Bosch TINYON IP 2000 WI Mounting instructions

Camera Browser Interface
TINYON IP 2000 WI / TINYON IP 2000 PIR
en Software manual
use
www.use-ip.co.uk
01304 827609

Table of contents
1Browser connection 11
1.1 System requirements 11
1.2 Establishing the connection 11
1.2.1 Password protection in camera 12
1.3 Protected network 12
2System overview 13
2.1 Live page 13
2.2 Playback 13
2.3 Settings 13
3Operation via the browser 14
3.1 Live page 14
3.1.1 Image selection 14
3.1.2 Digital I/O 15
3.1.3 System Log / Event Log 15
3.1.4 Saving snapshots 16
3.1.5 Recording video sequences 16
3.1.6 Recording status 16
3.1.7 Audio communication 16
3.1.8 Storage, CPU and network status 17
3.1.9 Status icons 18
3.2 Playback 19
3.2.1 Selecting recordings for playback 19
3.2.2 Exporting tracks 19
3.2.3 Searching for tracks 20
3.2.4 Controlling playback 20
4Basic Mode 22
4.1 Device Access 22
4.1.1 Name 22
4.1.2 Password 22
4.2 Date/Time 23
4.3 Network 24
4.4 Encoder 24
4.5 Audio 25
Camera Browser
Interface Table of Contents | en 3
Bosch Security Systems 2015.01 | v1.59x | AM18-Q0676

4.6 Recording 25
4.7 System Overview 25
5General settings 26
5.1 Identification 26
5.1.1 Naming 26
5.1.2 ID 26
5.1.3 iSCSI Initiator extension 26
5.2 Password 27
5.2.1 Enter Password 27
5.2.2 Confirm password 27
5.3 Date/Time 28
5.3.1 Date format 28
5.3.2 Device date / Device time 28
5.3.3 Device time zone 28
5.3.4 Daylight saving time 28
5.3.5 Time server IP address 29
5.3.6 Time server type 29
5.4 Display Stamping 30
5.4.1 Camera name stamping 30
5.4.2 Time stamping 30
5.4.3 Display milliseconds 30
5.4.4 Alarm mode stamping 30
5.4.5 Alarm message 31
5.4.6 Transparent stamping 31
5.4.7 Video authentication 31
5.5 GB/T 28181 31
6Web Interface 32
6.1 Appearance 32
6.1.1 Website language 32
6.1.2 Company logo 32
6.1.3 Device logo 32
6.1.4 Show VCA metadata 32
6.1.5 Show overlay icons 32
6.1.6 Select video player 33
6.1.7 JPEG size, interval and quality 33
4en | Table of Contents Camera Browser
Interface
2015.01 | v1.59x | AM18-Q0676 Bosch Security Systems

6.2 LIVE Functions 34
6.2.1 Transmit audio 34
6.2.2 Show alarm inputs 34
6.2.3 Show alarm outputs 34
6.2.4 Show event log 34
6.2.5 Show system log 34
6.2.6 Allow snapshots 34
6.2.7 Allow local recording 35
6.2.8 I-frames-only stream 35
6.2.9 Path for JPEG and video files 35
6.3 Logging 36
6.3.1 Save event log 36
6.3.2 Save system log 36
7Camera 37
7.1 Installer Menu 37
7.1.1 Base frame rate 37
7.1.2 Camera LED 37
7.1.3 Mirror image 37
7.1.4 Flip image 37
7.1.5 Reboot device 37
7.1.6 Factory defaults 37
7.2 Picture settings – Color 38
7.2.1 White balance 38
7.3 Picture settings – ALC 40
7.3.1 ALC mode 40
7.3.2 ALC level 40
7.3.3 Exposure/frame rate 40
7.4 Picture settings – Enhance 41
7.4.1 Backlight Compensation 41
7.4.2 Intelligent DNR 41
7.5 Encoder Settings 42
7.6 Privacy Masks 43
7.7 Audio 44
7.7.1 Adjust level 44
7.7.2 Recording format 44
Camera Browser
Interface Table of Contents | en 5
Bosch Security Systems 2015.01 | v1.59x | AM18-Q0676

7.8 Pixel Counter 45
8Encoder Settings 46
8.1 Introduction to encoder settings 46
8.2 Encoder Profile 47
8.2.1 Pre-defined profiles 47
8.2.2 Changing a profile 47
8.2.3 Profile name 47
8.2.4 Target bit rate 48
8.2.5 Maximum bit rate 48
8.2.6 Encoding interval 48
8.2.7 Standard definition video resolution 48
8.2.8 Expert Settings 48
8.2.9 Default 50
8.3 Encoder Streams 51
8.3.1 H.264 settings 51
8.3.2 JPEG stream 51
8.4 Encoder Regions 53
8.4.1 Selecting regions 53
9Recording 54
9.1 Introduction to recording 54
9.1.1 WiFi models 54
9.2 Storage Management 55
9.2.1 Device manager 55
9.2.2 Recording media 55
9.2.3 Activating and configuring storage media 56
9.2.4 Formatting storage media 56
9.2.5 Deactivating storage media 57
9.3 Recording Profiles 58
9.3.1 Recording track selection 58
9.3.2 Standard recording 59
9.3.3 Alarm recording 59
9.4 Maximum Retention Time 61
9.5 Recording Scheduler 62
9.5.1 Weekdays 62
9.5.2 Holidays 62
6en | Table of Contents Camera Browser
Interface
2015.01 | v1.59x | AM18-Q0676 Bosch Security Systems

9.5.3 Profile names 63
9.5.4 Activate recording 63
9.5.5 Recording status 63
9.6 Recording Status 64
10 Alarm 65
10.1 Alarm Connections 65
10.1.1 Connect on alarm 65
10.1.2 Number of destination IP address 65
10.1.3 Destination IP address 65
10.1.4 Destination password 65
10.1.5 Video transmission 66
10.1.6 Stream 66
10.1.7 Remote port 66
10.1.8 Video output 66
10.1.9 Decoder 67
10.1.10 SSL encryption 67
10.1.11 Auto-connect 67
10.1.12 Audio 67
10.2 Video Content Analyses (VCA) 68
10.3 Audio Alarm 69
10.3.1 Audio alarm 69
10.3.2 Name 69
10.3.3 Signal Ranges 69
10.3.4 Threshold 69
10.3.5 Sensitivity 69
10.4 Alarm E-Mail 70
10.4.1 Send alarm e-mail 70
10.4.2 Mail server IP address 70
10.4.3 SMTP user name 70
10.4.4 SMTP password 70
10.4.5 Format 70
10.4.6 Image size 70
10.4.7 Attach JPEG from camera 71
10.4.8 Destination address 71
10.4.9 Sender name 71
Camera Browser
Interface Table of Contents | en 7
Bosch Security Systems 2015.01 | v1.59x | AM18-Q0676

10.4.10 Test e-mail 71
10.5 Alarm Task Editor 72
11 Setting up VCA 73
11.1 VCA - Silent VCA 73
11.2 VCA - Profiles 74
11.2.1 Aggregation time [s] 74
11.2.2 Analysis type 74
11.2.3 Motion detector 75
11.2.4 Tamper detection 76
11.3 VCA - Scheduled 80
11.3.1 Weekdays 80
11.3.2 Holidays 80
11.4 VCA - Event triggered 82
11.4.1 Trigger 82
11.4.2 Trigger active 82
11.4.3 Trigger inactive 82
11.4.4 Delay [s] 82
12 Interfaces 83
12.1 Alarm input 83
12.1.1 Name 83
12.2 Alarm output 83
12.2.1 Idle state 83
12.2.2 Operating mode 83
12.2.3 Output follows 83
12.2.4 Output name 84
12.2.5 Trigger output 84
12.2.6 Illuminator 84
13 Network 85
13.1 Network Access 85
13.1.1 Automatic IP assignment 85
13.1.2 IP V4 address 85
13.1.3 IP V6 address 86
13.1.4 DNS server address 86
13.1.5 Video transmission 86
13.1.6 HTTP browser port 86
8en | Table of Contents Camera Browser
Interface
2015.01 | v1.59x | AM18-Q0676 Bosch Security Systems

13.1.7 HTTPS browser port 86
13.1.8 RCP+ port 1756 87
13.1.9 Telnet support 87
13.1.10 Interface mode ETH 87
13.1.11 Network MSS [Byte] 87
13.1.12 iSCSI MSS [Byte] 88
13.1.13 Network MTU [Byte] 88
13.2 DynDNS 89
13.2.1 Enable DynDNS 89
13.2.2 Provider 89
13.2.3 Host name 89
13.2.4 User name 89
13.2.5 Password 89
13.2.6 Force registration now 89
13.2.7 Status 90
13.3 Advanced 91
13.3.1 Cloud-based Services 91
13.3.2 RTSP port 91
13.3.3 Authentication (802.1x) 91
13.3.4 TCP metadata input 91
13.4 Network Management 92
13.4.1 SNMP 92
13.4.2 UPnP 92
13.4.3 Quality of Service 93
13.5 WLAN 94
13.6 Multicast 95
13.6.1 Enable 95
13.6.2 Multicast Address 95
13.6.3 Port 96
13.6.4 Streaming 96
13.6.5 Multicast packet TTL 96
13.7 Image Posting 97
13.7.1 JPEG posting 97
13.8 Accounts 98
13.9 IPv4 Filter 99
Camera Browser
Interface Table of Contents | en 9
Bosch Security Systems 2015.01 | v1.59x | AM18-Q0676

14 Service 100
14.1 Maintenance 100
14.1.1 Update server 100
14.1.2 Firmware 100
14.1.3 Upload History 101
14.1.4 Configuration 101
14.1.5 SSL certificate 101
14.1.6 Maintenance log 102
14.2 System Overview 103
15 Appendices 104
15.1 Copyright notices 104
10 en | Table of Contents Camera Browser
Interface
2015.01 | v1.59x | AM18-Q0676 Bosch Security Systems

Browser connection
A computer with Microsoft Internet Explorer is used to receive
live images, control the unit, and replay stored sequences. The
unit is configured over the network using the browser.
System requirements
– Network access (Intranet or Internet)
– Microsoft Internet Explorer version 9 (32-bit)
– Screen resolution at least 1024 × 768 pixels
– 16- or 32-bit color depth
– JVM installed
The Web browser must be configured to enable Cookies from
the IP address of the unit.
In Windows Vista, deactivate protected mode on the Security
tab under Internet Options.
To play back live video images, an appropriate ActiveX must be
installed on the computer. If necessary, install
Bosch Video Client. This can be downloaded from the following
address:
http://downloadstore.boschsecurity.com/
Establishing the connection
The unit must have a valid IP address to operate on your
network and a compatible subnet mask. By default, DHCP is pre-
set at the factory to On and so your DHCP server assigns an IP
address. With no DHCP server the default address is
192.168.0.1
1. Start the Web browser.
2. Enter the IP address of the unit as the URL.
3. During initial installation, confirm any security questions
that appear.
1
1.1
1.2
Camera Browser
Interface Browser connection | en 11
Bosch Security Systems 2015.01 | v1.59x | AM18-Q0676

Note:
If you cannot connect, the unit may have reached its maximum
number of connections. Depending on the device and network
configuration, each unit can have up to 50 web browser
connections, or up to 100 connections via Bosch Video Client or
Bosch Video Management System.
Password protection in camera
A unit offers the option of limiting access across various
authorization levels. If the unit is password-protected, a
message to enter the password appears.
1. Enter the user name and the associated password in the
appropriate fields.
2. Click OK. If the password is correct, the desired page is
displayed.
Protected network
If a RADIUS server is used for network access control (802.1x
authentication), the unit must be configured first. To configure
the unit, connect it directly to a computer using a network cable
and configure the two parameters, Identity and Password. Only
after these have been configured can communication with the
unit via the network occur.
1.2.1
1.3
12 en | Browser connection Camera Browser
Interface
2015.01 | v1.59x | AM18-Q0676 Bosch Security Systems

System overview
When a connection is established, the LIVE page is initially
displayed. The application title bar displays three items: LIVE,
PLAYBACK, SETTINGS.
Note:
The PLAYBACK link is only visible if a storage medium has been
configured for recording. (With VRM recording this option is not
active.)
Live page
The LIVE page is used to display the live video stream and
control the unit.
Playback
The PLAYBACK page is used for playing back recorded
sequences.
Settings
The SETTINGS page is used to configure the unit and the
application interface.
2
2.1
2.2
2.3
Camera Browser
Interface System overview | en 13
Bosch Security Systems 2015.01 | v1.59x | AM18-Q0676

Operation via the browser
Live page
After the connection is established, the LIVE page is initially
displayed. It shows the live video image on the right of the
browser window. Depending on the configuration, various text
overlays may be visible on the live video image.
Other information may also be shown next to the live video
image. The items shown depend on the settings on the LIVE
Functions page.
Image selection
Figure 3.1: Live page
Click a tab below the video image to display a camera image
stream.
3
3.1
3.1.1
14 en | Operation via the browser Camera Browser
Interface
2015.01 | v1.59x | AM18-Q0676 Bosch Security Systems

Digital I/O
The alarm input and the PIR alarm indicators are displayed in
the Digital I/O pane next to the image. These alarm symbols
light when an alarm input is detected or when the PIR sensor
detects movement.
The camera alarm Output 1 symbol allows the operation of an
external device (for example, a light or a door opener).
4To operate the alarm output, click the Output 1 relay
symbol.
The symbol is red when the output is activated.
The PIR detector can also be used to trigger the alarm output.
Refer to Output follows, page 83 to set up this function.
The white LED illuminator is switched on and off using the
illuminator symbol.
4To operate the illuminator, click the Illumination relay
symbol.
The symbol is red when the illuminator is activated.
The white LED illuminator can also be switched on and off by
various events, including PIR movement detection. Refer to
Output follows, page 83 to set up this function.
System Log / Event Log
The System Log field contains information about the operating
status of the camera and the connection.
Events such as the triggering or the end of alarms are shown in
the Event Log field.
1. To view, filter and save these messages to a file, click
in the top right-hand corner.
2. To clear the log, click in the top right-hand corner of
the relevant field.
3.1.2
3.1.3
Camera Browser
Interface Operation via the browser | en 15
Bosch Security Systems 2015.01 | v1.59x | AM18-Q0676

Saving snapshots
Individual images from the video sequence that is currently
being shown can be saved in JPEG format on the computer's
hard drive.
4Click the camera icon to save a single image.
The storage location depends on the configuration of the
camera.
Recording video sequences
Sections of the video sequence that is currently being shown on
the LIVE page can be saved on the computer's hard drive. The
sequences are recorded at the resolution specified in the
encoder configuration. The storage location depends on the
configuration of the camera.
1. Click the recording icon to record video sequences.
– Saving begins immediately. The red dot on the icon
indicates that a recording is in progress.
2. Click the recording icon again to stop recording.
Play back saved video sequences using the Player from
Bosch Security Systems.
Recording status
The hard drive icon below the camera images on the LIVE page
changes during an automatic recording.
The icon lights up and displays a moving graphic to
indicate a running recording. If no recording is taking place, a
static icon is displayed.
Audio communication
Audio can be sent and received via the LIVE page if the unit and
the computer support audio.
3.1.4
3.1.5
3.1.6
3.1.7
16 en | Operation via the browser Camera Browser
Interface
2015.01 | v1.59x | AM18-Q0676 Bosch Security Systems

1. Press and hold the F12 key on the keyboard to send an
audio signal to the unit.
2. Release the key to stop sending audio.
All connected users receive audio signals sent from the unit but
only the user who first pressed the F12 key can send audio
signals; others must wait for the first user to release the key.
Storage, CPU and network status
When accessing the unit with a browser, the local storage,
processor and network status icons are shown in the upper
right of the window next to the Bosch logo.
When a local storage card is available, the memory card icon
changes color (green, orange or red) to indicate the local
storage activity. If you hover over this icon with the mouse the
storage activity is shown as a percentage.
If you hover over the middle icon, the CPU load is shown.
If you hover over the right-hand icon, the network load is shown.
This information can help with problem solving or when fine
tuning the unit. For example:
– if the storage activity is too high, change the recording
profile,
– if the CPU load is too big, change the IVA settings,
– if the network load is too big, change the encoder profile to
reduce bitrate.
3.1.8
Camera Browser
Interface Operation via the browser | en 17
Bosch Security Systems 2015.01 | v1.59x | AM18-Q0676

Status icons
Various overlays in the video image provide important status
information. The overlays provide the following information:
Decoding error
The frame might show artifacts due to decoding errors.
Alarm flag
Indicates that an alarm has occurred.
Communication error
A communication error, such as a connection failure to the
storage medium, a protocol violation or a timeout, is indicated
by this icon.
Gap
Indicates a gap in the recorded video.
Watermark valid
The watermark set on the media item is valid. The color of the
check mark changes according to the video authentication
method that has been selected.
Watermark invalid
Indicates that the watermark is not valid.
Motion alarm
Indicates that a motion alarm has occurred.
Storage discovery
Indicates that recorded video is being retrieved.
3.1.9
18 en | Operation via the browser Camera Browser
Interface
2015.01 | v1.59x | AM18-Q0676 Bosch Security Systems

Playback
Click PLAYBACK in the application title bar to view, search or
export recordings. This link is only visible if a direct iSCSI or
memory card has been configured for recording. (With VRM
recording this option is not active.)
A collapsible panel on the left of the display has four tabs:
–Track list
–Export
–Search
–Search results
Select the recording number to be shown in the Recording
drop-down menu at the top of the window.
Selecting recordings for playback
To see all saved sequences:
1. Click the track list tab .
2. A list of tracks with a number assigned is displayed. Start
time and stop time, recording duration, number of alarms
and recording type are shown for each track.
3. At the bottom of the window, select the maximum number
of tracks to be displayed in the list.
4. Use the arrow buttons at the bottom to browse the list.
5. To view tracks beginning from a particular time, enter the
time code and click Get Tracks.
6. Click a track. The playback for the selected track starts.
Exporting tracks
1. Select a track in the track list.
2. Click the export tab .
3.2
3.2.1
3.2.2
Camera Browser
Interface Operation via the browser | en 19
Bosch Security Systems 2015.01 | v1.59x | AM18-Q0676

3. The start and stop time are filled-in for the selected track. If
required, change the times.
4. Select a target.
5. Select the original or a condensed speed.
6. Click the save icon .
Note:
The target server address is set on the Network / Accounts
page.
Searching for tracks
1. Click the search tab .
2. Click one of the Search mode options to define the search
parameters.
3. To limit the search to a particular time range, enter the
start and stop times.
4. Click Start Search.
5. The results are shown in the search results tab .
6. Click a result to play it back.
7. Click the search tab again to define a new search.
Controlling playback
The time bar below the video image allows quick orientation.
The time interval associated with the sequence is displayed in
the bar in gray. A green arrow above the bar indicates the
position of the image currently being played back within the
sequence.
The time bar offers various options for navigation in and
between sequences.
3.2.3
3.2.4
20 en | Operation via the browser Camera Browser
Interface
2015.01 | v1.59x | AM18-Q0676 Bosch Security Systems
