Bosch IXO Professional User manual

Robert Bosch Power Tools GmbH
70538 Stuttgart
GERMANY
www.bosch-pt.com
1 609 92A 41K (2017.09) T / 176
IXO Professional
en Original instructions
fr Notice originale
es Manual original
pt Manual original
cn 正本使用说明书
tw 原始使用說明書
ko 사용 설명서 원본
th หนังสือคู่มือการใช้งาน
ฉบับต้นแบบ
id Petunjuk-Petunjuk untuk
Penggunaan Orisinal
vi
Bản gốc hướng dẫn sửdụng
ar
fa
ςТЎϩХʉ ЌТϾϦφЍʉ ʌμВТЎϺυ
ΖЎϩʉ ˒μВЖЙʉʓ ИͳϞφЁʑ
OBJ_BUCH-1384-005.book Page 1 Thursday, September 28, 2017 11:13 AM

2|
1 609 92A 41K | (28.9.17) Bosch Power Tools
English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 7
Français . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 27
Español. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Página 41
Português . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Página 55
中文 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .页68
中文 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .頁79
한국어 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .페이지 91
 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  103
Bahasa Indonesia. . . . . . . . . . . . . . . . . . . . . . . . Halaman 116
Tiếng Việt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Trang 130
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
OBJ_BUCH-1384-005.book Page 2 Thursday, September 28, 2017 12:00 PM

Bosch Power Tools 1 609 92A 41K | (28.9.17)
| 3
A
IXO
11
5
1
23
56
10
4
97
8
OBJ_BUCH-1384-005.book Page 3 Thursday, September 28, 2017 12:00 PM

1 609 92A 41K | (28.9.17) Bosch Power Tools
4|
C
1
B
1
3
2
1
OBJ_BUCH-1384-005.book Page 4 Thursday, September 28, 2017 12:00 PM

Bosch Power Tools 1 609 92A 41K | (28.9.17)
| 5
E
D
2
1
2
14
13
15
12
16
OBJ_BUCH-1384-005.book Page 5 Thursday, September 28, 2017 12:00 PM

1 609 92A 41K | (28.9.17) Bosch Power Tools
6|
F
3
3
G
11
OBJ_BUCH-1384-005.book Page 6 Thursday, September 28, 2017 12:00 PM

English | 7
Bosch Power Tools 1 609 92A 41K | (28.9.17)
English
Safety Notes
General Power Tool Safety Warnings
Readallsafety warningsandallinstructions. Failure to
follow the warnings and instructions may result in electric
shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
Work area safety
Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create
sparks which may ignite the dust or fumes.
Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
Electrical safety
Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will reduce risk of electric
shock.
Avoid body contact with earthed or grounded surfaces, such as
pipes,radiators,ranges and refrigerators. There is an increased risk of
electric shock if your body is earthed or grounded.
Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or un-
plugging the power tool. Keep cord away from heat, oil, sharp edges
and moving parts. Damaged or entangled cords increase the risk of elec-
tric shock.
WARNING
OBJ_BUCH-1384-005.book Page 7 Thursday, September 28, 2017 12:00 PM

1 609 92A 41K | (28.9.17) Bosch Power Tools
8| English
When operating a power tool outdoors, use an extension cord suita-
ble for outdoor use. Use of a cord suitable for outdoor use reduces the
risk of electric shock.
If operating a power tool in a damp location is unavoidable, use a re-
sidual current device (RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
Personal safety
Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired or
under the influence of drugs, alcohol or medication. A moment of inat-
tention while operating power tools may result in serious personal injury.
Use personal protective equipment.Always wear eye protection. Pro-
tective equipment such as dust mask, non-skid safety shoes, hard hat, or
hearing protection used for appropriate conditions will reduce personal
injuries.
Prevent unintentional starting. Ensure the switch is in the off-posi-
tion before connecting to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch on invites
accidents.
Remove any adjusting key or wrench before turning the power tool
on.A wrench or a key left attached to a rotating part of the power tool may
result in personal injury.
Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewellery. Keep your
hair, clothing and gloves away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving parts.
If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used.
Use of dust collection can reduce dust-related hazards.
Power tool use and care
Do not force the power tool. Use the correct power tool for your appli-
cation. The correct power tool will do the job better and safer at the rate
for which it was designed.
OBJ_BUCH-1384-005.book Page 8 Thursday, September 28, 2017 12:00 PM

English | 9
Bosch Power Tools 1 609 92A 41K | (28.9.17)
Do not use the power tool if the switch does not turn it on and off. Any
power tool that cannot be controlled with the switch is dangerous and
must be repaired.
Disconnect the plug from the power source and/or the battery pack
from the power tool before making any adjustments, changing acces-
sories, or storing power tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to oper-
ate the power tool. Power tools are dangerous in the hands of untrained
users.
Maintain power tools. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power tool repaired be-
fore use. Many accidents are caused by poorly maintained power tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to control.
Use the power tool, accessories and tool bits etc. in accordance with
these instructions, taking into account the working conditions and
theworkto be performed.Use of the power tool for operations different
from those intended could result in a hazardous situation.
Battery tool use and care
Recharge only with the charger specified by the manufacturer. A
charger that is suitable for one type of battery pack may create a risk of
fire when used with another battery pack.
Use power tools only with specifically designated battery packs. Use
of any other battery packs may create a risk of injury and fire.
When battery pack is not in use, keep it away from other metal ob-
jects, like paper clips, coins, keys, nails, screws or other small metal
objects, that can make a connection from one terminal to another.
Shorting the battery terminals together may cause burns or a fire.
Under abusive conditions, liquid may be ejected from the battery;
avoid contact. If contact accidentally occurs, flush with water. If
liquid contacts eyes, additionally seek medical help. Liquid ejected
from the battery may cause irritation or burns.
OBJ_BUCH-1384-005.book Page 9 Thursday, September 28, 2017 12:00 PM

1 609 92A 41K | (28.9.17) Bosch Power Tools
10 | English
Service
Have your powertool serviced by a qualified repair person usingonly
identical replacement parts. This will ensure that the safety of the
power tool is maintained.
Safety Warnings for Screwdrivers
Hold power tool by insulated gripping surfaces, when performing an
operation where the fastener may contact hidden wiring. Fasteners
contacting a “live” wire may make exposed metal parts of the power tool
“live” and could give the operator an electric shock.
Hold the machine with a firm grip. High reaction torque can briefly
occur while driving in and loosening screws.
Securetheworkpiece.A workpiece clamped withclampingdevices or in
a vice is held more secure than by hand.
Always wait until the machine has come to a complete stop before
placing it down. The tool insert can jam and lead to loss of control over
the power tool.
Before any work on the machine (e. g., maintenance, tool change,
etc.) as well as during transport and storage, set the rotational
direction switch to the centre position. Unintentional actuation of the
On/Off switch can lead to injuries.
Protect the power tool against heat, e. g., against continuous
intense sunlight, fire, water, and moisture. Danger of
explosion.
In case of damage and improper use of the battery, vapours may be
emitted. Ventilate the area and seek medical help in case of com-
plaints. The vapours can irritate the respiratory system.
OBJ_BUCH-1384-005.book Page 10 Thursday, September 28, 2017 12:00 PM

English | 11
Bosch Power Tools 1 609 92A 41K | (28.9.17)
Safety Warnings for Battery Chargers
This charger is not intended for use by chil-
dren and persons with physical, sensory or
mental limitations or a lack of experience or
knowledge. This charger canbe usedby chil-
dren aged 8 and above and by persons who
havephysical,sensory ormentallimitations
ora lack ofexperienceor knowledgeif a per-
son responsible for their safety supervises
them or has instructed them in the safe op-
eration of the charger and they understand
the associated dangers. Otherwise, there is a
danger of operating errors and injuries.
Supervise children during use, cleaning and
maintenance.This will ensure that children do
not play with the charger.
Only charge Bosch lithium-ion batteries
with a capacity of 1.3 Ah or more (1 battery
cells or more). The battery voltage must
match the battery charging voltage of the
charger. Do not charge non-rechargeable
batteries.Otherwisethereisdangeroffireand
explosion.
Keep the battery charger away from rain or moisture. Penetra-
tionofwaterinthebatterychargerincreasestheriskofanelectric
shock.
Charge the power tool only with the supplied charger.
OBJ_BUCH-1384-005.book Page 11 Thursday, September 28, 2017 12:00 PM

1 609 92A 41K | (28.9.17) Bosch Power Tools
12 | English
Keep the battery charger clean. Contamination can lead to danger of an
electric shock.
Before each use, check the battery charger, cable and plug. If
damage is detected, do not use the battery charger. Never open the
battery charger yourself. Have repairs performed only by a qualified
technician and only using original spare parts. Damaged battery
chargers, cables and plugs increase the risk of an electric shock.
Do not operate the battery charger on easily inflammable surfaces
(e. g., paper, textiles, etc.) or surroundings. The heating of the battery
charger during the charging process can pose a fire hazard.
Products sold in GB only: Your product is fitted with a BS 1363/A
approved electric plug with internal fuse (ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be cut off and an
appropriate plug fitted in its place by an authorised customer service
agent. The replacement plug should have the same fuse rating as the
original plug.
The severed plug must be disposed of to avoid a possible shock hazard
and should never be inserted into a mains socket elsewhere.
Product Description and Specifications
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
Intended Use
The machine is intended for driving in and loosening screws.
The light of this power tool is intended to illuminate the power tool’s direct
area of working operation and is not suitable for household room illumina-
tion.
Product Features
The numbering of the product features refers to the illustration of the
machine on the graphics page.
1Screwdriver bit*
2Tool holder
OBJ_BUCH-1384-005.book Page 12 Thursday, September 28, 2017 12:00 PM

English | 13
Bosch Power Tools 1 609 92A 41K | (28.9.17)
3Rubber cap
4Indicator for right rotation
5Battery charge-control indicator
6Indicator for left rotation
7On/Off switch
8Rotational direction switch
9Worklight
10 Handle (insulated gripping surface)
11 Battery charger
12 Angle screw adapter*
13 Torque attachment*
14 Torque presetting ring*
15 Torque-setting mark*
16 Release ring*
*Accessories shown or described are not part of the standard delivery scope of the
product. A complete overview of accessories can be found in our accessories pro-
gram.
Technical Data
Cordless Screwdriver IXO
Article number 3 601 J60 2..
Rated voltage V= 3.6
No-load speed min-1 180
Max. torque for hard/soft screwdriving
application according to ISO 5393 Nm 4/3
Max. screw dia. mm 5
Weight according to EPTA-Procedure 01:2014 kg 0.35
Permitted ambient temperature
– during charging
– during operation* and during storage
°C
°C
0... +45
–20... +50
Battery Li-Ion
Capacity Ah 1.3
Number of battery cells 1
* limited performance at temperatures <0 °C
OBJ_BUCH-1384-005.book Page 13 Thursday, September 28, 2017 12:00 PM

1 609 92A 41K | (28.9.17) Bosch Power Tools
14 | English
Assembly
Before any work on the machine (e. g., maintenance, tool change,
etc.) as well as during transport and storage, set the rotational direc-
tionswitchtothecentreposition.Unintentional actuation of the On/Off
switch can lead to injuries.
Battery Charging (see figure A)
Do not use other battery chargers. The supplied battery charger is
designed for the Lithium-Ion battery in your machine.
Observe the mains voltage! The voltage of the power supply must
correspond with the data given on the nameplate of the battery charger.
Battery chargers marked with 230 V can also be operated with 220 V.
Note:The battery supplied is partially charged. To ensure full capacity of the
battery, completely charge the battery in the battery charger before using
your power tool for the first time.
The lithium-ion battery can be charged at any time without reducing its ser-
vice life. Interrupting the charging procedure does not damage the battery.
TheLithium-Ion battery is protected against deep discharging.When the bat-
tery is discharged, the machine is automatically switched off by a protective
circuit: The inserted tool no longer moves and a slight whistling noise can be
heard.
Do not continue to press the On/Off switch after the machine has
been automatically switched off. The battery can be damaged.
When the battery charge-control indicator 5lights up red while the On/Off
switch 7is depressed half way, then the battery has less than 30% of its
capacity and should be charged.
Battery Charger
Article number 2 607 225 093
Charging time h5
Protection class /II
Cordless Screwdriver IXO
* limited performance at temperatures <0 °C
OBJ_BUCH-1384-005.book Page 14 Thursday, September 28, 2017 12:00 PM

English | 15
Bosch Power Tools 1 609 92A 41K | (28.9.17)
Thechargingprocedurestartsas soonasthemainplugofthe batterycharger
is inserted into the socket and the cordless screwdriver is afterwards placed
on the battery charger 11.
The battery charge-control indicator 5indicates the charging progress. The
indicator lights up green during the charging process. When the battery
charge-control indicator 5is no longer lit, the battery is fully charged.
During the charging procedure, the handle of the machine warms up. This is
normal.
Disconnect the battery charger from the mains supply when not using it for
longer periods.
The power tool cannot be used during the charge procedure; it is not defec-
tive when inoperative during the charging procedure.
Protect the battery charger against moisture!
Observe the notes for disposal.
Changing the Tool (see figure B)
Do not use double-sided screwdriver bits that are longer than 25 mm.
Insert the screwdriver bit 1directly into the tool holder 2.
Torque Attachment/Angle Driver Head (see figures C – F)
The angle driver head 12 enables screwdriving at hard to reach locations.
With the torque presetting ring 14on the torque attachment 13, the request-
ed torque can be preset in 10 steps. With the correct setting, the tool bit is
stopped as soon as the screw is driven flush into the material or when theset
torque is reached.
Assembly (see figures C–D)
For assembly of the attachments, pull the rubber cap 3off toward the front.
Afterwards the attachments can be mounted. The attachments can be
mounted offset by 45°.
Dismounting (see figures E–F)
To dismount the attachments, turn the release ring 16 in rotation direction
and pull the attachment off toward the front. Afterwards, mount the
rubber cap 3again.
OBJ_BUCH-1384-005.book Page 15 Thursday, September 28, 2017 12:00 PM

1 609 92A 41K | (28.9.17) Bosch Power Tools
16 | English
Operation
Starting Operation
Reversing the rotational direction
The rotational direction switch 8is used to reverse the rotational direction
of the machine. However, this is not possible with the On/Off switch 7
actuated.
Right rotation: For driving in screws, push the rotational direction switch 8
left to the stop.
The indicator for right rotation 4lights up when the On/Off switch 7
is actuated and the motor is running.
Left Rotation: For loosening or unscrewing screws, push the rotational di-
rection switch 8right to the stop.
The indicator for left rotation 6lights up when the On/Off switch 7
is actuated and the motor is running.
Switching On and Off
To start the machine, press the On/Off switch 7and keep it pressed.
The power light 9lights up when the On/Off switch 7is slightly or completely
pressed, and allows the work area tobe illuminated when lighting conditions
are insufficient.
To switch off the machine, release the On/Off switch 7.
Fully automatic spindle locking (Auto-lock)
The spindle is locked when the On/Off switch 7is not pressed.
This enables screws to be screwed in, even when the battery is empty and
allows for the machine to be used as a screwdriver.
When the spindle is locked,do not press the On/Off switch 7 formore
than 15 seconds. Otherwise the power tool can be damaged.
Working Advice
Apply the power tool to the screw only when it is switched off.
Rotating tool inserts can slip off.
Upto13screwdriverbitscanbestored on thesideof thebattery charger11.
The fixture that holds the screwdriver bits can be removed.
OBJ_BUCH-1384-005.book Page 16 Thursday, September 28, 2017 12:00 PM

English | 17
Bosch Power Tools 1 609 92A 41K | (28.9.17)
Wall-mounting the Battery Charger (see figure G)
The battery charger 11 can be mounted to a wall. For this, hang the charger
via the slots on the side onto two screws.
Maintenance and Service
Maintenance and Cleaning
Before any work on the machine (e. g., maintenance, tool change,
etc.) as well as during transport and storage, set the rotational direc-
tionswitchtothecentreposition.Unintentional actuation of the On/Off
switch can lead to injuries.
For safe and proper working, always keep the machine and ventila-
tion slots clean.
When the battery is no longer operative, please refer to an authorised after-
sales service agent for Bosch power tools.
If the replacement of the supply cord is necessary, this has to be done by
Bosch or an authorized Bosch service agent in order to avoid a safety hazard.
After-sales Service and Application Service
Our after-sales service responds to your questions concerning maintenance
and repair of your product as well as spare parts. Exploded views and infor-
mation on spare parts can also be found under:
www.bosch-pt.com
Bosch’sapplicationserviceteamwillgladlyanswerquestionsconcerningour
products and their accessories.
In all correspondence and spare parts orders, please always include the
10-digit article number given on the nameplate of the product.
