Bosch HPC 400 User manual

Operating Instructions
User interface
HPC 400
6 720 810 300-00.2O
EMS 2
6 720 817 986 (2015/07) BD-en
ARUN-TWIN.
data in mm.
500, 600, 750, 900
1194 1754 2154
ARUN-TWIN model:
Standard design
The ARUN-TWIN model is the choice for perfectly tasteful and functional partitioning
of living space. It is convincing with its striking design and high flexibility: variable wall
installation possible with no limitations.
Your advantages: Elegance down to the
last detail guarantees a sophisticated
interior design.
RAL 3005
wine red
VOGEL&NOOT
CLIMATE CONTROL SYSTEMS

6 720 817 986 (2015/07) HPC 400
2 | Contents
Contents
1 Key to symbols and safety instructions . . . . . . . . . . . . 2
1.1 Key to symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.2 General safety instructions . . . . . . . . . . . . . . . . . 3
2 Product information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.1 Range of functions . . . . . . . . . . . . . . . . . . . . . . . . 3
2.2 Function as controller . . . . . . . . . . . . . . . . . . . . . 3
2.3 Declaration of Conformity . . . . . . . . . . . . . . . . . . 4
2.4 Operation after power failure . . . . . . . . . . . . . . . 4
3 Overview of control elements and symbols . . . . . . . . 4
4 Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.1 Selecting a heating circuit for the standard display
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4.2 Setting the operating mode . . . . . . . . . . . . . . . . . 8
4.3 Changing the room temperature . . . . . . . . . . . . . 9
4.4 More settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4.5 Favourite functions . . . . . . . . . . . . . . . . . . . . . . 12
5 Working with the main menu . . . . . . . . . . . . . . . . . . . 13
5.1 Main menu summary . . . . . . . . . . . . . . . . . . . . . 14
5.2 Adapting settings for heating system automatic
mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5.2.1 Heating temperature settings . . . . . . . . . . . . . . 15
5.2.2 Adapting the Time program for heating system
automatic mode . . . . . . . . . . . . . . . . . . . . . . . . 15
5.2.3 Setting the summer/wintertime changeover
threshold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5.2.4 DHW alternating operation settings . . . . . . . . . 19
5.2.5 Setting for heating circuit 1 priority . . . . . . . . . 19
5.3 Changing the settings for DHW heating . . . . . . 20
5.3.1 Setting the operating mode for DHW heating . 20
5.3.2 Setting the time program for DHW heating . . . 20
5.3.3 Extra DHW heating . . . . . . . . . . . . . . . . . . . . . . . 21
5.3.4 Thermal disinfection . . . . . . . . . . . . . . . . . . . . . 21
5.3.5 DHW alternating operation settings . . . . . . . . . 22
5.3.6 Settings for DHW circulation . . . . . . . . . . . . . . . 22
5.4 Settings for a heated swimming pool . . . . . . . . 23
5.5 Additional device (auxiliary heater) settings . . 23
5.5.1 Time program for the additional device . . . . . . 23
5.5.2 Settings for low-noise operation of the additional
device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
5.6 Setting up a holiday program . . . . . . . . . . . . . . 24
5.7 Adapting the settings to hybrid systems . . . . . 27
5.8 Smart grid gain . . . . . . . . . . . . . . . . . . . . . . . . . . 29
5.9 Photovoltaic gain . . . . . . . . . . . . . . . . . . . . . . . . 29
5.10 General settings . . . . . . . . . . . . . . . . . . . . . . . . . 29
6 Calling up information about the system . . . . . . . . . 31
7 Energy saving tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
8 FAQ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
9 Eliminate fault . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
9.1 Eliminating “sensed” faults . . . . . . . . . . . . . . . . 36
9.2 Removing a displayed fault . . . . . . . . . . . . . . . . 38
10 Environment / disposal . . . . . . . . . . . . . . . . . . . . . . . . 40
Technical terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
1 Key to symbols and safety instructions
1.1 Key to symbols
Warnings
The following keywords are defined and can be used in this
document:
•NOTICE indicates a situation that could result in damage to
property or equipment.
•CAUTION indicates a situation that could result in minor to
medium injury.
•WARNING indicates a situation that could result in severe
injury or death.
•DANGER indicates a situation that will result in severe
injury or death.
Warnings in this document are identified by a
warning triangle printed against a grey
background.
Keywords at the start of a warning indicate the
type and seriousness of the ensuing risk if
measures to prevent the risk are not taken.
ARUN-TWIN.
data in mm.
500, 600, 750, 900
1194 1754 2154
ARUN-TWIN model:
Standard design
The ARUN-TWIN model is the choice for perfectly tasteful and functional partitioning
of living space. It is convincing with its striking design and high flexibility: variable wall
installation possible with no limitations.
Your advantages: Elegance down to the
last detail guarantees a sophisticated
interior design.
RAL 3005
wine red
VOGEL&NOOT
CLIMATE CONTROL SYSTEMS

6 720 817 986 (2015/07)HPC 400
Product information | 3
Important information
Additional symbols
1.2 General safety instructions
These instructions are intended for the user of the heating
system
▶ Read the instructions (for heat source, modules etc.)
before use and keep them handy.
▶ Pay attention to the safety and warning instructions.
Intended use
▶ The product should only be used to control heating systems
in one-family houses.
All other use is not suitable. We cannot accept liability for
damages resulting from unauthorised use.
Inspection and maintenance
Regular inspection and maintenance are prerequisites for safe
and environmentally compatible operation of the heating
system.
▶ Have work carried out only by an approved contractor.
▶ If any faults are discovered, have them remedied
immediately.
Damage caused by frost
If the system is not in operation it can freeze:
▶ Follow the instructions to ensure protection from freezing.
▶ Always keep the system switched on for additional
functions, such as heating hot water or protection from
blocking.
▶ Rectify operating faults immediately.
Risk of scalding at the hot water draw-off points
▶ If hot water temperatures above 60 °C are set or if thermal
disinfection is activated, a mixer must be installed. If in
doubt, ask your contractor.
2 Product information
The HPC 400 user interface makes it easy to operate your heat
pump.
Turn the selector to set the required room temperature in your
home. The thermostatic valves at the radiators or the room
thermostats for the underfloor heating system also control the
room temperature. If a room temperature-dependent
controller is present in the reference room, the thermostatic
valves in this room must be replaced by throttle valves.
The optimised way in which they work allows the system to be
operated in an energy-efficient manner. This method of
controlling the heating or cooling system optimises comfort
whilst minimising energy consumption.
DHW heating can be adjusted conveniently and controlled
efficiently.
2.1 Range of functions
The functional scope and thus the menu structure of the user
interface are determined by the structure of the system:
• Settings for a variety of heating/cooling circuits are only
available if two or more heating/cooling circuits are
installed.
• Information about solar systems is only displayed if a solar
system is installed.
• Certain menu items are specific to certain countries and
are only displayed if the country in which the heat pump is
installed has been set accordingly on the user interface.
Your attention is drawn to the importance of the system
structure in the relevant places. The setting ranges and basic
settings are determined by the local system conditions and
may deviate from the information provided in these
instructions.
Consult your contractor if you have further questions.
2.2 Function as controller
The user interface can control up to a maximum of four heating/
cooling circuits. For each heating circuit, either weather-
compensated control or weather-compensated control with
room temperature influence can be set on the user interface.
The main control modes for the heating system are as follows:
•Weather-compensated:
– The room temperature is controlled based on the
outside temperature
– The user interface sets the flow temperature in
accordance with a simplified or optimised heating
curve.
•Weather-compensated with influence of room
temperature:
This symbol indicates important information
where there is no risk to people or property.
Symbol Explanation
▶ Step in an action sequence
Cross-reference to another part of the document
• List entry
– List entry (second level)
Table 1
ARUN-TWIN.
data in mm.
500, 600, 750, 900
1194 1754 2154
ARUN-TWIN model:
Standard design
The ARUN-TWIN model is the choice for perfectly tasteful and functional partitioning
of living space. It is convincing with its striking design and high flexibility: variable wall
installation possible with no limitations.
Your advantages: Elegance down to the
last detail guarantees a sophisticated
interior design.
RAL 3005
wine red
VOGEL&NOOT
CLIMATE CONTROL SYSTEMS

6 720 817 986 (2015/07) HPC 400
4 | Overview of control elements and symbols
– The room temperature is controlled based on the
outside temperature and the measured room
temperature. The remote control influences the flow
temperature based on the measured and required
room temperature.
– The user interface sets the flow temperature in
accordance with a simplified or optimised heating
curve.
2.3 Declaration of Conformity
The design and operation of this product comply
with European Directives and the supplementary
national requirements. Its conformity is
demonstrated by the CE marking .
You can ask for a copy of the declaration of conformity for this
product. For this see the contact address on the back cover of
these instructions.
2.4 Operation after power failure
In the event of a power failure, or periods with disconnected
heat source, no settings are lost. The control unit starts again
when the power returns. It may be necessary to redo the
settings for the time and date. No other settings are necessary.
3 Overview of control elements and symbols
Fig. 1 Control elements
[1] fav key – calls up the favourites menu
[2] extra DHW key – starts once-only DHW charging
[3] DHW key – sets the operating mode for DHW heating
[4] menu key – opens the menu
[5] info key – displays additional information
[6] Back key – switches to the previous menu item
[7] Selector
Rule of thumb for weather-compensated
control with influence of room temperature:
the throttle valves in the reference room (the
room in which a remote control is installed)
must be fully open!
The HMC300 user interface is installed in the
appliance and cannot be used as remote
control. Ask your contractor for available
remote controls.
fav
info
menu
6 720 810 300-01.1O
5
6
7
4
2
3
1
If the display lighting is off, pressing a control
element executes the command in question
and switches the lighting on. When you press
the selector for the first time, only the lighting
is activated (no commands are executed). If no
control element is actuated, the lighting turns
off automatically.
ARUN-TWIN.
data in mm.
500, 600, 750, 900
1194 1754 2154
ARUN-TWIN model:
Standard design
The ARUN-TWIN model is the choice for perfectly tasteful and functional partitioning
of living space. It is convincing with its striking design and high flexibility: variable wall
installation possible with no limitations.
Your advantages: Elegance down to the
last detail guarantees a sophisticated
interior design.
RAL 3005
wine red
VOGEL&NOOT
CLIMATE CONTROL SYSTEMS

6 720 817 986 (2015/07)HPC 400
Overview of control elements and symbols | 5
Fig. 1, page 4
Item Element Designation Explanation
1fav key ▶ Press to call up the favourites menu (favourite functions for heating circuit 1).
▶ Hold down to individually adjust the favourites menu (Chapter 4.5, page 12).
2extra DHW key ▶ Press to activate or deactivate extra DHW (Chapter 4.4, page 10).
3DHW key ▶ Press to select the operating mode for DHW (Chapter 4.4, page 10).
4menu key ▶ Press to open the main menu (Chapter 5, page 13).
5Info key If a menu is open:
▶ Press to call up more information about the current selection.
If the standard display is active:
▶ Press to open the info menu (Chapter 6, page 32).
6Back key ▶ Press to return to the higher menu level or discard a changed value.
If the need for a service or a fault is displayed:
▶ Press to switch between standard display and fault display.
▶ Hold to switch from a menu to the standard display.
7Selector ▶ Turn to change a setting value (e.g. temperature) or select from among the menus or
menu items.
If the lighting is switched off:
▶ Press to switch the lighting on.
If the lighting is switched on:
▶ Press to open a selected menu or menu item, confirm a set value (e.g. temperature)
or a message or to close a pop-up window.
If the standard display is active:
▶ Press to activate the input field for selecting the heating circuit in the standard
display (systems with at least two heating circuits only, Chapter 4.1, page 8).
Table 2 Control elements
fav
menu
info
ARUN-TWIN.
data in mm.
500, 600, 750, 900
1194 1754 2154
ARUN-TWIN model:
Standard design
The ARUN-TWIN model is the choice for perfectly tasteful and functional partitioning
of living space. It is convincing with its striking design and high flexibility: variable wall
installation possible with no limitations.
Your advantages: Elegance down to the
last detail guarantees a sophisticated
interior design.
RAL 3005
wine red
VOGEL&NOOT
CLIMATE CONTROL SYSTEMS

6 720 817 986 (2015/07) HPC 400
6 | Overview of control elements and symbols
Fig. 2 Example for a standard display of a system with more than one heating circuit
[1] Temperature
[2] Information line
[3] Outside temperature
[4] Text information
[5] Key lock
[6] Information graphic
[7] Mode
6 720 811 136-901.1O
6
1
3
7
2
4
5
5
Fig. 2, page 6
Item Symbol Designation Explanation
1– Temperature • Displays theheat source flow temperature or
• the room temperature if a remote control is installed for the displayed heating
circuit.
2– Information line Display of time of day, day of the week and date.
3Additional
temperature
display
Display of an additional temperature: outside temperature, temperature of the
solar collector or a DHW system (for further information page 30).
4– Text information E.g. the designation of the temperature currently displayed (Fig. 2, [1]). If a
fault is present, corresponding information will be displayed here until the fault
has been rectified.
5Key lock When the key is displayed, this means that the key lock is enabled (page 10,
Table 7).
Table 3 Symbols on the standard display
ARUN-TWIN.
data in mm.
500, 600, 750, 900
1194 1754 2154
ARUN-TWIN model:
Standard design
The ARUN-TWIN model is the choice for perfectly tasteful and functional partitioning
of living space. It is convincing with its striking design and high flexibility: variable wall
installation possible with no limitations.
Your advantages: Elegance down to the
last detail guarantees a sophisticated
interior design.
RAL 3005
wine red
VOGEL&NOOT
CLIMATE CONTROL SYSTEMS

6 720 817 986 (2015/07)HPC 400
Overview of control elements and symbols | 7
6Information
graphic
Information graphics are displayed in this section. These provide information
about what is currently active in the system.
DHW heating active
Thermal disinfection (DHW) active
Extra DHW active
Swimming pool is being heated
Heating active
Cooling active
Interruption by energy supplier
External switching contact closed (remote)
Holiday function active
Time program - program 1 or 2 for heating active
Function for smart grid activated
Screed drying active
Electric booster heater active
Power guard active
Additional device (auxiliary heater) active
Defrost function active
Heat pump running
Solar pump running
7 Optimise Mode
Program 1 The heating system follows the active time program for the corresponding heating
circuit. The heating system switches between heating mode and setback mode at
the times set.
Program 2
Heating mode in the displayed heating circuit active
Setback mode in the displayed heating circuit active
Fig. 2, page 6
Item Symbol Designation Explanation
Table 3 Symbols on the standard display
ARUN-TWIN.
data in mm.
500, 600, 750, 900
1194 1754 2154
ARUN-TWIN model:
Standard design
The ARUN-TWIN model is the choice for perfectly tasteful and functional partitioning
of living space. It is convincing with its striking design and high flexibility: variable wall
installation possible with no limitations.
Your advantages: Elegance down to the
last detail guarantees a sophisticated
interior design.
RAL 3005
wine red
VOGEL&NOOT
CLIMATE CONTROL SYSTEMS

6 720 817 986 (2015/07) HPC 400
8 | Getting started
4 Getting started
An overview of the structure of the main menu and the position
of the individual menu items can be found on page 13.
Each of the following descriptions takes the standard display as
its starting point (page 2, Fig. 6 at left).
4.1 Selecting a heating circuit for the standard
display
The standard display only ever shows data for a single heating
circuit. If two or more heating circuits are installed, a setting
can be made to determine which heating circuit the data in the
standard display relates to.
4.2 Setting the operating mode
An explanation of the technical terms “operating mode”,
“automatic mode” and “optimised operation” can be found on
page 41 and 42. Optimised operation is enabled by default.
There are no time programs for this operating mode. The
thermostatic valves/room thermostats control each room
individually so that heat is supplied individually, as required.
This avoids extended heat-up phases (e.g. following setback
mode) and allows for efficient operation.
Operating the appliance Result
▶ When the lighting is turned on, press the selector.
The number, operating mode and if applicable the name of the heating circuit that is
currently selected are shown in the lower part of the display.
▶ Turn the selector to select a heating circuit.
Only heating circuits that exist in the system are displayed for selection.
▶ Wait a few seconds or press the selector.
The standard display refers to the heating circuit selected.
Table 4 Getting started – Heating circuit in the standard display
6 720 812 775-02.2O
Operating the appliance Result
To activate automatic mode (by taking account of the time program),
▶ Press the menu key to open the main menu.
▶ Press the selector to open the Heating/Cooling menu.
▶ Press the selector to open the Operating mode menu.
▶ If two or more heating circuits are installed, turn the selector to highlight Heating
circuit 1, 2, 3or 4and press the selector.
▶ Turn the selector to highlight Auto and press the selector.
▶ Press and hold the Back key to return to the standard display.
All temperatures set in the currently valid time program for the heating system are
shown in a pop-up window in the lower part of the display. The currently valid
temperature flashes.
The user interface controls the room temperature according to the active time
program for the heating system.
Table 5 Getting started – Activating operating modes
6 720 812 775-03.1O
ARUN-TWIN.
data in mm.
500, 600, 750, 900
1194 1754 2154
ARUN-TWIN model:
Standard design
The ARUN-TWIN model is the choice for perfectly tasteful and functional partitioning
of living space. It is convincing with its striking design and high flexibility: variable wall
installation possible with no limitations.
Your advantages: Elegance down to the
last detail guarantees a sophisticated
interior design.
RAL 3005
wine red
VOGEL&NOOT
CLIMATE CONTROL SYSTEMS

6 720 817 986 (2015/07)HPC 400
Getting started | 9
4.3 Changing the room temperature
To activate optimised operation (without time program, default setting)
▶ Press the menu key to open the main menu.
▶ Press the selector to open the Heating/Cooling menu.
▶ Press the selector to open the Operating mode menu.
▶ If two or more heating circuits are installed, turn the selector to highlight Heating
circuit 1, 2, 3or 4and press the selector.
▶ Turn the selector to highlight Optimise and press the selector.
▶ Press and hold the Back key to return to the standard display.
The required room temperature is shown in a pop-up window in the lower part of the
display. The user interface will now constantly maintain the required room
temperature.
Operating the appliance Result
If it is too cold or too warm for you today: Change the room temperature temporarily
Automatic mode
Changing the room temperature until the next switching time
▶ Turn the selector to set the required room temperature.
The corresponding time slot is displayed in grey in the time program bar chart.
▶ Wait a few seconds or press the selector.
The user interface operates with the modified setting. The change applies until
the next switching time in your heating system time program is reached. After
this, the time program settings are restored.
Undoing a temperature change
▶ Turn the selector until the corresponding time slot turns back to black in the time
program bar chart and press the selector.
The change is undone.
Should it be permanently too cold or too hot for you: Set the required room temperature
Optimised operation
▶ Activate optimised operation (Chapter 4.2).
▶ Wait a few seconds or press the selector to close the pop-up window.
▶ Turn the selector to set the required room temperature.
▶ Wait a few seconds or press the selector. Press the selector to confirm the
change in the pop-up window (or press the back key to discard the change).
The room temperature that is currently valid is shown in a pop-up window in the
lower part of the display.
The user interface operates with the modified settings.
Table 6 Getting started – Room temperature
Operating the appliance Result
Table 5 Getting started – Activating operating modes
6 720 812 775-04.1O
6 720 812 775-05.1O
6 720 812 775-06.1O
ARUN-TWIN.
data in mm.
500, 600, 750, 900
1194 1754 2154
ARUN-TWIN model:
Standard design
The ARUN-TWIN model is the choice for perfectly tasteful and functional partitioning
of living space. It is convincing with its striking design and high flexibility: variable wall
installation possible with no limitations.
Your advantages: Elegance down to the
last detail guarantees a sophisticated
interior design.
RAL 3005
wine red
VOGEL&NOOT
CLIMATE CONTROL SYSTEMS

6 720 817 986 (2015/07) HPC 400
10 | Getting started
4.4 More settings
Automatic mode
▶ Press the menu key to open the main menu.
▶ Press the selector to open the Heating/Cooling menu.
▶ Turn the selector to highlight the Temperature settings menu.
▶ Press the selector to open the menu.
▶ If two or more heating circuits are installed, turn the selector to highlight
Heating circuit 1, 2, 3or 4and press the selector.
▶ Turn the selector to highlight Heating, Setback or Cooling.
▶ Press the selector.
▶ Turn the selector and press it to activate the required setting, e.g. for setback
mode.
▶ Turn and press the selector to set the temperature. The limits of the setting
values for the temperatures are determined by the settings for the other
operating mode in each case.
The user interface operates with the modified settings. The settings are applied
to all time programs for the heating system (if two or more heating circuits are
installed, it is only applied in the selected heating circuit).
Operating the appliance Result
If you need hot water outside of the times set in the time program: Activate extra DHW (= immediate DHW function).
▶ Press the extra DHW key.
DHW heating is active immediately with the set temperature and for the set duration.
After a few seconds, the symbol for extra DHW will be displayed in the information
graphic (Extra hot water settings Chapter 5.3.3, page 21).
To deactivate the extra DHW function before the end of the set duration:
▶ Press the extra DHW key again.
If the DHW is too cold or too hot for you: Change the DHW heating operating mode
▶ Press the DHW key.
The user interface will display a list of the DHW heating operating modes (for more
information Chapter 5.3.1, page 20).
▶ Turn the selector to highlight the required operating mode.
▶ Press the selector.
The user interface operates with the modified settings. Your contractor can set the
temperatures for the DHW and DHW reduced operating modes.
If optimised mode is active, the temperature will not be changed.
Table 7 Getting started – More settings
Operating the appliance Result
Table 6 Getting started – Room temperature
6 720 811 136-07.1O
6 720 811 136-08.1O
6 720 812 775-09.1O
6 720 811 136-10.1O
ARUN-TWIN.
data in mm.
500, 600, 750, 900
1194 1754 2154
ARUN-TWIN model:
Standard design
The ARUN-TWIN model is the choice for perfectly tasteful and functional partitioning
of living space. It is convincing with its striking design and high flexibility: variable wall
installation possible with no limitations.
Your advantages: Elegance down to the
last detail guarantees a sophisticated
interior design.
RAL 3005
wine red
VOGEL&NOOT
CLIMATE CONTROL SYSTEMS

6 720 817 986 (2015/07)HPC 400
Getting started | 11
Setting the date and time
If the user interface has been disconnected from the power supply for a prolonged
period, will prompt the user to enter the date and time and then changes into normal
operation.
▶ Restore the power supply.
The user interface displays the setting for the date.
▶ Turn the selector to set the day, month and year.
Continue is highlighted in the display.
▶ Press the selector.
▶ Set the time in the same way as the date.
Continue is highlighted in the display.
▶ Press the selector.
The user interface operates with the modified settings. No other settings are required
to recommission the user interface.
To prevent the settings for the user interface from being modified inadvertently:
Activate or deactivate key lock (child lock, page 42)
▶ Press and hold down the DHW key and the selector for a few seconds to activate or
deactivate the key block.
When the key lock is enabled, the key symbol appears in the display (Fig. 2 [5],
page 6).
To change the language of the display texts: Set language
▶ Press the menu key to open the main menu.
▶ Turn the selector to highlight Settings.
▶ Press the selector to open the Settings menu.
▶ Press the selector.
▶ Turn the selector to select a language.
▶ Press the selector.
The user interface operates with the modified settings.
If your day/night pattern changes (e.g. if you work shifts): Adapt time program
In the Heating/Cooling > Time program menu, the time program can be adapted to suit
your personal lifestyle habits or circumstances in just a few easy steps (Chapter 5.2.2,
page 15).
Operating the appliance Result
Table 7 Getting started – More settings
6 720 811 136-11.2O
6 720 811 136-12.1O
6 720 811 136-13.1O
6 720 815 237-14.1O
ARUN-TWIN.
data in mm.
500, 600, 750, 900
1194 1754 2154
ARUN-TWIN model:
Standard design
The ARUN-TWIN model is the choice for perfectly tasteful and functional partitioning
of living space. It is convincing with its striking design and high flexibility: variable wall
installation possible with no limitations.
Your advantages: Elegance down to the
last detail guarantees a sophisticated
interior design.
RAL 3005
wine red
VOGEL&NOOT
CLIMATE CONTROL SYSTEMS

6 720 817 986 (2015/07) HPC 400
12 | Getting started
4.5 Favourite functions
Via the fav key you have direct access to often used functions
for heating circuit 1. The first pressing of the fav key opens the
menu for configuring the favourites menu. There you can add
your personal favourites and if necessary later adapt the
favourites menu to your requirements.
The function of the fav key is independent of the heating circuit
displayed in the standard display. Settings changes via the
favourites menu always apply only to heating circuit 1.
Operating the appliance Result
To access a favourite function: Open the favourites menu
▶ In order to open the favourites menu, press the fav key.
▶ Turn the selector and press to select a favourite function.
▶ Change the setting (procedure is the same as when making a setting in the main
menu).
To adapt the list of favourites to meet your requirements: Select favourite functions
▶ Press and hold down the fav key until the menu for configuring the favourites menu is
displayed.
▶ Turn and press the selector to select a function (Yes) or to cancel your selection (No).
The changes are effective immediately.
▶ Press the Back key to close the menu.
Table 8 Getting started – Favourite functions
6 720 811 136-15.1O
ARUN-TWIN.
data in mm.
500, 600, 750, 900
1194 1754 2154
ARUN-TWIN model:
Standard design
The ARUN-TWIN model is the choice for perfectly tasteful and functional partitioning
of living space. It is convincing with its striking design and high flexibility: variable wall
installation possible with no limitations.
Your advantages: Elegance down to the
last detail guarantees a sophisticated
interior design.
RAL 3005
wine red
VOGEL&NOOT
CLIMATE CONTROL SYSTEMS

6 720 817 986 (2015/07)HPC 400
Working with the main menu | 13
5 Working with the main menu
Fig. 3 Menu structure of the main menu
1) Not available if Sweden or Finland is set as the country
(for the contractor only).
Main menu
Heating/Cooling Extra hot water Holiday
Operating mode Start now Hybrid system
Temperature settings Cancel Energy:price ratio
Heating Temperature Smart Grid
Setback Duration Heating
Cooling Thermal disinfection Selectable peak
Time program Start Forced peak
Activate time program Start now DHW
My time program 1 Cancel Selectable peak
Reset prog. Temperature PV system
My time program 2 Day Heating peak
Reset prog. Time of day DHW peak
Rename heating circuit Max. period Settings
Rename time program DHW alternating operation Language
Sum./wint. changeover DHW alternating operation Time format
Heating/Cooling DHW priority for Time of day
Heating mode from Prioritise heating for Date format
Cooling mode from Circulation
1)
Date
DHW alternating operation Operating mode Autom. time changeover
DHW alternating operation Start frequency Display contrast
DHW priority for My DHW circltn time prog. Warning sound
Prioritise heating for Pool Room temp. sen. adj.
Priority heating circuit 1 Activate pool heating DHW temperature
DHW Pool temperature Time correction
Operating mode Allow additional heat in pool Standard display
Time program Device Internet password
My DHW time program Time program additional Reset
Reset prog. Time program Activate Reset settings
My time program Reset service messages
Reset time program
Time program min. outdoor
Low-noise operation
Low-noise operation
Min. outdoor temperature
6 720 811 136-101.3O
ARUN-TWIN.
data in mm.
500, 600, 750, 900
1194 1754 2154
ARUN-TWIN model:
Standard design
The ARUN-TWIN model is the choice for perfectly tasteful and functional partitioning
of living space. It is convincing with its striking design and high flexibility: variable wall
installation possible with no limitations.
Your advantages: Elegance down to the
last detail guarantees a sophisticated
interior design.
RAL 3005
wine red
VOGEL&NOOT
CLIMATE CONTROL SYSTEMS

6 720 817 986 (2015/07) HPC 400
14 | Working with the main menu
5.1 Main menu summary
If two or more heating/cooling circuits are installed in the
system, an additional selection must be made in some menus:
▶ Turn the selector to select the heating circuit for which the
settings are being changed.
▶ Press the selector to display the menu.
Menu Purpose of the menu page
Heating/Cooling Change the operating mode, room temperatures and time program for the heating system
permanently.
15
Operating mode Select the heating operating mode, based on a time program or optimised. 4
Temperature
settings
Set the required room temperatures that can be assigned to the periods in the time
program, e.g. with heating and setback mode or cooling mode.
15
Time program Switch between heating and setback mode at defined times of day and on defined days of
the week (automatic mode). Separate time programs can be used for DHW and circulation.
Heating circuits and time programs are renamed in this menu.
15
Sum./wint.
changeover
Switch automatically between summer mode (heating off or cooling), winter mode (heating
on) or automatic mode (sometimes subject to outside temperature).
19
DHW alternating
operation
If DHW alternating operation is activated, the heat generated by the heat pump is used
alternately for heating and DHW heating.
19
Priority heating
circuit 1
Heating circuit 1 determines how the system behaves. If there is no heat requirement for
heating circuit 1, no heat requirements for other circuits are handled either.
19
DHW Change the water temperatures and time program for DHW heating permanently. 19
Operating mode Select the DHW heating operating mode, e.g. based on a time program or always on. 20
Time program Switch between DHW, reduced DHW heating and no DHW heating operating modes at
defined times of day and on defined days of the week (automatic mode).
20
Extra hot water Change the temperature and duration of the extra DHW function. 21
Thermal disinfection Heat up DHW to kill off pathogens. 21
DHW alternating
operation
If DHW alternating operation is activated, the heat generated by the heat pump is used
alternately for heating and DHW heating.
22
Circulation1)
1) Not available if Sweden or Finland is set as the country (for the contractor only).
Set time program for DHW circulation so that DHW is available without delay at the draw-off
points.
22
Pool Settings for operating a heated swimming pool. 23
Device Settings for operating an auxiliary heater (electric/gas/oil/solid fuel). 23
Time program
additional heat
The time program for the auxiliary heater specifies the periods during which additional heat
can be generated by the auxiliary heater.
23
Low-noise operation Settings for reducing noise emissions from the heat pump 24
Holiday Settings for operating the system during prolonged periods of absence (holiday program). 24
Hybrid system Set the energy/price ratio. 28
Smart Grid Use energy from the “smart grid” for heating or DHW heating. 29
Heating Temperature setting for forced or selectable peak 29
DHW Switch selectable peak on and off 29
PV system Use energy generated by the photovoltaic system for heating or DHW heating. 29
Settings Change general settings such as time, date, display contrast, etc. or restore settings saved
by the contractor.
30
Table 9 Main menu summary
ARUN-TWIN.
data in mm.
500, 600, 750, 900
1194 1754 2154
ARUN-TWIN model:
Standard design
The ARUN-TWIN model is the choice for perfectly tasteful and functional partitioning
of living space. It is convincing with its striking design and high flexibility: variable wall
installation possible with no limitations.
Your advantages: Elegance down to the
last detail guarantees a sophisticated
interior design.
RAL 3005
wine red
VOGEL&NOOT
CLIMATE CONTROL SYSTEMS

6 720 817 986 (2015/07)HPC 400
Working with the main menu | 15
5.2 Adapting settings for heating system
automatic mode
Menu: Heating/Cooling
Optimised operation (without a time program) is active for
each heating circuit by default. If required, the user can change
the setting and select the time-dependent automatic mode. A
constant room temperature value can be specified for cooling
mode.
Heating circuit 1 ... 4
If more than one heating circuit has been installed and
configured, the settings for heating circuits 1 ... 4 are changed
in the same way as for systems with one heating circuit.
However, changes are valid only for the selected heating
circuit. Assigning unique names to heating circuits makes it
much easier to make the right selection.
5.2.1 Heating temperature settings
The temperatures for the various operating modes can be set in
this menu. Depending on whether the user interface is working
in automatic mode or in optimised operation, the temperatures
have an effect on how the system is controlled.
Menu: Temperature settings
5.2.2 Adapting the Time program for heating system
automatic mode
The time program is only active for the heating system if
automatic mode is active (Chapter 4.2, page 8).
To set the same switching times for multiple days of the week:
▶ Set switching times for a group of days, e.g.
Mon-Sun or Mon-Fri.
▶ Adjust the time program for the specific days of the week
for which different settings are required under Monday ...
Sunday (detailed description Tab. 13, page 16).
Menu: Time program
The time program ensures automatic changeover between
operating modes at defined switching times. The user interface
has two time programs for each heating circuit. Two switching
times per day can be programmed, each with an operating
mode. The default settings for the time programs provide lower
heating overnight. Optimized mode provides the most
economic heating for both day and night.
If the settings, temperatures or switching times of the time
program do not meet your needs, you can adapt the time
program. If you do not require heating overnight, speak to your
contractor. He has access to additional settings for configuring
setback mode.
Menu item description
Heating If automatic mode is active, the room
temperature is maintained at the value
set here for the specified time slots with
the Heating operating mode.
Setback If automatic mode is active and a
temperature has been set here, the room
temperature is maintained at the value
set here for the specified time slots with
the Setback operating mode. If heating is
switched off here, no heating will occur
during these time slots.
Cooling If a heating/cooling circuit is installed, the
room temperature is maintained at the
value set here for the Cooling operating
mode.
Table 10 Heating system temperature settings
Menu item description
Activate time
program
Activating automatic mode triggers
control of the room temperature
according to the settings in the selected
time program (My time program 1 or My
time program 2).
My time
program 1
2 switching times can be set for each day
or group of days. One of the two
operating modes can be assigned to each
switching time in automatic mode. The
minimum duration of a time slot between
two switching times is 15 minutes.
Reset prog. Here My time program 1 can be reset to
the default settings.
My time
program 2
My time program 1
Reset prog. Here My time program 2 can be reset to
the default settings.
Rename heating
circuit
The name of the selected heating circuit
can be customised here (only available if
more than one heating circuit is
installed). This helps to select the correct
heating circuit, e.g. “underfloor heating
system” or “attic apartment”. The names
are set by default to Heating circuit 1 ...
4(Tab. 14, page 18).
Rename time
program
The names of the time programs can be
changed in the same way as the names of
the heating circuits. This helps to select
the correct time program, e.g. “family” or
“night shift”.
Table 11 Time program settings for heating
ARUN-TWIN.
data in mm.
500, 600, 750, 900
1194 1754 2154
ARUN-TWIN model:
Standard design
The ARUN-TWIN model is the choice for perfectly tasteful and functional partitioning
of living space. It is convincing with its striking design and high flexibility: variable wall
installation possible with no limitations.
Your advantages: Elegance down to the
last detail guarantees a sophisticated
interior design.
RAL 3005
wine red
VOGEL&NOOT
CLIMATE CONTROL SYSTEMS

6 720 817 986 (2015/07) HPC 400
16 | Working with the main menu
The following table shows you how to activate and select time
programs for the heating system.
The following table shows you how to adapt a time program for the heating system.
Operating the appliance Result
Select active time program for the heating system
▶ If the standard display is active, press the menu key briefly to open or close the main
menu.
▶ Press the selector to open the Heating/Cooling menu.
▶ Turn the selector to highlight Time program.
▶ Press the selector to open the Time program menu.
Activate time program is highlighted. Depending on the installed system, it may be
necessary to select a heating circuit.
▶ Press the selector.
▶ Turn the selector to highlight My time program 1 or 2and press the selector.
The user interface operates in automatic mode with the selected time program (if two
or more heating circuits are installed, it only operates in the selected heating circuit).
Table 12 Activating and selecting time programs for the heating system
Operating the appliance Result
Open the menu for adapting a time program for the heating system
▶ If the standard display is active, press the menu key briefly to open or close the main
menu.
▶ Press the selector to open the Heating/Cooling menu.
▶ Turn the selector to highlight Time program.
▶ Press the selector to open the Time program menu.
▶ Turn the selector to highlight My time program 1 or 2.
Depending on the installed system, it may be necessary to select a heating circuit.
▶ Press the selector.
▶ Press the selector again to activate the input field for the day of the week or the group
of days.
▶ Turn the selector to select a day of the week or a group of days and press the selector.
The changes in this menu only affect the selected day of the week or the selected
group of days.
Table 13 Adapting time program to suit individual preferences
6 720 811 136-16.1O
6 720 811 136-17.1O
6 720 811 136-18.1O
6 720 815 237-28.1O
ARUN-TWIN.
data in mm.
500, 600, 750, 900
1194 1754 2154
ARUN-TWIN model:
Standard design
The ARUN-TWIN model is the choice for perfectly tasteful and functional partitioning
of living space. It is convincing with its striking design and high flexibility: variable wall
installation possible with no limitations.
Your advantages: Elegance down to the
last detail guarantees a sophisticated
interior design.
RAL 3005
wine red
VOGEL&NOOT
CLIMATE CONTROL SYSTEMS

6 720 817 986 (2015/07)HPC 400
Working with the main menu | 17
The following table shows you how to change the names of heating circuits, for example.
Move switching time
▶ Open the menu for adapting a time program for the heating system.
▶ Turn the selector to highlight a switching time.
▶ Press the selector to activate the input field for the switching time.
▶ Turn the selector to move the switching time.
The modified time slot is displayed in grey in the time program bar chart.
▶ Press the selector.
The user interface operates with the modified settings.
Set the temperature for a time slot
▶ Open the menu for adapting a time program for the heating system (page 16).
▶ Turn the selector to highlight the operating mode of a time slot.
▶ Press the selector to activate the input field for the operating mode.
▶ Turn the selector to select an operating mode (heating or setback).
The modified time slot is displayed in grey in the time program bar chart.
▶ Press the selector.
The user interface operates with the modified settings.
Copy time program (e.g. transfer time program from Thursday to Monday and Tuesday)
▶ Open the menu for adapting a time program for the heating system (page 16) and
select the day of the week to be copied, e.g. Thursday.
▶ Turn the selector to highlight Copy.
▶ Press the selector.
A list of days of the week for which the time program should be overwritten with the
selected day of the week is displayed for you to make a selection.
▶ Turn and press the selector to select the day of the week, e.g. Monday and Tuesday.
▶ Turn the selector to highlight Copy and press the selector.
▶ The time program that has been copied is displayed in a pop-up window.
▶ Press the selector to close the pop-up window.
The user interface operates with the modified settings.
Operating the appliance Result
Table 13 Adapting time program to suit individual preferences
6 720 815 237-29.1O
6 720 815 237-30.1O
6 720 815 237-34.1O
6 720 811 136-23.1O
ARUN-TWIN.
data in mm.
500, 600, 750, 900
1194 1754 2154
ARUN-TWIN model:
Standard design
The ARUN-TWIN model is the choice for perfectly tasteful and functional partitioning
of living space. It is convincing with its striking design and high flexibility: variable wall
installation possible with no limitations.
Your advantages: Elegance down to the
last detail guarantees a sophisticated
interior design.
RAL 3005
wine red
VOGEL&NOOT
CLIMATE CONTROL SYSTEMS

6 720 817 986 (2015/07) HPC 400
18 | Working with the main menu
Operating the appliance Result
Call the menu for renaming a heating circuit (or the time programs)
▶ If the standard display is active, press the menu key briefly to open or close the main
menu.
▶ Press the selector to open the Heating/Cooling menu.
▶ Turn the selector to highlight Time program.
▶ Press the selector to open the Time program menu.
▶ Turn the selector to highlight Rename heating circuit (only available if two or more
heating circuits are installed) or Rename time program.
▶ Press the selector.
The cursor flashes to indicate the start position for data input. The names of the
heating circuits and time programs are assigned by default.
Enter and insert characters
▶ Turn the selector to move the cursor to the position where a character is to be
entered.
▶ Press the selector to activate the input field to the right of the cursor.
▶ Turn the selector to select a character.
▶ Press the selector to enter the selected character.
The selected character is entered. The input field for the next character in the text is
enabled.
▶ Turn the selector to enter more characters.
▶ Press the Back key when you have finished making entries.
The cursor flashes to the right of the character entered. The user interface operates
with the modified settings.
Delete characters/Delete entire name
▶ Turn the selector to position the cursor after the letters to be deleted.
▶ Press the selector to activate the input field to the right of the cursor.
▶ Turn the selector until <C is displayed.
▶ Press the selector to delete the character to the left of the enabled the input field
(<C remains active).
▶ Press the selector again to delete more characters or press the Back key to exit the
process.
The cursor flashes in the place where the character <C was previously located.
▶ Press the Back key to exit the input process and to use the entered name.
Table 14 Rename heating circuit
6 720 811 136-24.1O
6 720 811 136-25.1O
6 720 811 136-26.1O
ARUN-TWIN.
data in mm.
500, 600, 750, 900
1194 1754 2154
ARUN-TWIN model:
Standard design
The ARUN-TWIN model is the choice for perfectly tasteful and functional partitioning
of living space. It is convincing with its striking design and high flexibility: variable wall
installation possible with no limitations.
Your advantages: Elegance down to the
last detail guarantees a sophisticated
interior design.
RAL 3005
wine red
VOGEL&NOOT
CLIMATE CONTROL SYSTEMS

6 720 817 986 (2015/07)HPC 400
Working with the main menu | 19
5.2.3 Setting the summer/wintertime changeover
threshold
DHW heating is independent of the switching between summer
and winter modes.
Menu: Sum./wint. changeover
5.2.4 DHW alternating operation settings
In DHW alternating operation, DHW and heating have equal
priority and alternate based on time. A heat requirement from
the heating system is not taken into account while DHW heating
is active, and vice versa.
If DHW alternating operation is not active, DHW heating has
priority and interrupts the heat requirement of the heating
system, if necessary.
Menu: DHW alternating operation
5.2.5 Setting for heating circuit 1 priority
This menu item allows the other heating circuits to be restricted
via heating circuit 1.
When Priority heating circuit 1 is activated, heating circuit 1
is the primary heating circuit. Heat requirements for other
circuits are only handled if heating circuit 1 has a heat
requirement. This means that the flow temperature required
for heating circuit 1 limits the flow temperature of the other
heating circuits.
An example:
• Heating circuit 1 requires 50 °C.
• Heating circuit 2 requires 55 °C,butreceives a maximumof
50 °C (in line with heating circuit 1).
• Heating circuit 3 requires 45 °C and receives 45 °C (not
limited by heating circuit 1).
5.3 Changing the settings for DHW heating
Menu: DHW
These settings are only available if a DHW system is installed in
the system. The water can be heated via a cylinder.
NOTICE: System damage
▶ Do not switch over to summer mode if
there is a risk of frost.
The summer/wintertime changeover function
is only active if Heating/Cooling > Automatic
mode has been set.
Menu item description
Heating/
Cooling
•Constant summer mode (= OFF): The
heat pump is not used for either heating or
cooling.
•Automatic mode: Heating or cooling mode
is activated based on the outside
temperature. If the outside temperature is
between the two limits, the system is idle.
•Continuous heating: Cooling mode is
never activated and the system is never
idle.
•Continuous cooling: Heating mode is
never activated and the system is never
idle.
Heating
mode
from1)
1) This menu item is only displayed if the outdoor-
temperature-dependent switching between summer and
winter modes is active for the heating circuit concerned.
If the adjusted outside temperature2) exceeds
the temperature threshold set here, the
heating system is switched off.
If the adjusted outside temperature falls below
the temperature threshold set here by 1 °C, the
heating system is switched on. In systems with
more than one heating circuit, this setting
always relates to the corresponding heating
circuit in each case.
2) When the outside temperature is adjusted, changes to the
measured outside temperature are delayed and
fluctuations reduced.
Cooling
mode
from1)
If the outside temperature exceeds the
temperature set here, cooling is started.
Table 15 Settings for the summer/wintertime changeover
Menu item description
DHW altern.
oper. on
In the event of a simultaneous heat energy
demand, the system will alternate between
DHW heating and heating mode based on the
times set under DHW priority for and
Prioritise heating for.
DHW priority
for
Duration of DHW heating for DHW altern.
oper. on.
Prioritise
heating for
Duration of heating mode for DHW altern.
oper. on.
Table 16 DHW alternating operation settings
ARUN-TWIN.
data in mm.
500, 600, 750, 900
1194 1754 2154
ARUN-TWIN model:
Standard design
The ARUN-TWIN model is the choice for perfectly tasteful and functional partitioning
of living space. It is convincing with its striking design and high flexibility: variable wall
installation possible with no limitations.
Your advantages: Elegance down to the
last detail guarantees a sophisticated
interior design.
RAL 3005
wine red
VOGEL&NOOT
CLIMATE CONTROL SYSTEMS

6 720 817 986 (2015/07) HPC 400
20 | Working with the main menu
There is a factory-set custom time program for DHW heating.
Alternatively, DHW heating can be constant (Chapter 5.3.2,
page 20).
5.3.1 Setting the operating mode for DHW heating
In the default settings, DHW is heated based on a separate time
program.
• If Own time program is set, the DHW operating mode is
active daily from 05:00 (from 07:00 on Saturdays and
Sundays) until 23:00 (time program default settings).
Menu: Operating mode
5.3.2 Setting the time program for DHW heating
The time program for DHW heating can be adjusted in this
menu.
Menu: Time program
The following table shows you how to adapt the settings for DHW heating.
WARNING: Risk of scalding!
If the temperature for extra DHW has been set
to in excess of 60 °C or thermal disinfection
has been activated to avoid legionella, the
DHW is heated once to in excess of 60 °C or
65 °C. The factory setting for DHW
temperature depends on the installed heat
pump. There is a risk of scalding at the draw-
off points if the temperature is set higher than
this.
▶ Make sure that a thermal mixer is installed.
If in doubt, ask your installer.
Menu item description
Operating
mode
• DHW heating can be linked to the time
program for the heating system (As
heating circuit time program).
• You can use the Own time program to
set a time program for DHW heating that
works independently of the time
program for the heating system.
• If Always on - DHW red. or Always on -
DHW is set, DHW heating is active
constantly. Your installer can set the
temperatures for operating modes DHW
and DHW reduced (lower DHW
temperature than for DHW mode).
• If deactivated, there is no DHW heating/
maintenance of the temperature.
Table 17 Operating mode for DHW heating
Menu item description
My DHW time
program
6 switching times can be set for each
day or group of days. One of the up to
three operating modes can be assigned
to each switching time in automatic
mode. The minimum duration of a time
slot between two switching times is
15 minutes.
Reset prog. The time program for the DHW system
is reset to the default settings with this
menu item.
Table 18 Time program settings for DHW
Operating the appliance Result
Selecting and setting the time program for DHW heating
▶ If the standard display is active, press the DHW key.
▶ Turn the selector to mark the Own time program menu item and press the selector.
The time program for DHW is activated. The switching times can be set separately in
the DHW > Time program > My DHW time program menu (operation as described
in Chapter 5.2.2 starting on page 15). The DHW temperatures set for the operating
modes are valid in the time slots.
Table 19 Adapting the settings for DHW heating
6 720 815 237-41.1O
ARUN-TWIN.
data in mm.
500, 600, 750, 900
1194 1754 2154
ARUN-TWIN model:
Standard design
The ARUN-TWIN model is the choice for perfectly tasteful and functional partitioning
of living space. It is convincing with its striking design and high flexibility: variable wall
installation possible with no limitations.
Your advantages: Elegance down to the
last detail guarantees a sophisticated
interior design.
RAL 3005
wine red
VOGEL&NOOT
CLIMATE CONTROL SYSTEMS
