ADS 625X for ADAS Quick Start Guide
(en-US)

en-US |2|Quick Start Guide| ADS 625X for ADAS
1699504264 | VER 01 | 06.2022 © Bosch Automotive Service Solutions Inc
Bosch Technical Support: [phone]
Fax: [phone]
[e-mail]
Please record and retain this important information:
Part No:
Serial No:
Purchase Date:

1699504264 | VER 01 | 06.2022
© Bosch Automotive Service Solutions Inc
ADS 625X for ADAS | Quick Start Guide |3|en-US
Safety Precautions
BEFORE OPERATING THIS TOOL, ALL OPERATORS SHOULD
READ AND UNDERSTAND THIS QUICK START GUIDE AND
FOLLOW ALL SAFETY WARNINGS AND INSTRUCTIONS.
KEEP THESE INSTRUCTIONS WITH THE TOOL FOR FUTURE
REFERENCE. IF YOU HAVE ANY QUESTIONS, CONTACT
YOUR BOSCH REPRESENTATIVE OR DISTRIBUTOR.
DANGER
When an engine is operating, keep the service area well
ventilated or attach a building exhaust removal system
to the engine exhaust system. Engines produce carbon
monoxide, an odorless, poisonous gas that causes slower
reaction time and can lead to death or serious personal
injury.
WARNING:
• When working with hydraulic or fuel lines, be careful
that liquids under pressure do not escape and create a
dangerous condition. Use adequate ventilation and make
sure there are no sparks or possibility of sparks that
may ignite any vapor.
• Wear an American National Standards Institute (ANSI)
Z87.1 approved eye shield when testing or repairing
vehicles.
• Objects propelled by whirling engine components or
pressurized liquids escaping may cause personal injury.
• Set the parking brake and block the wheels before test-
ing or repairing a vehicle. It is especially important to
block the wheels on front-wheel drive vehicles because
the parking brake does not hold the drive wheels.
• Do not drive the vehicle and operate the software at the
same time.
• Maintain adequate clearance around moving compo-
nents or belts during testing.
• Moving components and belts can catch loose cloth-
ing, body parts, or test equipment and cause serious
personal injury or tool damage.
• Automotive batteries contain sulfuric acid and produce
explosive gases that can result in serious injury due to
ignition of gases. Keep lit cigarettes, sparks, ames,
and other ignition sources away from the battery at all
times.
• Refer to the service manual for the vehicle being ser-
viced. Adhere to all diagnostic procedures and precau-
tions. Failure to do so could result in personal injury or
otherwise unneeded repairs.
• Use only specially designed replacement parts (brake
hoses and lines) for ABS equipped vehicles.
• After bleeding the brake system, check the brake pedal
for excessive travel or a ”spongy” feel. Bleed again if
either condition is present.
• When installing transmitting devices (Citizen Band
radio, telephone, etc) on ABS-equipped vehicles, do
not locate the antenna near the ABS control unit or any
other control unit.
• This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interfer-
ence in a residential installation. This equipment gener-
ates and radiates radio frequency energy and, if not
installed and used in accordance with the instructions,
may cause harmful interference to radio communica-
tions.
• To reduce risk of injury, charge only Bosch Automotive
Service Solutions, Inc. supplied charging block and
power cord.
• Use of an attachment not recommended or sold by the
battery charger manufacturer may result in re, electric
shock, or personal injury.
• Do not operate the tool with a damaged cord or con-
nector. Replace damaged cords and connectors immedi-
ately.
• Do not operate the charger if it has received a sharp
blow, been dropped, or otherwise damaged in any way.
Take the charger to a qualied service person.
• Do not disassemble the charger. Take the charger to a
qualied service person if service or repair is necessary.
Incorrect reassembly may result in electric shock or re.
Unplug charger before attempting any maintenance or
cleaning. Turning off controls will not reduce this risk.
• To prevent possible hearing damage, avoid using the
tool at high volume levels for long periods.
• Do not expose tool or charger to rain, moisture, or
snow.
• Verify that cords are located where they will not be
stepped on, tripped over, or otherwise become a safety
hazard or subjected to damage or stress.
• Use only batteries that are approved for use with this
tool. Use of other types may increase the risk of re or
explosion.
• Do not carry a battery in your pocket, purse, or other
container where metal objects (such as car keys or pa-
per clips) could short-circuit the battery terminals. The
resulting excessive current ow can cause extremely
high temperatures and may result in damage to the bat-
tery pack or cause re or burns.
• The battery poses a burn hazard if you handle it im-
properly. Do not disassemble it. Handle a damaged or
leaking battery with extreme care. If the battery is dam-
aged, electrolyte may leak from the cells and may cause
personal injury.
• Keep the battery away from children.
• Do not store or leave your tool or battery near a heat
source such as a radiator, replace, stove, electric
heater, or other heat-generating appliance or otherwise
expose it to temperatures in excess of 60ºC (140ºF).
When heated to excessive temperatures, battery cells
could explode or vent, causing personal injury or risk of
re.
• Do not dispose of your tool’s battery in a re or with
normal household waste. Battery cells may explode.
Discard a used battery according to the manufacturer’s
instructions or contact your local waste disposal agency
for disposal instructions. Dispose of a spent or damaged
battery promptly.
CAUTION:
• To avoid damage or generation of false data, make sure
the vehicle battery is fully charged and the connection
to the vehicle Data Link Connector (DLC) is clean and
secure.
• Do not place the tool on the distributor of a vehicle.
Strong electromagnetic interference can damage the
tool.
• Never disconnect or reconnect any electrical connec-
tor while the ignition is on. Powertrain Control Module
(PCM) damage may result.

en-US |4|Quick Start Guide| ADS 625X for ADAS
1699504264 | VER 01 | 06.2022 © Bosch Automotive Service Solutions Inc
General Information
Introduction
1. Vehicle connection
indicator
2. VCI connection manager
3. Power button
4. Volume up button
5. Volume down button
6. Front facing camera
7. Ambient light sensor
8. USB C charging/data port
9. Main Menu functions
10. SD card access door
11. Back button
12. Home button
13. Recent app button
14. Docking station connector
TOP VIEW
BOTTOM VIEW
Connected
10:22
Main Menu
ADAS Calibration Pre/Post Scan
Settings
What’s New
Web Browser
Vehicle Diagnostics Repair Source Generic OBD II
Saved ADAS
Reports
Apps Shortcut
Video Tutorials
6 7
1
2
13 12 1114 10
9
34 5 8

1699504264 | VER 01 | 06.2022
© Bosch Automotive Service Solutions Inc
ADS 625X for ADAS | Quick Start Guide |5|en-US
Setup
1. Battery charging.
Connect the tablet to AC power
using the USB power block and USB
C charging cord and fully charge the
battery.
When the tablet is turned on, the
level of battery charge is indicated
in the upper right corner of the
screen.
Note: ADS 625X is supplied with 2 USB C
power cables and 1 USB power block.
2 ft. cable 6 ft. cable
Battery Life Tips
The tablet is an Android based touch-
screen tablet. The battery life icon
shows charge level. The scan tool lets
you know how much battery life is
left by viewing the icon located at the
top right of the home screen. Like all
Android devices, there are tips to help
extend or maximize battery life.
When not actively being used, the
screen will timeout and the scan
tool display will power off, while
application remains running in
background. The user can set the
length of delay between the last
screen touch and automatic screen
timeout (dim and lock). From the
Home screen, touch the Android App
button - Settings - Display.
Select Screen timeout, then select the
length of time from the last screen touch
and automatic screen timeout.
To use again, press the power button
to wake the tool up. This will allow
maximum run time, while not limiting
productivity.
When the tool is powered up, even if
it is not being actively used, Wi-Fi and
Bluetooth® radios as well as all other
necessary hardware are still being
powered. Battery life is comparable to
similar devices when in this state.
2. Docking station
The tablet, VCI, and cords should
be stored in the docking station
when not in use. The docking
station powers the VCI and provides
a slow, steady charge to the tablet
to preserve battery integrity.
Seat the tablet and VCI in the
docking station so that the docking
station connector at the bottom of
each device connects to the docking
station.
The docking station includes two
convenient USB ports to charge
accessories and other devices.
USB
ports
Notes:
• The docking station will not charge
the tablet if the tablet’s USB port is in
use. Ensure no devices are connected
to the USB port on the tablet before
connecting to the docking station.
• For fastest charging, charge the
tablet using the USB power block and
USB C charging cord.

en-US |6|Quick Start Guide| ADS 625X for ADAS
1699504264 | VER 01 | 06.2022 © Bosch Automotive Service Solutions Inc
3. Press the power button to
turn on the tablet.
Power Button Functions
The power button has four
functions
a. ON: Press and hold the power
button for about 5 seconds to turn
the tablet on.
b. OFF: Press and release the power
button. A pop up window will
appear to shut down the tablet.
ON: If the screen times out or is in
standby mode, press and release
the power button to wake up the
tablet. Turn ON: With tool off,
press to turn ON
c. OFF: Press the power button
and hold for 5 seconds to turn
the tablet off completely (not
recommended).
4. Register Device - Select a
Language
Step 1 of 7 - Select as Language
Español
Français
English
rt0002
5. Select Register Now.
Register the tool, begin a trial period,
or run the tool in demo mode.
Step 2 of 7 - Register
Registering your device allows you to get the latest software updates
Skip
Register Now
rt0003
6. Read and accept the End User
License Agreement.
Step 3 of 7 - End User License Agreement
End User License Agreement
Software Product License Agreement
Copyright (c) 2014-2017, Bosch Automotive Service Solutions Inc. All Rights Reserved
By clicking the i Agree button (or authorizing any other person to do so), you accept this Agreement and are
bound by its terms. If you are not sure that you are authorized by your employer to accept this Agreement, take
this package to a principal in your firm before proceeding. This Agreement is a legally binding document setting
forth the menner by which you may use the Bosch Automotive Service Solutions Inc. (”Bosch”) software that is
embedded on the Bosch device and any assoociated media, printed materials and electronic documentation
(collectively “Software Product”) Carefully read the terms and conditions of this Agreement before using this
Software Product. Use of this Software Product indicates your acceptance of the following terms and
conditions.
1. LICENSE. Bosch grants you a personal, non-transferable (except as noted in Section 8 (Assignment)) and
non-exclusive limited license (without the right to sublicense) to ise the Software Product embedded on this
SOFTWARE PRODUCT LICENSE AGREEMENT
Register My Device Now
Register My Device Later
Demo Mode
IMPORTANT: Do not continue until you have read this Software Product License Agreement (”Agreement”).
I Agree
rt0004
7. Select the correct Time Zone.
Step 4 of 7 - Setup Time Zone
Setup Time Zone
GMT-04:00 Eastern Standard Time
Next: Step Wi-Fi
rt0005

1699504264 | VER 01 | 06.2022
© Bosch Automotive Service Solutions Inc
ADS 625X for ADAS | Quick Start Guide |7|en-US
8. Enable Wi-Fi and select a
network and select Next.
Step 5 of 7 - Select Wi-Fi
Setup Wi-Fi
Secured with WPA
Wi-Fi
TEST 15
TEST 16
Trial Mode
Secured with WPA2
This will run your tool in Trial Mode for 30 days.
Next: Your Name
rt0006
Note:
• Wi-Fi Must be ON. If Wi-Fi is OFF slide the
Wi-Fi switch to the ON position and follow
the prompts on the screen.
• If a Network password is required the An-
droid Wi-Fi screen will be displayed. Follow
the prompts on the screen.
9. Activate subscription and
warranty
Step 6 of 7 - Activate Warranty
Activate Subscription and Warranty
Valued
Customer
Bosch
Bosch
Next: Contact info
Set Clock
rt0007
Enter your Name. Follow the prompts on
the screen to activate warranty.
Step 6 of 7 - Activate Warranty
Activate Warranty
[email protected]
123-555-1234
5678 Shop Lane
Detroit Michigan 48260
USA
Address 2 (optional)
Confirm Info
E0VTOW0000000000GR
rt0008
Enter contact information. Follow the
prompts on the screen.
Step 6 of 7 - Activate Warranty
Activate Warranty
[email protected]
ValuedCustomer
123-555-1234
Bosch
Bosch
5/15/2018
5678 Shop Lane
Detroit, Michigan 48260
USA
E0VTOW0000000000GR
Activate Now
rt0009
Conrm information. Follow the prompts
on the screen and activate warranty.
10. Connect the VCI to the
vehicle.
rt00001
1
2
3
1. OBDII/DLC Cable
2. DLC
3. VCI
11. Connect the tablet to the VCI.
Pairing
VCI Connection Manager Icon Denitions
Icon that will display when user is
connected to DVCI.
Icon will display when user is
connected to DVCI but signal is
degraded.
Icon will display when user is NOT
connected to DVCI.

en-US |8|Quick Start Guide| ADS 625X for ADAS
1699504264 | VER 01 | 06.2022 © Bosch Automotive Service Solutions Inc
VCI Connection Manager Icon Denitions
Icon will display when user is connected
to DVCI, but the version does not match
expected tablet version.
The VCI is paired to the tablet
during manufacturing and should be
paired out of the box.
a. Connect the VCI to the vehicle
DLC.
b. At this point VCI Connection
Manager icon should display
“Connected via Wi-Fi”.
c. If VCI Connection Manager icon
shows “No connection,” select the
VCI Connection Manager icon.
Connected
10:22
Main Menu
ADAS Calibration Pre/Post Scan
Settings
What’s New
Web Browser
Vehicle Diagnostics Repair Source Generic OBD II
Saved ADAS
Reports
Apps Shortcut
Video Tutorials
rt0011
d. Once VCI Connection Manager
icon is selected, VCI Connection
Manager dialog is displayed, listing
discovered VCIs.
e. Select “Connect” next to VCI in the
list to pair with it.
Once VCI Connection Manager icon
changes to “Connected via Wi-Fi”,
the tool is ready to use.
The tablet is now paired to a VCI.
To use a different VCI in the future,
repeat the steps for manually
pairing the VCI.
Select “Connect” next to desired
VCI. VCI Connection Manager dialog
will refresh to show successful
connection.
ss02876
5
6 7
2
1
3
4
1. Power port (used when necessary)
2. DLC/OBDII cable port
3. Power
Indicates the VCI has received power.
4. PC Connection
Indicates the VCI is communicating with
the PC.
5. Vehicle Connection
Indicates the VCI is communicating with
vehicle.
6. USB “B” Port.
7. Docking station connector.

1699504264 | VER 01 | 06.2022
© Bosch Automotive Service Solutions Inc
ADS 625X for ADAS | Quick Start Guide |9|en-US
Main Menu
1. ADAS Calibration
Access ADAS calibration options
2. Pre/Post Scan
Access pre/post scan function
3. Saved ADAS Reports
Access saved ADAS reports
4. Vehicle Diagnostics
Access vehicle diagnostic options
5. Repair Source
Access online automotive
diagnostic repair information
6. Generic OBD II
Access global OBDII emission-
related ECU information
7. Web Browser
Full internet access and shortcuts
to repair information and OEM
websites
8. Video Tutorials
Access video tutorials
9. What’s New
Preview scan tool features and
operation
10. Settings
Access tool settings, printer setup,
subscription information, software
updates, and more
11. Apps Shortcut
Access other available Android
applications

en-US |10 |Quick Start Guide| ADS 625X for ADAS
1699504264 | VER 01 | 06.2022 © Bosch Automotive Service Solutions Inc
ADAS Calibration Functions
After selecting a vehicle the user will be able to begin using ADAS calibration
functions on the vehicle.
1. Change Vehicle
Shortcut to select a new vehicle
(Choose this only to select a new
vehicle.)
2. Home
Shortcut to the Main Menu
3. Front Facing Camera
Access to systems for the front facing
camera calibration
4. Front Facing Radar
Access to the systems for the front
facing radar calibration
5. Pre-Post Scan
Access pre/post scan function
6. Surround View Camera
Access to the systems for surround view
camera calibration
7. Blind Spot Monitoring
Access to the systems for blind spot
monitor calibration
8. Rear Facing Camera
Access to the systems for rear facing
(back-up) camera calibration
9. LIDAR
Access to the systems for LIDAR
calibration
10. Saved ADAS Reports
Access saved ADAS reports
11. Go to Vehicle Diagnostics
Access diagnostic functions screen

1699504264 | VER 01 | 06.2022
© Bosch Automotive Service Solutions Inc
ADS 625X for ADAS | Quick Start Guide |11 |en-US
Guided Tour
The guided tour is a step-by-step work instruction, specific to the selected vehicle,
to easily guide the user through all of the steps to set up and recalibrate a vehicle’s
ADAS systems.
(Image for reference only. The guided tour is customized for each year/make/model based on vehicle selection.)
The guided tour includes Bosch’s innovative ADAS computer vision positioning
system to aid in accurate and speedy setup and recalibration of a vehicle’s ADAS
systems.

en-US |12 |Quick Start Guide| ADS 625X for ADAS
1699504264 | VER 01 | 06.2022 © Bosch Automotive Service Solutions Inc
ADAS Computer Vision Positioning Screen
The guided tour also includes Bosch’s innovative ADAS computer vision positioning
system to aid in accurate and speedy setup and calibration of a vehicle’s ADAS systems.
Your screen may look slightly different based on selections and process. When out of
tolerance, the green checkmark icons are replaced with red icons.
1. Wheel Clamp Targets
Left and right wheel clamp targets camera
view, including camera controls for
exposure and zoom
2. Required Set-up Distance
The required set-up distance of the ADAS
recalibration fixture to the vehicle is a static
value, dependent on vehicle and ADAS
system selection
3. Forward/Backward Position
The dynamic (forward/backward) position
value of the ADAS recalibration fixture
relative to the vehicle
4. Left/Right Position
The dynamic (left/right) position value of
the ADAS recalibration fixture relative to
the vehicle
5. Angular Position
The dynamic (clockwise/counterclockwise)
angular position value of the ADAS
recalibration fixture relative to the vehicle
(This screen shows the setting within
tolerance. Your screen will vary. When out
of tolerance a crosshair and dynamic value
is shown.)

1699504264 | VER 01 | 06.2022
© Bosch Automotive Service Solutions Inc
ADS 625X for ADAS | Quick Start Guide |13 |en-US
Diagnostic Functions
After selecting a vehicle the user will be able to begin using diagnostic functions on
the vehicle.
1. Change Vehicle
Shortcut to the select vehicle screen
2. Home
Shortcut to the Main Menu
3. Read DTCs
Read all DTCs on selected vehicle
4. Data Stream
The data stream function shows live sensor
and solenoid data streaming from the
vehicle ECU (electronic control unit)
5. All Special Tests
Access to bi-directional tests, relearns,
adjustments, calibrations, and all other
special tests
6. Special Tests Shortcuts
Access frequently used special maintenance
tests for specific systems to be recalibrated
or reset after service, including ADAS
recalibration
7. Enhanced Vehicle Scan
Access manufacturer-specific parameters
and information
8. Diagnostic Information
Diagnostic Information provides diagnostic,
repair, and reset information for the
selected vehicle
9. Wiring Diagrams
Access vehicle system wiring diagrams
(Wiring diagrams subscription required)
10. Enhanced OBDII
Access manufacturer-specific parameters
and information.
11. Saved Reports
Locate saved vehicle reports
12. Web Browser
Full internet access and shortcuts to repair
information and OEM websites
13. Apps Shortcut
Access other available Android applications
14. Go to ADAS Calibration
Access ADAS calibration functions screen
(ADAS subscription required)

en-US |14 |Quick Start Guide| ADS 625X for ADAS
1699504264 | VER 01 | 06.2022 © Bosch Automotive Service Solutions Inc
Features
OBDII/DLC Cable
The OBDII/DLC cable has a LED lamp to
locate vehicle DLC and voltmeter that
displays battery voltage
• The LED in the OBDII cable end is
activated by a button on the side
of the connector. This feature is
provided to assist users in finding
the vehicle DLC.
• The vehicle battery indicator is
activated when the OBDII cable
is plugged into the vehicle and
displays the Pin 16 voltage available
on the vehicle DLC. A voltage
reading below 11.8 Volts will
activate an indication of “LO” or
if above 15.5 Volts and indication
of “HI” will activate highlighting
that the battery or charging system
needs attention.
ss02659
1
2
3
4
1. LED Lamp
2. LED lamp switch
3. Battery cover
4. DLC tool connector with voltmeter
Software Updates
Software Updates: Periodically, updates
will become available and the user
will be notified through a message
on the screen. To receive updates
automatically, connect to Wi-Fi and leave
scan tool on overnight.
Note: Scan Tool will download updates
automatically when connected to the internet.
When download is complete, the user will be
informed with a pop up screen. To install an
update, the scan tool must be connected to
the AC power adapter, over 50% battery life
and not connected to a vehicles DLC.

1699504264 | VER 01 | 06.2022
© Bosch Automotive Service Solutions Inc
ADS 625X for ADAS | Quick Start Guide |15 |en-US
AutoDetect®
The new user interface utilizes graphic
“badges” to illustrate when critical
information is found. AutoDetect®
automatically detects vehicle-specific
solutions and graphically alerts the
user of on-tool or web-based repair
information found. To use the Code To
Fix® feature, press the Diagnostic Trouble
Code to launch the DTC Info screen for
access to exclusive experienced-based
fixes and repair information for that
specific vehicle and DTC.
Connected to 2008 Ford F-150 King Ranch 5.4L
10:22
Change Vehicle Home
Connected
10:22
Change Vehicle Home
DTC Scan
Change Vehicle
Scan Complete. Tap any item to see error codes
Add Image(s) to Report
PCM / PATS
P0030 - Fail Since Clear - Heated Oxygen Sensor Heater Control Circuit Sensor 1
P0036 - Fail Since Clear - Heated Oxygen Sensor Heater Control Circuit Sensor 2
P0016 - MIL Codes - Crankshaft Position (CKP) -Camshaft Position (CMP) Correlation
INSTRUMENT CLUSTER
4X4 CONTROL
3 DTC(S) found
3 DTC(S) found
3 DTC(S) found
Clear DTCs Refresh Share Save
Home
Details
Details
Details
rt0015
Connected to 2008 Ford F-150 King Ranch 5.4L
Connected
10:22
P0030
Change Vehicle
Heated Oxygen Sensor Heater Control Circuit Sensor 1
Description Description
Mitchell Diagnostics
System Wiring
Measures the amount of oxygen in the exhaust gas and sends a corresponding
signal to the ECM/PCM. The ECM/PCM uses this signal to help maintain an
optimum air/fuel ratio. The sensor has a heating element to allow quicker closed
loop operation.
Code Criteria
Code Assist
Location
Scan Test
PCM Pin
Help
Home
IDENTIFI
FIND AND FIX FASTER
6604
Google
Online Resources
rt0017
How to Power Off ADS 625X
a. Press and release the power
button.
Connected
10:22
Main Menu
ADAS Calibration Pre/Post Scan
Settings
What’s New
Web Browser
Vehicle Diagnostics Repair Source Generic OBD II
Saved ADAS
Reports
Apps Shortcut
Video Tutorials
b. Select Power Off. The tool will now
shutdown.
ADAS Calibration Pre/Post Scan
Settings
What’s New
Web Browser
Vehicle Diagnostics Repair Source Generic OBD II
Saved ADAS
Reports
Apps Shortcut
Video Tutorials
Connected
10:22
Main Menu
Power off Restart
rt0018
Note: When switching vehicles, it is best
to return to the home screen before
disconnecting the VCI from the vehicle to
avoid communication errors.

Bosch
Automotive Service Solutions, Inc.
655 Eisenhower Drive
Owatonna, MN 55060 USA
Phone: [phone] Option 1
www.boschdiagnostics.com
1699504264 VER 01
