Copyright
This manual is copyright protected by Bosch Security Systems. All rights
reserved. No part of this document may be reproduced or transmitted for any
purpose, by whatever method and by whatever means, electronically or mechan-
ically, without the express written permission of Bosch Security Systems.
Issue: July 2006 (Software version 1.5)
© Copyright 2006 Bosch Security Systems
Note
This manual has been prepared with all due care and all information contained
in it has been thoroughly checked. The description was complete and correct at
the time of going to press. Our products are constantly developed and upgraded;
as such, the content of the manual is subject to change without notice.
Bosch Security Systems accepts no liability for losses that arise directly or indi-
rectly as a result of errors, incompleteness or discrepancies between the manual
and the product described.
Trade marks
All of the hardware and software names used in this manual are highly likely to
be registered trade marks and must be treated as such.

Bosch Security Systems | 2006-07 | V1.5
VideoJet 8008 / VideoJet 8004 | Installation and Operating Manual EN | 3
Content 0
Chapter 1 Preface
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Intended use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
EU Directives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Rating plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Chapter 2 Safety information
Electric shock hazard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installation and operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Maintenance and repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Chapter 3 Product description
Components supplied. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
System requirements for setup . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Configuration requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Operational requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Overview of functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Connections on the rear panel . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Chapter 4 Installation
Installing in a switch cabinet. . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Power on/Power off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Setup using a terminal program . . . . . . . . . . . . . . . . . . . . . . . . . 25
Chapter 5 Configuration using a Web browser
Connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Choosing the configuration mode. . . . . . . . . . . . . . . . . . . . . . . . 31
Unit overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Configuration menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Function test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Chapter 6 Operation
Operation with Microsoft Internet Explorer . . . . . . . . . . . . . . . . 119
The LIVEPAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Saving snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

Bosch Security Systems | 2006-07 | V1.5
Installation and Operating Manual | VideoJet 8008 / VideoJet 8004
EN | 4
Recording video sequences . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Running recording program . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
The MEDIA-REPLAY page . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Backup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Installing MPEG viewer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Hardware connections between video servers. . . . . . . . . . . . . 132
Operation with decoder software . . . . . . . . . . . . . . . . . . . . . . . 134
Operating options on the front panel . . . . . . . . . . . . . . . . . . . . 135
Chapter 7 Maintenance and upgrades
Testing the network connection . . . . . . . . . . . . . . . . . . . . . . . . 139
Restart (Reset) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Repairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Transfer and disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Chapter 8 Appendix
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
LEDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
RS232/485 interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
RS232 interface (audio versions only) . . . . . . . . . . . . . . . . . . . 145
Terminal block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Second terminal block (audio versions only) . . . . . . . . . . . . . . 147
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
Technical data: VideoJet 8008 . . . . . . . . . . . . . . . . . . . . . . . . . 150
Technical data: VideoJet 8008 with audio . . . . . . . . . . . . . . . . 152
Technical data: VideoJet 8004 . . . . . . . . . . . . . . . . . . . . . . . . . 154
Technical data: VideoJet 8004 with audio . . . . . . . . . . . . . . . . 156
Chapter 9 Index

VideoJet 8008 / VideoJet 8004 | Installation and Operating Manual EN | 5
Bosch Security Systems | 2006-07 | V1.5 Preface
Preface 1
This manual is intended for persons responsible for the installation and opera-
tion of the VideoJet 8008 or VideoJet 8004. International, national and any
regional electrical engineering regulations must be followed at all times. Rele-
vant knowledge of network technology is required. The manual describes the
installation and operation of the unit.
Conventions
In this manual, the following symbols and notations are used to draw attention
to special situations:
Caution
This symbol indicates that failure to follow the safety instructions described
may endanger persons and cause damage to the unit or other equipment.
It is associated with immediate, direct hazards.
Note
This symbol refers to features and indicates tips and information for easier,
more convenient use of the unit.

Installation and Operating Manual | VideoJet 8008 / VideoJet 8004
EN | 6
Preface Bosch Security Systems | 2006-07 | V1.5
Intended use
The VideoJet 8008 and VideoJet 8004 network video servers transmit video and
control signals over data networks (Ethernet LAN, Internet). The integrated hard
drive allows you to use the device as a DVR. Audio signals can also be trans-
mitted with the audio versions of the units. The units are designed for use in
CCTV systems. Various functions can be triggered automatically by incorporat-
ing external alarm sensors. Other applications are not permitted.
In the event of questions concerning the use of the units which are not answered
in this manual, please contact your sales partner or:
Bosch Sicherheitssysteme GmbH
Robert-Koch-Straße 100
85521 Ottobrunn
Germany
www.bosch-sicherheitssysteme.de
EU Directives
The VideoJet 8008 and VideoJet 8004 network video servers comply with the
requirements of EU Directives 89/336 (Electromagnetic Compatibility) and
73/23, amended by 93/68 (Low Voltage Directive).
Rating plate
For exact identification, the model name and serial number are inscribed on the
bottom of the housing. Please make a note of this information before installation
if necessary so as to have it to hand in case of questions or when ordering spare
parts.

VideoJet 8008 / VideoJet 8004 | Installation and Operating Manual EN | 7
Bosch Security Systems | 2006-07 | V1.5 Safety information
Safety information 2
Electric shock hazard
❚Never attempt to connect the unit to any power network other than the type
for which it is intended.
❚Never open the housing.
❚If a fault occurs, disconnect the unit from the power supply and from all other
units.
❚Install the unit only in dry, weather-protected locations.
❚If safe operation of the unit cannot be ensured, remove it from service and
secure it to prevent unauthorized operation. Safe operation is no longer pos-
sible in the following cases:
– if there is visible damage to the unit or power cables,
– if the unit no longer operates correctly,
– if the unit has been exposed to rain or moisture,
– if foreign bodies have penetrated the unit,
– after long storage under adverse conditions, or
– after exposure to extreme stress in transit.
In such cases, have the unit checked by Bosch Security Systems.

Installation and Operating Manual | VideoJet 8008 / VideoJet 8004
EN | 8
Safety information Bosch Security Systems | 2006-07 | V1.5
Installation and operation
❚The relevant electrical engineering regulations and guidelines must be com-
plied with at all times during installation.
❚Relevant knowledge of network technology is required to install the unit.
❚Before installing or operating the unit, make sure you have read and under-
stood the documentation for the other equipment connected to it, such as
cameras. The documentation contains important safety instructions and
information about permitted uses.
❚Perform only the installation and operation steps described in this manual.
Any other actions may lead to personal injury, damage to property or damage
to the equipment.
Maintenance and repair
❚Never open the housing of a VideoJet 8008 or VideoJet 8004. The units do
not contain any user-serviceable parts.
❚Ensure that all maintenance or repair work is carried out only by qualified per-
sonnel (electrical engineers or network technology specialists).

VideoJet 8008 / VideoJet 8004 | Installation and Operating Manual EN | 9
Bosch Security Systems | 2006-07 | V1.5 Product description
Product description 3
Components supplied
❚VideoJet 8008 or VideoJet 8004 network video server
(basic version or audio version)
❚Power supply cable
❚Configuration cable
❚Mounting kit for installation in 19-inch racks
❚Quick Installation Guide
❚Product CD with the following content:
– Quick Installation Guide
– Manual
– System Requirements document
– MPEG ActiveX control
– MPEG viewer
– DirectX control
– Microsoft Internet Explorer
– Microsoft Virtual Machine
– Adobe Acrobat Reader
System requirements for setup
❚Computer with Windows 2000/XP operating system, access to a network and
Microsoft Internet Explorer (version 6.0 or higher)
or
❚Computer with Windows 2000/XP operating system, free serial interface and
terminal program

Installation and Operating Manual | VideoJet 8008 / VideoJet 8004
EN | 10
Product description Bosch Security Systems | 2006-07 | V1.5
Configuration requirements
❚Computer with Windows 2000/XP operating system, access to a network and
Microsoft Internet Explorer (version 6.0 or higher)
or
❚Computer with Windows 2000/XP operating system, access to a network and
receiver software, such as VIDOS
Note
Also note the information in the System Requirements document on the
product CD supplied.
Make sure the graphics card is set to 16- or 32-bit color depth and that
Microsoft Virtual Machine is installed and activated on your PC.
If necessary, you can install the required software and controls from the
product CD supplied (see Components supplied, page 9).
Operational requirements
❚Computer with Windows 2000/XP operating system, access to a network and
Microsoft Internet Explorer (version 6.0 or higher)
or
❚Computer with Windows 2000/XP operating system, access to a network and
receiver software, such as VIDOS
or
❚MPEG-4 compatible hardware decoder from Bosch Security Systems
(for example VIP XD) as a receiver and connected video monitor
Note
Also note the information in the System Requirements document on the
product CD supplied.
Make sure the graphics card for reception on the computer monitor is set
to 16- or 32-bit color depth and that Microsoft Virtual Machine is installed
and activated on your PC. If necessary, you can install the required soft-
ware and controls from the product CD supplied (see Components sup-
plied, page 9).

VideoJet 8008 / VideoJet 8004 | Installation and Operating Manual EN | 11
Bosch Security Systems | 2006-07 | V1.5 Product description
Overview of functions
Network video server
VideoJet 8008 and VideoJet 8004 are network video servers for eight indepen-
dent video channels. They are primarily designed for encoding video and control
data for transmission over an IP network. With the audio versions, audio signals
can also be transmitted to and from compatible units. The use of existing net-
works means that integration with CCTV systems or local networks can be
achieved quickly and easily.
The VideoJet 8008 offers full D1/4CIF resolution at a complete image rate of
25 images per second for 8 channels. The VideoJet 8004 is the more economic
variant with half the image rate per channel.
VideoJet 8008 and VideoJet 8004 are designed as desktop units and intended for
installation in the switch cabinet. Mounting in a 19-inch rack using the mounting kit
supplied is a quick and easy operation.
Receiver
Compatible MPEG-4 enabled hardware decoders (for example the VIP XD) can
be used as receivers. Computers with decoding software such as VIDOS or
computers with the Microsoft Internet Explorer Web browser can also be used
as receivers.
Video encoding
VideoJet 8008 and VideoJet 8004 use the MPEG-4 video compression stan-
dard. Thanks to efficient encoding, the data rate remains low even with high
image quality and can also be adapted to local conditions within wide limits. In
this manner, the simultaneous encoding of all eight video channels is supported.
Dual Streaming in the VideoJet 8008
Dual Streaming allows the incoming data stream to be encoded simultaneously
according to two different, individually customized profiles. With VideoJet 8008,
two data streams are created per camera that can serve different purposes, for
example, one can be used for local recording and one can be optimized for
transmission over the LAN.
The VideoJet 8004 does not offer Dual Streaming.

Installation and Operating Manual | VideoJet 8008 / VideoJet 8004
EN | 12
Product description Bosch Security Systems | 2006-07 | V1.5
Multicast
In suitably configured networks, the multicast function enables simultaneous
real-time video transmission to multiple receivers. The UDP and IGMP V2 pro-
tocols must be implemented on the network for this function.
DVR
The integrated hard drive means that VideoJet 8008 and VideoJet 8004 can be
used as digital video recorders for local long-term recording. Both units support
ANR technology, which guarantees seamless recording without gaps with
VIDOS-NVR, even during network failures.
Remote control
For remote control of external units such as pan or tilt heads for cameras or
motorized zoom lenses, control data is transmitted via the bidirectional serial
interface. This interface can also be used to transmit transparent data.
Configuration
The units can be configured with a Web browser via the local network (Intranet)
or via the Internet. In the same way, firmware updates and fast loading of device
configurations are possible.
Snapshots
Individual video images (snapshots) can be called up from the unit, stored on the
computer's hard drive or displayed in a separate browser window in JPEG format.
Backup
The LIVEPAGE and MEDIA-REPLAY pages both contain an icon for saving the
video images shown as a file on your computer's hard drive. Video sequences
can be stored by means of a mouse click and can be redisplayed using the
MPEG viewer supplied as part of the scope of delivery.

VideoJet 8008 / VideoJet 8004 | Installation and Operating Manual EN | 13
Bosch Security Systems | 2006-07 | V1.5 Product description
Summary
VideoJet 8008 and VideoJet 8004 offer the following main functions:
❚Video and data transmission over IP data networks
❚Dual Streaming function for every encoder to allow simultaneous encoding
based on two individually definable profiles (only VideoJet 8008)
❚Multicast function for simultaneous image transmission to multiple receivers
❚Eight independent analog BNC composite video inputs (PAL/NTSC)
❚Video encoding to international standard MPEG-4
❚Integrated Ethernet port (10/100/1000 Base-T)
❚Transparent, bidirectional data channel via RS232/RS422/RS485 serial inter-
face
❚Local long-term recording on integrated hard drive
❚Remote control for all internal functions with TCP/IP
❚Password protection to prevent unauthorized connection or configuration
changes
❚Ten alarm inputs for external sensors (such as door contacts)
❚Built-in video sensor for motion and tamper alarms
❚
Event-controlled automatic connection (for example at switch-on and for alarms)
❚Fast and convenient configuration using built-in Web server and browser
❚Firmware update using flash memory
❚Convenient uploading of configuration data
The various audio versions also offer:
❚Transmission and receipt of audio signals
❚Bidirectional audio (mono) for line or microphone/speaker links
❚Audio encoding to international standard G.711
❚Five relay outputs for switching external units (such as lamps or sirens)
❚Additional RS232 serial interface

Installation and Operating Manual | VideoJet 8008 / VideoJet 8004
EN | 14
Product description Bosch Security Systems | 2006-07 | V1.5
Connections on the rear panel
1Eight audio ports (Mono): Audio 1 to Audio 8 (audio versions only)
3.5 mm stereo sockets for connecting audio cables
2Additional terminal block (audio versions only)
Relay outputs, serial interface, audio port for microphone and loudspeaker
(speaking level)
3 Audio Out audio output (audio versions only)
3.5 mm stereo socket, stereo output with line-out level
4 RS232 serial interface (audio versions only)
9-pin sub-D socket (m) as additional serial interface
5Eight video inputs: Video 1 to Video 8
BNC sockets for connecting the video sources,
each with a switch for 75 Ohm terminating resistance
6Ten alarm inputs: IN1to IN10
Push-in terminal for connecting external signal sources or switches
7 RS232/485 serial interface
RJ45 socket for transmitting control data (standards RS232, RS422 and
RS485) and for configuration using a terminal program
8 10/100/1000 MBit Base-T RJ45 socket
for connecting to an Ethernet LAN (local network)
incl. green network connection LED (left) and
orange data transmission LED (right)
9Powersocket
for connecting the power supply cable

VideoJet 8008 / VideoJet 8004 | Installation and Operating Manual EN | 15
Bosch Security Systems | 2006-07 | V1.5 Product description
Front panel
10 Power LED
lights up green when ready for operation
11 IR diode
infrared receiver (for future function extensions)
12 HDD LED
flashes red during data transmission to and from the hard drive
13 Fail LED
flashes red during hardware error (defective fans)
14 Display
for displaying operating parameters
15 Menu/Exit key
for activating and deactivating the configuration menu
16 Set key
for saving changes to the operating parameters
(for future function extensions)
17 Arrow keys
for navigation in the display menu
For more information about the LEDs, see page 143.

Installation and Operating Manual | VideoJet 8008 / VideoJet 8004
EN | 16
Product description Bosch Security Systems | 2006-07 | V1.5

VideoJet 8008 / VideoJet 8004 | Installation and Operating Manual EN | 17
Bosch Security Systems | 2006-07 | V1.5 Installation
Installation 4
VideoJet 8008 and VideoJet 8004 are designed as desktop units and intended
for installation in a switch cabinet. Mounting in a 19-inch rack using the mounting
kit supplied is a quick and easy operation.
For desktop operation, four self-adhesive, non-slip rubber feet are included,
which you can stick to the bottom of the unit.
Caution
The unit is designed for indoor operation. Select a suitable location for in-
stallation where the unit will not be subjected to conditions of extreme tem-
perature or humidity. The ambient temperature must be between 0 and
+40 °C (+32 and +104 °F), and the relative humidity must not exceed 80%
(non-condensing).
The unit heats up during operation, so you should ensure that there is ad-
equate ventilation and enough clearance between the unit and heat-sen-
sitive objects or equipment.
Please ensure the following installation conditions:
❚Do not install the unit close to heaters or other heat sources. Avoid locations
exposed to direct sunlight.
❚Allow sufficient space for running cables.
❚Ensure that the unit has adequate ventilation. Bear the total heat output in
mind, particularly when installing multiple units in a switch cabinet.
❚When making connections, use only the cables supplied or use appropriate
cables immune to electromagnetic interference.
❚Position and run all cables so that they are protected from damage, and pro-
vide adequate cable strain relief where needed.
❚Avoid impacts, blows and severe vibrations as these can irreparably damage
the unit.

Installation and Operating Manual | VideoJet 8008 / VideoJet 8004
EN | 18
Installation Bosch Security Systems | 2006-07 | V1.5
Installing in a switch cabinet
VideoJet 8008 and VideoJet 8004 are set up for installation in a 19-inch rack.
The necessary mounting kit is already supplied.
Caution
When installing in a switch cabinet, ensure that there is sufficient ventilation
for each unit: There must be at least 5 cm (1.97 in.) of free space to the left
and right of the unit and at least 10 cm (3.94 in.) at the rear.
The ambient temperature must be between 0 and +40 °C
(+32 and +104 °F), and the relative humidity must not exceed 80%.
The unit heats up during operation, so you should ensure that there is
enough clearance between the unit and other heat-sensitive equipment or
objects.
When mounting additional units, direct contact is permitted, provided that
the surface temperature of the adjacent units does not exceed +40 °C
(+104 °F).
Installing the unit
– On the left and right-hand sides of the housing, loosen the two screws on
the front panel and remove them completely.
– Insert the two angle brackets from the mounting kit into the slots next to the
screw holes on the housing and secure them with the four housing screws.
– Set the unit in the switch cabinet frame and secure the angle brackets using
the four screws, washers and lock nuts provided.
– Connect the rubber connector of the power cable supplied to the
Power socket on the rear panel of the unit.

VideoJet 8008 / VideoJet 8004 | Installation and Operating Manual EN | 19
Bosch Security Systems | 2006-07 | V1.5 Installation
Installation overview

Installation and Operating Manual | VideoJet 8008 / VideoJet 8004
EN | 20
Installation Bosch Security Systems | 2006-07 | V1.5
Connections
Cameras
You can connect a maximum of eight standard video sources (such as CCTV
cameras). Any cameras and other video sources that produce a standard PAL
or NTSC signal are suitable.
Note
On the VideoJet 8008, the maximum resolution at the complete image rate
for each camera input is Full D1/4CIF. The VideoJet 8004 only supports
the Full D1/4CIF resolution when every other camera input is assigned,
that is, when the four uneven inputs (Video 1, 3, 5, 7) or the four even in-
puts (Video 2, 4, 6, 8) are assigned. If all eight inputs are assigned, the
VideoJet 8004 supports a maximum resolution of 2CIF at the full image
rate. Mixed assignment is also possible: for example, assign Video 1 to
Video 4 (2CIF) and then only Video 5 and Video 7 (4CIF each).
– Connect the cameras or other video sources with a video cable
(75 Ohm, BNC plug) to the BNC Video 1 to Video 8 sockets.
–Setthe75 Ωsliding switch under the BNC sockets to ●, in order to terminate
the video input, if the video signal is not looped through.
VideoJet 8008 Video 1 Video 2 Video 3 Video 4 Video 5 Video 6 Video 7 Video 8
4CIF 4CIF 4CIF 4CIF 4CIF 4CIF 4CIF 4CIF
VideoJet 8004 Video 1 Video 2 Video 3 Video 4 Video 5 Video 6 Video 7 Video 8
4CIF — 4CIF — 4CIF — 4CIF —
—4CIF—4CIF—4CIF—4CIF
2CIF 2CIF 2CIF 2CIF 2CIF 2CIF 2CIF 2CIF
2CIF 2CIF 2CIF 2CIF 4CIF — 4CIF —
