Troubleshooting
If a “LINK ERROR” message
appears, cycle the ignition
key to the OFF position for
10 seconds, then back ON,
then press the
ENTER
key. Make sure the ignition
key is in the ON not the
ACCESSORY position.
If the MIL Status is ON and
the MIL is not illuminated
with the engine running,
then a problem exists in the
MIL circuit.
PID Denitions
NOTICE
Although over 300
PIDS are available,
the tool only displays
the PIDs the vehicle
supports.
PID PID description
ABS FRP Absolute Fuel Rail Pressure
ABS LOAD Absolute Load Value
ABS TPS B, C Throttle Position B, C
ABSLT TPS Absolute Throttle Position
ACC POS D Accelerator Pedal D, E, F
ACC POS REL Relative Accelerator Pedal
Position
AECD1_TI-
ME1, TIME 2
Total Run Time with EI-AECD
#1 Timer 1 Active, #2 Timer
Active
AECD10_TI-
ME1, TIME 2
Total Run Time with EI-AECD
#10 Timer 1 Active, #2 Timer
Active
PID PID description
AECD11_TI-
ME1, TIME 2
Total Run Time with EI-AECD
#11 Timer 1 active, #2 Timer
Active
AECD12_TI-
ME1, TIME 2
Total Run Time with EI-AECD
#12 Timer 1 active, #2 Timer
Active
AECD13_TI-
ME1, TIME 2
Total Run Time with EI-AECD
#13 Timer 1 active, #2 Timer
Active
AECD14_TI-
ME1, TIME 2
Total Run Time with EI-AECD
#14 Timer 1 active, #2 Timer
Active
AECD15_TI-
ME1, TIME 2
Total Run Time with EI-AECD
#15 Timer 1 active, #2 Timer
Active
AECD16_TI-
ME1, TIME 2
Total Run Time with EI-AECD
#16 Timer 1 active, #2 Timer
Active
AECD17_TI-
ME1, TIME 2
Total Run Time with EI-AECD
#17 Timer 1 active, #2 Timer
Active
AECD18_TI-
ME1, TIME 2
Total Run Time with EI-AECD
#18 Timer 1 active, #2 Timer
Active
AECD19_
TIME1, TIME 2
Total Run Time with EI-AECD
#19 Timer 1 active, #2 Timer
Active
AECD2_
TIME1, TIME 2
Total Run Time with EI-AECD
#2 Timer 1 Active, #2 Timer
Active
AECD20_
TIME1, TIME 2
Total Run Time with EI-AECD
#20 Timer 1 active, #2 Timer
Active
AECD3_
TIME1, TIME 2
Total Run Time with EI-AECD
#3 Timer 1 Active, #2 Timer
Active
AECD4_
TIME1, TIME 2
Total Run Time with EI-AECD
#4 Timer 1 Active, #2 Timer
Active
AECD5_
TIME1, TIME 2
Total Run Time with EI-AECD
#5 Timer 1 Active, #2 Timer
Active
AECD6_
TIME1, TIME 2
Total Run Time with EI-AECD
#6 Timer 1 Active, #2 Timer
Active
AECD7_
TIME1, TIME 2
Total Run Time with EI-AECD
#7 Timer 1 Active, #2 Timer
Active
